The Peiseler rotary indexing table is at the heart of the rotary indexing machine, which has five stations for drilling and milling processes plus a loading and unloading station. "The key requirements for our design went beyond the need to achieve a maximum power density for highly dynamic indexing times in the smallest possible installation space", says Gronau. "In order to minimise the tolerances present, we had to position each of the two-axis rotary tilt tables as precisely as possible, both as standalone units and in relation to one another". Providing the media required to close, release and monitor the workpiece clamping device was also a complex task. A rotary manifold with eight ports was ultimately fitted for this purpose.

"This rotary indexing table is not only the largest we"ve built to date, but also a customer-specific solution that will shorten cycle times and reduce unit costs in the production of electric vehicle components", explains Gronau. As a high-precision manufacturer of trunnion tables, rotary tables, two-axis rotary tilt tables, swivel heads and workpiece changing tables, Peiseler is helping to build the reliable production processes that will lay the foundations for our future mobility.

A very high quality unused CNC rotary table manufactured by Peiseler of Germany. For use in the vertical position (horizontal axis) fitted with a pneumatic brake system and is offered in the first instance without motor or encoder, but could be prepared for any machine tool integration. General specifications:Centre height120mmOverall height190mmThrough hole35mmSpindle diameter120mmCarrying capacity36kgMotor mounted to the left hand side, you should check for limitations in the Y axis traverse to ensure that there is no collision with the rear of the machine covers or the doors of the machine.

Rotary tables with two rotational axes, usually arranged perpendicularly, allow for five-axis workpiece machining in machining centres. The trunnion axis mounted in the machine tool can be used either with or without a counter bearing. Up to four faceplates can be used as table axes in series. The spindle pitch of these faceplates is made to your specifications.

In the ZATC and ZAS series, worm gears are used, in the ZASD series, direct drives, and for the ZASR devices, gear drives. We offer you trunnion axes and table axes with different drives. ATD dyn solutions are available for turning.

The following chart shows specifications of two-axis rotary tilt tables with direct drives as well as in the table and trunnion axis. We can equip the last, in particular, with an alternate drive technology. For this axis worm gears or gear drives are prevalent. In the case of the ZASR 630 and ZASR 800, the trunnion axis is always designed with a pre-loaded gear drive. Other options are available if you require multi-spindle table axes for two-axis rotary tilt tables. The spindle pitch is machine builder dictated. We would be glad to explain this to you personally. Of course we can make modifications for your installation space requirements. The ZASD series can be equipped with the ATD dyn series in the C axis for turning applications.

Brown and Holmes are the exclusive UK and Ireland agents/distributors for Peiseler indexers, trunnions and special pallet systems. We also support existing and future owners of these Peiseler products with afull service and repair service, using genuine manufacturer parts.

Founded in 1819, the reliability and reputation of Peiseler products is second to none and a key reason for Brown and Holmes to offer them to its customers.

Peiseler rotary tables are available as single-axis and multi-axis with faceplates ranging from 80 to 3,500 mm diameter, with net weight holding capabilities up to 22,000 kg.

Clamping with axial-movement effects zero torsion on the faceplate, Peiseler install greased clamping discs and a material combination to prevent contact corrosion during lifetime

For the rotary manifolds we use a combination of hardened steel and nonferrous material for long lifetime, the seals were developed with a manufacturer especially for Peiseler to achieve long lasting function

We bring a lot of flexibility to adapt different systems like rotary manifold, zero point clamping systems, chucks, HSK System or any other clamping system to our units

With a rotary indexing table, Peiseler is helping to increase the productivity of a well-known German car manufacturer. The Remscheid-based company developed the innovation with its customers UNIOR Special Machines in Slovenia. The rotary indexing table is, so to speak, the centrepiece of a machine tool manufactured there, which will ultimately be used to machine lightweight components for the production of electric cars. "It has a diameter of 3,000 millimetres and weighs ten tonnes," explains Marc Gronau, Sales Manager at Peiseler, "making it the largest and most sophisticated unit of this type that we have ever built in our 200-year company history."

The basis is the worm-wheel-driven Peiseler ATU 1600 index table, which uses a direct path-measuring system to clock six ZATC 300 two-axis swivelling devices in five steps from one machining station to the next and then with a pilgrim step back to the starting position. For this, the rotary indexing table has a total of 13 axes and a maximum load of 250 kilograms per station. They ensure high-precision simultaneous machining of the workpieces.

The Peiseler rotary indexing table is the centre of the whole rotary indexing machine with five stations for drilling and milling as well as a loading and unloading station. "A special requirement for our design was not only to achieve maximum power density for highly dynamic cycle times in the smallest possible installation space," Gronau points out. "In order to keep the ever-present tolerances as low as possible, it was also necessary to position each of the two-axis swivelling devices among themselves with the utmost precision." Another complex task was the media supply for clamping, releasing and monitoring the workpiece clamping device. A rotary distributor with eight channels was used for this.

"Here we have not only built our largest rotary indexing table to date, but also developed a customised solution that ensures short cycle times and low unit costs in the production of electric vehicle components," Gronau is pleased to say. Thanks to the high precision, Peiseler, as a manufacturer of turners, index tables, two-axis swivelling devices, swivel heads and tool changing tables, also has a share in the process-reliable production of future-oriented mobility.

Established as a family business in 1819, PEISELER today services both manufacturers of machine tools and end customers in a wide variety of different sectors such as automotive, mechanical engineering and shipbuilding, medical engineering, watches and electrics as well as aircraft and turbine construction. Designed to fix and position workpieces, PEISELER’s NC rotary tables and NC rotary tilt tables enable flexible sequencing of operations on modern machining centres, manufacturing plants and transfer lines while at the same time reducing set-up and completion times. Apart from the initial set-up of machine tools, the company also offers retrofitting and other services as well as spare parts. The PEISELER Group comprises the main operating company in Remscheid as well as a production plant in Morbach and a US distribution subsidiary in Grand Rapids, Michigan. The high-precision, technology-intensive positioning of small as well as heavy workpieces at high speeds is the core competency of the company. PEISELER uses variable drive technology as well as specially adjusted designs to manage the forces to which the workpieces, some of them weighing up to 50 tons, are exposed during the fast positioning.

Indexing table 380 mm diameterDiameter graduation directly in 15 degree steps24 he graduation via index boltdirectly with crank and index plate7 Clamping fluteswidth 12 mmGes. height 120 mmWeight 55 kg

Compact precision small rotary table, suitable for single part or small series production in laser welding precision mechanics. A horizontal or vertical assembly is possible.

It is particularly suitable as a 4th axis on engraving and milling machines for engraving, lasering, drilling, grooving, slot milling, or for use on a tool or surface grinding machine.

6.-Round plate Ø 400mm fixed to the table´s saddle through a precision and combined THK type bearing, type RE25025 and a radial rigid one at the back. This offers a great rigidity t...

Peiseler is located in Remscheid on the original site where it was founded in 1819 as a manufacturer of files and rasps. The Morsbach brook powered the waterwheel and it still flows thru the property. Progress brought a steam engine with a boastful 180Hp, the case clock from the factory is proudly displayed in the lobby.
