The Peiseler rotary indexing table is at the heart of the rotary indexing machine, which has five stations for drilling and milling processes plus a loading and unloading station. "The key requirements for our design went beyond the need to achieve a maximum power density for highly dynamic indexing times in the smallest possible installation space", says Gronau. "In order to minimise the tolerances present, we had to position each of the two-axis rotary tilt tables as precisely as possible, both as standalone units and in relation to one another". Providing the media required to close, release and monitor the workpiece clamping device was also a complex task. A rotary manifold with eight ports was ultimately fitted for this purpose.

"This rotary indexing table is not only the largest we"ve built to date, but also a customer-specific solution that will shorten cycle times and reduce unit costs in the production of electric vehicle components", explains Gronau. As a high-precision manufacturer of trunnion tables, rotary tables, two-axis rotary tilt tables, swivel heads and workpiece changing tables, Peiseler is helping to build the reliable production processes that will lay the foundations for our future mobility.

Brown and Holmes are the exclusive UK and Ireland agents/distributors for Peiseler indexers, trunnions and special pallet systems. We also support existing and future owners of these Peiseler products with afull service and repair service, using genuine manufacturer parts.

Founded in 1819, the reliability and reputation of Peiseler products is second to none and a key reason for Brown and Holmes to offer them to its customers.

Peiseler rotary tables are available as single-axis and multi-axis with faceplates ranging from 80 to 3,500 mm diameter, with net weight holding capabilities up to 22,000 kg.

Clamping with axial-movement effects zero torsion on the faceplate, Peiseler install greased clamping discs and a material combination to prevent contact corrosion during lifetime

For the rotary manifolds we use a combination of hardened steel and nonferrous material for long lifetime, the seals were developed with a manufacturer especially for Peiseler to achieve long lasting function

We bring a lot of flexibility to adapt different systems like rotary manifold, zero point clamping systems, chucks, HSK System or any other clamping system to our units

The ZATC series are two-axis rotary tilt tables which are based on the ATC series. The modular character of the ZATC is ensured by the cubic housing shape of the ATC rotary tables. In the same way, we carried over the variety of options and offer this for various requirements. The pneumatic or hydraulic media supply of the table axis can be conducted through the rotary manifold in the mounting flange. It continues via the rotary manifold of the trunnion table axis into the central supply of the machine. The two-axis rotary tilt tables are available with one and multiple spindles. Designs with and without a counter bearing are available. The set-up in the machine tool can be realized via base plates or substructures, depending on the application requirements.

Indexing table 380 mm diameterDiameter graduation directly in 15 degree steps24 he graduation via index boltdirectly with crank and index plate7 Clamping fluteswidth 12 mmGes. height 120 mmWeight 55 kg

Compact precision small rotary table, suitable for single part or small series production in laser welding precision mechanics. A horizontal or vertical assembly is possible.

It is particularly suitable as a 4th axis on engraving and milling machines for engraving, lasering, drilling, grooving, slot milling, or for use on a tool or surface grinding machine.

6.-Round plate Ø 400mm fixed to the table´s saddle through a precision and combined THK type bearing, type RE25025 and a radial rigid one at the back. This offers a great rigidity t...

Established as a family business in 1819, PEISELER today services both manufacturers of machine tools and end customers in a wide variety of different sectors such as automotive, mechanical engineering and shipbuilding, medical engineering, watches and electrics as well as aircraft and turbine construction. Designed to fix and position workpieces, PEISELER’s NC rotary tables and NC rotary tilt tables enable flexible sequencing of operations on modern machining centres, manufacturing plants and transfer lines while at the same time reducing set-up and completion times. Apart from the initial set-up of machine tools, the company also offers retrofitting and other services as well as spare parts. The PEISELER Group comprises the main operating company in Remscheid as well as a production plant in Morbach and a US distribution subsidiary in Grand Rapids, Michigan. The high-precision, technology-intensive positioning of small as well as heavy workpieces at high speeds is the core competency of the company. PEISELER uses variable drive technology as well as specially adjusted designs to manage the forces to which the workpieces, some of them weighing up to 50 tons, are exposed during the fast positioning.

Peiseler is located in Remscheid on the original site where it was founded in 1819 as a manufacturer of files and rasps. The Morsbach brook powered the waterwheel and it still flows thru the property. Progress brought a steam engine with a boastful 180Hp, the case clock from the factory is proudly displayed in the lobby.
