If you are interested in a Wire Rope Clip, you have come to the right place. We offer U-Clips made with stainless steel or galvanized steel. These clamps are used to apply terminations on a cable assembly.

If you are looking for swage sleeves, which fulfill similar functions, we also have those available in their own category. However, if you are interested in picking up some Wire Rope Clips, we have prepared some information that you should find useful.

As we mentioned before, Wire Rope Clamps are used for a similar function to their not-so-distant cousin, the swage sleeve/ferrule. They are used to establish dead-ends and eyes at the end of a wire cable.

While using a clip may decrease the breaking strength of a rope slightly more than a swage would, there are a few advantages over swages. A Wire Rope Clip can be removed and even reused without much wear. This makes clips ideal for less permanent fixes.

When a clip is installed properly, the decrease in the breaking strength of the wire. Eyes installed with Cable Clips will maintain 80-90% of their strength. However, when a clip is not installed properly, the decrease in breaking strength will be much more significant.

Since we just discussed the importance of installing a wire clip properly, let’s talk about what you will need to get this kind of job done. If you already work with wire cables, chances are you already have everything you need.

For the most part, Galvanized Steel is a little easier on your wallet than Stainless Steel and it will take a lot of abuse without much damage to show. However Galvanized Steel is not quite as strong as Stainless Steel and it can’t be used in jobs where the rope may be exposed to saltwater or excessive moisture.

When you are choosing your wire cable, there is a general rule of thumb. Large wires generally stand up very well to abrasion but are not as resistant to fatigue as smaller wires. The size of the rope will help to determine both its strength and flexibility.

Steel Cable Clamps are used in a wide variety of applications. They can be used in towing, loading, rigging, agriculture, and household uses just to name a few areas. The key advantage to using Wire Cable Clamps is that they can be used in any application where an eye termination may need to be removed at some point.

US Rigging are a manufacturer and master distributor of climbing ropes, fall protection equipment, and industrial rigging equipment located in Santa Ana, California. This Orange County based company is proud to provide American Made products with both safety and service in mind. US Rigging has a legacy lasting over 40 years and are known for operational excellence.

We offer a variety of Wire Rope Clips to fulfill your needs in rigging, lifting, towing, and heavy construction applications. These Cable Clips are designed to reliably splice wires with dead-end eye terminations. They are perfect for applications where you need to apply terminations that can be removed.

Wire rope clips, sometimes referred to as u bolt clamps, u bolt clips, u clips, u clamps or cable clamps, are used to secure the loose end of a wire rope when forming an eye. Wire rope u clips have a u-bolt that is secured into a saddle by two nuts. Wire rope assemblies almost always require two, or more wire rope clamps to secure the wire rope properly. When using wire rope cable clamps to form an eye in a wire rope, the working load limit of the wire rope is reduced by about 20%.

Here at Tri-State Rigging Equipment we pride ourselves on providing only the highest quality wire rope clamps from only the most reputable manufacturers. We can provide you with any wire rope clip on the market so, if you are unable to find what you are looking for, or if you don’t know exactly what you need, call or email our sales team to speak with a rigging product specialist.

Wire rope cable clamps come in a variety of materials ranging from galvanized and zinc plated steel, to stainless steel. The two most important different types, however, are drop forged and malleable wire rope u bolt clips.

Drop forged wire rope clips are more heavy duty than malleable rope clips and can therefore be used for more heavy-duty rigging applications. In addition, they are galvanized with a heavy coating of zinc that resists the corrosion and abuse found in rugged work environments. Wire rope cable clamps of every type are not designed to be used in an overhead lift but drop forged wire rope u bolt clamps can be used to suspend an overhead load. This makes wire rope cable clamps ideal for use with:

Regarding the first question, if the load is being moved, wire rope clips are not to be used. If the load is being held in place, heavy-duty drop forged wire rope clips can be used. For the second question, if the load is near the ground, malleable wire rope clips may be used, as their lighter duty design is more than enough for the job. On the other hand, if the load is being suspended above the ground, heavier duty drop forged wire rope clamps must be used.

In the rigging and lifting industry there is a common saying that is used to remember the correct way to use wire rope u clips: “Never saddle a dead horse.” This means that the saddle of the u clamp should always be in contact with the live side of the wire rope rather than the dead side. The dead side of the wire rope is the side of the eye that has the cut end. The dead end is attached to the live end of the wire rope to form an eye and it is imperative that the saddle be on the live side of the wire rope.

Tri-State Rigging Equipment is a service provider and distributor for all wire rope cable clamps, and u bolt clips for rigging serving clients from coast to coast, Canada, Mexico and especially focused in the states of Missouri, Illinois, Indiana, Iowa, Kansas, Nebraska, Arkansas, Mississippi, Tennessee, Kentucky, South Carolina, Florida, and Oklahoma.

Also referred to as wire rope clamps, cable clamps, wire clamps, wire clips, u-bolts, or other local terms, wire rope clips are used to form a load-bearing eye at the end of a wire rope/cable and to connect two cables together using a lap splice.

While these clips are not designed to be used in an overhead lifting situation (swage sleeves should be used instead), wire rope clips are heavy-duty wire rope clips that used for sustaining overhead loads. Examples include guy lines, support lines, scaffolding, etc.

U.S. Cargo Control offers two types of clips: standard (or U-Bolt) and fist-grip (or "double saddle"). Our line includes high-quality clips that work for any situation, including:

Install the first clip at the dead end side of the rope. The "U" side of the clip must always cover the dead end of the rope, and the "saddle" side of the clip on the live end of the rope. Place the nuts of the clip and tighten them using a torque wrench.

Next, apply the second clip and place it as close to the eye loop as possible. Same application for the clip. Tighten the nuts of the clip with a wrench. (If you"re planning on using more than two clips, do not tighten the nuts on the clip.)

Place more clips on the rope if you need more than two on the wire rope. Be sure to space them evenly between the end clips. Finally, tighten the end clips and apply tension to reach the recommended torque for the wire rope.

Wire rope clips are quite small in relation to an entire wire rope setup, but this small hardware piece plays a key role in security and durability. The role of the wire rope clip is to join the end of the wire rope securely to create a loop. This may be used for overhead lifting, along with other numerous purposes, like:

There are different design styles for wire rope clips, but all clips work similarly. There is a rounded opening that fits around the wire rope. The clip is closed by two screws with bolts, causing the rounded opening to tighten around the wire rope, holding it firmly in place.

Since this hardware is used in applications that involve heavy equipment, which can be dangerous, wire rope clips need to be used correctly. Here are the things to keep in mind for a safe wire rope installation:

There are two types of wire rope clip designs: U-bolt or double saddle. It should be noted that only drop forged U-bold wire rope clips are permitted for overhead lifting, double saddle clips are not.

A U-bolt clip is made with a U-shaped bolt, along with a metal base or saddle piece that fits around the wire rope. This is held in place with two nuts that screw on the bottom of the clip.

A double saddle wire rope clip is made from two separate bolts that are held in place by bolts on either side. This different design is somewhat easier to use, as there is no top or bottom. However, they have a lower load capability, which is why they aren’t recommended for rigging.

There are also several types of metals used to make wire rope clips. As mentioned, drop forged clips are the only type that is permitted for overhead lifting. This is made from molten steel that is shaped into place with a ram hammer, making it quite durable. This type of clip is also hot galvanized for additional protection and corrosion resistance.

Wire rope clips may also be purchased in stainless steel and malleable electro-galvanized options. While stainless steel is a very strong metal, it is considered soft and may bend under heavy-duty applications – which is why it shouldn’t be used for overhead lifting. Malleable wire rope clips may even fracture under heavy loads and are best used for light-duty applications like fencing.

The way that a wire rope clip is installed is extremely important, as the placement and angle can interfere with its strength and hold. Before installing, the wire ropes should be inspected and the clips should be checked for several things, including:

Remember to inspect the wire rope before adding the clips on as well. Without proper care or handling, wires in the rope may snap or corrode. Even though the wire rope clips may be in good shape, they won’t hold well if the wire rope is damaged.

Be sure to double-check all safety factor calculations as well. When clips are used to create a sling for overhead lifting, it diminishes up to 75% of the wire rope’s original working load limit. Keep this in mind!

The next step in wire rope clip installation is placement and securement. First, you will measure out the end length of the wire rope that will need to be secured with the clips. A heavy-duty thimble may be added inside of the loop for added support.

Next, undo the clips so they are separated into two parts and fit the U-bolt around the two wire ropes. Then, tighten both of the bolts evenly until they are securely fastened, holding the ropes firmly in place.

Multiple clips should be used for added security with space measuring between 1.5 to 3 times the length of the clip apart. All wire rope clips must be facing the same direction and should be evenly spaced apart.

The majority of issues come with not following the proper requirements for wire clip installation. Failing to follow the rules for spacing, placement, or using the wrong type of clip can be quite dangerous, causing the rope to slip.

Another common issue is not torquing the bolts correctly. This includes both under-torquing and over-torquing. If the bolts are too tight, they will actually wear down the threads of the wire rope beneath. Be sure to follow the manufacturer’s directions on the clips for proper torquing techniques.

Finally, wire rope clips will need to be retightened or cycled out. No bolts will stay perfectly in place for a prolonged period of time, especially if there is a high level of friction. Clips should also be relocated and cycled out after multiple uses.

Ultimately, the quality of your wire rope clips should be a top priority, as this will impact how well the clips work and how long they last. You can purchase top-quality wire rope clips and additional hardware like thimbles, hooks, and wire ropes from Elite Sales. Contact us online to learn more or place an order today!

Bishop Lifting stocks 3 styles of Forged Wire Rope Clips for use as Wire Rope end Fittings. G-450 Red-U-Bolt® Clips, G-429 Fist Grip Clips and G-460 Soft Eye Bundle Clip, and the G-461 Thimble Eye Bundle Clip. Bishop Lifting is a proud distributor for the Crosby group including their line of wire rope clips.

Wire Rope Clips are used for forming eyes in the ends of wire rope by following an installation procedure provided by Crosby® and OSHA 1926.251. ASME states that when used for lifting wire rope clips shall be drop-forged steel of single saddle (u-bolt) or double saddle clip. Malleable cast iron wire rope clips shall not be used. The use of wire rope clips to fabricate slings is generally prohibited as per ASME B30.9. Efficiency ratings of a properly prepared loop or thimble eye terminations for clip sizes 1/8" through 7/8" is 80%, and sized 1" through 3-1/2" is 90%. U-Bolt style clips are not recommended for elevator, personnel hoist and scaffold applications, refer to ANSI A17.1 and ANSI A10.4. Consult the manufacturer before installing wire rope clips on plastic coated or plastic impregnated wire rope.

Before installing the wire rope clips make sure that you have the proper size clips and that the turnback is the proper length based on manufacturer"s recommendations. Place the wire rope clips on in the proper sequence, and make sure that you torque all of the wire rope clips evenly. The saddle of the wire rope clip should be placed on the live end of the wire rope, and the u-bolt should be placed on the dead end. Make sure that you use at least the minimum number of wire rope clips, proper spacing, and turnback length recommended by the manufacturer. Also make sure you torque the wire rope clips to the torque values recommended by the manufacturer. After assembly make sure that you test the connection to at least the anticipated working load, and the check and retighten the wire rope clips to the recommended torque values.

Crosby wire rope clips can be reused if they were installed properly and can pass inspection in between uses. Wire rope clips will wear out over time when they are reused. Check the threads for stretch and corrosion and check the saddle area for wear, deformation, and corrosion. The u-bolt must fit into the base without requiring a forceful change in u-bolt spread. The wire rope clip assembly must be properly installed and capable of being torqued to the proper values. The roddles (ridges) in the clip base must be undamaged, and the clip assembly must be retorqued after the initial load application to the specified torque values.

G-460 Soft Eye Bundle Clip and G-461 Thimble Eye Bundle Clips are used to hold pre-slinged choker eyes in position. These Bundle Clips reduce the rigging and handling time of drill pipe, casing and other down hole tubulars at shore bases, supply vessels and offshore installations.

1. Always apply the saddle of the wire rope clip to the live end (non turnback end) of the wire rope or cable. “Never Saddle a Dead Horse.” Turn back the specified amount of rope from the thimble. Apply the first clip one base width from the dead end of the wire rope.

Crosby® G-450 heavy duty wire rope clips are drop forged and have a Red U-Bolt® for easy identification. These wire rope clips are ideal for heavy duty applications and most often used with heavy duty rigging applications to secure the wire rope on the turn back. Each base has a Product Identification Code (PIC) for material traceability, the name CROSBY or CG, and a size forged into it.

The correct way to attach wire rope clips is illustrated above. Apply the first clip one base width from the dead end of the wire rope. The base or saddle should bear on the line end of the rope – U-bolt on the short end. Tighten nuts firmly.

Attach balance of clips spaced equally between first two clips. Tighten all nuts completely. Apply initial load – inspect nuts and retighten. Inspect all clips periodically.

The number of clips shown is based on using right regular or Lang lay wire rope, 6×19 class or 6×37 clasee, fibre core IWRC, IPS or XIPS. The number of clips shown also applies to right regular lay wire rope, 8×19 class and 18×7 class, fibre core, IPS or XIPS, sizes 1-1/2-inch and smaller.

If Seale construction or similar large outer wire type construction in the 6×19 class is to be used for sizes 1-inch and larger, add one additional clip. For other classes or wire rope not mentioned, it may be necessary to add additional clips to the number shown. If more clips are used than shown, amount of rope turn back should be increased proportionately.

Wire rope is commonly used to lift heavy loads. It consists of braided strands of metal, such as steel. When compared to traditional rope, wire rope is stronger and able to support heavier loads.

When using wire rope, however, you’ll need to secure it to an appropriate anchor point. Fortunately, there are wire rope clips available for this purpose

Wire rope clips are load-bearing components that are designed for use with wire rope. To lift an object with wire rope, you’ll typically need to use a load-bearing component. Wire rope clips offer an effective solution. You can mount them to the top of an object, after which you can secure the wire rope to it. The wire rope clip will hold the wire rope while allowing you to lift the object to which it’s mounted.

How do wire rope clips work exactly? There are different types of wire rope clips, each of which works in a different way. One of the most common types, though, is U-bolt.

U-bolt wire rope clips consist of a U-bolt, a saddle and a pair of nuts. You can see an example of a U-bolt wire rope clip in the photo above. The U-bolt itself is the semi-circular orange piece. The saddle, conversely, is the set of pronged metal pieces on the sides of the U-bolt. Finally, the nuts are the threaded fasteners attached to the bottom of the U-bolt.

To use a U-bolt wire rope clip, you’ll need to remove the nuts from the U-bolt. You can then insert the U-bolt wire rope clip onto the top of the object that you intend to lift. Once positioned, you’ll need to reattach the nuts. The nuts will hold the U-bolt wire rope clip to the object. You can then lift the object by placing wire rope through the center of the U-bolt.

There are also dual-saddle wire rope clips. As the name suggests, dual-saddle wire rope clips have two saddles rather than a single saddle. Each of the two saddles has a built-in bolt, which is attached to a nut. You can remove the nuts to place a dual-saddle wire rope clip on an object.

Wire rope clips are anchor points for wire rope There are U-bolt wire rope clips and dual-saddle wire rope clips. They work by creating a secure load-bearing point on objects so that equipment can lift the object with wire rope.
