Duplex Pumps - Used Emsco D-500 16" stroke, 500hp duplex pump only. 268 gpm @ 2720 psi @ 65rpm with 4 3/4" pistons. 751 gpm @ 970 psi @ 65 rpm with 7 1/2" Pistons More Info

Duplex Pumps - Used 3 1/2" - 5" x 10" stroke duplex pump,96 HP, 83 GPM @ 1500 PSI @ 85 RPM with 3 1/2" Pistons or 182 GPM @ 772 PSI @ 85 RPM with 5" pistons. More Info

We have a large stock of Double-Acting Duplex Pumps that are used for various applications such as fluid (including heavy oil) transfers in pipelines, mud pumping, cement pumping, water well drilling etc. in the Oil & Gas, Agriculture, Mining, Municipal & Manufacturing sectors. Duplex Pumps have two cylinders and are capable of handling different pressures, volumes and flow rates. We supply new, used and refurbished API 674 Double Acting Duplex Pumps of all leading manufacturers including Gaso, Wheatley, Gardner Denver, National & Oilwell.

A mud pump is a reciprocating piston/plunger pump designed to circulate drilling fluid under high pressure (up to 7,500 psi (52,000 kPa)) down the drill string and back up the annulus. A duplex mud pump is an important part of the equipment used for oil well drilling.

Duplex mud pumps (two piston/plungers) have generally been replaced by the triplex pump, but are still common in developing countries. Two later developments are the hex pump with six vertical pistons/plungers, and various quintuplex’s with five horizontal piston/plungers. The advantages that Duplex mud pumps have over convention triplex pumps is a lower mud noise which assists with better Measurement while drilling and Logging while drilling decoding.

Use duplex mud pumps to make sure that the circulation of the mud being drilled or the supply of liquid reaches the bottom of the well from the mud cleaning system. Despite being older technology than the triplex mud pump, the duplex mud pumps can use either electricity or diesel, and maintenance is easy due to their binocular floating seals and safety valves.

A mud pump is composed of many parts including mud pump liner, mud pump piston, modules, hydraulic seat pullers, and other parts. Parts of a mud pump:housing itself

Duplex pumps are used to provide a secondary means of fuel transfer in the event of a failure of the primary pump. Each pump in a duplex set is sized to meet the full flow requirements of the system. Pump controllers can be set for any of the following common operating modes:Lead / Lag (Primary / Secondary): The lead (primary) pump is selected by the user and the lag (secondary pump operates when a failure of the primary pump is detected.

Alternating: Operates per Lead / Lag (Primary / Secondary) except that the operating pump and lead / lag status alternate on consecutive starts. A variation is to alternate the pumps based on the operating time (hour meter) of the lead pump.

Preferred Pump offers the best rewards program in the water well equipment industry. Check out our social media pictures to see what you"ve been missing!

Explore a wide variety of duplex mud pump on Alibaba.com and enjoy exquisite deals. The machines help maintain drilling mud circulation throughout the project. There are many models and brands available, each with outstanding value. These duplex mud pump are efficient, durable, and completely waterproof. They are designed to lift water and mud with efficiency without using much energy or taking a lot of space.

The primary advantage of these duplex mud pump is that they can raise water from greater depths. With the fast-changing technology, purchase machines that come with the best technology for optimum results. They should be well adapted to the overall configuration of the installation to perform various operations. Hence, quality products are needed for more efficiency and enjoyment of the machines" full life expectancy.

Alibaba.com offers a wide selection of products with innovative features. The products are designed for a wide range of flow rates that differ by brand. They provide cost-effective options catering to different consumer needs. When choosing the right duplex mud pump for the drilling project, consider factors such as size, shape, and machine cost. More powerful tools are needed when dealing with large projects such as agriculture or irrigation.

Alibaba.com provides a wide range of duplex mud pump to suit different tastes and budgets. The site has a large assortment of products from major suppliers on the market. The products are made of durable materials to avoid corrosion and premature wear during operations. The range of products and brands on the site assures quality and good value for money.

Welcome to Pickett Oilfield’s mud pumps web page. Our company has been in the oil & gas drilling equipment industry for over 38 years, supplying new and used mud pumps and mud pump parts to customers in practically every producing region in the world. We are here to serve all your drilling equipment needs – if you don’t see it on this site, just give us a call or email. We can get it, if you need it!

Pickett Oilfield, LLC offers prospective buyers and extensive selection of quality new and used oil & gas drilling equipment, including mud pumps and parts to choose from at competitive prices. Browse our inventory of mud pumps and mud pump parts for sale at competitive rates.For more information or to request a quote, please Contact Us at 936-336-5154 or email to Sales@PickettOilfield.com.

We stock fluid end parts for the5×6 mud pump, 5×6-1/4 FM45 mud pump, 5×8 mud pump, 5-1/2×8 mud pump, 5X10 mud pump, 4-1/2×5 mud pump, 7-1/2×8 mud pump, and 7-1/2X10 mud pump.  The Gardner Denver mud pump model numbers for the above pumps are as follows: 5X6-FGFXG, 5X8-FDFXX, 5-1/2X8-FDFXX, 5X10-FDFXD, 4-1/2X5-FFFXF, 7-1/2X8-FYFXX, 7-1/2X10-FYFXD.  We also handle Wheatley, Gaso, Worthington, Failing and Centerline parts and pumps. We also stock Foot Valve, Liner Puller, Valve Seat Puller, (4″ Inline Check Valve.  Our Gardner Denver mud pump parts are not only competitively priced, they are also made in the USA.  Oil Recommended by Gardner Denver.  Call any of our experienced representatives to get the help and knowledge you deserve.

Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections.See all condition definitionsopens in a new window or tab

The 2,200-hp mud pump for offshore applications is a single-acting reciprocating triplex mud pump designed for high fluid flow rates, even at low operating speeds, and with a long stroke design. These features reduce the number of load reversals in critical components and increase the life of fluid end parts.

The pump’s critical components are strategically placed to make maintenance and inspection far easier and safer. The two-piece, quick-release piston rod lets you remove the piston without disturbing the liner, minimizing downtime when you’re replacing fluid parts.

Mud pump is one of the most critical equipment on the rig; therefore personnel on the rig must have good understanding about it. We’ve tried to find the good training about it but it is very difficult to find until we’ve seen this VDO training and it is a fantastic VDO training about the basic of mud pumps used in the oilfield. Total length of this VDO is about thirteen minutes and it is worth to watch it. You will learn about it so quickly. Additionally, we also add the full detailed transcripts which will acceleate the learning curve of learners.

Powerful mud pumps pick up mud from the suction tank and circulate the mud down hole, out the bit and back to the surface. Although rigs usually have two mud pumps and sometimes three or four, normally they use only one at a time. The others are mainly used as backup just in case one fails. Sometimes however the rig crew may compound the pumps, that is, they may use three or four pumps at the same time to move large volumes of mud when required.

Rigs use one of two types of mud pumps, Triplex pumps or Duplex pumps. Triplex pumps have three pistons that move back-and-forth in liners. Duplex pumps have two pistons move back and forth in liners.

Triplex pumps have many advantages they weight 30% less than a duplex of equal horsepower or kilowatts. The lighter weight parts are easier to handle and therefore easier to maintain. The other advantages include;

• One of the more important advantages of triplex over duplex pumps, is that they can move large volumes of mud at the higher pressure is required for modern deep hole drilling.

Triplex pumps are gradually phasing out duplex units. In a triplex pump, the pistons discharge mud only when they move forward in the liner. Then, when they moved back they draw in mud on the same side of the piston. Because of this, they are also called “single acting.” Single acting triplex pumps, pump mud at a relatively high speeds. Input horsepower ranges from 220 to 2200 or 164 to 1641 kW. Large pumps can pump over 1100 gallons per minute, over 4000 L per minute. Some big pumps have a maximum rated pressure of over 7000 psi over 50,000 kPa with 5 inch/127 mm liners.

Here is a schematic of a triplex pump. It has three pistons each moving in its own liner. It also has three intake valves and three discharge valves. It also has a pulsation dampener in the discharge line.

Look at the piston at left, it has just completed pushing mud out of the liner through the open discharge valve. The piston is at its maximum point of forward travel. The other two pistons are at other positions in their travel and are also pumping mud. But for now, concentrate on the left one to understand how the pump works. The left piston has completed its backstroke drawing in mud through the open intake valve. As the piston moved back it instead of the intake valve off its seat and drew mud in. A strong spring holds the discharge above closed. The left piston has moved forward pushing mud through the now open discharge valve. A strong spring holds the intake valve closed. They left piston has completed its forward stroke they form the length of the liner completely discharging the mud from it. All three pistons work together to keep a continuous flow of mud coming into and out of the pump.

Crewmembers can change the liners and pistons. Not only can they replace worn out ones, they can also install different sizes. Generally they use large liners and pistons when the pump needs to move large volumes of mud at relatively low pressure. They use a small liners and pistons when the pump needs to move smaller volumes of mud at a relatively high pressure.

In a duplex pump, pistons discharge mud on one side of the piston and at the same time, take in mud on the other side. Notice the top piston and the liner. As the piston moves forward, it discharges mud on one side as it draws in mud on the other then as it moves back, it discharges mud on the other side and draws in mud on the side it at had earlier discharge it. Duplex pumps are therefore double acting.

Double acting pumps move more mud on a single stroke than a triplex. However, because of they are double acting they have a seal around the piston rod. This seal keeps them from moving as fast as a triplex. Input horsepower ranges from 190 to 1790 hp or from 142 to 1335 kW. The largest pumps maximum rated working pressure is about 5000 psi, almost 35,000 kPa with 6 inch/152 mm linings.

A mud pump has a fluid end, our end and intake and the discharge valves. The fluid end of the pump contains the pistons with liners which take in or discharge the fluid or mud. The pump pistons draw in mud through the intake valves and push mud out through the discharge valves.

The power end houses the large crankshaft and gear assembly that moves the piston assemblies on the fluid end. Pumps are powered by a pump motor. Large modern diesel/electric rigs use powerful electric motors to drive the pump. Mechanical rigs use chain drives or power bands (belts) from the rig’s engines and compounds to drive the pump.

A pulsation dampener connected to the pump’s discharge line smooths out surges created by the pistons as they discharge mud. This is a standard bladder type dampener. The bladder and the dampener body, separates pressurized nitrogen gas above from mud below. The bladder is made from synthetic rubber and is flexible. When mud discharge pressure presses against the bottom of the bladder, nitrogen pressure above the bladder resists it. This resistance smoothes out the surges of mud leaving the pump.

Here is the latest type of pulsation dampener, it does not have a bladder. It is a sphere about 4 feet or 1.2 m in diameter. It is built into the mud pump’s discharge line. The large chamber is form of mud. It has no moving parts so it does not need maintenance. The mud in the large volume sphere, absorbs this surges of mud leaving the pump.

A suction dampener smooths out the flow of mud entering into the pump. Crewmembers mount it on the triplex mud pump’s suction line. Inside the steel chamber is a air charged rubber bladder or diaphragm. The crew charges of the bladder about 10 to 15 psi/50 to 100 kPa. The suction dampener absorbs surges in the mud pump’s suction line caused by the fast-moving pump pistons. The pistons, constantly starts and stops the mud’s flow through the pump. At the other end of the charging line a suction pumps sends a smooth flow of mud to the pump’s intake. When the smooth flow meets the surging flow, the impact is absorbed by the dampener.

Workers always install a discharge pressure relief valve. They install it on the pump’s discharge side in or near the discharge line. If for some reason too much pressure builds up in the discharge line, perhaps the drill bit or annulus gets plugged, the relief valve opens. That opened above protects the mud pump and system damage from over pressure.

Some rig owners install a suction line relief valve. They install it on top of the suction line near the suction dampener. They mount it on top so that it won’t clog up with mud when the system is shut down. A suction relief valve protects the charging pump and the suction line dampener. A suction relief valve usually has a 2 inch or 50 mm seat opening. The installer normally adjusts it to 70 psi or 500 kPa relieving pressure. If both the suction and the discharged valves failed on the same side of the pump, high back flow or a pressure surge would occur. The high backflow could damage the charging pump or the suction line dampener. The discharge line is a high-pressure line through which the pump moves mud. From the discharge line, the mud goes through the stand pipe and rotary hose to the drill string equipment.

A drilling mud pump is generally a duplex reciprocating pump or sometimes a triplex reciprocating drilling rig mud pump used to lubricate the drill bit on drilling projects or water well drilling projects. A solution of bentonite mud is used as the lubricant so drilling mud pumps are sometimes referred to as bentonite mud drilling pumps.

Duplex and triplex mud pumps for sale are suitable for geological deep hole drilling in various coal mining face, and it is also suitable for drilling in metallurgical geological and hydrogeological equivalent industries etc.

In the ground engineering, duplex and triplex drilling rig mud pump are also possible to use construction reinforcement, sealing grouting, and lubrication grouting between the pipe surface and the soil layer during pipe jacking construction.

The most important data for a mud pump, it is flow and pressure. Usually, flow is based on L/min. If the drilling hole diameter is big, the mud pump should have a big flow. Usually, the pressure is based on the drilling depth. More depth, the required pressure is also big.

Gaodetec is a drilling rig mud pump equipment company located in central China. We have been in business for more than 6 years. Many of our employees have background and experience in piston mud pump design and manufacture more than 20 years. We can create custom packages and perform modifications, as well as provide special designed reciprocating mud pump. We provide our customers with the right pump for drilling projects using.

Every pump, every part and every time. We deliver the innovation and quality mud pump for drilling rig. Our high-performance mud pumps for drilling rigs have been field-tested for many years, and all the models are the mature duplex mud pump and triplex mud pump. For more information about duplex mud pump and triplex drilling rig mud pump for sale, please email us:info@gaodec.com

We, at Waters, provide high-standard, quality built mud pumps and its parts for oil and gas drilling operations on sale! We provide both sparingly used mud pumps and its parts to our customers in Houston and other areas in the United States.

In a tight market, leasing or renting rig equipment is the smart move. Waters International offers its customers a wide range of leasing and rental programs that can significantly reduce capital costs and accelerate ROI

The drop-down menu at the top lists the items we usually have in-stock. All of them are also normally available for sale or for rent. Rental products also include additional systems such as Triplex Mud Pumps (Diesel or Electric), Mud Tanks and Solids Control Equipment. For fast and easy equipment request, we have provided online forms customized to each specific area of interest. The photos below illustrate just a few of the items available in our inventory.

The mud pump is an integral part of drilling operations. Also called mud drilling pump, it is a kind of plunger pump or a reciprocating piston, which circulates the drilling fluid through the drill string and back up the annulus. The operation takes place under very high pressure of about 7,500 psi or 52,000 kPa.

Waters provide mud pumps of varying configurations and sizes according to our customer’s requirements. Every oil rig requires a different kind of mud pumps and parts. That is why, at Waters, we offer customized mud pumps according to your requirements. Be it the triplex or three-piston pump for the petroleum rig or the duplex mud pumps, we have with us a wide range of products to satisfy your oil rig specifications.

A mud pump is pivotal to rig drilling operations and at Watersintl, we attach great importance to the quality, make and build of every drilling rig mud pump that we offer for rental. With competition causing margins to shrink, the way to financial and operational success is mud pump rental.Operational efficiency is the key to success and a mud pump can actually be the single biggest contributor to drilling operations. With a lot riding on the capacity and rugged build of a mud pump, a rental is definitely a better choice.

We, at Waters, believe in quality over quantity. For the past five decades, we have gathered enough inputs and experiences to ensure our clients go satisfied after the purchase of our mud pumps and parts.

We, therefore, offer a comprehensive price range on our mud pumps for drilling in Houston. We have both sparingly used and new mud pumps to suit our customers’ requirements. Whatever your budget is, we will provide you the best choice in mud pumps and promise to deliver quality products at an affordable price range.

We know how difficult it is to find that one perfect part or the whole mud pump to fit in your drilling operations. That is why; we keep minimum delivery time to ensure our customers do not suffer downtime.

If you are looking for a mud pump, we would be happy to help! Just call us with your requirements or talk to our experts to know more about our mud pumps and other products!

At Watersintl, our specialization in equipment for drilling, lends us with greater exposure on the all- important mud pump, permitting us to offer the best models. Choose from a wide range of models that feature on our list of equipment available for rental. Benefit from our technical expertise that improves the operational efficiency and reliability of every single mud pump we offer on rent. The inspection routines and servicing that we follow transforms every mud pump into a rugged workhorse that will help you improve operational ability. Browse through our extensive list of drilling equipment and benefit from qualitative superiority and our reputation as one of the very best in the industry.

Manufactured 1998, 1602 hours, 4" plungers with hydraulic charge pump, Detroit Series 50 (rebuilt), 5 speed, Skid mounted with fuel tank, Rebuilt expendables with seals, valves, seats, packings and gaskets.  Price:  $72,500

Complete without traction motors.  9” bore x 15” stroke, single acting, working pressure up to 7500 psi, (3) interchangeable forged steel fluid end modules with separate suction and discharge sections, Premium grade fluid end expendables with 6-1/2” pistons and liners, suction manifold with (3) 12” flanged inlets, SD8 suction desurger, pressure manifold with (2) 5-1/8” 10,000# API flanged outlets, liner wash system, 1 x 1-1/2” mission centrifugal pump p/b 3 hp electric motor, external power end lubrication pump, steel skid, suction line pressure relief valve, set of standard service tools  Price:  $675,000

CENTERLINE 7-1/2 X 10 MUD PUMP(Ref#14556Tb)  high pressure, no engine, needs retaining liner cage and (1) side suction manifold needs replacing, unmounted  Price:  $39,500

3 available in India. 1600 HP, rated pump speed 140 strokes per minute, maximum fluid cylinder liner bore 6-3/4", stroke 10", 10,000 PSI hydrostatic pressure of standard cylinder. 2.853 ratio of gears. 10" suction connection, 6" discharge connection. Valve pot mod .7., steel fluid ends, 5,000 psi pulsation dampener. Oilfield skid mounted. Performance Data: at 120 strokes per minute with 6-3/4" liners, pump will produce 4305 PSI and 574gpm. Set up for electric power. Dimensions and weight: 84,000 lbs, 209"L x 113"W x 75"H. Built 1976. Located India, removed from offshore drilling rig. Price: $75,000 each

approx. 7000 hours, Cat 3512C (1476 hp), 5000 psi fluid end cylinder, 5-1/2" piston cylinder, antifreeze heaters, WPT W21-CG-300 Type 1 PTO clutch, 16 grooove drive sheave, 16 groove bullwheel, 16 groove Kevlar belt with necessary guards, 5 x 6 x 11 charge pump c/w 50 hp@1200 rpm electric motor.  Discharge plumbing: 2" 5M XXH B/W Oteco gate valve, 4" 5M XXH b/w Oteco gate valve, 3" 5M Oteco popoff valve w/1502 connection, 2" 5M type D Oteco mud gauge with 1502 connection, Hydril 20 gal 5M pulsation damper.  Mounted on oilfield skid with separate, with expendables cabinet, knowledge box and removable engine skid for breaking the engine and pump into separate smaller loads.  Winterization package, oilfield lighting, explosion proof starters for charge pump, rod oiler pump and liner wash pumps.  Price:  $695,000 - Make Offer

Two Available, each complete with Cat 3508 diesel engines, pulsation dampener, and mud tanks with desander, desilter, etc.  Price for Package:  $110,000

Cat 3408 engine air start with pump drive and belt guard, PD55 Hydril dampener, 750 gallon fuel tank, mounted on heavy duty drop deck tandem trailer,  low hours  Price:  $87,500

14" stroke, 2" rod size, 400 hp, 75 strokes per minute, cast fluid ends, unitized on oilfield skid with Cat 3406 diesel engines, air start, new filters, oil and coolant, air receiver on deck, fluorescent lighting, drive belts with air clutch.  Gone over and in good operating condition, ready to be put into service.  Pumps currently have new 6" liners with production being 480 gpm @ 1000 psi.  All fluid end parts are brand new and never used, including the valves, gears, liners, pistons, rods, head gasket, and rod packing, equipped with pulsation dampener.  32" long x 11" wide x 7" high 50,000# weight

GARDNER DENVER TEE MUD PUMP(Ref#6440T)  New, unused, manufactured 2014, 4 available, bare pumps  Price:  $39,500 each  New Cat C7 engines available at additional cost

Pump only.  5" stroke, 300 hp, steel billet fluid end, 2-3/4" ceramic plungers, Delrim disc valves, 838 packing, 6" RF suction connection, 3" RTJ discharge connection, 231 gpm max, 2020 psi, max 360 rpm  Price:  $82,500

Two available, rebuilt, cast ductile iron fluid ends, used for oil service, bare pumps, no engines, unmounted, one is flanged for suction/discharge, one is threaded  Price:  $20,000 each

Cummins 150 hp reconditioned engine with snap-in clutch, 90 gal diesel tank with lock cap, Dayton oiler pump system and tank, 4” suction hose and winch boom, 4’ back up drill pipe bumper guard, front and rear loading hitches, epoxy primer and enamel paint, 44” bull wheel with power band belt, large belt guard Price: $82,500

Detroit 671 engine with Snap-In clutch (Gen Set approx. 1500 hours),  replaced fluid end parts with 4” liners,  mounted on 8’ x 12’ trailer with adjustable pintle and DOT lighting, 75 gal diesel tank with lock cap, Dayton oiler pump system and tank, 4” suction hose and winch boom, epoxy primer and enamel paint, 44” bull wheel with power band belt, large belt guard, 2’ x 2’ x 5’ lockable HD toolbox, mouting beams and steel/bolts  Price:  $41,500

Air driven, used with cement for grouting wells, sitting 3-4 years, valves will need rebuilding, trailer mounted, air over hydraulic brakes, includes 28 joints of 21’ pipe  Price:  $39,500

8" x 17" base (mud boat), John Deere 145 hp reconditioned engine with WPI snap in clutch, 90 gal diesel tank, Dayton oiler pump system and tank, 4" suction hose and winch boom, 4" backup drill pipe bumper guard, front and rear loading hitches, 42" bull wheel with power band belt, belt guard  Price:  $99,000 PRICE REDUCED:  $73,500

Cat engines, 4 speed transmissions, rigged up with secondary containment, onboard lighting, winterization canvas for cold weather operations, Also available with Cummins or John Deere engines Priced from $77,500 to $97,500

379 Cat didsel engine, Matco hi pressure forged steel fluid end, quick change valve heads, Hydril dampener, brand new expendables sill in box  Price:  $59,500

750 hp, 8" stroke, 6" suction inlet, 4" discharge outlet, piston size 4-1/2" - 7",  max rod load 85,000#, approx. weight 11,500#, lubrication force fed, steel pump power end, double helical gears, 4.95:1 gear ratio, rod bearings sheel type replaceable, main bearings straight roler, pinion bearings spherical roller, crankshaft 1pc forged alloy steel, connecting rod knuckle joint, crosshead guide bronze replaceable, piston type fluid end Monoblock design, from high strength alloy steel, treated and sonic tested, Cat D379 diesel engine, 500 HP max linear bore size 3-1/2 - 6-1/4 x 7-3/4" stroke, test pressure 10,000 psi, gear ratio 2.742.8" suction line to 4 discharge stroke, location South America  Price:  $110,000

Two available, Skidded, Detroit Series 60 diesel engine DDEC V (475 hp), Allison 750 (6-speed) transmission with lock up control pane, Mission 4 x 5 centrifugal suction pump, 4” plungers, pulsation dampener, pressure gauge, safety valve, 10,000 psi fluid end, 5000 psi working pressure, NOV plug valve control manifold (4-valve) configured for 15k operation.  Can be configured to kill wells, acidize, cement, reverse circulate, drill out frac plugs or run in tandem.  Self-contained with fuel and fluid tanks and controls.  Steel canopy over skids, covered battery boxes, new batteries and disconnect switches.  Well maintained and in excellent condition.  Low hours on pumps and motors.  Ready to work.  Price:  $154,500 each

1600 hp, 12" stroke, 5000 psi, pulsation dampeners, pop off pressure release valve, pump pressure gauge, forged discharge manifold, overhead track for chain hoist, mounted on shipping skid, line washer pump, 6" liners, overall size:  192 x 128 x 105-3/4", inspection report available  Price:  $137,500

14 liter Detroit Diesel, 6061 Allison automatic transmission, rebuilt power end, new expendables in fluid end, new charge pump, skid, tanks, Pilfer 5 valve manifold, 15k fluid end, new paint  Price:  $215,000

Manufactured 1999, 1000 gal holding tank, (2) 3 x 4 Mission Magnum pumps with mechanical seals, MC255-2C mud cleaner, sand guzzler, Versa-drill rig jacks, Perkisn engine, spare hyd pump and filters, well maintained, ready to work  Price:  $59,500PRICE REDUCED: $49,500

Mounted on 12K GVRW trailer, hydraulic powered spool with approximately 500 of 2” hose, internally routed power and safety cable, 7.5 HP pump and motor, Whisper Watt 25kva 3-phase diesel generator with approx. 3100 hours  Price:  $45,000
