f1600 mud pump piston factory

in various well drilling environment. The hub is forged from high quality steel, and the piston rubber is made from specially formulated compounds which are of heat, oil and water resistance.

2) Bonded Urethane Pistons dramatically extend service life in triplex pumps with ample water cooling. Harder, more dense polyurethane construction provides superior resistance to abrasive

A wide variety of bomco f1600 mud pump piston options are available to you, such as 1 year, not available.You can also choose from new, bomco f1600 mud pump piston,as well as from energy & mining, construction works , and machinery repair shops bomco f1600 mud pump piston, and whether bomco f1600 mud pump piston is 1.5 years, 6 months, or unavailable.

TENACITY produces a series of API 7K-compliant mud pumps ranging from F-500 to F-2200. F-2200 is atri-cylinder, single-action, heavy-duty, high-pressure drilling pump with amaximum power of 2,200HP, maximum working pressure of 52MPa, and maximum displacement of 77.65L/s.

F-1300, F-1600,F-1300L and F-1600 mud pumps have a Max Pump pressure of 34.5 MPa (5000Psi) and adisplacement of 46.5L/S with a liner of Φ180mm. These two models are the first choice for medium and deep drilling rig as an assortedcomponent.

F-1600, F-2200 mud pumps with high-power and high-pressure are developed to meet drilling requirements of offshore deep-water, terrestrial andhorizontal wells, especially in desert areas.

Our premium pistons are fully interchangeable with other API standard designedpistons and deliver maximum performance in almost all drilling conditions. Hightensile strength, resistance to chemicals, hydrocarbons, and abrasion, longService,and full interchangeability with other API designed pistons make our premiumpiston a sound value.

This one piece bonded constructed piston has no joints to leak. Eliminates abrasive fluids between piston and liner. The fluid expanded lip is not damaged by high pressure and fast pump strokes. This Fail-Safe piston seals off to greater diameter as liner wears.

Currently running in pumps using exotic muds and highest drilling pressures! Bonded construction - no joints, no leakage. Longer piston and liner life. This pistonwill run in higher-pressure, fast stroking pumps, and is resistant to oil basemuds and other additives currently being used. This Premium Piston has been inservice for years, providing unmatched performance under extreme drilling conditions. This one piece bonded unit provides the same series of advantages. being imprevious to oil and other chemicals

The piston rubber is made from specially formulated compounds which are resistant tothe effects of heat, oil and water. The multi-ply fabric reinforced backingsused in the production of the piston rubbers provide positive, wear resistantseals.

We mainly manufacturer emsco f-500, f-800, f-1000, f-1300, f-1600, gardner denver pz-9 and national 12-p-160 mud pumps. The quality products, competitive prices, respensive service and short delivery time earn a lot of reputation for us.

F series mud pump is applicable to the requirement of high pump pressure in oilfield and high displacement technology of well drilling with its solid and compact structure, small vallume and outstanding operation performance .It has long stroke maintaining operation at lower frequency resulting in enhancing the performance of giving water efficiency and prolonging the lifetime of the consumable hydrokinetic parts. The air-suction kit is advanced in structure and reliable at operation to reach the optimized absorbing target of air suction into linepipe.

F series pump powering side adopts the combined lubrication of forced and flashing lubrication featured with reliable lubrication and adding the operacation lifetime of powering part.

The series pump is producted strictly according to api spec 7k"the equipment specification of well drilling and repairing" , and performed the ex-work test under the specification thereof.

Haihua F1600 Mud Pump Piston Rod, HH0628.207.019 HH11309A.05.017.162 is connected to extension rod through clamp, the piston and piston rod are connected by piston nut.

Check if any abnormal sound exist at connection clamp between piston rod and extension rod. Tighten the clamp bolts or replace qualified clamp, piton rod or extension rod if any abnormal sound occurred.

Dismantle the connection clamp between piston rod and extension rod, and crank mud pump to separate the extension rod from piston rod. Then use the lifting tool to hold liner inside.

There is no need to remove piston core from piston rod when replacing piston rubber. Replacing the rubber only needs to remove the retainer (circlip) and clamping plate at the front of piston core.

The piston assembly is one of the main parts of the hydraulic end system of the mud pump, and it is also one of the vulnerable parts in the drilling work. The discharge pressure of the mud pump is generated by the reciprocating linear movement of the piston assembly in the piston. The piston assembly is composed of piston core, rubber, circlip, pressure plate, etc. The material of the piston core is 42CrMo, and the material of the piston rubber is nitrile rubber or polyurethane rubber

Has excellent oil resistance and wear resistance. The working temperature is not higher than 120℃, which is suitable for oil-based mud with working pressure below 35Mpa and working environment with high sand content.

We can supply many kinds of mud pump spare parts to fit your drilling needs, suiting to almost all popular mud pumps in the world.. Such as valve, valve seats, liner, piston, fluid end parts, crankshaft Assembly, Pinionshaft assembly, valve cover, liner cage, liner nut, valve seat puller, extension rod and piston rod, bearing, cylinder etc.

With the introduction of American Emsco technology, GEPEC could service the customer with six specifications pumps from 500 to 2200HP, and two pressure rating from 35 to 52MPa. F-1300 and F-1600 drilling pumps become the best choice for the middle...
