what pressure do you set pop off on mud pump manufacturer

Pressure relief valves are installed on mud pumps in order to prevent an overpressure which could result in a serious damage of the pump and serious or fatal injury to personnel.

The discharge pressure is routed to the closer mud tank, via a 3” XXS line clamped strongly on tank side . Mud is flowing into the mud tank until line bled off, bearing in mind that minimum slope is required to avoid mud settling in pipe ( around 1 inch/meter).

In any cases if you don’t know/ clearly understand how to do it don’t do it, ask your supervisor. Do not start or later on , stop the job if you feel to do so .

Pressure relief valves are set usually to 90% of the maximum working pressure of the liners in use. Read carefully manufacturer chart for pressure setting versus size of liners.

With a low pressure setting, ie, 1000psi, by adjusting the top nylon self lock nut to move on the vertical scale to get the same setting than the scale.

Discharge pressure losses close to the maximum preset pressure.The Pressure relief valves are usually installed on a upper point of the discharge side of the mud pumps.

The pressure relief valve can be reset, if not damaged during the release of pressure. Special care should be taken if no working platform available to access the PRV.

This website is using a security service to protect itself from online attacks. The action you just performed triggered the security solution. There are several actions that could trigger this block including submitting a certain word or phrase, a SQL command or malformed data.

1.1 OBJECTIVE.A key objective of ADC Procedures is to set up a step by step way of handling thejob. It is also an analysis of associated hazards pertaining to the jobs and measures tominimize the risks.This procedure has developed to be applied and discussed before each job listed inthe contents.1.2 SCOPE.This procedure applies to Rig AD-321.3 RESPONSIBILITY.It is the responsibility of the Tool-pusher and Rig Manager to insure all listedoperations are executed in a safe and efficient manner. It is their responsibility toconduct a Pre-job Safety Meeting and discuss and review the related JSA, prior tostarting each operation.Tool-pusher is responsible to ensure that each work permit has its dedicated JSAattached to.JSA to be reviewed and updated at least annually or When equipment is modified When processes are changed When material are changed When changing people/contractors When there is an accident or near miss.The Rig Sup. is accountable for keeping this document up-to date.The JSA date and the crew should be same as Work Permit date and crew.

Table of ContentsTASK ANALYSISIs Procedure relevant for the operation?What can interfere with the operation (Simops)?Who is going to be in charge, position?Who is giving instructions/signals, who replace him?How many people are required to do the job?-

Do you need a PTW/ Isolation (lockout, Tag out)?What is the PPE required?What tools/equipment do you need?Do you need a third party, crane, and forklift?Who else needs to know what you are doing?Do you need to barrier off the area?What are the safest access/escape routes?-

Pressure relief valves are installed on mud pumps in order to prevent an overpressurewhich could result in a serious damage of the pump and serious or fatal injury topersonnel.The discharge pressure is routed to the closer mud tank, via a 2 line minimum clamped allthe way along. Mud is flowing into the mud tank until 0 pressure in the line.Read carefully manufacturer instructions regarding setting, handling, refurbishing of suchequipment.In any cases if you dont know/ understand how to do it dont do it, ask your supervisor.1) Pressure relief valves are set usually to 90% of the maximum working pressure ofthe liners in use. Read carefully manufacturer chart for pressure setting versus sizeof liners.2) The most commonly used pressure relief valve is RETSCO, 500 and 750, whichstands for mud pumps maximum working pressure 5000psi and mud pumps7500psi.3) Prior to installing a pressure relief valve it needs to be tested on a bench.

nut to move on the vertical scale. If the pop off pressure matches the setting, then screw to the pressurerequired on the mud pump (check liner chart) and test again.

When the pressure test has been successful, put a tag on the pressure relief valve, whereit is mentioned:-The date of the test.-The pressure of the test.-If the pressure relief valve was reconditioned.Store it properly away from dust and adverse weather.

1) When/if the pressure relief valve activates due to: I_Bop kept closed and pump started. Build up pressure close to the maximum preset pressure.The pressure relief valve can be reset, if not damaged during the release of pressure.The Pressure relief valves are usually installed on a upper point of the discharge side ofthe mud pumps.Special care should be taken if no working platform available to access the PRV.A safety harness may be necessary in some places.1) Pull round button toward you.2) Pull handle towards you to reset / reposition the knuckle joint inside.3) The handle should have a hard point then come freely.4) If you cannot exert enough force due to position a 1 ID pipe can beused to pull the handle. DO NOT FORCE on the handle if nothingmoves, that means that the discharge piston inside is jammed.

7) Replace PRV by the one ready tested in the store.8) Restore the power on the mud pump.9) Start the pump slowly; check on the discharge pipe above the mudtanks if there are no leaks.10)If everything ok, close work permit, recondition worn pressure reliefvalve, with original parts, pressure test it and store it with a tag asmentioned earlier.

If you run a mud rig, you have probably figured out that the mud pump is the heart of the rig. Without it, drilling stops. Keeping your pump in good shape is key to productivity. There are some tricks I have learned over the years to keeping a pump running well.

First, you need a baseline to know how well your pump is doing. When it’s freshly rebuilt, it will be at the top efficiency. An easy way to establish this efficiency is to pump through an orifice at a known rate with a known fluid. When I rig up, I hook my water truck to my pump and pump through my mixing hopper at idle. My hopper has a ½-inch nozzle in it, so at idle I see about 80 psi on the pump when it’s fresh. Since I’m pumping clear water at a known rate, I do this on every job.

As time goes on and I drill more hole, and the pump wears, I start seeing a decrease in my initial pressure — 75, then 70, then 65, etc. This tells me I better order parts. Funny thing is, I don’t usually notice it when drilling. After all, I am running it a lot faster, and it’s hard to tell the difference in a few gallons a minute until it really goes south. This method has saved me quite a bit on parts over the years. When the swabs wear they start to leak. This bypass pushes mud around the swab, against the liners, greatly accelerating wear. By changing the swab at the first sign of bypass, I am able to get at least three sets of swabs before I have to change liners. This saves money.

Before I figured this out, I would sometimes have to run swabs to complete failure. (I was just a hand then, so it wasn’t my rig.) When I tore the pump down to put in swabs, lo-and-behold, the liners were cut so badly that they had to be changed too. That is false economy. Clean mud helps too. A desander will pay for itself in pump parts quicker than you think, and make a better hole to boot. Pump rods and packing last longer if they are washed and lubricated. In the oilfield, we use a petroleum-based lube, but that it not a good idea in the water well business. I generally use water and dish soap. Sometimes it tends to foam too much, so I add a few tablets of an over the counter, anti-gas product, like Di-Gel or Gas-Ex, to cut the foaming.

Maintenance on the gear end of your pump is important, too. Maintenance is WAY cheaper than repair. The first, and most important, thing is clean oil. On a duplex pump, there is a packing gland called an oil-stop on the gear end of the rod. This is often overlooked because the pump pumps just as well with a bad oil-stop. But as soon as the fluid end packing starts leaking, it pumps mud and abrasive sand into the gear end. This is a recipe for disaster. Eventually, all gear ends start knocking. The driller should notice this, and start planning. A lot of times, a driller will change the oil and go to a higher viscosity oil, thinking this will help cushion the knock. Wrong. Most smaller duplex pumps are splash lubricated. Thicker oil does not splash as well, and actually starves the bearings of lubrication and accelerates wear. I use 85W90 in my pumps. A thicker 90W140 weight wears them out a lot quicker. You can improve the “climbing” ability of the oil with an additive, like Lucas, if you want. That seems to help.

Outside the pump, but still an important part of the system, is the pop-off, or pressure relief valve. When you plug the bit, or your brother-in-law closes the discharge valve on a running pump, something has to give. Without a good, tested pop-off, the part that fails will be hard to fix, expensive and probably hurt somebody. Pop-off valve are easily overlooked. If you pump cement through your rig pump, it should be a standard part of the cleanup procedure. Remove the shear pin and wash through the valve. In the old days, these valves were made to use a common nail as the shear pin, but now nails come in so many grades that they are no longer a reliable tool. Rated shear pins are available for this. In no case should you ever run an Allen wrench! They are hardened steel and will hurt somebody or destroy your pump.

One last thing that helps pump maintenance is a good pulsation dampener. It should be close to the pump discharge, properly sized and drained after every job. Bet you never thought of that one. If your pump discharge goes straight to the standpipe, when you finish the job your standpipe is still full of fluid. Eventually the pulsation dampener will water-log and become useless. This is hard on the gear end of the pump. Open a valve that drains it at the end of every job. It’ll make your pump run smoother and longer.

Rig pump output, normally in volume per stroke, of mud pumps on the rig is  one of important figures that we really need to know because we will use pump out put figures to calculate many parameters such as bottom up strokes,  wash out depth, tracking drilling fluid, etc. In this post, you will learn how to calculate pump out put for triplex pump and duplex pump in bothOilfield and Metric Unit.

Legal status (The legal status is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the status listed.)

Current Assignee (The listed assignees may be inaccurate. Google has not performed a legal analysis and makes no representation or warranty as to the accuracy of the list.)

Priority date (The priority date is an assumption and is not a legal conclusion. Google has not performed a legal analysis and makes no representation as to the accuracy of the date listed.)

F16—ENGINEERING ELEMENTS AND UNITS; GENERAL MEASURES FOR PRODUCING AND MAINTAINING EFFECTIVE FUNCTIONING OF MACHINES OR INSTALLATIONS; THERMAL INSULATION IN GENERAL

Y—GENERAL TAGGING OF NEW TECHNOLOGICAL DEVELOPMENTS; GENERAL TAGGING OF CROSS-SECTIONAL TECHNOLOGIES SPANNING OVER SEVERAL SECTIONS OF THE IPC; TECHNICAL SUBJECTS COVERED BY FORMER USPC CROSS-REFERENCE ART COLLECTIONS [XRACs] AND DIGESTS

Y—GENERAL TAGGING OF NEW TECHNOLOGICAL DEVELOPMENTS; GENERAL TAGGING OF CROSS-SECTIONAL TECHNOLOGIES SPANNING OVER SEVERAL SECTIONS OF THE IPC; TECHNICAL SUBJECTS COVERED BY FORMER USPC CROSS-REFERENCE ART COLLECTIONS [XRACs] AND DIGESTS

Method and device for preventing a primary relief valve (12) in a mud system (1) from opening at a pressure lower than a nominal opening pressure, and where the mud system (1) includes a mud pump (2), wherein the method includes: - installing an flow restrictor (16) between the mud pump (2) and the primary relief valve (12); and -providing a cavity (20) between the flow restrictor (16) and the primary relief valve (12).

There is provided a method for preventing a primary mud re¬ lief valve from incorrect opening. More precisely there is provided method for preventing a primary relief valve in a mud system from incorrect opening, where the mud system includes a mud pump.

Mud systems, as known from drilling rigs, normally include a mud pump, a pulsation dampener and a relief valve, the latter herein termed "primary relief valve". The main pump is typi¬ cally a triplex pump. This kind of pump delivers a flow rate which is far from constant but fluctuates much because of i) variable piston speed - the pump is crank shaft driven, ii) mud compressibility and iii) valve and fluid inertia. The pulsation dampener is therefore included to smoothen the flow rate and mitigate the resulting pressure fluctuations. The primary relief valve may be of a design known as a "pop-off valve" in the industry, or a rupture disk. Other types of re¬ lief valves are also known.

The primary relief valve is a safety valve that is designed to prevent excessive pressure and possible hazards in the case the pump pressure exceed the certified pressure limit for the system. Normally the so-called trip pressure, at

which the primary relief valve shall switch from a closed to an open state, is set slightly higher that the system pres¬ sure of typically 5000 psi (345 bar) .

It is a well-known problem in the industry that the primary relief valve sometimes trips frequently even though the rec¬ orded pressure levels never reached the nominal trip pressure level .

Tripping of a primary relief valve represents a costly and highly undesired disruption of the drilling process, both because of the time it takes to refit a new rupture disk or to reset a resettable primary relief valve and because the well can be damaged during long periods of no circulation. To lower the risk for primary relief valve tripping one can therefore reduce maximum working pressure to say 80 per cent of the system pressure limit. This is also a costly solution be¬ cause flow rate and pressure is often a limiting factor that can lead to slower drilling and even cause well stability problems. The opposite solution of increasing the nominal trip pressure to compensate for the dynamic effect is also a highly undesirable solution that may lead to damage in other parts of the mud system. It may even be illegal to raise the nominal relief valve pressure to more than a few per cent over the certified system pressure.

According to a first aspect of the invention there is provid¬ ed a method for preventing a primary relief valve in a mud system from opening at a pressure lower than a nominal open-

A field study of above stated problem has revealed that the reason for the tripping of the primary relief valve at a pressure lower than the nominal opening pressure, most likely is relatively large pressure fluctuations in a pop-off line. Despite of the damping action of a pulsation dampener, there are substantial residual pressure fluctuation present in a discharge pipe between the pump and the dampener. The pop-off line itself represents a hydraulic resonator that can signif¬ icantly amplify these residual fluctuations at frequencies close to resonance frequencies. This explanation is supported by special pressure measurements just below the primary re¬ lief valve showing that the peak dynamic pressure can some¬ times exceed 115 per cent of the mean pressure.

These pressure fluctuations can lead to undesired primary re¬ lief valve trips, both because the peak pressure are really higher than seen on the standard pressure sensors, and be¬ cause they can lead to fatigue and lowering of the real trip pressure. This fatigue effect is especially relevant if the primary relief valve is a rupture disk.

It has thus been found that the opening of the primary relief valve is related to pressure variation at higher frequencies, typically in the region of 40Hz. Pressure fluctuations at this frequency has been measured to be up to 40 bars. Such fluctuations are superimposed on the mean pressure and are believed to cause the tripping of the primary relief valve at a pressure lower than the nominal opening pressure.

The high frequency pressure fluctuation components appear to be generated by the mud pumps and are related to the pump valve action. Both mud compressibility and pump valve inertia tend to cause sudden changes in the pump flow rate when the pump discharge valves open and closes. The changes give rise to a pressure pulse that is enhanced at frequencies close to the resonance frequencies of the closed primary relief valve line .

By installing a flow restriction between the mud pump and the primary relief valve in combination with a cavity positioned between the flow restriction and the primary relief valve, these higher frequency pressure fluctuations are dampened. The pressure acting on the primary relief valve is then the mean operating pressure of the mud system. The relation between the size of the flow restrictor and the cavity volume should be calculated according to known principles, or it should be found experimentally by testing different

The flow restrictor may be in the form of a tubing having a diameter much smaller than the so called characteristic di¬ mension of the cavity, say smaller than the cubic root of said cavity, and a length much longer than the diameter of the flow restriction.

Said flow restrictor may be in the form of an opening in a plate where the opening has a diameter much smaller than the characteristic dimension of the cavity.

The method may include placing a second relief valve in par¬ allel with the flow restrictor, preferably with a lower nominal trip pressure than the primary relief valve.

This second relief valve will normally only experience the dynamic pressure difference as it receives the mud pump pres¬ sure on one side and the smoothed pressure at the cavity on the other side.

According to a second aspect of the invention there is pro¬ vided device for preventing a primary relief valve in a mud system from opening at a pressure lower than a nominal opening pressure and where the mud system includes a mud pump, wherein a flow restrictor is positioned between the mud pump and the primary relief valve, and where a cavity is provided between the flow restrictor and the primary relief valve.

In a practical embodiment of the invention, the primary re¬ lief valve, the flow restriction, the second relief valve and the cavity may be produced as one unit that is fairly compact and suitable for installation in a mud system.

The method and device according to the invention render it possible to overcome the long felt problem of incorrect open¬ ing of the primary relief valve of a mud system.

On the drawings the reference number 1 denotes a part of a mud system that includes a mud pump 2 that draws mud from a mud reservoir 4 and discharge the mud via a discharge pipe 6 into a so-called stand pipe 8. A pulsation dampener 10 is connected to the discharge pipe 6. A primary relief valve 12 is connected to the discharge pipe 6 via a so-called pop-off line 14. In this exemplary embodiment, the primary relief valve 12 is a pop-off valve. However, in other embodiments, the primary relief valve 12 may be a rupture disk or another suitable valve.

According to the present invention a flow restriction 16 is provided between the mud pump 2 and the primary relief valve 12, or more precisely between the discharge pipe 6 and the primary relief valve 12.

A second relief valve 18, which may be of a type similar to the primary relief valve 12, is positioned in parallel with the flow restriction 16. A cavity 20 is closed off in the pop-off line 14 between the primary relief valve 12 and the second relief valve 18. The cavity 20 communicates with the discharge pipe 6 through the flow restriction 16.

As stated in the general part of the description, the cavity 20 in relation to the size of the flow restriction 16 should be determined according to well known principles in order to dampen the dynamic frequency pressure at the actual frequen¬ cies .

This done, as the mud pump 2 operates, the high frequency pressure fluctuation components are dampened in the flow re¬ striction 16/cavity 20 dampener system. Thus, the primary relief valve 12 only experiences the average pressure present in the cavity 20.

The second relief valve 18 has the pressure from the mud pump 2 acting on the side facing the discharge pipe 6, while the average pressure is acting on the side of the second relief valve 18 facing the cavity 20. The resultant pressure across the second relief valve 18 equals the dynamic pressure fluc¬ tuations in the discharge line 6, normally with zero mean.

Then, as the flow through the flow restriction 16 is minute compared to that of the primary relief valve 12, the pressure over the second relief valve 18 will equal the full pressure from the mud pump 2. The second relief valve 18 will then al¬ so open if the high average pressure is still present. To en¬ sure tripping of the second relief valve 18, its trip pres¬ sure may preferably be slightly lower than the trip pressure of the primary relief valve 12.

In an alternative embodiment, see fig. 2, the pressure sens¬ ing component of the second relief valve 18 is a rupture disk 22. A flow restriction 16 is incorporated in the rupture disk

22, see fig. 3. Aside from the second relief valve 18 being a rupture disk in this embodiment, rather than a pop-off valve, mud system 1 and its functioning are as previously described.

1. Method for preventing a primary relief valve (12) in a mud system (1) from opening at a pressure substantially lower that a nominal opening pressure, where the mud sys¬ tem (1) includes a mud pump (2) , c h a r a c t e r i z e d i n that the method includes:

i n that said restrictor (16) constitutes a tubing hav¬ ing a diameter much smaller than a characteristic dimension of said cavity (20) and a length much longer than the flow restrictor" s (16) diameter.

i n that said restrictor (16) constitutes an opening in a plate, where the openings diameter much smaller than a characteristic dimension of said cavity (20) .

5. A device for preventing a primary relief valve (12) in a mud system (1) from opening at a pressure lower than a nominal opening pressure and where the mud system (1) in¬ cludes a mud pump (2), c h a r a c t e r i z e d b y that a flow restrictor (16) is positioned between the mud pump (2) and the primary relief valve (12), and that a cavity (20) is provided between the flow restrictor (16) and the primary relief valve (12) . Device according to claim 5, c h a r a c t e r i z e d i n that a second relief valve (18) is placed in paral¬ lel with the flow resistor (16) .
