edm rotary table factory

MK250RAV00 Rotary Table (includes Quinte Controller) with compact design, high performance nd improved mounting. The innovative triple disc brake system & friction welded construction gives substantially ...

Our product range includes single and multiple axes, tilt/rotating tables, and indexing and high-speed spindles. Additionally, we offer customized solution tables for customer requests or OEM projects.

Even for EDM machines that have been in use for decades, we will work with you to determine the ideal rotary indexing table and/or rotating/indexing spindle solution.

Our state-of-the-art rotary indexing tables and customizable reference and clamping systems provide endless application possibilities and highly efficient solutions.

Manufacturing on an EDM equipped with our high-speed rotating and indexing spindles is an efficient alternative to hard turning or superfinishing for rotationally symmetric parts. Even smallest parts (pins, needles etc.) in stainless steel, hard metal or even conductive ceramics, which cannot be made by conventional processes like turning, grinding etc. can be manufactured efficiently.

Anyway, to answer your questions, I looked up the Hirschmann table you referenced and it looks to me like it"s a spinner and indexer, not a turn while burn table.

Hirschmann must have a similar provision to integrate their turn while burn capable tables to whatever machines they are going to be run on...I don"t think you can just buy one and bolt it to a machine without the interface kit to mate it to the control.

Turn while burn requires that the controller governs the rotary motion; this is because the rate of rotation has to be driven by the spark gap conditions in conjunction with the axis motion of the rest of the machine whether it"s X or Y or U or V.

It was faked by tilting the wire to an angle other than the thread helix angle with the U axis, then driving a fine pitch helix with B and X (B is the rotary axis on my machine).

You can imagine just how many passes that would take (a LOT), and you will always have a 0.005" radius at the junction of each flank and the root, which may or may not be acceptable depending on the application.

This control unit can be connected to any make or model of machine control and is started via M signal command. Programmable directly in either direction to any specified angle directly. The unit can be mounted vertically or horizontally at will. Motor is mounted to the left side on this device, through hole capability is closed due to the style and application of the device. Hofmann products are a high quality unit, this is no different being pre-owned is incredible value for money and come with a 1 year warranty. General dimensions are attached to this listing, however for clarity in vertical, the centre height is 160mm, the overall height is 250mm, in the horizontal plane, the height is 160mm. Carrying capacity vertically unsupported 120kg or 250kg with matching tailstock. Horizontal ;plane carrying capacity Is a very impressive 600kg. Net weight 60kg (Table and motor) This is a one only offer and cannot be repeated and is therefore subject to prior sale – contact technical sales for further information. The model number relates directly to the spindle and height, there is no faceplate with this unit.

Jauch & Schmider adds one, two, or three additional axes to an existing EDM machine. These ultra precise EDM tables are fully submergible and offered in standard and application specific multi-axis configurations. All tables are available for direct machine control integration or with the single/multi-axis Logipos control. Jauch and Schmider tables are designed to accommodate leading clamping systems such as Hirschmann, Erowa, System 3R, and others.komaprecision.com

Roller cam: Compared with worm gears type it is with higher wear resistance, high transmission efficiency , affordable prices and basically maintenance-free of table.

Table directly driven by a motor, high rotary speed , no backlash, no weariness and low inertia. But relatively technical requirement is high and difficulty, the price is the most expensive. Generally used for five-axis machine tools.

Our rotary table can be used in the aerospace industry, 3C high-tech industry semiconductor parts, auto parts and components automation manufacturing, or bathroom equipment and daily necessities manufacturing etc.

The backlash control of our rotary table is stable and reliable, it can be adjusted at the same time and is easy to operate to meet high-precision processing and production requirements, so that it can help customers reduce costs and create more profits.

The innovative rotary table incorporates a fully-closed feedback loop system using Fanuc servo motor and rotary encoder, making it the ideal addition to Fanuc EDM machines. As the CCR table is designed and manufactured by Fanuc, solely for the RoboCut EDM machines, it costs up to 50% less than a table from a third-party supplier and it has considerably more functionality built in.

The CCR table is equipped with a sensor that triggers a servo motor and an encoder alarm that sounds if a seal ruptures and water gets into the compartment where both are located. As a safety measure, this shuts down the machine and drains the water tank. This built-in technology minimises the potential for expensive water-related repairs to the motor and encoder.The robust 16kg CCR has a compact area of 155 by 170 by 130mm (LXWXH) that enables the operator to retain the spacious work envelope of the machine. The precision of the CCR is demonstrated by an indexing accuracy of 12 seconds and a repetition accuracy of +/-2 seconds. Despite its lightweight and highly accurate frame, the CCR permits a maximum workpeice weight of 40kg.

For some time, EDM customers have been adding rotary tables to their machines to accommodate the range of motion required to conduct work in high-tech markets such as the aerospace and medical sectors. This new CCR rotary table will now provide customers with this range of movement whilst adding speed, precision rigidity to the EDM process.

Rotary tables also have an economic impact on the manufacture of cutting tools, especially when paired with the relatively high production speeds of some Fanuc EDM machines. An example of this is the production of rotary PCD (polycrystalline diamond) tipped tool bodies where the CCR will deliver astounding benefits.

The MMK Matsumoto Corp. MDW series single axis EDM rotary table is specifically designed for wire EDM applications. MDW series indexers are protected from the EDM environment, fully sealed, air purged and impervious to debris, oil and water.

These EDM rotary tables can be mounded on the A-axis or B-axis. The table’s internal structure is completely isolated from the electric current, and the unit is equipped with current-collecting brushes, which help to effectively distribute electricity charge.

Matsumoto MDW series EDM rotary tables are built from stainless still and can be fully submersed in oil or water. The tables feature an OTT (German) worm gear system with optional power chuck, tailstock, and additional brushes for enhanced performance.

The EdmDrill™ RT3038 is a versatile, high-capacity machine designed for complex drilling of large and heavy parts common in the aerospace, automotive, power generation and cutting tool industries.

The RT3038 features table stroke of 30 inches in X and 38 inches in Y. The longer Y axis enables the use of large rotary tables that can be installed either horizontally or vertically to drill both flat and tall parts. The standard 5 axis configuration utilizes the reliable Nikken 5AX201 tilt/rotary table which is ergonomically installed at the front of the machine for easy part loading and unloading.

The extended Z axis head allows drilling with up to 24 inch long electrodes and the included EDM Milling feature provides the capability to create 3D shapes such as diffusers and slots. Clear safety shields keeps moving parts away from operators but enable full viewing of operation. The RT3038 is the ideal EDM driller for large turbine blades and vanes, large rings and tall cutting tools.

Methods Machine Tools, Inc., a supplier of precision machine tools, automation and accessories, has introduced a FANUC-built CCR Rotary Table on its FANUC Wire EDMs, including on the RoboCut a-CiA Series.

"The new single access, easy-to-use CCR Rotary Table is available exclusively on FANUC RoboCut EDMs," said a company spokesperson. "The table provides the range of motion that manufacturers in industries such as aerospace and medical require and allows for greater speed, precision and rigidity in EDM processes."

The CCR Rotary Table is a fully integrated all stainless steel table that is capable of full "turn and burn" machining and has a water leak monitoring function that shuts the machine down upon water detection, to minimize potentially costly water-related repairs.

Completely built by FANUC in Japan, the CCR Rotary Table weighs 35.27 lbs. (16 kg) and takes up minimal space - 6.1" x 6.7" x 5.1" (155 mm x 170 mm x 130 mm) - allowing the operator to retain the full work envelope of the machine. According to the company, index accuracy is 12 seconds and repeatability accuracy is +/- 2 seconds. The table can allow up to a maximum workpiece weight of 88.2 lbs. (40 kg). Standard configuration includes a faceplate for mounting a variety of workhold chucks or fixtures.

Our Milling department is equipped Matsuura mills.  They are Japanese-built and considered one of the best mills on the market today.   We can achieve 4 axis milling via our factory equipped Nikken rotary tables.  Our mills can hold tolerances down to +/- .0001 with superior surfaces finishes due to their rigidity and spindle quality.
