STAHL Crane Systems wire rope hoists range in capacity from 500 kg to 160,000 kg. STAHL wire rope hoists have a compact, sturdy construction which is extremely low-maintenance. The reliability, power and long service life of Stahl hoists are above average. The particularly smooth, precise starting and braking characteristics are common to all. Tri-State Overhead Crane is your go-to Stahl hoist parts distributor.

The STAHL CraneSystems AS7 wire rope hoist is an innovative choice in lifting and crane technology. The low-maintenance components and modular system are appreciated by users, crane and system manufacturers.

The STAHL SH wire rope crane hoist has been the standard in lifting and crane technology around the world for years. The modular system allows for practically unlimited combinations to meet any of your lifting needs.

TSOC sells, services and provides parts for STAHL wire rope crane hoists; serving clients from coast to coast, Canada, Mexico and especially focused in Missouri, Illinois, Indiana, Iowa, Kansas, Nebraska, Arkansas, Mississippi, Tennessee, Kentucky, South Carolina, Florida, and Oklahoma.

The SH Series is a heavy-duty, compact, low maintenance wire rope hoist from STAHL. Providing load capacity ranges from 1 Ton to 15 Tons. Standard dual speed motor for smooth lifts with speed options. The STAHL SH wire rope hoist can be used by itself or together with a trolley for standard cranes. Optional short headroom monorail trolley and double girder trolley available. IP 66 protection for outdoor use without a protective roof.

Motor -Motor is located outside rope drum. The SH series has a highly efficient motor cooling, maintenance-friendly, temperature control system by ptc thermistors. IP 55 protection, thermal class F. Classified according to ISO, high duty cycle, and switching operation frequency.

Control -Robust control pendant with emergency stop palm button and control cable. All switching elements for hoist, cross, and long travel are 2-step. IP 65 protection. Additional control pendant options are available.

Wire Rope & Guide -Highly flexible, long life wire rope. Single-grooved rope drum helps guides and secures wire rope for low resistance lifts. Spheroidal graphite cast iron enclosure for wire rope and guide withstands various temperature ranges. 360° rope tensioner, helps prevent slack rope.

Overload Protection -Permanent electronic monitoring of suspended loads. Limited maximum load by load measurement at the rope anchorage for multiple reeving.

Columbus McKinnon Corp. offers NEC-approved, Class I, Division 2 explosion-protected STAHL CraneSystems brand SH Ex wire rope hoists to its advanced hoist product portfolio. The STAHL CraneSystems SH Ex wire rope hoist is available in five frame sizes with 26-load capacity variants from 1,000 lbs. to 30 tons in deck mount, monorail trolley, and double girder trolley models for use with standard, customized or special crane applications.

“Based on the SH wire rope hoist platform, the explosion-protected SH Ex models allow for wider use in applications and industries with potentially hazardous environments,” said Thomas Kraus, global product manager, wire rope hoists. “Complying with ATEX, IECEx, and now NEC standards, the SH Ex wire rope hoist offers reliable operation, high efficiency, and increased safety.”

The explosion-protected models are also available with ATEX and IECEx approvals for EX Zone 1, Zone 2, Zone 21, or Zone 22 hazardous locations. ATEX compliance, required in the European Union, certifies that the SH Ex is safe to use in potentially explosive areas with flammable gases or dust. IECEx equipment certification signifies that the SH Ex conforms to international safety standards for environments where a potential exists for explosions. The SH Ex is also available with spark-resistant features such as coated hooks, brass wheels and brass drop lugs on trolley.

STAHL CraneSystems’ wire rope hoists cover the S.W.L. range from 500 kg to 125, 000 kg. They are based on a technically mature modular system that guarantees cost-effective production at the highest level of quality. What’s special about this: we can combine the individual components at will so that each of our wire roperead more...

The STD dual chain hoist was developed specifically for long material and loads that need to be picked up at two points. It is equipped with two load chains, which are moved synchronously by a hoist motor. The hookread more...

ElectroMech is the exclusive India partner for STAHL Crane Systems, Germanys range of Explosion protected crane and crane components. Explosion protected crane technology is used in industries such as chemicals, oil & gas, paints and pharmaceuticals. STAHL Crane Systems is the pioneer for explosion-protected craneread more...

With a wide range of wire rope and chain hoists from Stahl we offer you the greatest variety of hoists in the world. That means flexibility for your logistics tasks. Every material flow requirement, however unconventional, can be solved individually and at a particularly favorable ratio of performance and cost-effectiveness.read more...

STAHL Wire Rope Hoists are designed for safe working loads upto 100, 000 kg-available as a modular system in various ratings from 320 to 100, 000 kg. with 6 frame sizes and 26 SWL variations permit practically unlimited adaptability to all customer-specific applications. In addition they have low headroom and short approachread more...

Built on over a century’s worth of experience in the design and manufacturing of cranes, STAHL provides some of the highest quality crane components available anywhere. At Overhead Crane & Conveyor Service Corp, we use STAHL brand wire rope and chain hoists in many of our installations.

STAHL wire rope hoists are capable of lifting over 350,000 lbs. and are designed for years’ of use with minimal maintenance. By focusing on every detail of the hoist, STAHL has been able to produce wire rope hoists that last far longer than the average hoist and provide exceptionally smooth operation with precise starting and braking through the lift of the hoist.

The SH wire rope hoist programme has been the embodiment of perfection in lifting and crane technology all over the world for many years. Compact, high-performing and particularly maintenance-friendly. Users, crane manufacturers and system manufacturers appreciate the modular system based on field-proven, low-maintenance components. Series manufacture of the standard components means economic advantages for you. And this combined with precise manufacture of off-standard components makes the SH wire rope hoist a widely acknowledged top quality product. The modular system permits practically...

The SH wire rope hoist The models and travel carriage variants Different types and variants of travel carriage for the SH wire rope hoist open up the most varied applications. Individually tailored to your specific requirements as stationary hoisting or towing equipment, for use with a trolley or crab, or for systems manufacture. The travel carriages are equipped as standard with two travel speeds. But in this matter too we are open to your requirements. Other speeds are available as options. Our wire rope hoists are known worldwide for their flexible and versatile use. Compact dimensions...

Cram S/stems Stationary model The SH wire rope hoist can be used as stationary hoisting or towing equipment, for example in systems manufacture. Depending on the application, the rope lead-off angle, the attachment of the hoist and the mounting position of the hoist motor can be varied. OE double rail crab The OE double rail crab is intended for use on double girder overhead travelling cranes. The extremely compact construction makes very low approach and headroom dimensions possible and the available space can thus be used to the full. The double rail crab is available with various track...

The SH wire rope hoist It’s reassuring to know what convincing technology is concealed in the SH wire rope hoist. The largely maintenance-free components of the modular wire rope hoist are optimally matched to each other. They guarantee constant performance, high efficiency and long service life. The standard safety components such as gear limit switch, motor temperature control and overload device, or even an optional additional brake, increase workplace safety. ■ Highly flexible special rope with long service life ■ Field-proven enclosed rope guide in spheroidal graphite cast iron has no...

■ Low-maintenance asbestos-free brake; needs no adjustment ■ Long service life thanks to generously dimensioned brake ■ Brake easily accessible for inspection from outside ■ Motor management ensures low wear ■ IP 65 protection ■ Special-purpose motor for hoisting applications ■ Classified according to ISO, high duty cycle and switching operation frequency ■ IP 55 protection, thermal class F ■ Motor outside rope drum, highly efficient motor cooling, maintenance-friendly ■ Temperature control by ptc thermistors ■ Optimised ratio of drum to sheave diameter ensures low wear on rope ■ Flexible...

The SH wire rope hoist There’s always room for improvement. Although it is already first-class in standard design, you have the alternative of making your SH wire rope hoist even safer, even more cost-effective, even more convenient by selecting from numerous mechanical, electrical and electronic options. As a welcome side-effect, the service life of the wire rope hoists is prolonged. The extensions to the programme increase the performance of the wire rope hoist and adapt it to your individual requirements. Here we show you some examples of the options available. If you need further...

■ Continuous load monitoring by overload cut-off even if hoist is at a standstill ■ Overload protection with ALC automatic load control ■ Load spectrum memory for load-related operating time summation ■ Operating data registration, e.g. operating hours, load spectrum, motor switching operations and load cycles ■ Data exchange with PC possible ■ Travel limit switches on trolley/crab for cross travel, optional ■ Limiting for both directions of travel ■ Switchover from "fast/slow" (predisconnect) ■ Switch contacts designed for control current ■ IP 66 protection ■ SLD four-digit 7-segment load...

The SH wire rope hoist | The options ■ The brake release device permits the hoist brake to be released manually and thus the load to be lowered during a power cut. ■ As an option, every hoist can be equipped with this supplementary equipment to the standard brake. ■ Redundant brake system provides increased safety ■ Intercept and holding brake, prevents the load falling even if the gear should break ■ Control is effected with a centrifugal switch or safety PLC Frequency control ■ Smooth starting and braking characteristics ■ Load swing greatly reduced ■ Fast, precise positioning of the...

The SH wire rope hoist Engineering means innovation and individuality. Constantly redefining the lifting and transporting of loads for complex requirements even in explosive areas is a job for our experts. Drawing on one of the widest product ranges of standard components, they regularly develop modern, individual off-standard and customised solutions. Hardly any other manufacturer of lifting and crane technology can offer you this diversity of precisely designed top quality customised solutions with maximum cost-effectiveness. The SH wire rope hoist programme forms the basis for a wide...

Example 1 TDC Twin Drive Concept The TDC Twin Drive Concept TDC is the uncompromising solution for hoists complying with DIN EN 14492-2, Annex B. Hoists in TDC design are intended for transport of molten metals and for use in high-risk applications: acids, alkalis, gases or transport over gas and acid pipelines. They are equipped as standard with two motor-gear units. Both motors are always synchronously controlled. The brakes mounted on the two motors are designed so that in an emergency each one is capable of braking or holding the load by itself. The two brakes are activated in...

The STAHL CraneSystems brand stands for reliable and safe hoists and crane components as well as methodical engineering solutions. The products are used in standard, special and explosion-protected bridge cranes or hoisting systems in industries such as automotive, oil and gas, power station construction, chemical industry, transport and logistics, steel and concrete industry, food industry, mechanical and plant engineering, air and road transport industry as well as in the pharmaceutical and food industry. STAHL CraneSystems is a globally recognized brand for explosion-protected crane technology and comprises one of the most extensive, seamless product portfolios. Customers include crane builders, machine/plant manufacturers as well as planning and general contractors all over the world.

Stahl are a German based manufacturer that has been operating in the lifting industry since 1876. Producing industrial strength wire rope and chain hoists as well as crane components for the global market. Ranked among the leading manufacturers of hoisting technology Stahl are at the forefront of the market when it comes to supplying an efficient, powerful and economical solution. For more bespoke applications Stahl employ global teams of experts ready to design and manufacture specialist equipment such as ATEX explosion proof hoists, ultra low headroom configurations, dual hook systems and many more.

The Stahl (400volt) ST chain hoist is a classic simple powered chain hoist model, trusted by thousands, Stahl is one of the market leaders for hoisting equipment, obviously, there are positive reasons for this; high quality build, design with ergonomics in mind, swift ability to deliver parts overnight when required. There are many more reasons why people choose Stahl, find out yours when you purchase a Stahl hoist from Lifting Equipment Store.

Stahl ST Electric Chain Hoists are brightly colored for safety purposes (in classic standard Stahl green and black). Lightweight and compact, this easy-to-install hoist can be up and running in just a few moments. Most units come complete with a chain box for storing slack load chain when the load is being hoisted upwards towards the unit. The low voltage pendant control sits lightly in the hand and is simple and efficient to operate making this hoist unit a pleasure to use.

You should choose your desired specification from the drop-down menus. Choose your desired mounting: Lug, Hook, Manual Trolley or Powered Trolley in single or twin-speed. Choose your lifting height from 3m to 10m (for larger please call) and then sit back, relax and wait for your brand new German-made (shipped from the UK) Stahl Electric Chain Hoist to be delivered to your door!

Buyer Beware:There are a number of Electric Chain Hoists being sold on the market (some are even using household electronics names) that look very convincing based on aesthetics and price. Be advised that if you are using a hoist in an industrial environment then you should only consider one suitable for such arduous environments like the Stahl ST model (and any other European branded models offered by LES). Just because the hoist conforms to an EU/British standard and ticks the "price" box does not guarantee value or a European origin. When you purchase a Stahl ST, we guarantee great value and long service life when used in the correct manner. These hoists are proudly manufactured by Stahl Cranesystems in Germany. Yes, these hoists are a little more expensive than a far-eastern import, however- as the old saying goes- "Buy it once".

Don"t believe us? Watch the video in the tab above titled "Video". Still not sure? Give our Electric Chain Hoist experts a call today and they"ll walk you through the journey step-by-step from choosing the correct hoist to getting you the best deal on the market and delivered in record times to meet your next deadline and exceed your expectations.

When used in industrial applications Stahl ST Hoists are frequently fitted with a selection of different suspension or mounting types offering static up/down lifting or horizontal traverse (left/right) via their integrated beam trolleys- available in a manual or powered configuration. We always recommend powered travel trolleys when lifting over 1tonne- this is because large loads can be difficult to move, and once they start moving they can be difficult to stop- thanks to the Stahl powered trolley this is made easy.

German designed equipment from one of the industries leading manufacturers, Stahl Cranes offer a range of Electric hoists, Overhead Cranes, Jib Cranes and spares to suit. Stahl are well known for their reliability and competitive pricing. Cranes-UK work very closely with Stahl Cranes and can provide some of the best offers on all types of new and used Stahl Cranes and Hoists.
