wire rope 7 x 19 made in china

The main items including AISI 304 and AISI 316 stainless steel wire rope 1x19,7x7 and 7x19. Our products have a good reputation due to strict quality control, mature production technology and stable quality.

Product Description : As outer strands of the rope go through crimping wheels, the strand becomes thicker – metal cross sectional area increases, strand form becomes smoother, and round.

We can do customized sample, can supply sample within 5 days if have in stock, around 10-30 days for customized sample. Sample fee and express fee will be returned once your order reach to 1 ton.

1)Meaning: 7 strands each consisting of 19single wires. All wires in all strands have the same or similar dia. IWRC is independend wire rope core. FC is fiber core.

7x7 construction is a medium flexible wire rope ideal for rigging applications where some flexiblity is needed. It is a strong, medium flexible cable commonly used for lifelines, fencing, and safety railings. There are 7 strands and each strand contains 7 individual wires for medium flexibility.

7x19 construction has excellent flexibility commonly used with winch lines, garage door cable, exercise equipment, fencing, and safety railings. The flexible construction includes 7 strands with 19 wires per strand.

*Although 7x19 is typically referred to as "aircraft cable", it is not intended for for aircraft use unless actual ARICRAFT GRADE is specified and purchased.*

The galvanized finish provides medium resistance to corrosion, though not as much corrosion resistance as stainless steel wire rope. The trade-off is that galvanized wire rope has a greater breaking strength than stainless steel wire rope.

Hilifting is the leading stainless steel wire ropes supplier in china, our ss wire ropes are ompliment with other stainless steel wire rope end fittings in applications for cable railing, architectural cables, cable balustrading, cable display systems, and cable trellis.

6×19 construction wire rope is available with either FC (fibre core) or WSC (wire strand core). When supplied with a wsc the rope is more commonly referred to as 7×19. The rope is very popular in diameters from 3mm to 16mm and is used on a variety of applications. 6×19 FC and 6×19 WSC (7×19) is very flexible in diameters 3mm to 6mm and is used for many requirements where wire ropes are running over pulleys. 7×19 construction is readily available in both galvanised and marine grade stainless steel.

Galvanized steel wire ropes are made of fine Carbon Steel Wire , There are Hot dip galvanized and Electric Galvanized wire rope, The galvanized wire ropes have higher tensile strength and better oxidation resistance than ungalvanized.

CIVMATS produces high quality stainless steel wire rope. Our annual production capacity is roughly 8000 tons, among which stainless steel wire rope amounts to 400 tons per month. The tolerance of our stainless steel wire rope can be as small as ±0.01mm. CIVMATS produces strictly according to ISO9001:2000. Every product delivered from CIVMATS is a reputation warranty.

Wire rope can be divided into multi-strand wire rope and single-strand wire rope. It is structured with at least two layers of steel wire or a plurality of strands spirally wound around a center or a core. Stainless steel wire rope refers to a steel wire rope made of stainless steel. In dynamic systems, stainless steel wire ropes are widely applied in the lifting of cranes and elevators, the transmission of mechanical power, the control of automobile cockpit poles and the operation of aircraft control systems, etc. In static systems, stainless steel wire ropes are also employed in various industries such as the stability of the sling bridge"s pulling support tower and the design of new railings.

Stainless steel wire rope features high temperature resistance, good fatigue resistance, excellent breaking force, long service life and durability. It is widely used in coal, petroleum, metallurgy, chemical industry, shipbuilding, bridge, electric power, rubber, military, tourism, water conservancy and light industry. The products can be produced according to ISO, BS, DIN, JIS, ABS, LR and other international and foreign advanced standards

In CIVMATS, all of our stainless steel wire ropes are packaged as per international standard to prevent any possible damage or loss. They are neatly wrapped in accurate length with securely tied rope ends. For enhanced customer experience, we also provide dedicated package as per your special requirements.

Our main grades for stainless steel wire rope are 304 and 316. We can also customize stainless steel wire rope as per your specified grades and sizes for your reference.

1. Point contact: The adjacent stainless steel wires contact in the form of point in the strands. The diameters of all the stainless steel wires, excluding the central wire are equal, and the strands are formed by layering.

2. Line contact: There is a linear contact between the adjacent layers of stainless steel wire in the strand, and the strands are made of stainless steel wires of different diameters in one process.

4. Point and line contact: There are two kinds of contact forms between the adjacent layers of stainless steel wires in the strand. The strands are made of wires of different diameters.

1. In the equipment reform of chemical, fertilizer, chemical fiber and other industries, stainless steel wire rope was used for the deployment of the updated equipment.

2. Stainless steel wire ropes are used in the applications of popular stainless steel welding rods and a considerable number of stainless steel components, springs, connecting parts, etc.,

5. Stainless steel wire ropes are also extensively used in railway electrification, decoration industry, rigging industry, fishing gear industry, automobile and motorcycle industry and other industries.

This kind of 7X19 Stainless Steel Wire Rope is made up of 7 steel wires and then 19 strands are twisted into a Stainless Steel Wire Rope. Totally 133 filaments are twisted together, thus this 7X19 Stainless Steel Wire Rope has good toughness. It has high tensile strength and yield strength, low cold work hardening rate, good cold forming performance. In addition, it also has the advantages of corrosion resistance, high temperature resistance, good mechanical properties, and no rust. The 7X19 Stainless Steel Wire Rope is widely used in the construction industry, it wins a good reputation among our customers all over the world.

7X19 Stainless Steel Wire Rope is made from 316 marine grade or aircraft stainless steel. The cables are more flexible than 1X19, 7X7, 7X19 strands ropes. It has sizes of 1.2, 2, 3, 4, 5, 6, 8, 10, 12, 16, 18, 20, 22mm. 7X19 wire rope has 7 strands with 19 wires per strand. It’s widely used for marine, industrial, architectural applications.
