wire rope for railings price

Complete cable railing assembly kits are available and include everything you need (angled railings may require additional hardware) for installation. All of our assemblies are available in 1/8", 3/16", and 1/4" diameters of stainless steel type 316 wire cable. The 1x19 construction creates a semi-rigid feel with minimal stretch. It can be used for most railing applications as it can be safely bent up to 45°. A 7x7 construction is available for more decorative uses where the ability to bend greater than 45° is needed. All of our cable rail systems can be machine swaged or hand swaged.

Cable railing cost will vary depending on size and style and installation method. Machine swage systems require more exact cable measurements when ordering, but do not require a swaging tool for installation. Hand swage systems offer more flexibility because exact cuts are made during installation.

We suggest choosing an assembly that includes a turnbuckle, as it will allow you to easily tension the cable if it begins to sag over time. Although it is not structurally necessary for cable runs less than 28", including a turnbuckle in your assembly can also increase your cable span allowance to up to 50". Adding an additional turnbuckle can increase your run span even more.

For corners, it is recommended to terminate the cable and start a new run at the change in direction. Experienced contractors will sometimes set up continuous runs around corners, however this impacts the allowable cable span. If you choose to run a cable around a corner, the maximum angle is generally 45° for 1x19 cable to preserve the integrity of the cable, and can be achieved by using a two post corner.

Configuring the location of your end and intermediate posts is the first step in configuring your cable railing system design. This is necessary in order to determine your cable length, number of cables and assemblies, and any additional hardware necessary for attaching to the post, rounding corners, and accommodating angled runs. We recommend installing posts prior to gathering cable measurements.

End posts in stainless steel cable railings are located at each starting and stopping point for each cable run. The distance between the starting end post and the terminating end post is considered one cable span. Typically, end posts for deck cable railing is placed at least 3"- 4" away from the house or wall to allow access for attaching cable end fittings. Corner posts commonly refer to the post located at each change in direction. A complete assembly (end fitting, cable, and if applicable, a turnbuckle) is needed for each cable span.

The end and corner posts in cable deck railing systems must be strong enough to support the tension of the cable assemblies (typically 350 lbs. per cable assembly). Our wire railing systems will work with wood or metal posts. Composite posts are not recommended as they can warp when the cables are tightened.

Requirements for rail height and horizontal cable spacing will determine the number of cables and assemblies needed for each span of your cable rail system. Typically, the rail height must be a minimum of 36" from the surface for residential uses and 42" for commercial uses. Stair or grip cable handrail may have different requirements. Most codes recommend horizontal cable to be spaced no more than 4"on center apart. Spacing should be targeted at 3" in order to meet a 4" code for wire deck railing. Construction codes will vary between city and county.

While end fittings for a stainless cable railing is selected primarily based on style, consideration should be given to how the fitting will attach to the post. The three most common attachment methods include: face mount, through mount and tab/eye mount.

Tensioning steel cable railing is critical during the initial set up and adjustments may be needed overtime as the cable may stretch. Generally, cable railing for decks, stairs, etc. is recommended to be tensioned at 350 lbs. in order to maintain the integrity of the railing and to meet standard code. For shorter runs, a threaded terminal will also allow you to tension the cable when needed.

Choosing cable railings for decks, platforms, stairways and docks will vary depending on the size and scope of your project. Because there are so many variables, we ask that you call and speak to one of our cable railing supplies specialists to order your assemblies. This will ensure you order the correct wire deck railing and hardware for your needs.

wire rope for railings price

Brand new: Lowest priceThe lowest-priced brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable).Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag.See details for additional description.

Amadget Stainless Steel Wire Rope, 316 Marine Grade Cable Railing Kit, Aircraft Wire Rope & Picture Hanging Kit for Railing, Decking, DIY Balustrade, Boat Marine Hardware (1/16" x 33 Feet). 【STRONG CABLE】 Marine Grade 316 Stainless Steel has the highest corrosion protection, durable, stable, anti-fatigue, weather resistance, heat resistance, corrosion resistance.

wire rope for railings price

Rainier cable railing is part of the AGS Stainless Clearview® line of stainless steel railing systems which are well-revered throughout the industry, and can be accompanied with wide array of top rail options for a fully-customized look. AGS will create CAD drawings specifically for your custom railing system.

Atlantis Rail Systems offers a complete line of stainless steel cable railing systems. This innovative collection of low maintenance railings offers unobstructed views capable of fitting any indoor or outdoor, commercial or residential design. Cable hardware can be surface mounted using a turnbuckle style compression fitting or through-posted using hand swage fittings.

is a manufacture of glass railing systems, including welded or non-welded components. Standard railings are designed for tempered glass and can include a combination of stainless steel, aluminum, brass or wood components including caps and sub-rails. Commercial, industrial or residential, complex or simple.

Durarail aluminum component railing system for new construction or remodeling. Available in several rail profiles and several powder coated stock or custom colors, Durarail is designed for fast and versatile installation to fit any deck configuration. It is available in view-through tempered glass and traditional picket designs meeting all national building codes. CAD, BIM, Specs, Product Data and Evaluation Reports are all available on our website.

Excell aluminum railings are an engineered railing system that meets IBC International Building Code requirements for spacing and loading. Our durable cable railing systems are constructed of powder-coated aluminum stainless steel fasteners cleverly hidden within the posts, with cables available in 3 sizes. Ideal for interior or exterior applications and residential or commercial projects.

Fortress® is at the front line of railing design with our vertical and horizontal steel cable railing systems. Virtually maintenance-free and easy to install with pre-assembled railing panels, choosing Fortress means unobstructed views with less hassle or up-keep. Backed by a 15-year warranty.

is the worldwide leader in manufacturing custom-made AISI 316 stainless steel wire rope, nets, rods, fasteners and fittings. We strive to combine the aesthetic sense of the architect with the structural requests of the contractor and engineer, which allows us to offer an incredibly broad product range.

Trex Commercial Products is a leading national provider of both pre-engineered and custom commercial railing systems. Our highly versatile cable railing systems are suitable for corporate offices, healthcare facilities, education buildings, sports facilities and retail based developments to name a few. Visit our website for downloadable railing product data sheets, specifications, CAD files and photos.

4specs Discussion Forum- Great place to ask questions about specifications, products and technical data. Free - no registration required to read or post (subject to moderation).

Seco South is the leader in stainless steel cable systems for balustrade infill. Now we provide complete cable railing systems in stainless steel, carbon steel or aluminum for any residential or commercial building project. Our systems are completely mechanical and require no welding. We provide design assistance, engineering, CAD details, approval drawings and installation nationwide.

wire rope for railings price

The cost of cable railing installed by a contractor is $60 to $165 per linear foot based on the materials used for posts, the number of cable rails and the complexity of the deck itself.

The average cost of cable railing professionally installed is about $135 per linear foot. The breakdown is roughly $100 per foot for the most common materials and $30 per foot for installation labor, which includes installing the materials and getting the permit. If old railing is removed and disposed of by the contractor, additional costs will come into play.

Cable railing gives any deck a contemporary profile with minimal obstruction. But it comes at a higher price than most other options like aluminum or similar like metal and cast iron railings. The cost of cable deck railing is only exceeded by glass railing prices.

This cable railing price guide discusses cost factors to help you consider which materials fit your budget. A list of retail costs and a comparison of cable railing price based on what materials are used for posts and rails. Composite railings are a very popular choice and keep the modern look and appeal, when matched with cable runners. There’s a place for homeowners to submit their costs providing real-life prices for other readers. Consider bookmarking this page of Costimates and return to share your project prices with others.

Cost estimates for cable deck railing vary widely, and most sites underestimate price. Deck Cost Guide pegs the price at $40-$60 per linear foot, but you’d have to use the cheapest materials and install them yourself into existing posts to get close to that cost. Even Home Advisor, a typically reliable site, offers a narrow cost range of $60 to $135, definitely on the low side of what homeowners are paying for cable deck rail systems.

Many homeowners install cable into existing wood posts when refurbishing or repairing an old deck. Whether you’re repairing an existing deck or constructing a new one, here are cable railing cost comparisons for materials.

$60 – $90 per linear foot | Aluminum Cable Railing Kits – they are an affordable choice for homeowners willing to assemble them. DesignRail kits by Feeney are a popular example.

$30 – $150 | A permit including an inspection is required for any deck with a railing. Deck size and where you live determines exact cost of the deck permit.

Here’s what DIY cable deck railing installation will save you. The low end is for decks with predrilled wood and metal posts, while time/costs go up if wood posts must be drilled onsite.

wire rope for railings price

This listing is about T316 Stainless Steel Wire Rope. As a high-quality product with 1 x 19 construction, it features a stainless steel structure and 2100 lbs bearing capacity. Widely used in outdoor and indoor activities, such as clothesline, stair cable railing, garden fence, shipbuilding, etc. An excellent assistant in your daily life!
