First and foremost, you should consider the desired pressure rating that you need for your application. You will want to review the job with your engineering team and field service personnel to help determine the appropriate pressure output that is needed for your hydraulic equipment.

Manual pumps typically come in two pressure ranges: a low-pressure range and a high-pressure range. Low pressure pumps are rated for 10,000 psi or lower and are used to supply hydraulic pressure to a variety of hydraulic tooling. High pressurehydraulicpumps can reach operational pressures of up to 40,000 psi and are commonly used for dilation during the installation or removal of a keyless tapered coupling hub.

Air driven pumps can be preset to a desired maximum pressure rating at the factory, and traditionally have a maximum operational pressure of 22,000 – 40,000 psi.Air operated hydraulic pumpsare commonly used for tensioning bolts and nuts during the installation of compressors and other machinery.

There will be times where you will find yourself in need of a varying supply of hydraulic pressure to your equipment or tooling in order to finish a job. Determining the type of supply that is needed will help you select the appropriate pump for the job.

One of the main differences between a manual pump and an air driven pump is the quantity of hydraulic pressure that is supplied to your tooling or equipment.

A Riverhawk hydraulic pusher mated with a low-pressure pump allows the operator to accurately install the coupling to the desired position along the tapered shaft while maintaining control of the hydraulic pressure feeding to the pusher tool.

Anair powered hydraulic pumpconstantly supplies a set amount of hydraulic pressure so long as the pump is actuated. This makes the pump ideal for operating multiple pieces of equipment at once without requiring constant mechanical input from the operator. An example of this would be the installation of a casing on a compressor.

The casing requires multiple studs and nuts be properly and evenly tightened, which can be difficult to achieve through mechanical torquing methods. By utilizing an air driven pump and multiple Riverhawk hydraulic nuts daisy-chained in succession, hydraulic pressure is applied evenly to each of the nuts. This allows for even load distribution to each of the studs, thus eliminating the concerns of excessive or erratic bolt loads.

Riverhawk is committed to providing electronic accessibility to all individuals under the Americans with Disabilities Act (ADA.) If you need assistance accessing information on our website, please utilize the “Accessibility Menu” at the top of the screen. If you need further assistance, please contact our HR Department at (315) 768-4855 or email us at hr@riverhawk.com and we will work with you to provide the information, item or transaction you seek through a communication method that is accessible for you.

Riverhawk is committed to providing electronic accessibility to all individuals under the Americans with Disabilities Act (ADA.) If you need assistance accessing information on our website, please utilize the “Accessibility Menu” at the top of the screen. If you need further assistance, please contact our HR Department at (315) 768-4855 or email us at hr@riverhawk.com and we will work with you to provide the information, item or transaction you seek through a communication method that is accessible for you.

Riverhawk is committed to providing electronic accessibility to all individuals under the Americans with Disabilities Act (ADA.) If you need assistance accessing information on our website, please utilize the “Accessibility Menu” at the top of the screen. If you need further assistance, please contact our HR Department at (315) 768-4855 or email us at hr@riverhawk.com and we will work with you to provide the information, item or transaction you seek through a communication method that is accessible for you.

What is the Riverhawk “HRT” Hydraulic Rod Tensioner System? The Riverhawk Hydraulic Rod Tensioner (HRT) (Figure 1) system is a compact, two-part tensioning device that can be readily retrofitted to existing studs and restricted footprints. The Hydraulic Rod Tensioner does …

Riverhawk engineers have been working to develop new coating options that will enhance durability and further extend the life of our metal seals used in our high-pressure hydraulic nuts. A hydraulic nut is a device designed to replace large diameter …

The Riverhawk Hydraulic Crosshead Nut is a hydraulic nut designed for long-service life.  A hydraulic nut provides a quick, efficient method of producing and retaining high clamping forces (preload) in the crosshead joint.  This is accomplished by connecting a hose …

Let’s start this discussion by introducing a term used in hydraulic bolt tensioning called elastic recovery, or more commonly just called relaxation; which is the difference between force applied by a hydraulic bolt tensioner and the residual preload left in …

Riverhawk has announced that the Hydraulic Shrink Disc is now an acceptable alternative to traditional shaft end connections as defined in the newest release of the American Petroleum Institute standard 671(API STD 671).

Hydraulic pump kits are sometimes overlooked as a critical component of maintenance and repair. Learn about the two types most commonly associated with our industry.

Measuring torque in a rotating shaft can be done in a variety of ways. Riverhawk has been producing a strain gage based torque measuring system since the late 1970’s (formerly known as Indikon).

For many years Riverhawk, has provided hydraulic hub installation kits. These kits include but are not limited to: hydraulic pushers, pullers, pump kits and fittings.

HET’s are tools that apply hydraulic preloads to studs by gripping the exposed threads above an existing nut. It does this by creating axial loads using hydraulic pressure to stretch the stud rather than torqueing the nut.

The Riverhawk Hydraulic Torque Coupler (HTC) provides high integrity keyless fit joints for coupling hubs on shaft ends using convenient, low cost slip-fit designs.

Riverhawk has a large installed customer base of 500 Series Vibration Monitoring Systems. To better provide continued support to that base and address new opportunities, Riverhawk is developing a new vibration monitoring system designated as the 500N Series. The updated …

Riverhawk has designed the Manual Hydraulic Pump Kit as a comprehensive solution with two pumps and the associated gauges installed on a welded sledge. The kit, furthermore, comes with all the necessary adapters, fittings and hoses.

The hoses supplied with the hydraulic pump kit feature six layers of wound steel pressure support, a nylon outer cover as well as swivel fittings at both ends and Derlin inner liner.

Designed to be a complete solution, our kits come standard with two pumps and fitted with gauges, appropriate fittings, adapters and hoses. To learn more about these and the rest of our Hydraulic Pump Kit line, Click here:http://riverhawk.com/hydraulic-pump-kits-accessories/…
