Hydraulic Pumps are one of the most important parts of a hydraulic system. International Fluid Power, Inc. offers of full line of pressure loaded fixed displacement hydraulic gear pumps to meet your needs. Pump displacement ranges from .16cc to 89cc. Standard SAE AA, A, or B mounts with keyed or splined shaft offerings. Straight gear, helical gear, or incline gear styles are available to help meet any noise reduction requirements you may encounter. Aluminum body with cast iron mount and cap are standard. Hi-Lo pumps are also included in our offering.

Brevini Fluid Power is a leading manufacturer of hydraulic components in Italy and Europe. Its headquarters is located in Reggio Emilia, Italy and has direct subsidiaries in Italy, France, England, The Netherlands, Germany, Romania, China, India, Singapore and the USA.

Dynamic Fluid Components, Inc. is an ISO 9001:2008 quality certified company offering a full range of hydraulic products and supported by a full service test and repair facility. Dynamic Fluid Components, Inc. product offerings include, fixed displacement hydraulic gear pumps, including a dual stage HI/LO pump, low speed high torques hydraulic motors, flow control valves, check valves, pressure gauges, pressure switches and hydraulic pressure test points and diagnostic testing kits.

Brevini Fluid Power is a leading manufacturer of hydraulic components in Italy and Europe. Its headquarters is located in Reggio Emilia, Italy and has direct subsidiaries in Italy, France, England, The Netherlands, Germany, Romania, China, India, Singapore and the USA.

For many years FluiDyne has provided our customers with professional and competitive services and products. Our Promise is to serve and respect the distributors and resellers of North America and the global market with high quality new and remanufactured pumps, motors, valves, filters and filter elements.

1.5PE Series Aluminium Gear Pump, 0.57 cu in/rev, 2-Bolt SAE AA Mounting Flange, 1/2 St. Keyed x 1.06 long SAE AA Shaft, SAE -10 Side Inlet, SAE -8 Side Outlet, CW Rotation

These are high-quality Vivolo Italian-made hydraulic gear pumps. Hydraulics demands extremely fine tolerances & quality materials. Vivolo has been producing hydraulic items for over 30 years. We offer a 12-month warranty These are interchangeable with much more expensive hydraulic pumps such as Casapa. These come with Clockwise rotation as a standard, but we can supply as counterclockwise. Please contact us for this option.

If you are unsure about identifying your pump, please clean & send a photo of numbers & letters stamped in the housing of all pumps. We may be able to interpret this for you

The flange of this model has a diameter of 50,8 mm. The rotation verse of the pump is clockwise or counterclockwise and you can reverse it without having to add any components* to optimize storage space and adapt the product to your needs. Please refer to page 22 of this catalogue for instructions on changing the rotation verse.

At OneHydraulics, we aim for 100% customer satisfaction on every order. If you are not completely satisfied with your order, please contact us right away so we can make it right.

Items purchased on onehydraulics.comwith inventory from our Houstonlocation can be returned within 30 days from the date it was shipped. Items purchased that come from our manufacturer"s stock may be subject to restocking fees as determined by our manufacturers. Before returning any products, please verify with OneHydraulics if a restock fee is required for the product return.

Any item custom manufactured for a customer’s application,including winches and other made-to-order products, may be non-cancellable and non-returnable. OneHydraulics will not accept returns on those items for any reason. If you may need to return a product you are ordering, please verify if it may be returned prior to ordering.

All items must be returned in NEW condition, in the original packaging. We will not accept items that have been used or purchased from another company. All returns are subject to a restocking fee and shipping fees are non-refundable. If a return is required as a result of an error made by OneHydraulics (e.g., shipping an incorrect item, etc.), the abovementioned fees may not apply. Please contact your sales person or emailsales@onehydraulics.comso we can fix any errors relating to your order immediately.

Please see our Terms and Conditions relating to warranty claims. Prior to shipping an item back to OneHydraulics, you must first obtain a Return Goods Authorization (RGA) form and number. All returns must be shipped prepaid, with the RGA number clearly marked on the outside of the shipping carton. All items must be packaged properly to prevent damage upon shipping back to OneHydraulics. Failure to do so may result in a rejection of the return. Following our inspection, you will be notified of the product’s disposition and charges, if any. Products returned for factory warranty issues must be accompanied by a report explaining the non-performance or failure of the returned part. Please contact OneHydraulics prior to shipping back any item relating to a warranty issue, as those items may need to ship back to the factory directly.

Any item labeled ‘Final Sale’ on the website is non-cancellable and non-returnable. Any item custom manufactured for a customer’s application is non-cancellable and non-returnable. OneHydraulics will not accept returns on those items for any reason.

Anfield gear pumps are rugged and highly reliable making it an ideal choice for a wide range of applications. Anfield gear pumps feature a floating bushing design with bodies made of high strength cold extruded aluminum which can withstand pressures of over 4000 psi. Anfield Gear pumps are offered in various models featuring all-aluminum body, aluminum body with cast iron end caps and also available in all cast iron construction. SAE flange and porting styles are standard ISO and DIN styles are also available along with a wide range of shaft and port combinations.

Lovejoy Hydraulics Pump / Motor Mounts help power unit designers and fabricators simplify their Power Unit designs. The Pump / Motor Mount, commonly called the “Bell Housing”, allows direct mounting of flange mount pumps to NEMA “C-Face electric motors. This eliminates the need for coupling guards, foot brackets, shims, risers, and motor mounting plates, and assures accurate shaft alignment.

The ease of assembly reduces power unit fabrication costs. Lovejoy precision machines each cast aluminum alloy pump/motor mounts to 0.003 inch concentric from the motor pilot to the pump pilot, and the mounting faces parallel to each other and perpendicular to the pilot Centerline within 0.002 inch. This assures accurate shaft alignment, which prolongs bearing, seal and coupling life. This also helps to reduce noise and vibration in the power unit.

Lovejoy Hydraulics Cast Aluminum Pump / Motor Mounts are cast from a lightweight, high strength aluminum alloy. For safety, a molded OSHA orange coupling access cover is included for mounts larger than the 56C motor frame size.

Should you have a problem finding a Lovejoy Hydraulics distributorin your area, please contact a Lovejoy sales representative or ask your current Lovejoy Power Transmission distributorto start carrying and supporting the new products!

For many years the only standardization on pump and motor shafts and mounting flanges had been the SAE (Society of Automotive Engineers) Standard J744a. It was widely accepted by other industries as well as the automotive and is still a valid standard. The NFPA (National Fluid Power Association) started work in 1962 on a set of standards which would more directly apply to industrial fluid power pumps and motors, and would be more complete. This set of standards was unanimously approved by the NFPA Board of Directors and issued in 1965 as NFPA Recommended Standard T3.9.65.1. In 1966 it was also adopted by the ANSI (American National Standards Institute) and issued as B93.6-1966. It has since been revised and now carries the numbers ANSI B93.6-1972 and NFPA T3.9.2 R1. Copies are available from the NFPA.

The purpose of the standard is to encourage manufacturers to use interchangeable dimensions on both mounting flanges and shafts as far as possible to simplify dimensional interchangeability. No standards presently exist for foot mounting dimensions. No performance specifications exist although recommended methods of testing pumps and motors and the manner of presenting test data are given in NFPA Recommended Standard T3.9.17-1971.

The new NFPA and ANSI standards are similar to the SAE standards but differ in these respects: Additional shaft diameters and an alternative long length shaft have been added to the straight-shaft-without-thread listings. Additional mounting flange sizes have been added to provide a wider selection for the designer. NFPA has not assigned any horsepower ratings, making it the responsibility of the pump designer. However, the SAE horsepower ratings are shown for mounting flanges.
