gardner denver 5x6 mud pump for sale made in china

Manufactured 1998, 1602 hours, 4" plungers with hydraulic charge pump, Detroit Series 50 (rebuilt), 5 speed, Skid mounted with fuel tank, Rebuilt expendables with seals, valves, seats, packings and gaskets.  Price:  $72,500

Complete without traction motors.  9” bore x 15” stroke, single acting, working pressure up to 7500 psi, (3) interchangeable forged steel fluid end modules with separate suction and discharge sections, Premium grade fluid end expendables with 6-1/2” pistons and liners, suction manifold with (3) 12” flanged inlets, SD8 suction desurger, pressure manifold with (2) 5-1/8” 10,000# API flanged outlets, liner wash system, 1 x 1-1/2” mission centrifugal pump p/b 3 hp electric motor, external power end lubrication pump, steel skid, suction line pressure relief valve, set of standard service tools  Price:  $675,000

CENTERLINE 7-1/2 X 10 MUD PUMP(Ref#14556Tb)  high pressure, no engine, needs retaining liner cage and (1) side suction manifold needs replacing, unmounted  Price:  $39,500

3 available in India. 1600 HP, rated pump speed 140 strokes per minute, maximum fluid cylinder liner bore 6-3/4", stroke 10", 10,000 PSI hydrostatic pressure of standard cylinder. 2.853 ratio of gears. 10" suction connection, 6" discharge connection. Valve pot mod .7., steel fluid ends, 5,000 psi pulsation dampener. Oilfield skid mounted. Performance Data: at 120 strokes per minute with 6-3/4" liners, pump will produce 4305 PSI and 574gpm. Set up for electric power. Dimensions and weight: 84,000 lbs, 209"L x 113"W x 75"H. Built 1976. Located India, removed from offshore drilling rig. Price: $75,000 each

approx. 7000 hours, Cat 3512C (1476 hp), 5000 psi fluid end cylinder, 5-1/2" piston cylinder, antifreeze heaters, WPT W21-CG-300 Type 1 PTO clutch, 16 grooove drive sheave, 16 groove bullwheel, 16 groove Kevlar belt with necessary guards, 5 x 6 x 11 charge pump c/w 50 hp@1200 rpm electric motor.  Discharge plumbing: 2" 5M XXH B/W Oteco gate valve, 4" 5M XXH b/w Oteco gate valve, 3" 5M Oteco popoff valve w/1502 connection, 2" 5M type D Oteco mud gauge with 1502 connection, Hydril 20 gal 5M pulsation damper.  Mounted on oilfield skid with separate, with expendables cabinet, knowledge box and removable engine skid for breaking the engine and pump into separate smaller loads.  Winterization package, oilfield lighting, explosion proof starters for charge pump, rod oiler pump and liner wash pumps.  Price:  $695,000 - Make Offer

Two Available, each complete with Cat 3508 diesel engines, pulsation dampener, and mud tanks with desander, desilter, etc.  Price for Package:  $110,000

Cat 3408 engine air start with pump drive and belt guard, PD55 Hydril dampener, 750 gallon fuel tank, mounted on heavy duty drop deck tandem trailer,  low hours  Price:  $87,500

14" stroke, 2" rod size, 400 hp, 75 strokes per minute, cast fluid ends, unitized on oilfield skid with Cat 3406 diesel engines, air start, new filters, oil and coolant, air receiver on deck, fluorescent lighting, drive belts with air clutch.  Gone over and in good operating condition, ready to be put into service.  Pumps currently have new 6" liners with production being 480 gpm @ 1000 psi.  All fluid end parts are brand new and never used, including the valves, gears, liners, pistons, rods, head gasket, and rod packing, equipped with pulsation dampener.  32" long x 11" wide x 7" high 50,000# weight

GARDNER DENVER TEE MUD PUMP(Ref#6440T)  New, unused, manufactured 2014, 4 available, bare pumps  Price:  $39,500 each  New Cat C7 engines available at additional cost

Pump only.  5" stroke, 300 hp, steel billet fluid end, 2-3/4" ceramic plungers, Delrim disc valves, 838 packing, 6" RF suction connection, 3" RTJ discharge connection, 231 gpm max, 2020 psi, max 360 rpm  Price:  $82,500

Two available, rebuilt, cast ductile iron fluid ends, used for oil service, bare pumps, no engines, unmounted, one is flanged for suction/discharge, one is threaded  Price:  $20,000 each

Cummins 150 hp reconditioned engine with snap-in clutch, 90 gal diesel tank with lock cap, Dayton oiler pump system and tank, 4” suction hose and winch boom, 4’ back up drill pipe bumper guard, front and rear loading hitches, epoxy primer and enamel paint, 44” bull wheel with power band belt, large belt guard Price: $82,500

Detroit 671 engine with Snap-In clutch (Gen Set approx. 1500 hours),  replaced fluid end parts with 4” liners,  mounted on 8’ x 12’ trailer with adjustable pintle and DOT lighting, 75 gal diesel tank with lock cap, Dayton oiler pump system and tank, 4” suction hose and winch boom, epoxy primer and enamel paint, 44” bull wheel with power band belt, large belt guard, 2’ x 2’ x 5’ lockable HD toolbox, mouting beams and steel/bolts  Price:  $41,500

Air driven, used with cement for grouting wells, sitting 3-4 years, valves will need rebuilding, trailer mounted, air over hydraulic brakes, includes 28 joints of 21’ pipe  Price:  $39,500

8" x 17" base (mud boat), John Deere 145 hp reconditioned engine with WPI snap in clutch, 90 gal diesel tank, Dayton oiler pump system and tank, 4" suction hose and winch boom, 4" backup drill pipe bumper guard, front and rear loading hitches, 42" bull wheel with power band belt, belt guard  Price:  $99,000 PRICE REDUCED:  $73,500

Cat engines, 4 speed transmissions, rigged up with secondary containment, onboard lighting, winterization canvas for cold weather operations, Also available with Cummins or John Deere engines Priced from $77,500 to $97,500

379 Cat didsel engine, Matco hi pressure forged steel fluid end, quick change valve heads, Hydril dampener, brand new expendables sill in box  Price:  $59,500

750 hp, 8" stroke, 6" suction inlet, 4" discharge outlet, piston size 4-1/2" - 7",  max rod load 85,000#, approx. weight 11,500#, lubrication force fed, steel pump power end, double helical gears, 4.95:1 gear ratio, rod bearings sheel type replaceable, main bearings straight roler, pinion bearings spherical roller, crankshaft 1pc forged alloy steel, connecting rod knuckle joint, crosshead guide bronze replaceable, piston type fluid end Monoblock design, from high strength alloy steel, treated and sonic tested, Cat D379 diesel engine, 500 HP max linear bore size 3-1/2 - 6-1/4 x 7-3/4" stroke, test pressure 10,000 psi, gear ratio 2.742.8" suction line to 4 discharge stroke, location South America  Price:  $110,000

Two available, Skidded, Detroit Series 60 diesel engine DDEC V (475 hp), Allison 750 (6-speed) transmission with lock up control pane, Mission 4 x 5 centrifugal suction pump, 4” plungers, pulsation dampener, pressure gauge, safety valve, 10,000 psi fluid end, 5000 psi working pressure, NOV plug valve control manifold (4-valve) configured for 15k operation.  Can be configured to kill wells, acidize, cement, reverse circulate, drill out frac plugs or run in tandem.  Self-contained with fuel and fluid tanks and controls.  Steel canopy over skids, covered battery boxes, new batteries and disconnect switches.  Well maintained and in excellent condition.  Low hours on pumps and motors.  Ready to work.  Price:  $154,500 each

1600 hp, 12" stroke, 5000 psi, pulsation dampeners, pop off pressure release valve, pump pressure gauge, forged discharge manifold, overhead track for chain hoist, mounted on shipping skid, line washer pump, 6" liners, overall size:  192 x 128 x 105-3/4", inspection report available  Price:  $137,500

14 liter Detroit Diesel, 6061 Allison automatic transmission, rebuilt power end, new expendables in fluid end, new charge pump, skid, tanks, Pilfer 5 valve manifold, 15k fluid end, new paint  Price:  $215,000

Manufactured 1999, 1000 gal holding tank, (2) 3 x 4 Mission Magnum pumps with mechanical seals, MC255-2C mud cleaner, sand guzzler, Versa-drill rig jacks, Perkisn engine, spare hyd pump and filters, well maintained, ready to work  Price:  $59,500PRICE REDUCED: $49,500

Mounted on 12K GVRW trailer, hydraulic powered spool with approximately 500 of 2” hose, internally routed power and safety cable, 7.5 HP pump and motor, Whisper Watt 25kva 3-phase diesel generator with approx. 3100 hours  Price:  $45,000

Preferred Pump offers the best rewards program in the water well equipment industry. Check out our social media pictures to see what you"ve been missing!

A wide variety of gardner denver mud pumps options are available to you, such as 1 year, not available and 3 years.You can also choose from new, gardner denver mud pumps,as well as from energy & mining, construction works , and machinery repair shops gardner denver mud pumps, and whether gardner denver mud pumps is 1.5 years, 6 months, or unavailable.

This website is using a security service to protect itself from online attacks. The action you just performed triggered the security solution. There are several actions that could trigger this block including submitting a certain word or phrase, a SQL command or malformed data.

This website is using a security service to protect itself from online attacks. The action you just performed triggered the security solution. There are several actions that could trigger this block including submitting a certain word or phrase, a SQL command or malformed data.

We stock fluid end parts for the5×6 mud pump, 5×6-1/4 FM45 mud pump, 5×8 mud pump, 5-1/2×8 mud pump, 5X10 mud pump, 4-1/2×5 mud pump, 7-1/2×8 mud pump, and 7-1/2X10 mud pump.  The Gardner Denver mud pump model numbers for the above pumps are as follows: 5X6-FGFXG, 5X8-FDFXX, 5-1/2X8-FDFXX, 5X10-FDFXD, 4-1/2X5-FFFXF, 7-1/2X8-FYFXX, 7-1/2X10-FYFXD.  We also handle Wheatley, Gaso, Worthington, Failing and Centerline parts and pumps. We also stock Foot Valve, Liner Puller, Valve Seat Puller, (4″ Inline Check Valve.  Our Gardner Denver mud pump parts are not only competitively priced, they are also made in the USA.  Oil Recommended by Gardner Denver.  Call any of our experienced representatives to get the help and knowledge you deserve.
