The P600 is a stand-alone, self-powered pump packed with the GPM needed to always keep you moving. This versatile machine is compatible with any drill brand and made with an innovative engine enclosure that reduces jobsite dBs. With this ultra-quiet operation and an ideal footprint, the P600 dominates jobs of all shapes and sizes.

American Augers mud pumps are standardstand-alone, self-powered machines thatare the perfect accessories to use with mudmotors, large reamers or whenever moremud volume is needed down hole.* Optional Quiet Pak for optimum noise reduction controlP-600 and P-750 Mud Pumps• allow the operator to get enoughflow to keep the bore flushed cleanof cuttings• are designed with a compact skidmounting and provide a smallfootprint that are ideal for mostdrilling environments.• are compatible with any drill brandmaking them suitable for contractorsoperating a variety of sizes, makesand models of drilling equipment.www.AmericanAugers.com

P-600Mud PumpTypical Flow Rates for Popular Size Mud MotorsBe sure to allow enough extra mud flow to flood the boreMUD MOTOR SIZEFLOW RATE/MINUTEInches Millimeters U.S. Gallons Liters3 3/8 85.72 30 - 120 113.6 - 454.23 1/2 88.9 75 - 160 283.9 - 605.74 3/4 120.6 100 - 250 378.5 - 946.46 3/4 171.4 300 - 600 1,136 - 2,271

What Type of Contractor Should Use aMud Pump?• Users of drilling equipment withpumping capacities of 25 U.S.Gallons (95 L)/minute or largerregardless of soil type or conditions.• Drillers typically making bores thatare greater than 6 1/2 in. (165 mm)diameter and more than 200 ft.(61 m) long.• Owners of mud motors for rockdrilling applications.• Operators in areas where muddisposal is expensive or restricted.Both the P-600 and the P-750should be considered when workingin rock formations where the operatingdrill"s on-board mud pump has fluidlimitedcapacities and cannot produceenough pressure to drive the mud motor.www.AmericanAugers.com

MUD MOTOR SIZEP-750Mud PumpTypical Flow Rates for Popular Size Mud MotorsBe sure to allow enough extra mud flow to flood the boreFLOW RATE/MINUTEInches Millimeters U.S. Gallons Liters3 3/8 85.72 30 - 120 113.6 - 454.23 1/2 88.9 75 - 160 283.9 - 605.74 3/4 120.6 100 - 250 378.5 - 946.46 3/4 171.4 300 - 600 1,136 - 2,2718 203.2 400 - 900 1,514 - 3,407

P-600PERFORMANCE SPECIFICATIONSPower TrainEngine:Caterpillar ® C-15 Tier III Diesel* Tier III or Tier 4i determined by country of purchaseFuel Capacity: 300 U.S. Gallons (1,136 L)Rating:475 HP (354 kW)Transmission: Eaton-FRO-16210B, 10 speedMaximum Speed: 2100 RPMClutch:15 1 /2 in. (394 mm) twin diskNoise Rating: 1 meter distance 104 dB(A)3 meter distance 95 dB(A)Battery:(2) Deka 908DMF 12V, 1450 CCAPumpPump Design:Maximum Pressure:Rated Capacity:Bore x Stroke:Tri-Plex 600GPM1,505 psi (104 bar)600 U.S. Gallons* (2,067 L)/minute6 x 6 in. (152.4 x 152.4 mm)* Note: Pump capacity will vary depending on the overall mud weight,drilling fluid mixture/content and working elevationControlsRemote Controls:Instruments:Mud pump throttle, Mud pump start/stop,clutch actuator, horn remoteDigital mud flow meter (gallons/liters per minute)DimensionsLength: 20 ft. (6.096 m)Height: 9 ft. (2.7 m)Width: 8 ft. (2.49 m)WeightTotal Weight:29,800 lbs. (13,520 kg) estimated39,600 lbs. (17,962 kg) with sound enclosureAccessoriesPulsation dampener on inlet and discharge(2) 25 ft. (7.6 m) suction hoses with 6 in. (152.4 mm)kamlock fittings(2) 25 ft. (7.6 m) discharge hoses with 3 in. (76.2 mm)NPT hammer unionsLiner wash system with supply tank(2) 24 volt work lights* Note: All product performance specifications,components, weights, dimensions and otherrelated information is subject to change withoutnotice from the manufacturer.

P-750PERFORMANCE SPECIFICATIONSPower TrainEngine:Caterpillar ® C-18 Tier III Diesel* Tier III or Tier 4i determined by country of purchaseFuel Capacity: 300 U.S. Gallons (1,136 L)Rating:600 HP (447 kW)Transmission: Eaton-RTLO-22918B, 10 speedMaximum Speed: 2100 RPMClutch:15 1 /2 in. (394 mm) twin diskNoise Rating: 1 meter distance 104 dB(A)3 meter distance 95 dB(A)Battery:(2) Deka 908DMF 12V, 1450 CCAPumpPump Design:Maximum Pressure:Rated Capacity:Bore x Stroke:Quintiplex, piston and liner1,500 psi (103 bar)750 U.S. Gallons* (2,839 L)/minute5 1 /2 x 7 7 /8 in. (139.7 x 200 mm)* Note: Pump capacity will vary depending on the overall mud weight,drilling fluid mixture/content and working elevationControlsRemote Controls:Instruments:Mud pump throttle, Mud pump start/stop,clutch actuator, horn remoteDigital mud flow meter (gallons/liters per minute)DimensionsLength: 25 ft. 6 in. (7.8 m)Height: 10 ft. 3 in. (3.12 m)Width: 8 ft. (2.49 m)WeightTotal Weight:47,800 lbs. (21,680 kg)AccessoriesPulsation dampener on inlet and discharge(2) 25 ft. (7.6 m) suction hoses with 6 in. (152.4 mm)kamlock fittings4 in. (102 mm) NPT hammer union discharge connectionLiner wash system with supply tank(2) 24 volt work lights* Note: All product performance specifications,components, weights, dimensions and otherrelated information is subject to change withoutnotice from the manufacturer.

AMERICAN AUGERSThe American Augers line of underground construction equipment is second-to-none.• Auger Boring Machines• Maxi-Rig & Mid-Size Directional Drills• Oil & Gas Drilling Rigs• Mud Pump & Cleaning Systems• Product Tooling & AccessoriesAmerican Augers products are manufactured at the company’s 241,000 square-foot facility in West Salem, Ohio,in the heart of Amish country between Columbus and Cleveland.Since the founding of American Augers in 1970, there has never been a change in the company’s core value:having products developed by a can-do work force that focuses on mechanical, technological and customer-baseddesign improvements. Our goal is to always exceed customer expectations by providing products that are not acost of doing business, but an Investment in Success.Did You Know? American Augers was the first HDD manufacturer to eliminate chain and utilize a rack andpinion carriage design which is now the industry standard. Our rack and pinion drive provides smoother carriagemovement, more precise operating control, long system life and no complicated parts.American Augers machines are supported through a dedicated parts and technical service department. We are hereto help whenever you need us 24 hours a day, 7 days a week, emergency or not.www.AmericanAugers.comEnvironmental CommitmentAmerican Augers is committed to manufacturing equipment that helps to preserve the sanctity of the globalenvironment, and has done so by reducing noise and/or emissions outputs, and emphasizing the fact that ourtrenchless technology equipment requires little or no open cutting, which has very minimal impacts on naturalsurfaces, features, or habitats.1212

Mud motors offer the proven way to get acceptable penetration rates when drilling in hard formations and rock. The mud pump has to supply the mud motor, but also has to flush the cuttings to the surface for disposal. The table below shows typical flow rates for popular size mud motors. Be sure to allow enough extra mud flow to flood the bore. American Auger’s mud pumps can be used with any brand or size of a directional drill.

One 2014 model Kem Tron Tango 1500 Mud System. This new unit boasts the Hyper and Shaker systems that provide the most efficient shaker systems on the market today. These systems are isomounted and provide for very quiet operation, as well as dynamic cleaning capacity.

One 2012 model Kem Tron Tango 1000 Mud System. Same basic design as the Tango 1500 Unit, but it only holds 7,500 gallons and cleans 1,000 G.P.M. instead of holding 10,000 gallons and cleaning 1,500 G.P.M. likes its big brother does.

Our drilling division operates a fleet of drilling rigs including three rotary drills, two cable tool rigs and an auger rig. The rotary drills are capable of drilling up to 24 inch diameter using dual rotation, mud or air rotary techniques. Our cable tool rigs are used for drilling large diameter production wells under difficult down hole conditions and as work-over rigs for well rehabilitation, casing perforation and pulling large pumps. The auger rig is equipped with angle capabilities and has the torque and flexibility to turn 8 inch and 12 inch diameter hollow-stem augers, solid augers, mud or air rotary roller bits, rotary wash wire-line coring, and a variety of geologic sampling tools. The auger rig is primarily used for geotechnical studies and environmental investigations. Our range of drilling expertise includes; large and small diameter production wells for domestic uses, industry, agriculture and municipal clients with pumping capacities up to 2,800 feet deep and exceeding 5,000 gallons per minute. We have installed monitoring wells from 10 feet to over 1,000 feet under safety levels B, C and D protocols. Our experience and capabilities also include mineral exploration, geothermal wells in excess of 2,000 feet, cathodic protection installations along natural gas pipelines, well repair, rehabilitation, abandonment and down hole videos. Our pump division maintains three pump service trucks to provide full service and supply of water systems including pumps, water softeners and water treatment systems for all uses including environmental remediation systems. Our pump rig operators are all licensed for specialty plumbing and electrical installations. To support and augment the drilling and pump service operations we maintain large assemblages of air compressors, mud pumps, fluid handling systems, service trucks and transport vehicles. Our mechanical fabrication and machine shop is used to keep the equipment in top running form and to manufacture specialty tools as needed to complete projects in nearly any environment. Hiddleston Drilling & Pump Company is a long established firm with the professional staff and equipment necessary to successfully complete your project. If you have any questions or would like more information on our capabilities, equipment, project references or to discuss your special drilling needs do not hesitate to contact us.

Bean 35 Mud Pump, Tooling For Auger Work And Diamond Core To 2000", Injection Pump, Low Hours, 71 XXX Miles On Carrier. Mounted On 76 International 4X4.

3L8 Moyno Mud Pump, (2) Winches, Toolboxes, Auger Rack, Hyd. Leveling Jacks, Electric Over Hyd. Controls, Deck Mtd. Hyd. Drive 2,000 PSI Steam Cleaner / Power Washer. Mounted On 90 International 4 X 2 w/ DT466 185 HP. Good Condition.

3L8 Moyno Mud Pump, Cummins Diesel Deck Engine. Tandem Axle, (4) Hydraulic Leveling Jacks, (2) Winch Lines, Breakout Wrench, Side Port Swivel, Angle Drilling Attachments, (2) Swivel Auger Racks Mounted On The Rig, Drillers Stand, Sliding Drawworks, (Side To Side Also Back & Forward), Mounted On 89 Kodiak 70 Series, w/ 3208 Cat Diesel. Good More Info »

PTO, No Deck Engine. 1500 Gallon Water Tank, 3" Bowie Loading Pump, Heated Pump Box & Water Tank, Jake Brake, A/C. Mounted On 89 Ford 9000, w/ 3306 Cat. Excellent Condition.

Bean Mud Pump, 6 Cyl. Ford Deck Engine. One Owner Rig, (3) Hyd. Jacks, Hyd. Safety Hammer, (3) Winches, In/Out & Side/Side Slide Base, 45" Of 6 1/4" HS Auger, 100" Of NW Rod. Mounted On 1986 Ford 8000, w/ 3208 Cat. Good Condition.

3L6 Moyno Mud Pump, PTO, NO Deck Engine. (3) Hyd. Jacks, Safety Driver Hoist, Pullmaster Main Hoist, Auger Rack. Mounted On 1986 Muskeg Bombardier. Good Condition.

4 Cyl. Ford Deck Engine. Auto Hammer, 3L6 Moyno Pump, In/Out Slide Base, (2) Winches, 200 Gallon Water Tank, Front Hyd. Winch, (3) Leveling Jacks, Mounted On Yanmar C-60R, w/ Diesel.

3L8 Moyno Mud Pump. Breakout Table And Breakout Wrench, Auto Hammer (Replaced 2016), (4) Winches, Wireline 1800#, Main Winch 7000#, High Speed Aux 1800#, Low Speed Aux 3200#, 12250 Hours, Professionally Refurbished In 2013, 2250 Hours Since Refurbished, Mounted On ATV Carrier, w/ 4BT Cummins Turbo Diesel. Good Condition.

Deutz 5 Cyl. Diesel Deck Engine. One Owner Rig, Cathead, 10K LB. Main Winch, 4,000 Lb. Aux. Winch, 3L6 Moyno Pump, 500 Gallon Water Tank, 4,688 Hours On Deck Engine Rebuild, 161, 914 Miles On Truck, Mounted On 1990 Ford F800 4 x 2. Good Condition.

Duetz 57HP Diesel Deck Engine, 18" Mast, Angle Drill Capabilities, In-Out And Side To Side Slide Base, 435 Bean Pump, 140 Lb. Auto Hammer, 3,200 Lb. Main Hoist, (1) Wire Line, Recovery Winch, (3) Hyd. Leveling Jacks, (2) Side Tool Boxes, (3) Rod Racks, Front Auger Rack, Approx. 444 Hours, New Engine Installed In 2015, More Info »

3L6 Moyno Mud Pump. Safety Driver Winch, Cathead, Aux Winch, Main Winch, (3) 36”Jacks With Controls In The Drivers Area, Ready To Work, Mounted On ATV Carrier, w/ 4BT Cummins. Good Condition.

Cummins Deck Engine. Breakout Wrench, 3L8 Moyno Water Pump, Wiggle Tail, Wireline Winch, Hyd. Leveling Jacks, Mounted On 1992 Ford Single Axle, w/ Diesel.

Deutz 4 Cyl. Diesel Deck Engine, Rebuilt 4 1/2 X 5 Gardner Denver Mud Pump W/ Reinforcement Plates For Mounting, Automatic Hammer, Automatic Hammer Calibration Done In 2019, (3) Leveling Jacks, (2) Winches, Can Add A Third Winch, New WRM Top Feed Swivel 2JW, U-Joint For Augers 1-5/8 HEX, Extruder For Shelby Tubes Samples, New More Info »

6 Cyl. Ford Deck Engine, Moyno Pump, Water Tank, (2) Auger Racks, 6-5/8" & 4-1/4" 50" Each Augers, Includes Side Port Swivel And 3 1/2" Air Hammer. Auger / Air / Mud Drilling. Well Maintained, Mounted On Ford 8000, w/ Cat Diesel. Good Condition.

Kohler Gas, Three Speed W/ Two Speed For Coring, Moyno Pump , Cathead, One Winch, Has Wheels To Move On Hard Surface And Skids Can Be Bolted To Drag Machine.
