Crown Oilfield Instrumentation’s mud pressure gauges are extremely accurate and widely used in the harshest drilling environments. Each of our mud pressure systems are designed to meet or exceed API specifications, and you can count on a Crown mud pump pressure gauges to stand up to whatever the oil and gas industry can throw at them.  Our mud pressure systems monitor the pump pressure for a variety of pumps and applications to ensure that you are getting the most out of your drilling fluids. Our single pointer systems use a 6" aluminum cast gauge to detect the slightest pressure changes and come with three different sensors: diaphragm gauge protector, 1:1 piston separator and 4:1 debooster gauge protector. The  Crown compound pointer system uses  unique pointer design that affords the reader to see the smallest pressure changes at a glance. Crown"s unitized pressure gauges are gauge and protector in one and can be mounted on a standpipe and seen up to 60 ft. away. Crown’s pressure gauges are designed, developed and tested to be durable, reliable and dependable, and all systems can stand up to the rigors of the oilfield. Manufactured in the US, you can depend on our pressure gauge systems to provide years of service.

Mud pressure gauges are extremely accurate pressure measuring devices, designed to operate in harsh working environments. Mud pressure gauges operates even at a high temperature of 120°C and a vibration range up to 15 Hz. They are mostly used in the drilling, mining, petroleum and chemical industries. The mud pressure gauge are used for the measurement of static mud pressure.

Mud pressure gauges are of critical importance to the drilling process. They allow the driller to observe the pressure while drilling on land or offshore drilling rigs. At the time of drilling, it is the pressure that indicates the problems downhole, such as if the pressure is too low, it may indicate worn pump packing or liners, broken drill strings or loose joints, washed-out pipe orbit nozzles or lost returns due to formation breakdown and if the pressure is too high, it may indicate an increase in mud density or viscosity or a plugged drill bit.

Reliable pressure information from mud pressure gauges provides an early warning of the upcoming problems, enabling the driller to make corrections and thus avoid major problems.

Mud pressure gauges can withstand high vibration and high-pressure pulsations. The built-in dampening in mud pressure gauges minimizes the gauge fluctuations and their liquid-filled gauge arrangement minimizes vibration and wear to gauge movement so that even minor pressures can be seen and recorded accurately.
