mud pump stroke sensor manufacturer

The Magneto® Pump Stroke Sensor is the latest new product from ASD Holdings (Advanced Sensor Design). ASD has successfully introduced unique products for the Oil & Gas Industry for over a decade. In this newest creation we find that the Magneto® Pump Stroke Sensor has been patented by Advanced Sensor Design. It is the world’s first pump stroke sensor that is mounted to the outside housing of the rig pump. It is mounted and stays in place by the use of a heavy duty magnet. The Magneto PSS is completely capable of detecting and counting Oil Rig “mud pump piston strokes” without having to make or be in contact with the pistons.

It is no longer a requirement to open the covers of the Oil Rig mud pumps to install a C-clamp style micro switch with a metal whisker. (Note picture below labeled C-clamp style micro switch) No longer is it necessary to bore a hole through the pump housing in order to get a proximity switch close enough to a piston to count actual strokes. (Note picture below labeled Cable going through pump housing) The Magneto® Pump Stroke Sensor is simple to install and easy to monitor!

The magnetic base of the Magneto® PSS makes it totally different than anything available in the marketplace today relative to its form and fit. However, that is not its only outstanding feature. Advanced Sensor Design is using “State of the Art” electronic circuitry that has the ability to give the end user (Oil Rig Mud Pump Operator) an On/Off switch type electrical output. Just like what the conventional mud pump sensors emit today. The obvious benefit to the oil rig is that No Special accommodations to their Data Acquisition Systems are required.

IML-BC11 pump impulse sensor is an inductive proximity switch type sensor, which is used to measure the pump impulse or rotary speed. It has the characteristics of wide voltage range, high precision of repeated positioning, fast frequency response, long service life, vibration resistance, corrosion resistance, water resistance, etc. The bracket adopts galvanizing process, the distance of sensor is easy to adjust, and the direction of change fixation can be adjusted by 90 °.

The pump impact sensor can be fixed in a proper position with a bracket, and the closest distance between the sensing surface of the tested object and the end face of the sensor can be adjusted to be within 15mm (generally 80% of the rated action distance is taken in consideration of the impact of the use environment). Turn on the working voltage, when the sensor is close to the end face of the sensor, the indicator light will be on; when it is far away from the sensor, the indicator light will be off.

1.The pumping sensor can be fixed to the mud pump head by the bracket, or the appropriate part of the turntable, and the closest distance between the position of the sensing surface of the measured object and the end surface of the sensor is within 30 mm. (According to the influence of the use environment, the rated working distance is generally taken. 80%), plus the working voltage, when the end of the inductive sports sensor is close, the indicator light is on; when away from the sensor, the indicator is off.

2.The turntable speed sensor can be fixed to the appropriate part of the drive shaft of the turntable with the bracket. It should be convenient to install and repair. The model of the drill is selected. A piece of iron with a length and width of 30mm is welded on the shaft of the drive shaft or the airbag clutch. The position of the end face should be close to the end face of the sensor. Adjust the fixing nut of the sensor so that the distance between the iron sensor is within the effective range of the working distance.

The Two-pump Digital Stroke Rate Meter monitors and displays the Rate and Total Strokes of up to two individual pumps simultaneously. The unit continually displays, on large easy to read, low power LCD displays, RPM, TOTAL ACCUMULATED STROKES (0-9999 total strokes) and STROKE RATE (8-350 strokes per minute) for each pump. The unit is internally powered by a battery source having an operational life of 3 years.

At Matherne Instrumentation, we"re proud to provide both our two-pump and three-pump stroke counters to companies and oilfield operators across the states of Texas, Louisiana, North Dakota, and Pennsylvania. While our offices are based in Odessa, TX; Lafayette, LA; and Houma, LA, we"re proud to serve those across the cities of Midland, TX; Houston, TX; Williston, ND; and Pittsburgh, PA. To learn more or for a quote, please feel free to give us a call today!

The RIGCHINA Pump Stroke Counter/Rate Meter displays both the total number of strokes and the strokes per minute for 3 mud pumps up to 1,024 strokes per minute for each pump. Push buttons conveniently located on the front of the instrument make it easy for the operator to reset each pump count

The HDI 2100 Pump Stroke Counter is an intrinsically safe, certified, solid-state electronic stroke counter primarily used for monitoring mud pumps. Found most commonly within the HDI 9000 Choke Console System, the HDI 2100 monitors and displays the total accumulated mud pump strokes and the stroke rate of up to 4 individual mud pumps simultaneously. The stroke rate for each mud pump can be individually selected for display and is updated every second. Once installed, there is virtually no maintenance or calibration required. The quartz crystal oscillator provides high precision counts with no drift. The stainless steel case is completely sealed and features stainless steel piezo switches for long life. The entire package is constructed to operate in harsh environments and high vibration conditions encountered in land and offshore drilling. All HDI Gauges provide safety, accuracy, reliability, and low maintenance for the user.

The market is evolving to better and smarter sensors, which can gather more detailed data in order to improve safety, efficiency and geological precision of the well. A big issue now, is that companies have difficulty in measuring the exact amount of drilling fluids (mud) going into and out of the well.

Hohner Automation is based in Wrexham and since 1980, has been making optical encoders to automate general machinery but over the years, have specialised in encoders for the oil and gas industry. Their main customer base now is mud logging companies where they manufacture fully certified rig instrumentation and sensors for mud logging.

The aim of this project is to develop an innovative new sensor for counting mud pump strokes and also monitoring position, speed and efficiency of individual strokes.

This project would see a significant increase in R&D activity for the business and if successful, could result in increased sales and new jobs. Hohner Automation already has an existing route to market/client base and potential of successful commercialisation is high. The market is very large with around 2,000 drilling rigs active in the world and each of these, has several mud pumps.

The SK-8Y2X series alloy film sensor consists of an ion-beam sputtering alloy film sensor and a signal modulation circuit and is applicable to detection of fluid pressure, differential pressure or liquid level. The Sensor is made using the modern film equipment and etching technique. The sensor has unique technique and excellent performance and can stably run in severe environment. The liquid medium pressure/differential pressure acts on the corrosion resistant stainless steel elastic film to deform the film, as shown in the strain schematic diagram. An alloy film strain resistance comprising Wheatstone bridge has been made on the film. Film deformation changes the geometry and value of the resistance, and the bridge outputs corresponding electrical signals. The electronic circuit amplifies the bridge output signals and converts them into standard 4~20mA current signals for output.

Acadiana Pump Stroke Counter or Rate Meter Displaying both the total number of strokes and the strokes per minute for two or three mud pumps (up to 1,024 strokes per min per pump), the  Acadiana Oilfield Instruments’ pump stroke counter has easy to use push buttons for resetting the pump count. Built-in a stainless steel design, this indicator will last in any environment.

Our firm aims to operating faithfully, serving to all of our shoppers , and working in new technology and new machine consistently for Mud Pump Stroke Counter Sensor, , , , With a rapid advancement and our buyers come from Europe, United States, Africa and everywhere in the world. Welcome to visit our manufacturing unit and welcome your order, for further more inquires be sure to don"t hesitate to get hold of us!

Our pump stroke counter systems (CPS101 Series) measure the stroke rate and number of strokes on mud pumps. The oilfield pump stroke system is user-friendly and reliable and is configurable to measure up to three mud pumps at once. Our digital pump stroke counter systems are manufactured here in the U.S. by Crown Oilfield Instrumentation, and Crown’s Pump Stroke Counter provides easy monitoring of strokes per minute on multiple mud pumps. Each mud pumps’s stroke rate can be selected individually and the display is updated regularly for accurate monitoring. LCD displays indicate both pumps strokes per minute and the total number of strokes. Located at the bottom of the panel, push buttons provide easy operation and reseting of each pump. When you need to accurately monitor and maintain the amount of mud being pumped, you can trust Crown’s oilfield stroke counters.

Monitors and displays the total accumulated mud pump strokes and the stroke rate of up to 4 individual mud pumps simultaneously. Constructed to operate in harsh environments and high vibration, conditions encountered in land and offshore drilling.

Monitors and displays the total accumulated mud pump strokes and the stroke rate of up to 4 individual mud pumps simultaneously. Constructed to operate ...

IRIS RMS is an on-board integrated riser instrumentation system for drilling risers. IRIS RMS integrates sensors with finite element software as well as providing measured data used to predict ...

Monitors and displays the total accumulated mud pump strokes and the stroke rate of up to 4 individual mud pumps simultaneously. Constructed to operate ...

US-based MicroSilicon is an early-stage startup focused on developing advanced micro-sensors for industrial process monitoring. The company"s product Electron Paramagnetic Resonance (EPR) spectrometer can monitor and analyze the chemical contents of hydrocarbon fluids in real-time. The company uses IOT solutions to provide real-time analytics and alerts to improve operational efficiency and productivity.

Rheidiant has developed connected solution for real-time monitoring of pipeline infrastructure for leaks and other factors. The solution consists of wireless nodes that are compatible with range of sensors, these nodes pick up data from sensors and detect loss of integrity before damage is done. The collected data from cloud is available to user through web or smartphone application. Claims to have received "Most Promising energy and Clean Tech Venture Award".

EnsMax has developed an IoT-based solution for real-time gas monitoring, flame detection and gas sampling in various industries. The solution developed by the company includes wireless and wired sensors developed using carbon-nanotube (CNT), that can detect toxic & combustible gases such as hydrogen sulfide, methane, propane, sulphur dioxide, carbon monoxide, natural gas, ammonia etc. The company also offers a cloud-based platform that can be used to collect and analyse the sensor data and generate reports and create alerts.

Geovox Security is a provider of an Avian (Advanced Vehicle Interrogation And Notification System) heartbeat detector. It detects the presence of persons hidden in vehicle and building using the seismic sensors that are placed on the vehicle, It reads the shock wave generated by the beating heart.

Ziel has developed a wearable device that can be used for identifying harmful pitching in baseball. The arm sleeve like device uses muscle sensors and motion sensors for analysing the hand movement and indentifying harmful pitching. The device can be used for detecting stress-related injuries in any repetitive physical activity. As of Sept 2017 the company has not launched the device.

Advanced Sensor Design manufactures pump stroke sensors for the oil and gas industry. It is mounted and stays in place by using a heavy-duty magnet. The pump stroke sensor is used for detecting and counting oil rig mud pump piston strokes without having to make contact with the pistons. Other offerings of the company include mud flow transmitter, pressure strap, and hook load transducer.

Babbitt International provides level sensors for measuring the level of liquids in an enterprise. These sensors are available in 3 varieties - Level Gauge Sensors, Multi-point sensors and Ultrasonic sensors. The former 2 categories are used for measuring the level of the liquid on contact and the latter one is used to measure and transmit the signal without any contact. The sensors are used across multiple industries, such as Oil&Gas, Dry Bulk Solids, Power Plant and Liquid Process Control.

Houston Radar is a manufacturer of doppler and FMCW radars to measure and track car speed, distance, count and classification for the traffic management and safety industry. The product portfolio of the company includes a wide range of radar data collectors, radar displays, sensors, and software.

Katy Instruments manufactures sensors for current measurement. Its products include RMS current sensors, split-core current sensors, current switches, and accessories including signal interface module. The sensors are encased in metal which allows RFI rejection and improves accuracy. The sensors can accommodate AC currents up to 1500 Amps and temperature ranges from -25°C to 85°C. The sensors have application in multiple industries including electronics and electrical industry.
