Woven by Rachel SnackWeave two overshot patterns with the same threading using this downloadable weave draft to guide you. This pattern features the original draft along with one pattern variation. Some yarns shown in the draft are available to purchase in our shop: 8/2 cotton, wool singles, 8/4 cotton (comparable to the 8/4 linen shown).

please note: this .pdf does not explain how to read a weaving draft, how to interpret the draft onto the loom, or the nuances of the overshot structure.

This project was really popular when I posted it on Instagram, so I thought I would share it here also. It is a simple overshot pattern - with a twist. Also a great way to show off some special yarn. The yarn I used for my pattern was a skein of hand spun camel/silk blend. I wove the fabric on my Jack loom but you could also use your four or eight shaft loom.

Overshot is a weave structure where the weft threads jump over several warp threads at once, a supplementary weft creating patterns over a plain weave base. Overshot gained popularity in the turn of the 19th century (although its origins are a few hundred years earlier than that!). Coverlets (bed covers) were woven in Overshot with a cotton (or linen) plain weave base and a wool supplementary weft for the pattern. The plain weave base gave structure and durability and the woollen pattern thread gave warmth and colour/design. Designs were basic geometric designs that were handed down in families and as it was woven on a four shaft loom the Overshot patterns were accessible to many. In theory if you removed all the pattern threads form your Overshot you would have a structurally sound piece of plain weave fabric.

I was first drawn to Overshot many years ago when I saw what looked to me like "fragments" of Overshot in Sharon Aldermans "Mastering Weave Structures".

I wanted to use my handspun - but I only had a 100gms skein, I wanted to maximise the amount of fabric I could get using the 100gms. I thought about all the drafts I could use that would show off the weft and settled on overshot because this showcases the pattern yarn very nicely. I decided to weave it “fragmented” so I could make my handspun yarn go further. I chose a honeysuckle draft.

Overshot: The earliest coverlets were woven using an overshot weave. There is a ground cloth of plain weave linen or cotton with a supplementary pattern weft, usually of dyed wool, added to create a geometric pattern based on simple combinations of blocks. The weaver creates the pattern by raising and lowering the pattern weft with treadles to create vibrant, reversible geometric patterns. Overshot coverlets could be woven domestically by men or women on simple four-shaft looms, and the craft persists to this day.

Summer-and-Winter: This structure is a type of overshot with strict rules about supplementary pattern weft float distances. The weft yarns float over no more than two warp yarns. This creates a denser fabric with a tighter weave. Summer-and-Winter is so named because one side of the coverlet features more wool than the other, thus giving the coverlet a summer side and a winter side. This structure may be an American invention. Its origins are somewhat mysterious, but it seems to have evolved out of a British weaving tradition.

Multi-harness/Star and Diamond: This group of coverlets is characterized not by the structure but by the intricacy of patterning. Usually executed in overshot, Beiderwand, or geometric double cloth, these coverlets were made almost all made in Eastern Pennsylvania by professional weavers on looms with between twelve and twenty-six shafts.

America’s earliest coverlets were woven in New England, usually in overshot patterns and by women working collectively to produce textiles for their own homes and for sale locally. Laurel Thatcher Ulrich’s book, Age of Homespun examines this pre-Revolutionary economy in which women shared labor, raw materials, and textile equipment to supplement family incomes. As the nineteenth century approached and textile mills emerged first in New England, new groups of European immigrant weavers would arrive in New England before moving westward to cheaper available land and spread industrialization to America’s rural interior.

Southern coverlets almost always tended to be woven in overshot patterns. Traditional hand-weaving also survived longest in the South. Southern Appalachian women were still weaving overshot coverlets at the turn of the twentieth century. These women and their coverlets helped in inspire a wave of Settlement Schools and mail-order cottage industries throughout the Southern Appalachian region, inspiring and contributing to Colonial Revival design and the Handicraft Revival. Before the Civil War, enslaved labor was often used in the production of Southern coverlets, both to grow and process the raw materials, and to transform those materials into a finished product.

Overshot is the most American and most Canadian of weave structures. I’m not saying that the U.S. and Canada are the only countries that can claim overshot or that they invented the structure. What I am saying is that weavers north and south took the overshot drafts brought over from Europe and made them their own.

To understand the reason for overshot’s popularity, you need to understand the weavers of pre-Industrial Revolution America and Canada. With the exception of those who worked on luxury, specialized fabrics, most weavers made household linens. The cloth needed to be strong and serviceable, and there was little room for experimentation or creativity—except, of course, for coverlets. Coverlets were functional items, but they also served the purpose of decoration. So, weavers of coverlets were free to play at the loom—and play they did.

The reason that weavers loved overshot then is much the same reason that many of us love it now—it’s a simple structure that produces complex patterning on just 4 shafts. With overshot, you can create circles, stars, flowers, and more. It’s also easy to take a draft and adjust it to create seemingly endless variations, which is exactly what happened during the 1700s and beyond. Household weavers would riff on drafts to create new designs, give them names, and then share the drafts with other weavers near and far.

In fact, you can find more delightful stories and names in Hall’s book, which is available for free here. The book, which contains a wealth of information on traditional coverlets and designs, is well worth a read. For further reading, I have to suggest Ozark Coverlets: The Shiloh Museum of Ozark History Collection, by Martha “Marty” Benson and Laura Lyon Redford. It’s my favorite book on coverlets, and it beautifully covers (no pun intended) the history of Ozark coverlet weaving and the lives of those weavers, and, best of all, it includes modern drafts of the designs.

As weavers it’s not uncommon to come across weaving drafts that are decades or even centuries old. In her article for the November/December 2017 issue of Handwoven, Madelyn van der Hoogt teaches you how to decipher old overshot drafts. Check out the issue to discover more vintage drafts and projects inspired by famous weavers. ~Christina

Overshot is a miracle of design potential on only four shafts. Somewhere, sometime long ago, a weaver looked at 2/2 twill and said: What if I add a tabby weft and repeat each two-thread pair for longer floats? Incredible patterns evolved, shared by colonial weavers with each other on small pieces of precious paper. Luckily, many of these drafts were saved and have become part of our weaving literature. In some of the older sources, the drafting format looks very confusing. Here is a guide to using them.

In the days when paper was hard to come by and writing was done by dipping a quill in ink, drafting formats for weaving were as abbreviated as possible. Overshot patterns are so elaborate that they can’t be communicated by words or short repeats the way simple twills can (point, rosepath, straight, broken, etc.). Complete drafts are necessary. Threading repeats are often long—some with as many as 400 threads. A number of shorthand methods thereby evolved that are similar to our use of profile drafts for other block weaves. But the way overshot works doesn’t allow a strict substitution of threading units for blocks on a profile threading draft.

Overshot drafting formats: Figure 1 is from Davison’s A Handweaver’s Source Book, Figure 2 is from Weaver Rose, and Figure 3 is from Wilson and Kennedy’s Of Coverlets.

Figures 1–3 show the most common early drafting methods. (Compare their length with the thread-by-thread version in Figure 5.) In shorthand drafts, each overshot block contains an even number of threads, four per block in these. (Block labels in red are added to Figures 1, 2, and 3 for clarity.) In Figure 1, from Marguerite Davison’s A Handweaver’s Source Book, the numbers tell how many times to thread each block; the rows tell which block to thread (A = 1-2, B = 3-2, C = 3-4, and D = 1-4). Note how the blocks always start on an odd shaft to preserve the even/odd sequence across the warp. The first column of numbers on the right (2/2) means to thread Block A (shafts 1-2) two times, then thread Block B (shafts 3-2) two times, etc.

In Figure 2, the method used by Weaver Rose, the lines represent the shafts. The numbers represent the order in which to thread the shafts. Reading from the right: Thread shaft 1, 2, 1, 2 for Block A. Then, moving to Block B, thread 3, 2, 3, 2, etc. In Figure 3, from Of Coverlets, the pair of shafts for each block is given with the number of times to thread it. Reading from the right: Thread 1-2, 2x; 3-2, 2x; 3-4, 2x, 1-4, 2x, etc. Figure 4 shows the actual thread-by thread draft for Figures 1–3. It also shows the way this threading would appear in Keep Me Warm One Night. In the drafts in this book, each block is threaded with an even number of threads and circled.

However, in overshot, blocks share shafts. That is, Block A (on shafts 1-2) shares shaft 2 with Block B and shaft 1 with Block D. Block B shares shaft 2 with Block A and shaft 3 with Block C, etc. When, for example, Block B is woven, a pattern-weft float covers the four threads that have been threaded for Block B and the thread on shaft 2 in Block A and the thread on shaft 3 in Block C. The circled blocks in Figure 5 show the warp threads that will actually produce pattern in each block using the drafts in Figures 1–4. Notice that Block B on the right will show a weft float over six threads, but on the left over only four. The same imbalance occurs with Block C; see also the drawdown in Figure 8. In the drafts derived from these shorthand drafts, float lengths over blocks in symmetrical positions always differ from each other by two warp threads.

Unbalanced drafts can be balanced by removing (or adding) pairs of shafts from the circled blocks; see Figures 6–10. In fact, to reduce or enlarge any draft, first circle the blocks so that they overlap to include their shared threads as in Figure 5. Then add or subtract pairs of threads. Notice that Block D has an odd number of threads, which is true of all “turning” blocks. Turning blocks are blocks where threading direction changes (any shift from the ABCD direction to the DCBA direction or vice versa).

The overshot drafts in Marguerite Davison’s A Handweaver’s Pattern Book and in Mary Meigs Atwater’s The Shuttle-Craft Book of American Hand-Weaving have all been balanced; see their drafting formats in Figures 11 and 12.

One of the best tools a weaver can have is choices. Knowing how to do things in multiple ways to accommodate different fibers, equipment and projects opens up all sorts of possibilities.In addition to learning to warp front to back we will be learning to read overshot drafts and weaving cottonlin kitchen towels in an overshot pattern. There are 4 looms available, or you can use your own 4+ harness loom.

It is thought that overshot was brought over from Europe with the early arrivals to the New Land. Settlers brought many ideas and tools with them and adapted them to the new life here. With a colder climate and long winters, overshot blankets meant you had a thick stable cloth, woven on four shafts, that kept the sleeper warm and also served as a decorative bed covering.

Lets get back to our weaving with overshot and some of the basics with the four shaft variety. I need to point out here that these are simple guidelines and by no means complete. Just a small primer to pique your interest. I will post reading / study material list at the end. These notes are based on an overshot study I undertook some years ago.

Most new weavers are introduced to overshot at an early newbie weaver stage and usually start with a draft from Marguerite Davison"s classic: A Handweaver"s Pattern Book.Itsstill available to purchase after all these years. The drafts in this book are for sinking shaft looms such as counterbalance looms. You can flip the tie up for jack looms. If you don"t, it means you will be weaving the pattern upside down, which isn"t a problem but it would be nice to see the front as you weave. This little detail would make it confusing for new weavers starting on overshot for the first time, in addition to handling two shuttles!

Overshot is a twill derivative using two threads to create a unit block. This means you can have four blocks on four shafts. One thread in each block, is shared by the next block. This one thread in common creates half units in between blocks of either all pattern or all tabby. (This can be expanded through to eight shafts but we"ll stick with four shafts for this post) See what I mean by this in the picture below:

Overshot is actually two pieces of cloth, being woven simultaneously; one is a tabby or plain weave cloth, the second is the pattern that "over-shoots" the plain weave. You throw one shuttle for the plain weave and a second shuttle for the pattern weft, beating *very* firmly between each shot. If you were to take away the pattern weft, you would find a perfectly balanced 50/50 plain weave cloth. The pattern weft should compact well but be "lofty" to cover and produce blocks of solid colour with no plain weave peeking through. Normally the pattern weft is twice the size of the tabby yarn. Traditionally, cotton for tabby and with wool for pattern.

I keep the "odd" tabbies of treadles one and three to enter from the left hand side, and the "even" tabbies of treadles two and four from the right hand side. Also I work with both shuttles, tabby and weft, on one side of the warp. If you end up with divided shuttles then you have a treadling error to find!. The shuttles can be awkward to coordinate at first but you soon develop a rhythm. Be aware that many overshot drafts may say "use tabby" but don"t show it in the treadling. Then there are some that don"t mention the tabby at all. They are assuming you know to insert it.

The majority of overshot is woven "as drawn in" which means you repeat the exact threading as your treadling. Old drafts say "tromp as writ" which is the same thing.

Twill fashion is where you treadle a block over again to produce exact squares. This may be more repeats than is in the threading. You can also follow twill treadlings such as: rosepath ( 1, 2, 3, 4, 1, 4, 3, 2, 1), point twill (1, 2, 3, 4, 3, 2, 1) , or broken twill (1, 2, 4, 3). Its then called overshot treadled as rosepath, or treadled as summer and winter. There are many other ways to vary the treadling and these all make very pretty borders! The following examples are from my first level of the Guild of Canadian Weavers Test. I took portions of the treadling and created these border patterns. They had to have a purpose for being woven. Click to enlarge...

When designing overshot patterns you can place many identical units together and then continue through to other blocks but the turning point block in your design will have an uneven number of threads. When treadling, the turning blocks are treadled one extra repeat.

So besides bed coverlets, what else can you make with overshot? I have seen beautiful modern looking table runners, scarves, overshot style borders on placemats and towels. I saw a beautiful (apparently) plain weave table cloth that had inlaid overshot motifs scattered like stars! They looked like snowflakes on the royal blue cloth.

I always thought it would be a neat challenge to weave overshot and have it look totally modern and comfortable in today"s home. ( Its on my "to-do" list..)

So if you have followed me through to this point and are now thinking it might be nice to try some overshot study yourself. Perhaps try inventing some borders for towels? Here are a few books on overshot that are on my library shelf:
