This post is the third in a series introducing you to common weaving structures. We’ve already looked at plain weave and twill, and this time we’re going to dive into the magic of overshot weaves—a structure that’s very fun to make and creates exciting graphic patterns.

Overshot is a term commonly used to refer to a twill-based type of weaving structure. Perhaps more correctly termed "floatwork" (more on that later), these textiles have a distinctive construction made up of both a plain weave and pattern layer. Requiring two shuttles and at least four shafts, overshot textiles are built using two passes: one weaves a tabby layer and the other weaves a pattern layer, which overshoots or floats, above.

Readers in the United States and Canada may be familiar with overshot textiles through woven coverlets made by early Scottish and English settlers. Using this relatively simple technique, a local professional weaver with a four-shaft loom could easily make a near-infinite variety of equally beautiful and complex patterns. If you’d like to learn more about overshot coverlets and some of the traditions that settlers brought with them, please see my reading list at the bottom of this article!

As it is twill-based, overshot will be very familiar to 4 shaft weavers. It’s made up of a sequence of 2-thread repeats: 1-2, 2-3, 3-4, and 1-4. These sequences can be repeated any number of times to elongate and create lines, curves, and shapes. These 2-thread repeats are often referred to as blocks or threading repeats, IE: 1-2 = block 1/A, 2-3 = block 2/B.

There are three ways weft appears on the face of an overshot cloth: as a solid, half-tone, or blank. In the draft image I’ve shared here, you can see an example of each—the solid is in circled in blue, the half-tone in red, and the blank yellow. Pressing down the first treadle (shafts 1 and 2), for example, creates solid tones everywhere there are threads on shafts 1 and 2, half-tones where there is a 1 or 2 paired with 3 or 4, and nothing on the opposite block, shafts 3 and 4. Of course, there’s not really nothing—the thread is simply traveling on the back of the cloth, creating a reverse of what’s on the face.

Because overshot sequences are always made up of alternating shafts, plain weave can be woven by tying two treadles to lift or lower shafts 1-3 and 2-4. When I weave two-shuttle weaves like overshot, I generally put my tabby treadles to the right and treadle my pattern picks with my left foot and my tabby with my right. In the draft image I’ve shared above, I’ve omitted the tabby picks to make the overarching pattern clearer and easier to read. Below is a draft image that includes the tabby picks to show the structure of the fabric.

Traditional overshot coverlets used cotton or linen for warp and plain weave wefts, and wool pattern wefts—but there’s no rule saying you have to stick to that! In the two overshot patterns I’ve written for Gist, I used both Mallo and Beam as my pattern wefts.

In the Tidal Towels, a very simple overshot threading creates an undulating wave motif across the project. It’s easy and repetitive to thread, and since the overshot section is relatively short, it’s an easy way to get a feel for the technique.

The Bloom Table Squares are designed to introduce you to a slightly more complex threading—but in a short, easy-to-read motif. When I was a new weaver, one of the most challenging things was reading and keeping track of overshot threading and treadling—but I’ve tried to make it easy to practice through this narrow and quick project.

Overshot works best with a pattern weft that 2-4 times larger than your plain weave ground, but I haven’t always followed that rule, and I encourage you to sample and test your own wefts to see how they look! In the samples I wove for this article, I used 8/2 Un-Mercerized Cotton weaving yarn in Beige for my plain weave, and Duet in Rust, Mallo in Brick, and Beam in Blush for my pattern wefts.

The Bloom Table Squares are an excellent example of what weavers usually mean when they talk about traditional overshot or colonial overshot, but I prefer to use the term "floatwork" when talking about overshot. I learned this from the fantastic weaver and textile historian Deborah Livingston-Lowe of Upper Canada Weaving. Having researched the technique thoroughly for her MA thesis, Deborah found that the term "overshot" originated sometime in the 1930s and that historical records variably called these weaves "single coverlets’ or ‘shotover designs.’ Deborah settled on the term "floatwork" to speak about these textiles since it provides a more accurate description of what’s happening in the cloth, and it’s one that I’ve since adopted.

This book contains the collected drafts and work of Frances L. Goodrich, whose interest in coverlets was sparked when a neighbor gifted her one in the 1890s. Full of charming hand-painted drafts, this book offers a glimpse into North Carolina’s weaving traditions.

Amanda Ratajis an artist and weaver living and working in Hamilton, Ontario. She studied at the Ontario College of Art and Design University and has developed her contemporary craft practice through research-based projects, artist residencies, professional exhibitions, and lectures. Subscribe to herstudio newsletteror follow her onInstagramto learn about new weaving patterns, exhibitions, projects, and more.

In its simplest form – overshot is a weaving technique that utilizes at least 2 different types of weft yarns and floats to create a pattern. These patterns are often heavily geometric.

Ground weft– plain weave pattern that is used between each row of your overshot pattern. This plain weave gives the textile structure and allows for large areas of overshot to be woven without creating an overly sleazy fabric. Without the use of a ground weft on an overshot pattern, the weaving would not hold together because there would not be enough warp and weft intersections to create a solid weaving.

They were most popular though in southern Appalachia and continued to be so even after textile technologies advanced. When other parts of colonial America moved to jacquard weaving, the weavers of southern Appalachia continued to weave their overshot coverlets by hand.

Since the overshot coverlets were most often woven at home on smaller looms they usually had a seam down the middle where two woven panels were sewn together.

The thing about overshot is that no matter the application, it is pretty impressive. Perhaps that is just my opinion, but due to how complex it can look, I feel that it is pretty safe to say.

Just because it was originally used for coverlets, does not mean it can only be used for coverlets. Changing aspects of the pattern like the colors used, or the way you use your ground weft can drastically change the look and feel of your weaving.

In the image below you can see the ground weft is not the same color throughout. Instead, I wove the ground weft as discontinuous so that I could add extra pattern and design into the weavings. In this case, you may be wondering how to deal with your weft yarns when they are in the middle of the weaving and not at the selvage.

The discontinuous weft yarns will float onto the back of the weaving until you are ready for them in their next pick. This does make your overshot weaving one sided since it will have vertical floats on the back. Keep this in mind if you want to try this technique out.

Also seen in the image above, the overshot yarn that I used was not all one color! This is a really simple way to get extra dimension and interest in your overshot if that is something you are looking for.

This makes it simple to be able to only weave overshot in certain parts of your weaving. If you want to do this then you can continue to weave your plain weave across the entire width of your weaving, but only weave overshot in specific areas. This creates a overshot section that functions similar to inlay.

Since the overshot pattern is strongly influenced by the weft yarns that are used it is important to choose the right yarns. Your weaving will be set up to the specification needed for a balanced plain weave. Make sure you understand EPI in order to get the right warp sett for your overshot weaving.

The ground weft used is almost always the same yarn as your warp. This allows the overshot weft to really be able to shine without contrasting warp and weft plain weave yarns.

In order to get the full effect of the overshot, it must be thick enough that when you are weaving your pattern it covers up the ground weft between each pass. If it is not thick enough to do this, it will still be overshot, but the full effect will not be seen.

What this warp thread does is serve as an all-purpose selvedge that does not correspond with your pattern. Instead, you would make sure to go around this warp thread every time to make sure that you are able to weave fully to the selvedge. Without this, your overshot weft will float awkwardly on the back of your weaving whenever the pattern does not take it to the edge.

I have mentioned this book multiple times because it really is such a great resource for any weaver looking to weave patterns of all types. It contains 23 pages of different overshot patterns (among so many other patterns) that you can set up on your floor or table loom.

Like a lot of different types of weaving, it is possible to do it on almost any type of loom that you have. The difference being that it might take you a little bit longer or require a bit more effort than if you did it on a traditional floor loom.

Weaving overshot on a frame loom or rigid heddle loom will require the use of string heddles and pick-up sticks that you have to manually use to create a shed.

Many years ago, I finally got to try weaving. I took the Beginning to Weave workshop through the Ottawa guild. At that time, 1989, the OVWSG did not have a studio space to house what guild equipment we had acquired. (The Guild had an old second-hand 100 inch loom and 6 or 7 table looms. There may have been a floor loom too but I was distracted by the 100 inches of loom, so do not remember). All the looms lived in one of our guild members’ very big basements. On weekends, she either taught weaving workshops or hosted weavers working on the 100 inch loom. It sounded like a busy basement! I remember 4 weekends of driving to a little town just east of Ottawa. I took the table loom home each week to do homework. I still remember the sound of the mettle heddles rattling as I drove down the highway, back and forth to the classes. Then I think there were two more weekends of Intermediate weaving and Dona sent me off and I was weaving!

It all starts with yarn, wind it carefully, attach it to the back beam, wind on, thread the heddles, slay the reed, tie on to the front beam, check the tension and then start to weave. It sounds like a lot of work but it is all worth it as you start to pass the shuttle through the shed and the cloth begins to appear. Weaving was like Magic! From a pile of string to POOF, actual cloth!!!

During the workshop, I found pickup seemed strangely familiar as my brain watched my fingers happily lifting and twisting threads for the various lace and decorative weave patterns. The other thing that my brain went “ooh this is cool!” was Overshot. It is a weave structure that requires a ground and a pattern thread, (two shuttles). One is fine like the warp and the pattern thread is thicker and usually wool. I was still reacting to wool so I used cotton for both.  My original goal was to draft and weave a Viking textile for myself but I put that aside for a moment, I will get back to that later.

The first thing I wove after my instruction was a present for my Mom. she had requested fabric to make a vest. I looked through A Handweaver’s Pattern Bookby Marguerite Porter Davison and found an overshot pattern that I thought we both would like. I wove it in two shades of blue (Mom’s favourite colour), at a looser thread count than usual. (Originally the overshot weave structure was used to make coverlets, so were tightly woven and a bit stiff, while I liked the pattern I wanted the fabric to be much more drapey.) Even worse, I did not want it to be as hard-edged in the pattern as it was originally intended so I tried a slub cotton as a test and loved it.

In the Exhibition The Inkle band, hanging beside the overshot, I wove much more recently. I used an Inkle loom and a supplemental warp thread. This means weaving with an extra separate thread that was not part of the main warp on the loom.  I used a yarn with a fuzzy caterpillar-like slub.

You may be able to see how I wove the weird slubby supplemental warp. The yarn is weighted and left hanging over the back peg of the Inkle loom. It comes over the top peg (usually labelled B in diagrams) and floats above the weaving.  In the areas where the Caterpillar (Slub) is not present I catch the yarn with the shuttle and weave it into the band. In the area the caterpillar appears I would leave the yarn above the warp and then start weaving it in again as I reached the end of the caterpillar. I hope that explanation doesn’t sound like mud and makes a bit of sense. Using a supplemental warp on an Inkle loom is not quite normal but it is a lot of fun.

I was going to tell you about my original goal in learning to weave, the mysterious Fragment #10 from a Viking excavation from around the year 1000, but  I have likely confused you with weaving enough for one day. So I will save that for another chat. (don’t forget the Inkle loom I would like to tell you a bit more about that in another post too. I promise I will get back to felting in the not-too-distant future)

You may remember that I recently returned from a visit to The Philippines. It may not surprise you that I am always on the lookout for interesting textiles, and especially handwoven fabrics. I don’t mean to do that; it just happens… Well, when I met sweet Beth at the Sunday market, I felt like I hit the jackpot! Beth and I had a common language – Handweaving! (She speaks fine English, too, of course; but you know what I mean.)

Cloth is woven on a grid of vertical warps and horizontal wefts. But, with a bit of knowledge about designing weaving drafts, you can use these rectilinear elements to create smoothly flowing lines in your woven fabric.

In this article, I focus on designing with overshot blocks in order to create flowing curves large enough to be seen at a distance. I will also discuss "weaving as overshot" which is a method of applying overshot techniques to other weave structures and, finally, finish up with some strategies for designing curves in any weave structure.

In the twill draft above, the diagonal lines are only three threads apart, which might be too subtle an effect. To make the scale of your design larger, you can use a diagonal progression of weave-structure blocks instead of individual threads. The following draft shows an example of a diagonal progression using overshot blocks on four shafts.

Overshot is a weave structure creating a plain-weave cloth with decorative supplementary weft floats. These floats lie on top of (float over) the ground cloth. If you pull out all of the pattern weft threads, you are left with a plain weave cloth formed by the warp and the tabby weft. There are never any warp floats because of the tabby weft.

Weaving software is very helpful for testing hues and values for weft yarns to use with your warp. If you choose to weave overshot with a single shuttle, choose a contrasting value to the warp for a subtle design but faster weaving.

If you put the curve in your threading, the waves travel across the fabric horizontally, in the direction of the weft. You can see this in the overshot draft below.

Another disadvantage to putting the curves in the threading is that it limits your ability to improvise curved designs organically at the loom. It"s easy to change treadling patterns during weaving. Changing the threading, however, is a much more involved process.

I learned how to make curves by studying a traditional overshot draft called Blooming Leaf (page 133 in A Handweaver"s Pattern Book by Marguerite Davison). In this draft, the treadling maintains a diagonal progression but the scale changes to make the shape "bloom" and undulate.

[Note: When I create overshot drafts, I place the first pattern block on treadle three; I like to weave the tabby picks with my left foot (alternating between treadles one and two) and use my right foot (on the remaining treadles) to weave the pattern weft and create the design.]

Now that you know how to create curves, undulations, and reflected curves, you have the tools you need to create any kind of curve or diagonal line in four-shaft overshot. For a challenge, try making a long curve followed by a short curve, like a meandering river.

The methods described above also work for overshot on six, eight, ten, or more shafts. As you add additional shafts to your design, you gain the ability to create smoother and more dramatic curves.

Below is an example of an eight-shaft overshot threading; in this case a diagonal progression with a point and mirror symmetry. My treadling in this draft is an S-shaped curve. This is just one example of the many different curves you can weave on this threading.

Because the underlying structure of overshot is plain weave, any threading which can produce plain weave can theoretically be woven as overshot, alternating tabby and pattern weft.

I wove the draft above using a 20/2 silk sett at 30 epi. I chose to sett the yarn this densely so I could weave both an overshot and twill version on the same warp. You can see the resulting cloth in the picture below.

How do I weave as overshot when my sett is more appropriate for twill? I use a tabby weft that is much finer than the warp, in this case 140/2 silk from Lunatic Fringe.

Other times I choose to weave as overshot because the floats show off the pattern-weft yarn, such as the handspun wool used as the pattern weft in the cloth below.

It is easy and fun to make up a curved treadling at the loom, especially when weaving as overshot. Even after forty-two years of weaving, I still enjoy working with long, non-repeating treadlings; watching the curves grow and change as I weave. Instead of memorizing a sequence and repeating it carefully, I watch the design and think about where I want the next curve to go.

A side benefit of weaving long, undulating curves instead of small, repeated patterns is that a small variation in a repeat will stand out, but design variations are normal in organic curves.

The drape of overshot fabric is not as fluid as that of a twill fabric. So for a scarf or shawl I might choose a structure other than overshot. Fine silk, however, has such nice drape that I can weave as overshot and still get good results.

With weaving software, it is easy to create curved overshot designs. Simply draw a freehand curve in the treadling—smoothing it out if necessary—and then add the tabby shots. Once you have the general idea from designing drafts, you can improvise new curved designs at the loom.

For other weave structures, creating a profile draft can be helpful. A profile draft is a design template that represents the woven design at one level of abstraction. To convert a profile draft into a weaving draft, you replace each block in a profile draft with the appropriate block of a given weave structure. You can, therefore, express a single profile draft in many different weave structures: overshot, summer-and-winter, Bronson lace, huck lace, double weave, etc.

Profile drafts with smooth, flowing curves are also useful for learning how to design graceful lines. Weaving software helps because you can quickly create and edit drafts. None of the weaving programs I"m familiar with have an option to create "graceful" or "smooth" curves. So you"ll have to train your hand and eye, but this comes with practice.

I like smooth, flowing curves that are visible at a distance. So I look for structures that give me the maximum number of pattern blocks to design with. Generally I use weave structures where I have as many pattern blocks as there are shafts on my loom. On a four-shaft loom, I use crackle, overshot, advancing and network-drafted twills, advancing points, turned taqueté, rep, and shadow weave.

If you work with graph paper, remember to check the repeats, i.e., transitions, in the threading and treadling to make sure there aren"t gaps or discontinuous areas that affect the flow of your curve. In weaving software, you can do this easily by zooming out the view to check the draft over several repeats.

They"ve long been overshadowed by quilts, but overshot coverlets deserve their own place in the sun. The nubby-textured textiles, loomed from wool and cotton into arresting geometric patterns, first migrated to America from Europe in the 1770s. Later, industrial mills replicated the handcrafted heirlooms, and today these versions are plentiful at antiques fairs and on Etsy.

Of course, there"s nothing wrong with using these blankets as intended—as actual bed coverlets. Should you score a piece of overshot fabric that"s large enough to decorate your bed (and in mint enough condition to display), replace your winter quilt with this lighter iteration when the weather warms. Or, attempt our Envelope-Backed Pillow Cover, which calls for this fabric. However you decide to use these visually dynamic cloths, with our easy ideas, you will be able to weave some style and history into your home in no time.

Overshot weave is the topic this week. Even if you haven’t heard of overshot before, I’m guessing you will still recognize it. Have you ever seen a historical coverlet before? That is overshot. Typically 2 colors. ALL about the pattern. That’s the one! Overshot.

Overshot is a partnership between 2 shuttles. The first shuttle is all about the pattern. She flits all over the fabric making big leaps and seemingly impossible designs. The second shuttle is all plain weave. She’s the reliable one, making sure the fabric will actually hold together.

Overshot Weave – Overshot is a weaving pattern that was very common in Southern Appalachia. I found a great article with some history about overshot from Comfort Cloth Weaving. Here’s the link.

Weaving Draft – A weaving draft is like sheet music. It tells you how to set up the loom and then the order in which to toss the shuttles in order to recreate a specific pattern. Once you can read a draft, the weaving world is your oyster!

Great news – I have created a free .pdf that follows along with this weaving pattern series! It provides an overview of each weaving pattern. Tells you how to recognize it and what it is used for. Plus, I’ve included a few notes on how to create the pattern on your loom. It’s a fabulous resource! Click here to get your copy today. Happy Weaving!

Weaving rag rugs is an immensely satisfying process that enables you to use cast-off remnants of fabric - and a favorite old shirt or two - to make something beautiful and functional for your home. In this book, you"ll explore the fascinating history of rag weaving, learn how to weave a basic rag rug, master some of the most popular traditional designs, and experiment with contemporary techniques for weaving and embellishing rugs. Filled with scores of colour photographs of rugs by more than 40 artists from around the world, this book is a delight for weavers and non-weavers alike.

Weaving with rags developed out of genuine necessity centuries ago, when cloth was so highly treasured that it was often unwoven in order to reuse the thread. Although fabric is now commonly available at very low cost, weaving rag rugs remains an especially satisfying process. Transforming fabric remnants and old articles of clothing into beautiful, functional rugs yields a wonderful feeling of accomplishment, and it instills a sense of connection with history and tradition.

The basics of rag rug weaving have remained the same over the years, but the materials, designs, weave patterns, and color combinations have changed significantly. Today"s weavers have access to an abundant array of warp and weft materials, with a wide variety of fiber content, color, and pattern. There are few-if any-limitations on what you might incorporate into your design: plastic shopping bags, bread wrappers, nylon stockings, and industrial castoffs have all been included.

Once you feel comfortable with the basic techniques, you"ll want to sample the rag rug projects. There are a dozen in total, ranging in style from a subtle gradation of stripes to a vibrant tapestry inlay. You"ll find seaside motifs and square blocks, pale pastels and brilliant jewel tones. There is even a double weaving project chenille "caterpillars" are woven first, and these become the weft in a wonderfully textured chair pad. Each project is described in complete detail and accompanied by a weaving draft.

Throughout the book are full-color photographs of works by more than 40 artists from a dozen countries around the world. These images, together with how-to photography and detailed illustrations, will instruct you and inspire you to sample new directions in your weaving. A fascinating history of rag weaving complements this glorious collection of contemporary rugs.

Overshot: The earliest coverlets were woven using an overshot weave. There is a ground cloth of plain weave linen or cotton with a supplementary pattern weft, usually of dyed wool, added to create a geometric pattern based on simple combinations of blocks. The weaver creates the pattern by raising and lowering the pattern weft with treadles to create vibrant, reversible geometric patterns. Overshot coverlets could be woven domestically by men or women on simple four-shaft looms, and the craft persists to this day.

Summer-and-Winter: This structure is a type of overshot with strict rules about supplementary pattern weft float distances. The weft yarns float over no more than two warp yarns. This creates a denser fabric with a tighter weave. Summer-and-Winter is so named because one side of the coverlet features more wool than the other, thus giving the coverlet a summer side and a winter side. This structure may be an American invention. Its origins are somewhat mysterious, but it seems to have evolved out of a British weaving tradition.

Double Cloth: Usually associated with professional weavers, double cloth is formed from two plain weave fabrics that swap places with one another, interlocking the textile and creating the pattern. Coverlet weavers initially used German, geometric, block-weaving patterns to create decorative coverlets and ingrain carpeting. These coverlets contain twice the yarn and are twice as heavy as other coverlets.

Multi-harness/Star and Diamond: This group of coverlets is characterized not by the structure but by the intricacy of patterning. Usually executed in overshot, Beiderwand, or geometric double cloth, these coverlets were made almost all made in Eastern Pennsylvania by professional weavers on looms with between twelve and twenty-six shafts.

America’s earliest coverlets were woven in New England, usually in overshot patterns and by women working collectively to produce textiles for their own homes and for sale locally. Laurel Thatcher Ulrich’s book, Age of Homespun examines this pre-Revolutionary economy in which women shared labor, raw materials, and textile equipment to supplement family incomes. As the nineteenth century approached and textile mills emerged first in New England, new groups of European immigrant weavers would arrive in New England before moving westward to cheaper available land and spread industrialization to America’s rural interior.

Coverlet weavers were among some of the earliest European settler in the Northwest Territories. After helping to clear the land and establish agriculture, these weavers focused their attentions on establishing mills and weaving operations with local supplies, for local markets. This economic pattern helped introduce the American interior to an industrial economy. It also allowed the weaver to free himself and his family from traditional, less-favorable urban factory life. New land in Ohio and Indiana enticed weavers from the New York and Mid-Atlantic traditions to settle in the Northwest Territories. As a result, coverlets from this region hybridized, blending the fondness for color found in Pennsylvania coverlets with the refinement of design and Scottish influence of the New York coverlets.

Southern coverlets almost always tended to be woven in overshot patterns. Traditional hand-weaving also survived longest in the South. Southern Appalachian women were still weaving overshot coverlets at the turn of the twentieth century. These women and their coverlets helped in inspire a wave of Settlement Schools and mail-order cottage industries throughout the Southern Appalachian region, inspiring and contributing to Colonial Revival design and the Handicraft Revival. Before the Civil War, enslaved labor was often used in the production of Southern coverlets, both to grow and process the raw materials, and to transform those materials into a finished product.

Because so many coverlets have been passed down as family heirlooms, retaining documentation on their maker or users, they provide a visual catalog of America’s path toward and response to industrialization. Coverlet weavers have sometimes been categorized as artisan weavers fighting to keep a traditional craft alive. New research, however, is showing that many of these weavers were on the forefront of industry in rural America. Many coverlet weavers began their American odyssey as immigrants, recruited from European textile factories—along with their families—to help establish industrial mills in America. Families saved their money, bought cheaper land in America’s rural interior and took their mechanical skills and ideas about industrial organization into the American heartland. Once there, these weavers found options. They could operate as weaver-farmers, own a small workshop, partner with a local carding mill, or open their own small, regional factories. They were quick to embrace new weaving technologies, including power looms, and frequently advertised in local newspapers. Coverlet weavers created small pockets of residentiary industry that relied on a steady flow of European-trained immigrants. These small factories remained successful until after the Civil War when the railroads made mass-produced, industrial goods more readily available nationwide.

The origin of the technique itself may have started in Persia and spread to other parts of the world, according to the author, Hans E. Wulff, of The Traditional Crafts of Persia. However, it is all relatively obscured by history. In The Key to Weavingby Mary E. Black, she mentioned that one weaver, who was unable to find a legitimate definition of the technique thought that the name “overshot” was a derivative of the idea that “the last thread of one pattern block overshoots the first thread of the next pattern block.” I personally think it is because the pattern weft overshoots the ground warp and weft webbing.

Overshot gained popularity and a place in history during the turn of the 19th century in North America for coverlets. Coverlets are woven bedcovers, often placed as the topmost covering on the bed. A quote that I feel strengthens the craftsmanship and labor that goes into weaving an overshot coverlet is from The National Museum of the American Coverlet:

Though, popular in many states during the early to mid 19th centuries, the extensive development of overshot weaving as a form of design and expression was fostered in rural southern Appalachia. It remained a staple of hand-weavers in the region until the early 20th century. In New England, around 1875, the invention of the Jacquard loom, the success of chemical dyes and the evolution of creating milled yarns, changed the look of coverlets entirely. The designs woven in New England textile mills were predominantly pictorial and curvilinear. So, while the weavers of New England set down their shuttles in favor of complex imagery in their textiles, the weavers of Southern Appalachia continued to weave for at least another hundred years using single strand, hand spun, irregular wool yarn that was dyed with vegetable matter, by choice.

And, due to the nature of design, overshot can be woven on simpler four harness looms. This was a means for many weavers to explore this technique who may not have the financial means to a more complicated loom. With this type of patterning a blanket could be woven in narrower strips and then hand sewn together to cover larger beds. This allowed weavers to create complex patterns that spanned the entirety of the bed.

What makes overshot so incredibly interesting that it was fundamentally a development of American weavers looking to express themselves. Many of the traditional patterns have mysterious names such as “Maltese Cross”, “Liley of the West”, “Blooming Leaf of Mexico” and “Lee’s Surrender”. Although the names are curious, the patterns that were developed from the variations of four simple blocks are incredibly intricate and luxurious.

This is only the tip of the iceberg with regard to the history of this woven structure. If you are interested in learning more about the culture and meaning of overshot, check out these resources!

The National Museum of the American Coverlet- a museum located in Bedford, Pennsylvania that has an extensive collection of traditional and jacquard overshot coverlets. Great information online and they have a “Coverlet College” which is a weekend series of lectures to learn everything about the American coverlet. Check out their website - coverletmuseum.org

Textile Art of Southern Appalachia: The Quiet Work of Women – This was an exhibit that traveled from Lowell, Massachusetts, Morehead, Kentucky, Knoxville, Tennessee, Raleigh, North Carolina, and ended at the Royal Museum in Edinburgh, Scotland. The exhibit contained a large number of overshot coverlets and the personal histories of those who wove them. I learned of this exhibit through an article written by Kathryn Liebowitz for the 2001, June/July edition of the magazine “Art New England”. The book that accompanied the exhibit, written by Kathleen Curtis Wilson, contains some of the rich history of these weavers and the cloth they created. I have not personally read the book, but it is now on the top of my wish list, so when I do, you will be the first to know about it! The book is called Textile Art of Southern Appalachia: The Quiet Work of Women and I look forward to reading it.
