overshot weaving technique in stock

While it looks like it would be a very time-intensive and difficult technique to weave – it really isn’t! You just have to understand how and why it works the way it does. (We will get to that.)

In its simplest form – overshot is a weaving technique that utilizes at least 2 different types of weft yarns and floats to create a pattern. These patterns are often heavily geometric.

Ground weft– plain weave pattern that is used between each row of your overshot pattern. This plain weave gives the textile structure and allows for large areas of overshot to be woven without creating an overly sleazy fabric. Without the use of a ground weft on an overshot pattern, the weaving would not hold together because there would not be enough warp and weft intersections to create a solid weaving.

They were most popular though in southern Appalachia and continued to be so even after textile technologies advanced. When other parts of colonial America moved to jacquard weaving, the weavers of southern Appalachia continued to weave their overshot coverlets by hand.

Since the overshot coverlets were most often woven at home on smaller looms they usually had a seam down the middle where two woven panels were sewn together.

The thing about overshot is that no matter the application, it is pretty impressive. Perhaps that is just my opinion, but due to how complex it can look, I feel that it is pretty safe to say.

Just because it was originally used for coverlets, does not mean it can only be used for coverlets. Changing aspects of the pattern like the colors used, or the way you use your ground weft can drastically change the look and feel of your weaving.

In the image below you can see the ground weft is not the same color throughout. Instead, I wove the ground weft as discontinuous so that I could add extra pattern and design into the weavings. In this case, you may be wondering how to deal with your weft yarns when they are in the middle of the weaving and not at the selvage.

The discontinuous weft yarns will float onto the back of the weaving until you are ready for them in their next pick. This does make your overshot weaving one sided since it will have vertical floats on the back. Keep this in mind if you want to try this technique out.

Also seen in the image above, the overshot yarn that I used was not all one color! This is a really simple way to get extra dimension and interest in your overshot if that is something you are looking for.

This makes it simple to be able to only weave overshot in certain parts of your weaving. If you want to do this then you can continue to weave your plain weave across the entire width of your weaving, but only weave overshot in specific areas. This creates a overshot section that functions similar to inlay.

Since the overshot pattern is strongly influenced by the weft yarns that are used it is important to choose the right yarns. Your weaving will be set up to the specification needed for a balanced plain weave. Make sure you understand EPI in order to get the right warp sett for your overshot weaving.

The ground weft used is almost always the same yarn as your warp. This allows the overshot weft to really be able to shine without contrasting warp and weft plain weave yarns.

In order to get the full effect of the overshot, it must be thick enough that when you are weaving your pattern it covers up the ground weft between each pass. If it is not thick enough to do this, it will still be overshot, but the full effect will not be seen.

What this warp thread does is serve as an all-purpose selvedge that does not correspond with your pattern. Instead, you would make sure to go around this warp thread every time to make sure that you are able to weave fully to the selvedge. Without this, your overshot weft will float awkwardly on the back of your weaving whenever the pattern does not take it to the edge.

I have mentioned this book multiple times because it really is such a great resource for any weaver looking to weave patterns of all types. It contains 23 pages of different overshot patterns (among so many other patterns) that you can set up on your floor or table loom.

Like a lot of different types of weaving, it is possible to do it on almost any type of loom that you have. The difference being that it might take you a little bit longer or require a bit more effort than if you did it on a traditional floor loom.

Weaving overshot on a frame loom or rigid heddle loom will require the use of string heddles and pick-up sticks that you have to manually use to create a shed.

Crazyshot - creative overshot weaving - introduces anyone who uses a rigid heddle loom to a whole world of creative weaving. Using just one heddle and one pick-up stick, you’ll explore color, design, and texture, taking your weaving to the next level.

Complete step-by-step instructions are included for weaving all 14 of the designs in this book. Also provided are how-tos for the single heddle overshot technique, reading charts for the rigid heddle loom, and finishing techniques, along with lots of tips and tricks for successful and

Complex patterning is easier than it looks with this simple charted technique. All you need are basic rigid heddle warping and weaving skills to start your next weaving adventure!

Crazyshot Companion contains over 100 charted designs, along with complete instructions for incorporating them into your Crazyshot projects. You’ll also find ways to combine or modify charts, to add color, or to translate traditional weaving drafts for use with the Crazyshot technique.

Weave structures often have specific threading and treadling patterns that are unique to that particular weave structure and not shared with others. This book takes you out of the traditional method of weaving overshot patterns by using different treadling techniques. This will include weaving overshot patterns as Summer/Winter, Italian manner, starburst, crackle, and petit point just to name a few. The basic image is maintained in each example but the design takes on a whole new look!

Each chapter walks you through the setup for each method and includes projects with complete drafts and instructions so it’s easy to start weaving and watch the magic happen! Try the patterns for scarves, table runners, shawls, pillows and even some upholstered pieces. Once you"ve tried a few projects, you"ll be able to apply what you"ve learned to any piece you desire!

Overshot is perhaps the most iconic weaving technique--think antique coverlets and fancy table runners--yet many weavers are intimidated by its complex-looking structure. But it doesn"t have to be difficult! In this book, Susan Kesler-Simpson makes overshot approachable by breaking it down piece by piece so that the weaver understands how it works, and then she puts it all back together so that weavers will have the confidence to make their own overshot patterns or to try any of the 38 overshot projects she has designed for the book.

Lots of people think that overshot must be a complicated 8-shafts-and-above weave structure, but that is far from true. Most overshot designs can be woven on 4-shafts, and once you get into a weaving rhythm of pattern-tabby-pattern-tabby, weaving goes smoothly as the beautiful patterns emerge on your loom. That said, designing and weaving overshot requires a bit more concentration than plain weave.

Here are five tips from designer Pattie Graver, author of Next Steps in Weaving, to ensure great overshot results. The first three are probably ones you’ve already heard about weaving other structures, but the last two are about looking at overshot designs and color choices in a mindful way.

I follow the advice of Helene Bress in The Weaving Book: “Identify a diagonal line that appears in the cloth as you weave and try to keep that at 45 degrees.” I keep a protractor by my loom!

If warp and pattern weft are too close in value, the overshot designs will not appear in strong contrast. Remember, too, that the eye follows light, so bits of lighter pattern weft add interest to the cloth.

Debbi Rutherford used name drafting to create this overshot pattern and then used a variegated yarn for her pattern weft. Handwoven January/February 2017. Photo by Joe Coca.

Over three years ago, when my David Louet floor loom was still somewhat new to me, I wrotethis post on overshot. If you read it, you will discover that my initial relationship with overshot was not a very positive one.

Back then, I was a little harder on myself as a learning weaver. By now, I’ve realised that weaving, just like life, is a journey that has a beginning but no end. Back then, I thought that my ultimate goal was to be a “master weaver”.

The happy ending to the initial overshot sob story is that I can weave overshot now. Quite well, in fact! And I also teach it. And I happen to love it, very, very much. Don’t you love a happy ending?

I don’t think there was any particular moment where I thought to myself “I can weave overshot now!” I didn’t even weave any overshot for quite some time after that initial attempt. But slowly it tempted me back, and we started over. It was just a matter of sticking with it, employing some specific techniques and practice, practice, practice until it feels like an old friend.

My love of overshot has only increased with my more recent discovery of American Coverlets. I loved the look of the coverlets and the history behind them before I realised that so many of them were woven in the wonderfully humble 4 shaft overshot.

I’ve put a lot of research time into coverlets this year and have made it a big weaving goal of mine to weave my first coverlet, which is quite an undertaking, but I relish the thought.

Now that I have quite a lot of experience weaving overshot, I want to share my best overshot tips with you in hope that you too will fall in love with this wonderful weave structure.

To weave overshot you need a warp yarn, a tabby yarn and a pattern weft yarn. Using the same yarn for warp and tabby works perfectly. For the pattern weft, I like to use a yarn that is twice the size of the tabby/warp yarn. I have experimented with using doubled strands of tabby/warp yarn in a contrasting colour, but it just doesn’t look as good. A thicker pattern yarn is the way to go.

What will the size of your item be? A miniature overshot pattern may get lost in a blanket, but may be perfect for a scarf. As a general rule, a good way to estimate the size of one repeat of your pattern just by looking at the draft is to see how many repeats are in one threading repeat. Also consider the thickness of your yarns and the sett you intend to weave.

Just to give you an idea, my current project is woven at 20 ends per inch with 8/2 cotton for warp and tabby and fingering weight wool for the pattern weft. The weaving draft has 50 threads in one threading repeat. My design repeats on the loom are around 2.5″ wide and just under 5″ long, which is a great size for the 30″ x 99″ throw I’m weaving.

This is a non negotiable for overshot if you want neat edges and less headaches! You get used to using floating selvedges very quickly, so don’t stress if you have no experience with them.

There are 6 treadles needed for overshot, even though you weave on 4 shafts. The two extra treadles are for the tabby weave. I always set up my pattern treadles in the centre of the loom – two on the left and two on the right. Then I set up a “left” tabby and a “right” tabby treadle. To do this on my 8 shaft loom I leave a gap between the pattern treadles and the tabby treadles so that my feet can “see” and differentiate between a pattern and tabby treadle.

I like to advance little and often. You will find your own preference or “sweet spot” for weaving, but I find that with overshot I advance a lot more frequently at a much smaller amount than I do usually.

An example of this is that I wove an overshot sampler right before Is started my main project (the throw). It was a narrow warp (around 8″) and a different overshot threading and treadling than I’m using for the project.

I personally do not use a temple. Some weavers will say they won’t weave without one. I’ve tried using a temple on many of my projects, particularly if I’m getting broken edge warp threads (signs of tension problems and too much draw in). But I will avoid using one wherever I can get away with it, and I don’t use one for weaving overshot.

I find that if I’m careful with weft tension and warping evenly, I do not get excessive draw in. It is something I’m constantly aware of while weaving and remind myself of tip 4 so that my weft picks are not pulling in at the edges.

Classes are emailed to you as a downloadable pdf ebook. Just save the pdf to your computer, device or cloud storage - you have access to it forever! You can work at your own pace. Inside the ebook are links to videos. Use whatever materials you have on hand to practice the techniques.

Patterns, videos, written instructions, photos, and pdf designs are copyright. If you purchased a class and created the project, you are more than welcome to sell the piece if you wish. You made it, so be proud! However, please do not purchase my classes and share/sell the techniques or patterns via YouTube, Instagram Stories/Posts, Workshops, etc. I only ask that while you are showing off your amazing new skills, you send anyone who is interested in learning my way, instead. Thanks!

Weave structures often have specific threading and treadling patterns that are unique to that particular weave structure and not shared with others. This book takes you out of the traditional method of weaving overshot patterns by using different treadling techniques. This will include weaving overshot patterns such as Summer/Winter, Italian manner, starburst, crackle, and petit point just to name a few. The basic image is maintained in each example but the design takes on a whole new look!

Each chapter walks you through the setup for each method and includes projects with complete drafts and instructions so it’s easy to start weaving and watch the magic happen! Try the patterns for scarves, table runners, shawls, pillows, and even some upholstered pieces. Once you"ve tried a few projects, you"ll be able to apply what you"ve learned to any piece you desire!

Author of the popular Overshot Simply and Shadow Weave Simply now shares her explorations of overshot weaving structures. Her teaching style is to break down the weave structure into its basic parts so that it is easy to understand, and then teach you how the parts work together to create the weave structure so that you can use any pattern or create your own.

Overshot is a magical structure. The first time you weave it you can hardly believe the cloth that grows on your loom. Traditionally used to weave bed coverings, overshot has many beautiful applications in today"s world, from useful household textiles to breathtaking works of art. This versatile weave is subject to endless variations. Here are a few of our favorite tips and a few truly spectacular projects, too! If you are inspired, come visit us and learn from a master weaver, Joanne Hall. See details below about her workshop.

A slouchy bag by FiberMusings on Weavolution pairs leftover BFL singles with sturdy Cottolin to create a fashionable yet functional multi-colored bag. The draft is a design from Ann Weaver"s Handweavers Pattern Dictionary, and it"s a great way to integrate Overshot techniques while making an eye-catching accessory!

Another project that caught our eye recently was a shower curtain shared by GailR@30 shared on Weaving Today - it"s nothing short of amazing (click here to see for yourself)! Consisting of thirteen different overshot pattern threadings woven in thirteen different treadlings, 169 different design effects are created based on designs from Osma Gallinger Tod"s book The Joy of Handweaving. As Gail noted on her project page, a great way to make each design stand out is to separate them with twill bands (even though it might mean a little more work in the process!)

Or, you may choose to elevate your weaving like the work of art it most certainly is, as Evaweave did with her Overshot Study pieces. These two miniature silk rugs look lovely in a frame, don"t you think? The overshot pattern was adapted from Overshot Weaving by Ellen Lewis Saltzman, complementing one another perfectly.

Think overshot is too difficult to try? Deb Essen thinks otherwise! Fiber artist, designer, and teacher, Deb is a passionate weaver who specializes in using overshot name drafts to create "secret messages" in cloth.

On her website, she explains: "Overshot is a weave structure and a draft is the weaver"s guide to creating patterns in cloth. Overshot name drafts assign the letters of a name or phrase to the shafts on a loom, creating a pattern that is unique. The one-of-a-kind patterns become a secret hidden message in the cloth and only those knowing the secret can break the code."

Deb lets you in on the secret with her clever kits, each with a hidden message. We"re particularly fond of her That"s Doable kit, which features Mountain Colors hand-painted yarns and, as the name would imply, is our first choice for those new to overshot weaving.

Overshot is perhaps the most iconic weaving technique--think antique coverlets and fancy table runners--yet many weavers are intimidated by its complex-looking structure. But it doesn"t have to be difficult! In this book, Susan Kesler-Simpson makes overshot approachable by breaking it down piece by piece so that the weaver understands how it works, and then she puts it all back together so that weavers will have the confidence to make their own overshot patterns or to try any of the 38 overshot projects she has designed for the book.

Others"Susan’s explanations are to the point and easy to understand. When you read through the chapters, it’s as if Susan is sitting there with you, telling you in a friendly voice how to weave overshot step by step."--excerpt from the Foreword by Tom Knisely

Centerpiece sized handwoven tabletop runner crafted by Kate Kilgus, Harrisville, New Hampshire. Overshot weaving in royal blue and white cottons. This handcrafted textile can be used on the dining table, buffet, bureau, or coffee table. A two shuttle weave, overshot allows for the creation of curves

“The Mermaid Scarf & the Freeform Overshot Technique" 20-page FULL COLOR eBooklet By Lisa Rayner NOTE: CHART NOT INCLUDED. Purchase the chart for my 2018 Mermaid Scarf 2.0 separately. This ebooklet is a freeform overshot technique primer that uses my 2015 Mermaid Scarf and five freeform overshot projects woven by other people around the world as examples. I wove my original Mermaid Scarf 1.0 with a PICK UP STICK on my 25-inch-wide Schacht Flip rigid heddle loom. Warp 3/2 weaving cotton, tabby weft 10/2 weaving cotton, pattern weft fingering wool singles. Watch my short freeform overshot video on my Lisa Rayner Handwoven"s Facebook page: https://www.facebook.com/lisaraynerhandwovens. This booklet contains: * A detailed description of the weave structure of freeform overshot. * Close-up photographs of the BACK of my Mermaid Scarf showing design detail. * A description of my creative process and inventing the technique. * A detailed, easy-to-follow description of how to weave a Mermaid-style scarf of your own (no pattern chart). * Excerpts and photographs from blog posts I wrote while I was weaving the scarf. * Directions on how to apply the freeform overshot technique to any weaving project. * Photographs of freeform overshot scarves and comments from five other weavers. * How to use weaving software to design freeform overshot patterns. * How to weave freeform overshot-style patterns on a dobby loom. Handwoven magazine published my short article on my Mermaid Scarf in the Nov./Dec. 2015 issue. This ebooklet is MUCH longer, MORE detailed, and easier to follow than the magazine article. The article was only three pages long and the editors shortened my version of the article even further. This ebooklet is 20 pages long and includes a lot of written information and many color photos not included in the magazine article. Reading this eBooklet requires Adobe Acrobat Reader 8.0 or newer. This booklet does NOT contain a Mermaid Scarf chart. In November 2018, I finally designed and charted a Mermaid Scarf 2.0. You can purchase this pattern chart separately in this shop: https://www.etsy.com/listing/650996510/ebook-mermaid-scarf-pattern-20-freeform?ref=shop_home_feat_3&pro=1. A Mermaid Scarf Yarn Kit is also available. It includes the warp and tabby weft in different color choices and the Wisdom Poems sock yarn pattern weft included in the original: https://www.etsy.com/listing/651253852/mermaid-scarf-yarn-kit-only-yarn-only?ref=shop_home_feat_4. I also sell a COMPLETE kit that includes the Mermaid Scarf 2.0 Yarn Kit, Mermaid Scarf 2.0 chart, and freeform overshot ebooklet here: https://www.etsy.com/listing/654077978/complete-mermaid-scarf-20-freeform?ref=shop_home_active_1&frs=1. Do you wish you could weave fabric with complex Jacquard-like patterns? Do you like tapestry motifs, but want to weave wearable, drapeable cloth? You can weave such fabrics on any loom, from rigid heddle looms, pin looms, backstrap looms, and even full size inkle looms, to simple shaft looms, multishaft table and floor looms, and dobby looms using the freeform overshot technique. Most looms require freeform overshot to be woven with a pick up stick. All rights reserved. No part of this booklet may be duplicated, reprinted or shared electronically without written permission from the author, except for brief quotes and reviews. Respecting copyright supports the important work of authors. In addition, my patterns are for personal use only, not commercial use. Thank you.
