api 5ct manual pup joint price

Find parts you need to repair or maintain your machines. At Alibaba.com, you can shop for pup joint drill pipe at affordable rates to tackle new obstacles and challenges. In the ever-changing industry, you can find what you need and speak to the supplier directly. Thanks to Alibaba’s collection of wholesale pup joint drill pipe you also get to buy these parts at lower prices, which means you can explore new levels every day more comfortably. From bulldozers to dragline excavators, wheel tractor scrapers to shotcrete machines, any part you need for a heavy-duty mining machinery; you can find it at Alibaba.com.

Looking for purpose-built machine parts? Find them at Alibaba.com. From new components to used parts straight from the manufacturers. Plus, if you need custom-made pieces, you can chat with the supplier, give specifications and wait on delivery. From stone crushers to excavator undercarriage parts, buckets, and even drill bits to get you through the rocks, the pup joint drill pipe from Alibaba offers you the chance to continue operating without a hitch. Whether you are looking to introduce concrete into the rock walls for more consistency and safety during mining, then pup joint drill pipe that goes at wholesale prices at Alibaba will be an excellent addition to your machinery.

Before buying a component, you’d want the equipment to suit your application and offer value. The list of pup joint drill pipe at Alibaba.com lets you dig into earth deposits, and the compare tool checks out other similar parts to give you the information you need to make a purchasing decision. You’ll get wholesale pup joint drill pipe that specializes in mining, with reinforced chassis, and run on more powerful engines. Whether you want to transport minerals or the workers to the mining site, introduce explosives or arms to help you remove materials from your mine pits, Alibaba.com has it all.

A wide variety of pup joints and crossovers options are available to you, such as energy & mining, construction works  and retail.You can also choose from unavailable, 1.5 years and 6 months pup joints and crossovers,As well as from provided, {2}, and {3}. and whether pup joints and crossovers is kazakhstan, russia, or egypt.

We manufacture pup joints in all sizes, grades, and thread profiles to meet any requirement. Our tubing pup joints are manufactured out of seamless tubing and machined or upset to final dimensions. All API casing and tubing pup joints are manufactured according to API Spec 5CT. Special requirements are available on request.

Pup joint is kind of pipe without non-standard length to adjust the length of tubular strings to its exact requirement. API casing and tubing pup joint are produced according to API SPEC 5CT standard. Beyond the standard of oil casing pipe is called pup joint, the main oil casing pup joint material: J55, K55, N80, L80, C90, T95 and P110. Anson steel is a professional pup joint manufacturers in the steel line with good reputation.

  Casing or Tubing Pup Joints at Group 1, J55/PSL 1, K55/PSL 1, N80(1)/PSL 1;  Manufacture Accessories at Group 1, J55/PSL 1, K55/PSL 1, N80(1)/PSL 1;  Threader.

  Casing or Tubing Pup Joints at Group 1, J55/PSL 1, K55/PSL 1, N80(1)/PSL 1;  Manufacture Accessories at Group 1, J55/PSL 1, K55/PSL 1, N80(1)/PSL 1;  Threader.

API Spec 5CT Licensing Information Form, Product Removal, Changes and Additions under the API Monogram ProgramPlease be advised that the API Spec 5CT Licensing Information Form has been updated with changes that include product removal, product gradechanges, and product naming changes.Changes to the API Spec 5CT Licensing Information Form include:• • Group selections 1, 2, 3 and 4 have been removed

• • Product “Threader” is now product “Pipe Threader” 1-1. Licensees can transition to a registration under API Spec Q1. Facilities interested in the transition to API Spec Q1 certification shall apply prior to July 1, 2019. Applications can be submitted through the myCerts system (mycerts.api.org).

PUP JOINTS are a joint of pipe of non-standard length used to adjust the length of tubular strings to exact requirement. We provide both tubing (2 3/8” to 4”) and casing (4” to 13 3/8”) in all lengths. With our myriad of licenses (quality page) we are able to cut to length, thread and couple to meet specified needs. API casing and tubing pup joints are manufactured according to API Spec 5CT using prime API monogrammed, seamless oil country tubing. Premium pup joints are also available with premium connections and in API or exotic alloy grades.

MARKER JOINTS are a joint of tubing used in a workover or completion tubing string that serves as a position or depth indicator. In most cases, a marker joint is significantly shorter than other joints in the string so that it is easily noticeable.

BLAZE is adequately equipped to supply NPST Pup joints made of high quality seamless pipeline with  male & female detachable hammer union. NPST has uniform bore for greater flow capacity. NPST pup joints are available in 2″ to 4″ sizes, length for pup joint range from 1 feet to 20 feet at 15000 psi. Pup joint with Non- pressure seal thread union (NPST) are especially engineered for high pressure, abrasive services where welded connections are not desired. The design provides a strong, permanent end connection without butt welding. An epoxy thread-locking compound secures the connection.

Casing or Tubing Pup Joints, Casing or Tubing Connectors and Casing or Tubing Couplings. In addition it is capable of Threading items at Groups 1, 2, 3 & 4 of API spec. 5CT. Items supplied by BLAZE meet the Quality Standards as defined in API 5CT assuring

BLAZE is also well equipped to supply Line Pipe Couplings/ NPST pup joints with wide range of specifications. In addition we can supply thread Line Pipes and its accessories of various sizes. Items meet the quality standards as laid down in API – 5L.

APT 5CT specified the requirements of Casing and tubing for the purpose of oil or gas production, must be cased with material with sufficient strength and functionality.

The length of the oil casing pipe must be defined when the customer inquiries. As a casing tubing supplier and manufacturer,we are according with API 5CT strictly.Our all tubing meet API minimum requirements.It"s remarkable that the following requirements should be specified on the purchase order:

The price of pipe is also different as the tubing length change, so it is necessary to make the length of the pipe clear.Here we will discuss the length of API 5CT casing and tubing.Piping lengths from the factory not exactly cut to length but are normally delivered as:

Range 1 from 18 to 20 ft ,Range 2 from 27 to 30 ft and Range 3 from 38-45 feet.Range 2 is normally used. Shorter tubing joints (pup joints) are available in 2-, 3-, 4-, 6-, 8-, 10-, and 12-ft lengths with a tolerance of ± 3 in. A complete set of tubing pups with the same connections as the tubing string typically is purchased for each well.

In this article, the last updated list of API & ISO standards for Tubulars (Casings, Tubings, Threads, Drill Pipe, Line Pipe) is presented. These standards can be considered as reference documents as well as a basis for training classes in the subject of Tubular Goods.

API RP 5A3/ISO 13678:2010 – Recommended Practice on Thread Compounds for Casing, Tubing, Line Pipe, and Drill Stem Elements (includes Errata 1 dated April 2011):

API RP 5A3 provides requirements, recommendations, and methods for the testing of thread compounds intended for use on threaded casing, tubing, and line pipe connections and for thread compounds intended for use on rotary shouldered connections. The tests outlined are used to evaluate the critical performance properties and physical and chemical characteristics of thread compounds under laboratory conditions.

API RP 5A5 specifies requirements and gives recommendations for field inspection and testing of oil country tubular goods (OCTG). This International Standard covers the practices and technology commonly used in field inspection;

Spec 5B covers dimensions and marking requirements for API Master thread gauges. Additional product threads and thread gauges, as well as instruments and methods for the inspection of threads for line pipe, round thread casing, buttress casing, and extreme-line casing connections, are included. It is applicable when so stipulated in the API standard governing the product. The inspection procedures for measurements of taper, lead, height, and angle of thread are applicable to threads having 111/2 or less turns per in. (111/2 or less turns per 25.4 mm). All thread dimensions shown without tolerances are related to the basis for connection design and are not subject to measurement to determine acceptance or rejection of product. Pages: 125.

This bulletin is not intended as a design manual. Its purpose is to provide minimum performance properties on which the design of casing, tubing, and drill pipe strings may be based.

The purpose of this bulletin is to show the formulas used in the calculation of the various pipe properties given in API standards, including background information regarding their development and use. This bulletin is under the jurisdiction of the Committee on Standardization of Tubular Goods.

API TR 5C3/ISO 10400:2007 – Technical Report on Equations and Calculations for Casing, Tubing, and Line Pipe used as Casing or Tubing; and Performance Properties Tables for Casing and Tubing (includes Addendum 1 dated October 2015):

API RP 5C5 establishes minimum design verification testing procedures and acceptance criteria for casing and tubing connections for the oil and natural gas industries. These physical tests are part of a design verification process and provide objective evidence that the connection conforms to the manufacturer’s claimed test load envelope and limit loads.

API RP 5C6 created to provide a standard industry practice for the shop or field welding of connectors to pipe. The technical content provides requirements for welding procedure qualification, welder performance qualification, materials, testing, production welding, and inspection. Additionally, suggestions for ordering are included. Pages: 7.

This standard specifies the technical delivery conditions for steel pipes (casing, tubing, and pup joints), coupling stock, coupling material, and accessory material and establishes requirements for three Product Specification Levels (PSL-1, PSL-2, PSL-3). The requirements for PSL-1 are the basis of this standard. The requirements that define different levels of standard technical requirements for PSL-2 and PSL-3, for all grades except H-40, L-80 9Cr, and C110, are contained in Annex H. This standard can also be applied to tubulars with connections not covered by API standards. This standard is not applicable to threading requirements. This standard is based on the 8th Edition of Spec 5CT. Pages: 269.

Spec 5DP specifies the technical delivery conditions for steel drill-pipes with upset pipe-body ends and weld-on tool joints for use in drilling and production operations in petroleum and natural gas industries for three product specification levels (PSL-1, PSL-2, and PSL-3). This International Standard covers the following grades of drill-pipe:

This International Standard can also be used for drill-pipe with tool joints not specified by ISO or API standards. This International Standard is based on Spec 5D and Spec 7.
