A pup joint is Casing, Pipe or Tubing shorter in length than a standard tubular string. This allows for the adjustment and installation of tools and various tubular components when placement downhole is critical for a specific project. A Spacer Pipe is another reference used to identify pup joints. Pup joint features consist of connections, lengths, weights and material grade.

Crossover pup joints are manufactured from seamless mechanical tube. As with all Crossover products, each piece is marked with a distinctive job number and heat number that is fully traceable. A complete range of sizes (1" to 4.5"), weights (standard or heavy wall), and grades (J-55, N-80, L-80, and P-110) are commonly available from stock in 2", 3", 4", 6", 10", and 12" lengths. Lengths up to 20" are available upon request.

Manufactured according to API Spec 5CT using prime API monogrammed, seamless oil country tubing. Optional diameters, lengths, weights, and grades are available upon request.

Seamless pup joints with premium connections are available in API and exotic alloy grades. Premium ends are threaded by the manufacturer or authorized licensee.

Available with standard or special perforation spacings. Each joint has four rows of ⅜ inch holes drilled longitudinally along the tube. Optional patterns, hole size, and lengths furnished upon request.

Crossover, Inc. handles many types of API Couplings. As a rule, we stock enough of your common couplings which enable us to ship the same day if needed. We carry in stock J-55, L-80, N-80, and P-110. As for sizes, we carry 2 3/8”, 2 7/8” 3 ½”, 4 ½” tubing and some of the casing sizes up to 13 3/8”. Stock connections are EU 8 Rd., Nu 10 Rd., LTC, STC, and BTC. Our couplings are primarily of USA manufacture. If origin is not important, we can source other origins and sometimes beat the USA manufactured cost.

We manufacture a wide range of Crossover Couplings. Couplings are used to connect two sizes of pipes, or two different dissimilar threaded parts together. We offer special clearance couplings, special clearance couplings with bevels on both ends, and couplings with the API Seal Ring Modification.

Crossover swages are made from API grades of pipe and mechanical tubing. Rigid quality standards are maintained throughout the manufacturing process by frequent inspection and testing. Raw material quality is assured by our quality assurance program.

A blast joint is shorter in length than standard tubular joint. Built with a heavy wall pipe it is incorporated in the production string to facilitate production across any perforated interval and zone. Blast Joints are manufactured to the following specs connections, lengths, weights and material grade.

Crossover Blast Joints are heavy wall pin by box connectors used in tubing strings and are designed to minimize the effect of external erosive action caused by production fluids. Blast joints are located opposite the location of perforations in the production casing or just below the tubing hanger in sand frac designs. Crossover blast joints are manufactured from seamless mechanical tube in sizes ranging from 2 3/8” to 4 1/2” OD. Any length, grade of material, and threading is available at the customers request. Typical lengths are 10" and 20". Both API and Premium threads are available.

Crossover Flow Couplings are heavy wall box by box connectors used in tubing strings and are designed to minimize the effect of internal erosive action caused by production fluids. Flow couplings are located just above or below Landing Nipples, Safety Valves or Control Devices where turbulent flow problems are likely to occur. Crossover flow couplings are manufactured from seamless mechanical tube in sizes ranging from 2 3/8” to 4 1/2” OD. Any length, grade of material, and threading is available at the customers request. Typical lengths are 3" and 6". Both API and Premium threads are available.

Crossover Coarse Thread Tubing Safety Joint provides for emergency recovery of the major portion of the tubing string should it become necessary to abandon the equipment below. Precision left-hand threads facilitate the release of the joint by right-hand tubing rotation. Equipment requiring right-hand rotation should not be used below the Safety joint.

Crossover Straight-Pull/Shear-Out Safety Joint is used between packers in dual and triple completions and in selective completions using Hydrostatic Single-String Packers. It is also used when rotational releasing is not desired. When ran above the upper packer in a single-string completion, however, the shear value should be adjusted to compensate for any hydraulic conditions that exist when the string is landed, or that are created by well treating operations. They are available in keyed and non-keyed configurations.

Crossover can build these in any of the regular API Grades such as J-55, L-80, or P-110. These are usually only made going up or down one size in either direction such as ¾” to 1” or 1 ½” to 2”.

A saver sub falls under the drill string accessory tool category and a short pipe that is replaceable and expendable without a major investment. This accessory protects the Kelly or topdrive component threads and those components represent a significant capital cost and considerable downtime when replaced. Saver sub are manufactured to the following specs connections, lengths, weights and material grade.

Crossover rotary shoes are manufactured from specially tempered steel to provide the ultimate in toughness and durability. They are used to cut a clearance between the fish and the wall of the well bore. Each shoe is tailored to fit a particular downhole need and normally is run on the bottom of one or more joints of washover pipe. Shoe design is dictated by whether it cuts on the bottom, on the OD, on the ID, or any combination of these. When hole sizes permit, additional clearances can be cut using side ribs, thus providing greater circulation.

  Casing or Tubing Pup Joints at Group 1, J55/PSL 1, K55/PSL 1, N80(1)/PSL 1;  Manufacture Accessories at Group 1, J55/PSL 1, K55/PSL 1, N80(1)/PSL 1;  Threader.

  Casing or Tubing Pup Joints at Group 1, J55/PSL 1, K55/PSL 1, N80(1)/PSL 1;  Manufacture Accessories at Group 1, J55/PSL 1, K55/PSL 1, N80(1)/PSL 1;  Threader.

API Spec 5CT Licensing Information Form, Product Removal, Changes and Additions under the API Monogram ProgramPlease be advised that the API Spec 5CT Licensing Information Form has been updated with changes that include product removal, product gradechanges, and product naming changes.Changes to the API Spec 5CT Licensing Information Form include:• • Group selections 1, 2, 3 and 4 have been removed

• • Product “Threader” is now product “Pipe Threader” 1-1. Licensees can transition to a registration under API Spec Q1. Facilities interested in the transition to API Spec Q1 certification shall apply prior to July 1, 2019. Applications can be submitted through the myCerts system (mycerts.api.org).

Summary of Product Specification Level (PSL) RequirementsJ.1 GeneralThis informative annex is provided for the convenience of the user of this standard and identifies the places whereadditional requirements are detailed when product is ordered to PSL-2 or PSL-3.Detailed requirements are given in the sub-sections indicated in square brackets [ ] after each item.The PSL-3 requirements are in addition to the PSL-2 requirements.There are no PSL-2 or PSL-3 requirements for Grade H40.J.2 Grades J55 and K55J.2.1 PSL-2The following requirements shall be satisfied:a) Full-body, full-length heat treatment (after upsetting if applicable) [H.2.1].b) Mandatory Charpy V-notch impact testing and requirements (according to K.9 (SR 16)) [H.6.2.1].c) No product to be susceptible to having material detach during make-up (appropriate processing or abrasiveblasting) [H.10 and H.12].d) Seal-ring groove machining and tolerances [H.11].e) Metallographic examination of the weld zone [H.15].f) Alternative test pressures for Label 1 larger than 9 5/8 [H.16].g) Wall thickness measurement with 25 % coverage [H.17.1].h) NDE for longitudinal internal and external defects to acceptance level L4 [H.18.1.1].i) K55 only: Ultrasonic testing of the weld seam after hydrotest [H.18.2].j) Seal-ring to be shipped separately [H.19].J.2.2 PSL-3The following requirements shall be satisfied:a) Wall thickness measurement with 100 % coverage, report the minimum wall thickness [H.17.2].b) NDE for longitudinal and transverse, internal and external defects to acceptance level L2 (no MPI) [H.18.1.4].c) NDE of pipe ends after end finishing [H.18.3].J.3 Grades N80, (all types)J.3.1 PSL-2The following requirements shall be satisfied:a) Charpy V-notch impact shear area minimum of 75 % [H.6.1].b) Mandatory Charpy V-notch impact testing and requirements (according to K.9 (SR 16)) [H.6.2.1].c) No product to be susceptible to having material detach during make-up (appropriate processing or abrasiveblasting) [H.10 and H.12].d) Seal-ring groove machining and tolerances [H.11].e) Tensile test frequency as for Grade L80 [H.13].f) Metallographic examination of the weld zone [H.15].g) Wall thickness measurement with 25 % coverage [H.17.1].h) NDE for longitudinal and transverse, internal and external defects to acceptance level L3 (no MPI) [H.18.1.2].i) Seal-ring to be shipped separately [H.19].J.3.2 PSL-3The following requirements shall be satisfied:a) Only grade N80Q shall be furnished for PSL-3 [H.2.2].b) Process control plan or surface hardness test of each pipe body, upset end and coupling [H.14.1].c) Wall thickness measurement with 100 % coverage, report the minimum wall thickness [H.17.2].d) NDE: mandatory ultrasonic test plus one other method [H.18.1.5].e) NDE of pipe ends after end finishing [H.18.3].J.4 Grade L80 Type 1J.4.1 PSL-2The following requirements shall be satisfied:a) Charpy V-notch impact shear area minimum of 75 % [H.6.1].b) Mandatory Charpy V-notch impact testing and requirements (according to K.9 (SR 16)) [H.6.2.1].c) Minimum martensite content of 90 % (based on a minimum Rockwell C-scale hardness for an as-quenchedsample) [H.7.1].d) No product to be susceptible to having material detach during make-up (appropriate processing or abrasiveblasting) [H.10 and H.12].e) Seal-ring groove machining and tolerances [H.11].f) Metallographic examination of the weld zone [H.15].g) Wall thickness measurement with 25 % coverage [H.17.1].h) NDE for longitudinal and transverse, internal and external defects to acceptance level L2 [H.18.1.3].i) NDE of coupling stock sold as coupling stock [H.18.4].j) Seal-ring to be shipped separately [H.19].J.4.2 PSL-3The following requirements shall be satisfied:a) Surface hardness test of each pipe body, upset end and coupling [H.14.1].b) Wall thickness measurement with 100 % coverage, report the minimum wall thickness [H.17.2].c) NDE: mandatory ultrasonic test plus one other method [H.18.1.5].d) NDE of pipe ends after end finishing [H.18.3].e) NDE of coupling stock [H.18.5].J.5 Grade L80 13CrJ.5.1 PSL-2The following requirements shall be satisfied:a) Mandatory Charpy V-notch impact testing and requirements (according to K.9 (SR 16)) [H.6.2.1].b) Inside surface preparation [H.8].c) No product to be susceptible to having material detach during make-up (appropriate processing or abrasiveblasting) [H.10 and H.12].d) Seal-ring groove machining and tolerances [H.11].e) NDE for longitudinal and transverse, internal and external defects to acceptance level L2 [H.18.1.3].f) NDE of coupling stock sold as coupling stock [H.18.4].g) Wall thickness measurement with 25 % coverage [H.17.1].h) Seal-ring to be shipped separately [H.19]..5.2 PSL-3The following requirements shall be satisfied:a) SSC test: for NACE TM0177-2016 Method A, demonstrate a threshold stress of 80 % of the specified minimumyield stress in a test solution with pH 3.5 and a hydrogen sulfide partial pressure of 0.1 bar (1.5 psi) [H.9.2].b) Wall thickness measurement with 100 % coverage, report the minimum wall thickness [H.17.2].c) NDE: mandatory ultrasonic test plus EMI for the outside surface [H.18.1.5].d) NDE of pipe ends after end finishing [H.18.3].e) NDE of coupling stock [H.18.5].J.6 Grades C90 and T95J.6.1 PSL-2The following requirements shall be satisfied:a) Hot straightening requirement with a minimum temperature or cold straightening followed by stress relief [H.3.1].b) Charpy V-notch impact shear area minimum of 75 % [H.6.1].c) Mandatory Charpy V-notch impact testing and requirements (according to K.9 (SR 16)) [H.6.2.1].d) No product to be susceptible to having material detach during make-up (appropriate processing or abrasiveblasting) [H.10 and H.12].e) Seal-ring groove machining and tolerances [H.11].f) Wall thickness measurement with 25 % coverage [H.17.1].g) NDE of coupling stock sold as coupling stock [H.18.4].h) Seal-ring to be shipped separately [H.19].J.6.2 PSL-3The following requirements shall be satisfied:a) Information on chemical composition [H.4.2].b) Minimum martensite content of 95 % (based on a minimum Rockwell C-scale hardness for an as-quenchedsample) [H.7.2].c) SSC test: for NACE TM0177-2016 Method A, test three pipes per heat at an applied stress of 90 % of thespecified minimum yield stress [H.9.1].d) Through-wall hardness test of both ends of each pipe [H.14.2].e) Wall thickness measurement with 100 % coverage, report the minimum wall thickness [H.17.2].f) NDE of pipe ends after end finishing [H.18.3].g) NDE of coupling stock [H.18.5].J.7 Grade R95J.7.1 PSL-2The following requirements shall be satisfied:a) Hot straightening requirement with a minimum temperature or cold straightening followed by stress relief [H.3.2].b) Charpy V-notch impact shear area minimum of 75 % [H.6.1].c) Mandatory Charpy V-notch impact testing and requirements (according to K.9 (SR 16)) [H.6.2.1].d) No product to be susceptible to having material detach during make-up (appropriate processing or abrasiveblasting) [H.10 and H.12].e) Seal-ring groove machining and tolerances [H.11].f) Metallographic examination of the weld zone [H.15].g) Wall thickness measurement with 25 % coverage [H.17.1].h) NDE for longitudinal and transverse, internal and external defects to acceptance level L4 [H.18.1.3].i) NDE of coupling stock sold as coupling stock [H.18.4].j) Seal-ring to be shipped separately [H.19].J.7.2 PSL-3The following requirements shall be satisfied:a) Surface hardness test of each pipe body, upset end and coupling [H.14.1].b) Wall thickness measurement with 100 % coverage, report the minimum wall thickness [H.17.2].c) NDE: mandatory ultrasonic test plus one other method [H.18.1.5].d) NDE of pipe ends after end finishing [H.18.3].e) NDE of coupling stock [H.18.5].J.8 Grade P110J.8.1 PSL-2The following requirements shall be satisfied: a) Hot straightening requirement with a minimum temperature or cold straightening followed by stress relief [H.3.2]. b) b) Charpy V-notch impact shear area minimum of 75 % [H.6.1]. c) c) Mandatory Charpy V-notch impact testing and requirements (according to K.9 (SR 16)) [H.6.2.1]. d) d) No product to be susceptible to having material detach during make-up (appropriate processing or abrasive e) blasting) [H.10 and H.12]. f) e) Seal-ring groove machining and tolerances [H.11]. g) f) Wall thickness measurement with 25 % coverage [H.17.1]. h) g) NDE of coupling stock sold as coupling stock [H.18.4]. i) h) Seal-ring to be shipped separately [H.19]. j) J.8.2 PSL-3 k) The following requirements shall be satisfied: l) a) Surface hardness test of each pipe body, upset end and coupling [H.14.1]. m) b) Wall thickness measurement with 100 % coverage, report the minimum wall thickness [H.17.2]. n) c) NDE: mandatory ultrasonic test plus one other method [H.18.1.5]. o) d) NDE of pipe ends after end finishing [H.18.7]. p) e) NDE of coupling stock [H.18.5]. q) J.9 Grade Q125 r) J.9.1 PSL-2 s) The following requirements shall be satisfied: t) a) Charpy V-notch impact shear area minimum of 75 % [H.6.1]. u) b) Statistical impact testing according to K.7 (SR 12) [H.6.2.2]. v) c) No product to be susceptible to having material detach during make-up (appropriate processing or abrasive w) blasting) [H.10 and H.12]. x) d) Seal-ring groove machining and tolerances [H.11]. y) e) Wall thickness measurement with 25 % coverage [H.17.1]. z) f) NDE of coupling stock sold as coupling stock [H.18.4]. aa) g) Seal-ring to be shipped separately [H.19].

J.9.2 PSL-3The following requirements shall be satisfied:a) Maximum yield strength of 965 MPa (140 ksi) specified [H.5].b) Surface hardness test of each pipe body, upset and coupling [H.14.1].c) Wall thickness measurement with 100 % coverage, report the minimum wall thickness [H.17.2].d) NDE of pipe ends after end finishing [H.18.3].e) NDE of coupling stock [H.18.5].

Pup joints are a type of non-standard length pipe which is often utilized to adjust tubular strings to individual requirements. API casing and tubing pup joints are manufactured according to API Spec 5CT with API monogrammed, seamless oil country tubing. These joints are also used to adjust the height of full-length tubing and casing and are mainly applied as depth markers for drill strings, Products on tubing, or casing. A pup joint is widely used in the energy sector, including renewable electricity, coal, and gas. These applications include interconnecting flow lines, full traceability, and customized lengths based on the client"s requirements.

Further, the Pup Joint market is segmented by Product Type, Technology, End-User, and geography. Based on Product Type, the Pup Joint market is segmented under Crossover Pup Joint, Tubing Pup Joint, and Drill Pipe Pup Joint. Based on the Technology, the Pup Joint market is segmented under Hot Rolled and Cold Rolled. Based on End-User, the Pup Joint market is segmented under Chemical Industry, Mining,Oil & Gas, Construction, and Others. By geography, the market covers the following regions: North America, Europe, Asia-Pacific, South America, and Middle East & Africa. For each segment, the market sizing and forecasts have been done on the basis of value (in USD Million).

The key factors affecting the industry include technological advancements in drilling techniques and faster industrialization in developing countries. In addition, the rise in population will lead to an increase in the demand for natural gas and oil, which will help the pup joint market flourish during the forecast period. Growth in the demand for high-grade pup joints within various industry verticals is expected to boost the market growth during the forecast period. Additionally, the increase in energy consumption, economic development of the shipping industry, and surge in seaborne trade are the major factors driving the market.

The majority of major companies are focusing on upgrading their equipment according to market needs in the coming years. Key players are focusing on developing products that would benefit the industry in the next few years. As an example, Ace Oil Tools introduced its new Ace Splice Clamp (ASC) to the completions market. The ASC allows multiple lines to be spliced with a single clamp and protects control lines during the completion process. Ace Splice Clamps attach to tubing or pup joints, providing the same reliability and functionality that is usually offered by submersibles. The increase in launches will help the industry to grow during the forecast period.

Renewable offshore wind energy is becoming increasingly affordable, environmental-friendly and cost-effective. It will help to reduce greenhouse gases. During the forecast period, renewable energy is expected to be more affordable than existing oil and gas sources. It will act as a restraint on the global pup joint market.

A boom in demand for pup joints to be used for untapped businesses is where key players are focusing their efforts. This is leading to advancements in the coming years and giving opportunities to key players. To increase revenue generation, major players are focusing on acquiring more companies so that they can use the distribution channels of the acquired companies. This is a significant opportunity for key players.

COVID-19 has greatly affected the world economy in a negative way, which is why the pup joint market suffered a decrease in revenue. The government of several countries implemented strict regulations on pup joints, which greatly negatively affected the market. Moreover, the lockdown situation is causing industries to focus on innovations, which could help gain the attention of the majority of players during the forecast period.

By Product Type,the Pup Joint Market is segmented into Crossover Pup Joint, Tubing Pup Joint, and Drill Pipe Pup Joint. The Tubing Pup Joint segment had the highest market share in 2021. Because these pup joints are also used to handle production tubing accessories, the tubing pup joint segment is expected to have a huge demand. A tubing pup joint is a short piece of tubing that is used for spacing.

By Technology, the Pup Joint Market is segmented into Hot Rolled and Cold Rolled. The Hot Rolled segment had the highest market share in 2021.The most common type of pup joint is the hot-rolled pup joint. Steel is heated to a high temperature and then rolled into a cylindrical shape. This type of pup joint has higher tensile strength, but it is also less corrosion resistant.

By End-User, the Pup Joint Market is segmented into Chemical Industry, Mining, Oil & Gas, Construction, and Others. The Oil & Gas segment had the highest market share in 2021, and it will boost the market growth during the forecast period.As various emerging economies rely on petroleum-based products, dependence on oil & gas has increased. Petroleum is used to make various chemical products, including fertilizers, pharmaceuticals, and solvents. Private and public companies are showing interest in exploring new oil reserves to meet future demand. Investment by major companies in oil exploration is expected to boost the market for pup joint ventures.

The North America region held the highest market share in 2021.The pup joint industry is the leading revenue generator for the North American market. The growing demand for energy from the oil & gas and chemical industries in this region is driving the growth of this market. As a result of technological advancements and an increase in foreign direct investment for various exploration projects, manufacturers are also entering new markets in developing countries like Mexico and Canada.

The market"s major companies have a significant impact because most of them have extensive global networks through which they can reach their massive client bases. To drive revenue growth and strengthen their positions in the global market, key players in the market, particularly in North America and Europe, are focusing on strategic initiatives such as acquisitions, new collection launches, and partnerships.

The objective of the report is to present a comprehensive analysis of theGlobalPup Joint market to the stakeholders in the industry. The report provides trends that are most dominant in the GlobalPup Joint market and how these trends will influence new business investments and market development throughout the forecast period. The report also aids in the comprehension of theGlobalPup Joint Market dynamics and competitive structure of the market by analyzing market leaders, market followers, and regional players.

The qualitative and quantitative data provided in theGlobalPup Joint market report is to help understand which market segments, regions are expected to grow at higher rates, factors affecting the market, and key opportunity areas, which will drive the industry and market growth through the forecast period. The report also includes the competitive landscape of key players in the industry along with their recent developments in theGlobalPup Joint market. The report studies factors such as company size, market share, market growth, revenue, Product Type Typeion volume, and profits of the key players in theGlobalPup Joint market.

The report provides Porter"s Five Force Model, which helps in designing the business strategies in the market. The report helps in identifying how many rivals exist, who they are, and how their Product Type Type quality is in theGlobalPup Joint market. The report also analyses if theGlobalPup Joint market is easy for a new player to gain a foothold in the market, do they enter or exit the market regularly, if the market is dominated by a few players, etc.

The report also includes a PESTEL Analysis, which aids in the development of company strategies. Political variables help in figuring out how much a government can influence theGlobalPup Joint market. Economic variables aid in the analysis of economic performance drivers that have an impact on theGlobalPup Joint market. Understanding the impact of the surrounding environment and the influence of environmental concerns on the GlobalPup Joint market is aided by legal factors.

Heavy Weight Drill Pipes are machined from 31ft bars of AISI 4145H Mod. alloy steel, full-length quenched and tempered to obtain the API Spec.7-1, NS-1 and DS-1 mechanical properties.

When delivered each HWDP has been inspected according to API Spec.7-1, NS-1 and DS-1. An inspection certificate is provided including mechanical properties, chemical analysis and inspections.

API relieve groove pin and bore back box stress relief features are standard. Thread roots are cold-worked to improve fatigue resistance of the connection. All connections are phosphatized and coated with API thread compound to prevent corrosion and galling. Standard pressed steel protectors are installed to ensure adequate thread protection.

DIC OIL TOOLS is well-reputed manufacturer and exporter of Oil and Gas Equipment. Our products are manufactured by using best material and modern techniques, which make them extremely up to the standard in this challenging domain. The offered products are highly appreciated among customers due to their corrosion resistance, robust design, optimum finish and high tensile strength. Also, these are available in various sizes, dimensions and patterns in order to meet the requirements of customers.

DIC OIL TOOLS is a well-reputed manufacturer and exporter Oil and Gas Equipment. Our products are manufactured by using the best material and modern techniques, which make them extremely up to the standard in this challenging domain. The offered products are highly appreciated among customers due to their corrosion resistance, robust design, optimum finish, and high tensile strength. Also, these are available in various sizes, dimensions, and patterns in order to meet the requirements of customers.DIC OIL TOOLS considers quality as an integral aspect of our process as it"s not only to satisfy customers but also imparts us with a feeling of contentment. Quality is our mission. We maintain a strict quality management policy, which is religiously practiced within the organization.

These J55, L80, N80Q & P110 pup joints are manufactured from seamless Grade J-55, L80 N80Q and P110 mechanical tubing. The API 5CT tubing pup joint is mainly used to adjust the height of the tubing strings. It is also used to adjust the depth of down-hole tools.

Tube Turns insulated joints are prefabricated, one-piece unions of butt-weld, forged body construction used to electrically isolate and protect pipe work and associated equipment from corrosion damage caused by stray electrical currents and unwanted electrical potentials that come to the pipeline from overhead power lines, parallel pipelines and other sources.

Isolation Joints prevent metal to metal contact across the joint; and this protection is long term and maintenance-free. Custom built to your specifications, Isolation Joints are manufactured to any diameter or wall thickness and are through-bored to allow for the passage of pigs and scrapers; and each Isolation Joint is serialized, heat code identified and traceable.

Monolithic isolation joints shall be bolt less and completely factory assembled in accordance with the appropriate requirements of ASTM, API, DIN and BS codes. All welds shall be butt weld construction. The dielectric isolation material shall be a high temp thermosetting fiberglass epoxy material. Sealing shall be by dual static, self energized “O” ring seals housed in accurately machined grooves, fully protected from cavitation in full compliance with ASME design codes. Interior and exterior coating shall be a two part epoxy with a thickness of .016 to .024” (.40-.60mm) to within 2” of each end. Each unit shall be tested for Electrical (@5kv, 25 Mohm), Hydrostatic (@ 1.5 x O.P.) and Weld (Ultrasonic/Magnetic Particle).
