For more than 50 years, Camco global products have been the industry standard for the highest quality cam-actuated, motion control products available. Camco Indexers and Servo Drives assist with device indexing. Indexing is the starting and stopping of a device in precise intervals at precise locations. DESTACO"s Camco cam-operated rotary indexers move a wide variety of products and components with precision. Larger E-Series indexers can rotate several tons of automotive body parts in seconds while smaller Parallel and Roller Gear indexing drives accurately index pharmaceutical or electronic components in milliseconds.

Camco offers a range of high performance servo positioners for light to heavy duty applications. All of the series feature large center thru-holes and zero backlash mechanisms. Larger positioners can rotate several tons of automotive body parts in seconds while smaller Parallel and Roller Gear indexing drives accurately index pharmaceutical or electronic components in milliseconds. These servo positioners feature easy integration into a multi-axis system, 60+ cycles per minute, and programmable motion profile of the servo motor to fit your desired index motion/dwell times.

DESTACO’s CAMCO cam-operated rotary indexers move a wide variety of products and components with precision. A larger indexer can rotate several tons of automotive body parts in seconds, while smaller parallel and roller gear indexing drives accurately index pharmaceutical or electronic components in milliseconds. Preloaded for no backlash, they have the capacity for handling high loads and speeds with smooth motion and controlled acceleration and deceleration for repeatable, accurate positioning. They require little or no maintenance and have known power requirements and displacement-time relationship.

The industry’s first scalable indexing solutions, CAMCO MDE and HDE Series mechanical and servo-based indexers, are built for precision positioning and long-term endurance applications. The HDE1200S is a freely-programmable servo-based index drive, while the HDE1200M is a mechanical indexer using an AC induction motor drive package. The open base mounting frame can be scaled in both width and height to fit existing and new assembly line requirements. The MDE is a high-performance rotary indexer with an industry leading torque rating. These cost-effective rotary index drives have high dynamic payload capacity while still maintaining a fast indexing speed, flexible mounting options and easily replaceable cam followers.

The CAMCO E-Series is ideal for heavy-duty rotary dial applications. These models feature durable welded steel housing, precision cam with preloaded cam followers for maximum accuracy and preloaded center-rib design for smooth acceleration and deceleration with precision positioning. This design includes a large output mounting surface that’s supported by a 4-point contact bearing that provides superior thrust and moment capacity. The large center thru-hole accommodates stationary center post, electrical wiring, and air or hydraulic lines. This complete motorized drive package with reducer and AC inverter drive is suitable to most applications.

The CAMCO ring drive offers easy-to-integrate automation that fits into a wide array of operations. Minimize machine footprint by mounting equipment inside the through-hole of the CAMCO Ring Drive. Tool the ring drive by attaching fixtures directly to the dial ring, eliminating the need for an additional dial plate. Popular applications for this model include print/decorating machines, rotary automatic assembly and assembly systems that require a large number of tooling stations.

These CAMCO drives are robust, versatile units suitable for many applications, available with a flange (RGD) or shaft (RGS) output, and all six surfaces are machined for universal mounting. The optional center thru-hole in the flange version facilitates passage of electrical wiring, pneumatic lines or mechanical linkages. This series features short camshaft motion periods, due to oversized cam design, and is well suited for continuous running applications or for special motion requirements such as oscillating motions.

The CAMCO RDM Series index drive is ideal for rotary dial applications and feature a large output mounting surface supported by 4-point contact bearing that offers superior thrust and moment capacity. This series of index drives also offer a low-profile design, large center thru hole and optional output overload clutch.

The CAMCO RA Series indexer is ideal for dial applications or actuation-type applications such as driving a linkage or in-line conveyor. These models feature a fixed center distance between input and output, a hardened ground barrel cam and a compact design that requires minimum use of floor space. They also feature preloaded center-rib design with modified-sine motion that provides smooth acceleration and deceleration with precision positioning.

These CAMCO drives have a robust, flexible design with superior load capabilities. These models feature short camshaft motion periods, due to oversized roller gear cam design, and are well suited for continuous running applications or for special motion requirements such as oscillating motions. This series also offers universal mounting, including a horizontal mounting option ideal for trunion applications. Additionally, they are designed with optional stationary center post with thru-hole to provide mounting for upper tool plates.

Camco P Series drives are ideal for high-speed applications or for actuation-type applications such as driving a linkage or a conveyor. These models feature hardened and ground conjugate cams, yoke-mounted, preloaded cam followers that are non-reversing for high capacity and speed, and preloaded tapered roller bearings for rigidity and backlash-free operation. This design allows for whole or fractional stops, oscillating and complex custom motions. Long transfer distances are achieved with simple linkages.

For more information on Rotary Indexers from DESTACO (CAMCO, Robohand), as well as how Power Motion can help, please contact us. We have locations in St. Louis, Kansas City and Little Rock, providing distributor and automation solutions services for Missouri, Kansas, Arkansas, Nebraska, Southern Illinois, Southern and Western Iowa, Northern Louisiana, Eastern Oklahoma and Northeast Texas. Not all products available in all areas.

Rotary motion equipment and products assist with device indexing. Indexing is the starting and stopping of a device in precise intervals at precise locations. CAMCO cam-operated rotary indexers move a wide variety of products and components with precision.

RGD Roller Gear Index Drives are robust, versatile units suitable for a wide variety of applications.  Key Features Universal mounting with mounting holes on all six ...

The DX Series Drive is a programmable direct drive rotary servo actuator with Safe Torque Off (STO) designed for small flexible dial applications. Key Features 10 ...

RGS Roller Gear Index Drives are robust, versatile units suitable for a wide variety of applications.  Key Features Universal mounting with mounting holes on all six ...

Camco Modular Conveyors offer precision positioning with a modular design.  Key Features Modular frame in fixed increments for quick assembly and delivery High-speed, ...

CAMCO Custom Cams serve as an economical alternative to "in house" cam design, engineering and manufacturing. Backed by over 60 years of experience, we offer a ...

Cam Indexer Technology is Sankyo Automation’s specialty. We’re continuously working to develop new, innovative technologies in motion control. Our collection of high-speed, high-precision rotary indexing solutions are frequently utilized in manufacturing systems that require accurate, high speed actions.

... RIGIDIAL" rotary tables by COLOMBO FILIPPETTI spa have a globoidal cam which transforms the uniform rotary input motion into an intermittent rotary output ...

The indexing rotary tables of the "IR" Minindex series by COLOMBO FILIPPETTI spa are cylindrical cam mechanical units that transform the uniform rotary ...

The ITP Series are the package version of the IT Rotary Tables. They are equipped with a gearbox and three-phase induction motor for a shorter lead time and fast delivery ...

The TRP Series are the package version of TR Rotary Tables. They are equipped with gearbox and three-phase induction motor for a shorter lead time and fast ...

The FTP Series are the package version of FT Ring Tables. They are equipped withgearbox and three-phase induction motor for a shorter lead time and fast reaction to the market ...

This is a Servo driven rotary indexing table manufactured by Italplant which has been a study for automation of the whole unit. It comes with a wide range of product such as robot guided ...

G.P.A. Italiana pneumatic rotary indexing tables are available in two versions: TAR 270 and TAR 160. TAR 270 can handle bigger loads, aided by the hydraulic control and double cylinder ...

Numerous advantages are offered by indexing tables. No matter whatever is the transfer velocity or the load is, the motion is very smooth and progressive. Robust and accurate MCPI cam ...

The TS Series is manufactured by SOPAP Automation. It is a rotary indexing table, that is constructed mainly for plates of a large diameter. Features of the TS includes continuous or ...

Motion’s Multi-dex Indexer solution provides one large base rotary index table with smaller satellite indexers. This allows the tooling or part to be rotated on one end of the work cell ...

Index tables, also called indexers or rotary indexers, are designed to move parts from one stage of the assembly process to another. Index tables/indexers allow for the most efficiency possible to be achieved by an automation system. Index tables/indexers reduce labor substantially, while also increasing production rates. Dial-X Automated Equipment, Inc. has experience with all types of index tables/indexers and can help you determine your needs.

We combine rotary index tables with industrial automation systems so each task of your manufacturing process blends seamlessly into the next. For example, in the past we’ve created industrial automation systems that join rotary indexing machines with pick-and-place units for some of our clients. Contact us to see what we can do for you.

Rotary indexers are just one part of the equation when building a custom assembly cell. It’s important to remember the entire scope of the project and be cognizant that the rotary table should be able to move precise distances before stopping cleanly, with no backlash or wobbling. It needs to be balanced and capable of handling the tasks at hand.

Our automation experts have years of experience in consulting with our customers to create machines that suit their needs. We incorporate rotary tables from industry leaders like WEISS, Fibro, and Camco into our machines to create the perfect fusion of form and function. Our dedication to quality is unmatched in the world of custom machinery.

We seamlessly integrate rotary indexing tables into our automated machinery to provide you with custom solutions that work for your business. If you’re looking to take your manufacturing process to the next level, give the custom machine builders at Paramount Tool a call at (616) 582-5300 today. We’re always happy to answer any questions you may have about our rotary indexing machines or the machine building process as a whole. For a free quote, fill out our contact form and we’ll get back to you as soon as we can.
