Our product range includes single and multiple axes, tilt/rotating tables, and indexing and high-speed spindles. Additionally, we offer customized solution tables for customer requests or OEM projects.

Even for EDM machines that have been in use for decades, we will work with you to determine the ideal rotary indexing table and/or rotating/indexing spindle solution.

Our state-of-the-art rotary indexing tables and customizable reference and clamping systems provide endless application possibilities and highly efficient solutions.

Cost and time pressure in part machining on EDM are new challenges for industry and trade. The key to success can be found in set-up times – where efficiency can increase productivity. For more than 40 years we develop and manufacture rotary indexing tables with coordinated reference and clamping systems. With them you can optimize machine running times and improve economics.

With decades of experience and perfected engineering we are leading manufacturer of rotary indexing tables, a-axes, rotating and indexing spindles together with total clamping technology for EDM technology. Due to high vertical range of manufacturing the customers approach only to one contact person and receive the guarantee that all components are not only assembled but made by Carl Hirschmann. Even for products which are in use for decades the company still offers suitable parts.

Rotary indexing tables combined with wire and sinking EDM offer completely new application possibilities. In wire and sinking EDM processes shapes can be realized far beyond the capabilities of turning, grinding or milling. In an erosive grinding process today microtechnology structures can be realized that seemed to be unthinkable even not long ago.

With our new and further innovations, constructions with zero and small series, test runs and prototypes we already opened a multitude of the nearly endless opportunities. In our high-precise rotary indexing tables, rotary tables and rotary axes are decades of experience and the know-how of special requirements of spark erosion, HSC and laser technology.

Project oriented research and development, in-house testing on our own benches and a high level of vertical integration are all available from Carl Hirschmann out of one source.

Sample Applications Sinking EDM • Undercuts • Tooth systems • Perforations Wire EDM • Curved shapes • Spirals Uniaxial rotary indexing tables Multi-axial rotary indexing tables Rotary indexing tables with hollow axle Rotating and indexing spindles Customized special solutions If requested, all rotary indexing tables can be equipped with a precise clamping system. Common characteristics • Complex shapes • Completely sealed (IP68) for use in dielectric fluid • Maintenance-free, patented EDM power transmission for wire EDM • Maintenance-free AC drive • Applicable on any EDM, laser oder HSC...

Rotary Indexing Table Goes Digital - for digital control during manufacturing process Functions: • Measuring and reporting of temperature and humidity inside the axis. • Readable using an app via Bluetooth on tablet or smartphone. • Data is transmitted, can be read out, evaluated and corresponding statistics on minimum-maximum-average-standard deviations can be generated • Values can also be read directly from LED display on the rotary table without any technical devices • Configuration of limit values for monitoring with visual and acoustic alarm function Advantages: • Increase of humidity...

Uni-axial Rotary Indexing Tables At Carl Hirschmann all parts are homemade with high technical know-how and are assembled professionally to complete units consisting of rotary indexing table, palletizing and clamping system. With uniaxial rotary tables a vertical and horizontal machining with best positioning accuracy, concentricity and axial run-out accuracy is possible. If requested uniaxial rotary indexing tables can be delivered also with SK or HSK tapers. Two-axial Rotary Indexing Tables Our two-axial rotary indexing tables stand for highest precision, accuracy and continuity. The...

Hollow Axes With our precise uniaxial and two-axial rotary indexing tables with hollow axle the workpiece can be machined up to its center. Wire EDM is possible also for small workpieces. Customized solutions Due to our high manufacturing depth it is guaranteed to our customers that all components are made and not only assembled by Carl Hirschmann. We are pleased to meet individual customer requirements. Please contact us directly to find the perfect product for your demand. Carl Hirschmann - System provider with more than 4 0 years of experience For more than 40 years Carl Hirschmann...

HEILBRONN KARLSRUHE A81 A8 STUTTGART Carl Hirschmann GmbH Kirchentannenstraße 9 78737 Fluorn-Winzeln Germany Carl Hirschmann, Hirschmann, Inc. Inc. 165 East Commerce Drive Ste 104 Ste 104 Schaumburg, IL 60173 Schaumburg, IL 60173, USA USA Carl Hirschmann Hirschmann Room C528, Block 180, South Chang Jiang Road Bao Shan District, Shanghai P. R. CHINA 200433 T +86 139 16 13 58 45 E info@carlhirschmann.com.cn E info@carlhirschmann.cn

In addition, since rotary motion is often performed for the purpose of processing, measurement, or some other subsequent operation, the use of rotary tables by themselves is rare.

Rotation mechanisms used in chairs and other equipment are also classified as rotary stages in the broad sense of the term, so they are used not only in manufacturing but also in home applications.

A crossed roller bearing is a bearing structure in which rollers are arranged between the inner and outer rings. The rollers are arranged in a straight row with a 45° contact angle, enabling the back bearing structure of a ball bearing to be realized with a single row, and the structure is capable of receiving loads from multiple directions simultaneously. The rotary table and cross roller bearings can be directly connected, which reduces the number of structural parts.

Since the rotational accuracy of the rotary table is directly related to the accuracy of the rollers, high rotational accuracy can be obtained depending on the accuracy grade of the rollers. In addition, since cross roller bearings have low frictional force and can be operated with light force, micrometer heads can be used in the fine-tuning rotation mechanism to obtain high positioning accuracy.

Lyndex Nikken – Hydraulic Chucks & Toolholders, 3 Jaw Chucks and Angle Heads, Rotary Tables, Live Tools for Turning Cneters, Shrink Fit Machines & Holders, Precision Collets

100 mm (3.9") High-Speed Tilting 2-Axis Rotary Table, with indexing up to 1000 deg/sec. Requires a Haas mill with 4th- and 5th-axis drives for true 4th- and 5th-axis operation.

Quad-Spindle 5C Collet Tilting 2-Axis Rotary. Requires Haas mill with 4th-and 5th-axis drives for true 4th- and 5th-axis operation. This unit has no collet closing capability as standard.

Anyway, to answer your questions, I looked up the Hirschmann table you referenced and it looks to me like it"s a spinner and indexer, not a turn while burn table.

Hirschmann must have a similar provision to integrate their turn while burn capable tables to whatever machines they are going to be run on...I don"t think you can just buy one and bolt it to a machine without the interface kit to mate it to the control.

Turn while burn requires that the controller governs the rotary motion; this is because the rate of rotation has to be driven by the spark gap conditions in conjunction with the axis motion of the rest of the machine whether it"s X or Y or U or V.

It was faked by tilting the wire to an angle other than the thread helix angle with the U axis, then driving a fine pitch helix with B and X (B is the rotary axis on my machine).

You can imagine just how many passes that would take (a LOT), and you will always have a 0.005" radius at the junction of each flank and the root, which may or may not be acceptable depending on the application.
