walter rotary table factory

Founded in 1936 by Mr. Gotthilf Walter as a mould making company for the concrete industry, the company developed and adjusted their portfolio through the decades to meet the trends and demands, especially these of the machine- tool market.

Already in the early 60’s WALTER has moved from the completely manual indexing units to digital readout units. From there it was only a logical step forward in the 70’s to the first NC-controlled units.

With its CNC controlled Dividing Heads and Rotary Tables and customer specific solutions based on these units, GOTTHILF WALTER GMBH is one of the technology leaders in this industrial sector.

Dividing Heads „Made by WALTER“ are first-choice throughout the industry – small, medium and large companies, especially when high quality manufacturing of a complex workpiece is required.

More than 50 highly skilled and motivated personal are giving their highest possible efforts to ensure that WALTER Dividing Heads and Rotary Tables and the involved services give you already today the deciding

The 2-axes NC-dividing head TANiH2S-Evolution , with its two full CNC axes, is characterised by the highest efficiency with a very compact design. The WALTER TRIPLEX CLAMPING SYSTEM and the option of having a direct measuring system in both of the axes gives you the highest precision and effectivity in your production of parts and subassemblies. Together with the 3 axes of the machine or machining centre, a full 5-axes machining can be realised.NC controlled tilting range from -5° – +95°

The 2-axes NC-dividing head TANiH2-S evolution-XS. The rotation axis without a counter bearing is suitable for mediumheavy machining forces and gives you the value to reach the component from 4 sides! A full 5-axes machining can be realised. The option of having a direct measuring system in both of the axes gives you the highest precision and effectivity in your production of parts and subassemblies.NC controlled tilting range from +120°/-120

Employing our TAD series dividing heads with torque-motor (direct drive) offers you new manufacturing possibilities, due to the high speed and dynamic movement. The encoder is mounted directly to the spindle, which eliminates any kind of backlash. These units are available as table top versions (TAD) or built-in version (TED).Highly dynamic units with accelaration up to 20.000°/sec²

RTN Rotary tables, with a horizontal, non-lifting faceplate, are designed for use on NC-controlled machine-tools and machining- centres. Face-plate diameter ranging from Ø250 mm up to Ø2.000 mm.acceptance of high machining forces

The manual tiltable NC-dividing head TANiP-S, allows for a free inclination of the whole unit from a horizontal to a vertical position. The option of a reduction gear drive enables an easier handling. The exact tilting position can be determined by a nonius. Adigital readout is available as option.Inclinable from 0° – 90°

The indexing units in the VTW series are manual indexing devices with a stable construction and low height, for rapid and simple manual indexing. The required indexing angle can be engaged rapidly and directly by means of the built-in indexing plate. The standard indexing plate with 24 notches permits 15° divisions.Special indexing plates are available.Hardened and ground indexing spindle with high precision runout

The tailstock series RSe is designed to meet the requirements of modern manufacturing technologies. Functionallity for the use on state of the art machining centres as well as a stable and rigid design are the main aimof these units. These tailstocks can be used either in right- or left hand design. Hydraulic or pneumtic options for automatic movement and clamping are available. Standard centre heights ranging from 80 to 320 mm.Rigid design with big handwheel

Programmable CNC positioning controller type CPS or CDS, providing special functions adapted to rotary tables or dividing heads with position controlled drive systems. Easy and comfortable programming and operation due to menue assisted sequences. Automatic clamping and control, processing.

RALMTEC came into existence in 1994 following the restructuring of a manufacturing company which had been involved in rotary & linear motion since 1986.

The RALMTEC line is delineated from its competition by its specialization. Many years ago we introduced the first rotary with preloaded crossed roller main bearings (providing immense rigidity in a very low profile) and a spring loaded floating tail bearing (economically maintaining constant solid mesh between the worm & gear).

Fully Factory Rebuilt, Factory Refurbished Rotary Tables, to as new factory specifications: Horizontal, Weight approx 2100kg, Loading capacity approx 18,000kg/39,600lbs, .  Refurbished October 2017 by Rusach International.  Fanuc Alpha 30 motor, Heidenhain ROD800C +/-3.5 Arc Second encoder, Siemens hydraulic pump.  Table Top is set up for a pallet receiver.  Need it modified, please let us know!

Reversible clamp, 4th axis, rotary table, rotary dividing table, controlled rotary table, dividing attachment, dividing head, rotary indexing table rotary coupling
