Tsudakoma had been providing best-in-class rotary tables for over 100 years, offering multiple models and configurations to ensure seamless integration with your machining centers. Koma Precision has been distributing Tsudakoma’s tables for over 40 of those years and our North American sales team and in-house engineers will work with you to determine which model best suits your machining needs.

Rotary Tables└ Workholding Supplies└ Workholding & Toolholding└ CNC, Metalworking & Manufacturing└ Business & IndustrialAll CategoriesAntiquesArtBabyBooks & MagazinesBusiness & IndustrialCameras & PhotoCell Phones & AccessoriesClothing, Shoes & AccessoriesCoins & Paper MoneyCollectiblesComputers/Tablets & NetworkingConsumer ElectronicsCraftsDolls & BearsMovies & TVEntertainment MemorabiliaGift Cards & CouponsHealth & BeautyHome & GardenJewelry & WatchesMusicMusical Instruments & GearPet SuppliesPottery & GlassReal EstateSpecialty ServicesSporting GoodsSports Mem, Cards & Fan ShopStampsTickets & ExperiencesToys & HobbiesTravelVideo Games & ConsolesEverything Else

KOMA Precision Inc. introduces a new improved line of extra-large center bore, dual disc hydraulic clamping rotary tables from Tsudakoma. Like all Tsudakoma rotary tables, RCB Series has the proprietary dual lead worm gear system with ultra-precision cross roller bearings. The Tsudakoma dual lead gearing system delivers the optimal balance between power, durability and smooth cutting performance.

Three new models are available, with table diameter of RCB-350, R being 8.45", RCB-450, R with 10.4" and RCB-550, R with 12.4". The RCB Series rotary tables can be mounted either vertically or horizontally. Various options such as chucks, tailstocks, support spindles, and faceplates are available. Pneumatic and Hydraulic rotary joints for automatic load and unload of the work piece are also available.

"Koma Precision Inc. and Tsudakoma share a commitment to providing quality products that maximize the performance of machine centers," states Frank Cerrito, General Manager for KOMA Precision. "The features offered on the RCB Series are ideal for large-diameter work piece manufacturing that is mainly seen in the oil/energy industry."

KOMA Precision Inc. has introduced a new line of high performance, attractively priced 4th axis rotary tables from Tsudakoma. The RNE Series 4th axis rotary tables are compact, high-performance tables offered at economy line pricing.

Four new models are available, ranging from the RNE-160 with 6.3" (160mm) face-plate capacity to the RNE-320 with 12.6" (320mm) face-plate capacity. The RNE Series tables feature speeds ranging from 25 to 44.4 RPM and indexing accuracies ranging from 10 to 12.5 arc seconds. Various options such as chucks, tailstocks, support spindles and faceplates are available. Pneumatic and hydraulic rotary joints for automatic load and unload of the work piece are also available.

Like all Tsudakoma rotary tables, the RNE Series feature heavy-duty construction, combining Tsudakoma casting material with Tsudakoma"s dual lead worm gearing system featuring the largest tooth engagement of any rotary table manufacturer. This proprietary gearing system generates up to 85 percent torque transfer efficiency. These tables also feature Tsudakoma"s ultraprecision cross roller bearings that support radial, axial and movement loads four times the level of stiffness as angular contact bearings.

"Koma Precision Inc. and Tsudakoma share a commitment to providing quality products that maximize the performance of machine centers," states Hiro Ichikawa, OEM Sales Manager for KOMA Precision. "The features offered on the RNE Seriesare ideal for those looking for economical ways to improve the flexibility and productivity of their operation without compromising rigidity and accuracy."

For years, Martin Trunnion Tables has been a proud integrator and fixture builder for KOMA Precision rotary tables. We help support and develop trunnion packages for automation solutions, high-mix job shops, and everything in between. Below you will find a variety of solutions ranging from 4-sided tombstones to fully cast, single-sided Stallion Trunnions. If the featured solutions aren"t exactly what you are after, don"t hesitate to reach out to our team.

Koma Precision distributes Tsudakoma’s line of rotary tables. The pictured table is part of the TWM line, which best pairs with high-production single- or dual-spindle vertical machining centers that require five-axis machining.

Live demonstrations with customer parts headline the show at Koma Precision’s bright green booth. This IMTS, the company is showcasing Tsudakoma rotary tables in common fixturing setups for automotive parts. In addition to stock Tsudakoma rotary tables, Koma Precision is also emphasizing its specialty rotary tables, which are born from collaboration between Tsudakoma, Koma Precision and the end user.

Koma Precision is also showcasing Alberti NEO right angle heads, which the company says add versatile high-torque and coolant-through options to its line of machine tool accessories. Video displays highlight overhead hydraulic products for high-production horizontal and vertical machining centers, as well as the company’s machine tool presetters with auto-measuring functions.

“Automation is the trend of the industry,” says company president David Meo, and all the products Koma Precision is demonstrating at the show are primarily optimized for robotic tending rather than manual tending.

September 15, 2006 - The Tsudakoma TN-130 super compact NC tilting rotary table features massive clamp torque utilizing a newly designed dual disc tapered ball clamping system. The TN-130 is a high speed table with total flexibility for the addition of rotary joints, scales, and hydraulic chucks.

September 15, 2006 - Koma PARR+ precision pneumatic chucks provide ultra precise chucking (up to .00002 repeatability) for accurate thin wall turning and grinding. PARR+ chucks feature integral adjustable pneumatic power and high speed, maintenance free performance. Internal and external chucking is possible with the same unit. Standard models are usable up to 8,000 rpm and special models are available for use up to 11,000 rpm.

September 15, 2006 - KOMA Z+ angle heads effectively create an additional (Z+) axis for a CNC machining center. Equipping a VMC or HMC with a KOMA Z+ angle head reduces fixturing and set-up requirements, resulting in an increase in part accuracy and machine throughput. KOMA Z+ tools are available with 90° and dual 90° outputs, custom fixed angle outputs, and adjustable angle outputs. Heavy duty flange mounted heads and application specific custom heads are also available. KOMA Z+ angle head options...

September 2, 2003 - East Windsor, CT August 25, 2003...Koma Precision, Inc. the exclusive U. S. sales and marketer for Albert tooling, announces the availability of the Alberti HSK equipped right angle heads and universal heads with either HSK input or output spindle that deliver high speed, high precision and higher clamping forces. Alberti outputs are available in HSK 32, 40 50 and 63 size while inputs in HSK 50, 63, 80 and 100 sizes. The flange face of Alberti HSK system perfectly fits the face of the machine...

March 5, 2003 - East Windsor, CT February 24, 2003. . .Tsudakoma combination table for high production engine block manufacturing is designed especially to be encapsulated in automotive flexible transfer lines or built into high production automotive parts machines. The table features an oversize driving mechanism and hydraulic tailstock support capable of handling heavy eccentric loads along with a powerful dual disk hydraulic clamping system on both the driving and outboard side of the cradle. A 10 port...

November 13, 2002 - for immediate release East Windsor, CT October 28, 2002...Koma Precision, Inc. announces the new Tsudakoma multi-faced NC rotary table designed for high production 5th axis applications on horizontal machining centers. Four 6 inch diameter platens rotate simultaneously at 33.3 RPM driven by an additional machine axis, or Tsudakoma"s own TPC-Jr controller with RS-232C interface capability. Powerful 156 N.m clamp for position machining is standard. Accuracy specification is +/- 7.5 arc second...

August 27, 2002 - Koma Precision, Inc. IMTS Booth A 8441 East Windsor, CT June 14, 2002...Koma Precision, Inc., will exhibit the new Tsudakoma TN Series Rotary Tables that feature high clamp torque of up to 625 ft. lbs., and high indexing speed, up to 44 RPM for the rotating axis, 22 RPM for the tilting axis, and a wide tilting range for greater performance, dramatic reductions in machining cycle times, at extremely cost competitive levels. With a smaller footprint, the TN Series compact design suits a wide...

April 10, 2002 - East Windsor, CT March 13, 2002. .Koma Precision announces the addition of the new low cost Tsudakoma RZ Series Indexer package that features compact design, high speed 33.3 RPM performance, high clamp torque of 1400 inch pounds and the TPC Jr controller with 1000 block programming capacity and RS 232C programming function standard--no MDI programming required. With renown Tsudakoma reliability, the RZ Series package is built for small VMC"s, drill and tap centers and pallet machines. The new...

Since 1982, Koma Precision, Inc. has supplied the world’s highest quality attachments and accessories through a nationwide distributor network. We are the exclusive importer, national distributor and service center for Tsudakoma rotary tables, Alberti angle heads & live tools, Romai angle heads, Inbis swiss tools and our own line of elite Tool Presetters.

We do much more than simply pull stock off the shelf and ship it. Our production services staff modifies and customizes Tsudakoma NC rotary tables and indexers to suit new machine tool installations. We completely integrate tables with the machine tool to ensure the right fit within the confines of the machines guardwork and working envelope. We design and build electrical and hydraulic cable packages for your machine tool"s specification"s including selection, installation and interface of motors, encoders and switches with the CNC controller. More than ever KOMA is noted in the industry as the company with the experience and know-how to deliver "plug and play" product in this complex field.

For customers who require repair of their equipment vs. a new purchase, Koma precision is staffed with factory trained technicians who completely inspect and evaluate your equipment, repair and build, and add upgrades as necessary. All units are thoroughly tested and painted to your specification and returned to you as good as new. In addition, our complete spare parts inventory ensures fast response to meet your critical production requirements.
