Rotary tables, rotary-tilting tables, tilting heads equipped with electrospindle: these are some of the products that Lcm Precision Technology designs, produces and markets. Innovative and customized solutions in manifold geometries, with different sizes and various magnitudes, with which the company intends to represent a reliable and qualified partner in national and international ambit.

Headquartered at Castell’Alfero, in Asti province, Lcm Precision Technology is an engineering company that since 1986 has been designing, producing and marketing accessories for machine tools. Forefront components developed thanks to a team of skilled technicians able to comply with specific needs and to turn them into high quality added-value solutions. Result enabled by the precious contribution of around ninety employees, a dozen of whom working in the Research & Development Department, for a turnover that reaches about 15 million Euros (70% of which beyond the borders).

«A high-quality product – specifies Giorgio Panatero, sales executive of Lcm Precision Technology – that in most cases directly reaches machine tool manufacturers, that is to say OEM, and is also intended for OE applications».

Rotary tables, rotary-tilting tables, tilting heads equipped with electrospindle: they are some of the products designed, produced and marketed by the company.

«A production – adds Panaterpo –that includes both tables with conventional rotation system, that is to say mechanical, with worm screw and crown, or with direct-drive, torque motors. Flexibility with which we can satisfy the various market requirements».

The torque motor technology permits the company to manufacture tables with torque performances in operation resembling the tables with screw-crown system but very high rotation speeds. Another important advantage is the backlash absence and the consequent high dynamic response and precision, thanks to the quick bi-directional response.

The range developed by Lcm Precision Technology can be practically subdivided into three big families where innovation and competences converge. The first includes the rotary tables belonging to BRC and BRS series, solutions conceived for the application on 5-axis machining centres, equipped with rotary-tilting system directly integrated into the bed of the machine itself. They are executions implementable in the sizes of 200, 300, 400, 600, 800 mm (sizes of the rotary surface), up to the biggest one, with 1,200 mm plate and a loading capacity that can reach 2,000 kg.

The family called MD includes instead tilting milling heads (with +/- 100° for those with mechanical transmission and hydraulic clamping and +/-120 for the models with torque motor), the related milling electrospindles (belonging to the ELQ series) and the rotary tables to be integrated or fixed on the machine worktable (being part of TDE/M and TRB series).

The above-mentioned solutions are completed by the inserted rotary tables for machining centres, that is to say with 4th and 4th/5th axis, with rotary plate sizes from a minimum of 125 to a maximum of 350 mm.

«In other words – adds and ends Panatero –the possibility, which more and more often the manufacturers of milling machines are trying to supply to their customers, of executing also small turning operations on their machines. Concerning this, we are developing a series of targeted products, both rotary tables that can rotate with speeds consistent with turning, and we are speaking of 500 rpm on 800 mm of diameter and electrospindles and heads able not only to mill but also to manage, to grip and to clamp a turning tool».

... OptionsThe turntable machine R 703 is also available as an Atex version. 4-6-8-12 or 24 spindles are available as options; half of the selected spindles can be equipped with a directional rotation reverse function. The ...

The Heavy-Duty Manual Turntable maximizes workspace and minimizes wasteful motion. Bench top turntables allow workers to stay in one position and rotate items for access from all sides. ...

... impacts or forces while gear type or torque motor type rotary tables are not likely do. Its accuracy and rigidity obtained by zero-backlash technique that achieves high accurate positioning with the rotational ...

... acoustics Remote-operated Turntable HRT I is used for automated orientation-dependent acoustic measurements, allowing to rotate the device under test to specific angles in the measurement field.

The cumulative rotary table is an auxiliary device for the accumulation of packs before group packaging or other tasks. The storage disk made of stainless material, which allows the use of the table ...

This is the Hollow Rotary Table model number GSN60-05K-SV with table size 60mm gear ratio 1:5 for servo motor. GIGAGER Hollow Rotary Table also called ...

... Aerosol or Bag on Valve Stations. Our 36″ Rotary Index can accept a maximum of 6 stations, our 18″ Rotary Index can accept a maximum of 4 stations, and our 9″ Rotary Index can accept ...

... 40 inch diameter Rotary Bottle Loading Turntables are manufactured in 1/8″, 304 stainless steel. Power is provided for the TAU-4000 by a DC gear motor. Variable speed up to 150 containers per minute.

Job shops may believe that all CNC rotary and index tables are essentially alike. As a result, they often base their selection on price and hope they can use their machining creativity to maximize a rotary or index table.

However, to expand the capabilities of their machine tools when purchasing new ones or retrofitting existing equipment, considering the quality of a table’s sealing, braking and bearing systems and how those systems impact a shop’s current and projected applications can pay big dividends down the road. Shops are also wise to consider the effectiveness of a cable management system—which ensures a rotary table is always connected to the machine without operator intervention and extends connector life—when palletizing tables.

“The initial quality of the rotary table makes a big difference,” said Lee Flick, national sales manager for HPI-Pioneer, “especially at job shops.” The Elk Grove Village, Ill., company supplies CNC rotary and index tables from Yukiwa Seiko Inc., Japan.

Predictably, many end users—especially shops on limited budgets—push the limits of a rotary table’s weight capacity and capability. “Some of our customers will put a car on a little table and try to turn it,” Flick quipped. But by specifying the correct rotary table for the job, shops can extend equipment life while reducing maintenance issues and continuing to machine high-quality parts.

After 2 years of operation, the inside of a Yukiwa rotary table (left) with an automatic air-purge system and a competitor’s table without a purge system.

A table axis’ lack of durability and inadequate clamping power can cause out-of-tolerance features and rough surface finishes. One solution is a dual-bearing system that supports the table on the front and rear with large bearings, according to Flick. Even with an overhanging weight load, this design prevents the table from leaning, he added.

One of the key factors that determine the life span of a rotary table is how well it is sealed against potential contaminants, such as metalworking fluids. Flick noted the most common rotary table service is repairing electronics damage caused by coolant infiltration. “Within 20 years I believe the market will be dry cutting,” he said. “But as long as coolants are involved, sealing is extremely critical.”

Flick indicated that there are three basic sealing arrangements: sealing just the motor cavity, sealing the entire table and sealing the table and incorporating an automatic-purge system similar to check-valve pressure on an airplane. “You pressurize the cabin and if you were to get a leak, it blows outwards,” he said, adding that a rotary table with that type of seal typically lasts twice as long as one that doesn’t, whether it’s an entry-level or higher quality table.

HPI-Pioneer President Nobu Kiriyama explained that the Yukiwa air-purge system uses the 70-psi shop air that also supplies a table’s braking system and enables a table to effectively function when submerged for EDMing. For those applications, an optional nickel-plating is appropriate when the table is submerged in water-based dielectric fluid.

Of course, chips, swarf and other debris produced during cutting can abrade any seal material and provide a passageway for contaminants into a table’s inner mechanisms. Therefore, John Arnestad, tooling product manager for Koma Precision Inc., recommends against aiming a high-pressure coolant line at a seal or an area where a seal is located to reduce that risk. The East Windsor, Conn., company supplies rotary tables from Tsudakoma Corp., Japan, which have seals directly behind the faceplate. The tables also have a metal cover that shields the main seals to decrease the chance of debris abrasion.

For high-pressure coolant applications, Rotec Tools Ltd., Millwood, N.Y., recommends a labyrinth seal on the rotary table. Rotec distributes rotary tables from Peter Lehmann AG, Switzerland. Ivo Straessle, Rotec president, noted the air-supported labyrinth seal attaches to the spindle nose of the table, extending the standard spindle seal, and creates an air cushion underneath the seal to keep coolant out. “We prefer oil-based over water-based coolants because they’re not so aggressive on the rotary tables,” Straessle said. “Many water-based coolants attack seals, cables and electrical components.”

In addition, Lehmann rotary tables have an air-purge seal on the motor housing, and the gear housing has a positive oil pressure at all times. “That makes it very difficult for debris or coolant to penetrate the seal system from the outside,” Straessle said.

To ensure longevity of the rotary table and its sealing system, pressure is reduced to the internal components of the pressurization system during rotation on most of the table models offered by L.C.M. Srl, Italy, said Mike Bickham, president of distributor ITI Tooling Co. Inc., Ramsey, N.J. Then, the pressure increases when the table reaches the preprogrammed working positions.

Cutaway of a Lehmann rotary table: 1) The clamping ring applies 360° equal clamping force on the rotary axis; 2) the rotary axis; 3) the preloaded radial and axial needle bearings; 4) the gear train; and 5) the standard spindle seal, which can be extended with a labyrinth seal for high-pressure coolant application.

Unless it’s an older table, coolant infiltration behind the rotary table seals isn’t an issue in 99 percent of machining applications, according to Jamie Schwarz, national sales manager for CNC Indexing & Feeding Technologies, Mason, Ohio, which offers Taiwanese-made Ganro rotary tables. A combination of oil seals, O-ring seals and silicone caulking keeps contaminants out of the tables’ inner workings, and the company offers an air-purge system as an option.

When coolant penetrates a rotary table, it can short out a servomotor, and fine chips can wreak wear-related havoc on the brake, worm wheel, worm shaft and other parts. “That can get expensive when you start replacing internal components that are important to the table’s accuracy and repeatability,” Schwarz said.

Pressure also comes into play when selecting the appropriate braking system for a rotary table. According to HPI- Pioneer’s Flick, two basic variations exist: a disc brake system and a hydraulic version that provides higher braking pressure than a disc brake. Although hydraulic systems are prevalent, he pointed out that the company offers models with the less-typical air-over-hydraulic booster inside the table’s motor cover, eliminating the need for a hydraulic pump or other external hydraulic supply. Instead, 70-psi shop air does the trick. This is because the table clamp mounted inside the air-hydro structure boosts the hydraulic pressure and achieves higher clamping power simply by providing air pressure. (See image below.)

“The higher the braking pressure, the more aggressive machining you can perform on the rotary table,” Flick said. “Hydraulic boosters are becoming more common because people want to machine harder and harder on the table.”

He added that there’s no angular pressure on any braking system when using a rotary table to cut on-center, but the type of system makes a significant difference when machining off-center because the pressure created on the cutting location increases based on its distance from the center. Hydraulic systems permit more aggressive cuts, even when machining farther out on the table.

The heavy-duty, zero-backlash braking systems on the rotary tables from ITI Tooling can use hydraulic pressure up to 870 psi, according to Bickham, but 580 psi is more typical. In addition, the tables can use an air supply together with an air-over-oil intensifier, which provides benefits because shop air is generally more readily available and is restricted to a safer pressure than a hydraulic system. Bickham added that whether it’s an air- or a hydraulic-actuated brake, the brake operates in the same manner by expanding a 360° pressurized sleeve that wraps around the table’s center axle, holding it rigidly in place.

Cost considerations can play a prominent role when selecting a rotary table’s braking system. The disc brake is the most popular type because repairs are fairly inexpensive, according to CNC Indexing’s Schwarz. The repair is usually performed on tables 10 years and older used for heavy machining, he said. “We can get the repair done within a day for a few hundred dollars.”

With the air-over-hydraulic brake system in Yukiwa’s rotary tables, the increased hydraulic pressure can achieve stronger clamping power by providing air pressure.

Arnestad indicated that Koma offers several braking system options. Called the RNE series table, the pneumatic, dual-disc system is the most economical, while offering good accuracy and a good torque drive, he noted. The mid-range RNA series table has a dual-taper clamping system that uses a pressure intensifier, where a ring of ball bearings are captured between the clamping ring and the piston.

“The piston has an angular feature on it, as well as an angled member inside the braking system so, as the piston moves forward, it displaces that ring of ball bearings and triples the clamping force,” Arnestad said. This enables taking heavier off-center cuts without the fear of the rotary faceplate turning under force.

Arnestad added that the hydraulic, dual-disc clamping system, called the RBA series table, is the company’s most robust. “That’s targeted for high-volume production,” he said, “where they need to hold very close tolerances and want to machine at the fastest rate possible.”

According to Rotec’s Straessle, Leh-mann rotary tables have the same braking system for any application, using a built-in air-over-oil intensifier. This booster coverts 90-psi shop air into more than 4,000 psi of hydraulic pressure, he added, and a clamping ring equally applies 360° clamping force to the rotary axis. “A high clamping force allows high feed rates and high workpiece accuracy.”

End users can also increase machining parameters when a rotary table’s bearing configuration enhances table rigidity. For example, preloaded axial and radial needle bearings in front of the table next to the spindle nose and preloaded axial needle bearings in the rear of the spindle (all inside the gear housing) provide a high level of rigidity, Straessle explained. Preloading eliminates the undesirable “give” for the bearings in the axial and radial directions. “This design allows the customer to work with heavy workpieces and, at the same time, reduces overall vibration,” he said.

According to Arnestad, a cross-roller bearing construction provides the best rotary table support. “It gives better stiffness and less runout than, say, tapered roller bearings, which have a chance of losing their preload over time,” he said.

Yukiwa rotary tables from HPI-Pioneer have a dual-bearing system, where two sets of bearings at both ends of the body provide triple-contact support and the largest angular contact bearing is underneath the table face to enhance bearing support.

In terms of runout, HPI-Pioneer’s Kiriyama noted the bearings in Yukiwa’s rotary tables provide a 0.0001" runout and are the same grade as the ones machine tool builders use for their spindles. According to the company, the tables have a dual-bearing system, where two sets of bearings at both ends of the body provide triple-contact support, and the largest angular contact bearing is underneath the table face to maximize bearing support.

HPI-Pioneer repairs and replaces worn bearings from its rotary tables, as well as from its competitors. “A good table will go 5 to 10 years before it needs work, just like a machine,” Flick said. “With a low-end table, you’re doing it annually. It’s that dramatic of a difference.”

Similar to a braking system, a high-quality bearing configuration effectively supports the workpiece load and machining pressure in the axial and radial directions. This proves beneficial when machining on a rotary table that’s not adequately matched to the application. “Everyone wants to buy the least expensive table they can and push it to its limits rather than going the next size up,” said CNC Indexing’s Schwarz.

When high-volume manufacturers and those performing lights-out machining use rotary tables, they often palletize the tables. In this scenario, the main consideration is the cable management system, which enables a palletized table to shuttle in and out of the machine tool without disconnecting cables while keeping them clear of the machining process, according to Schwarz. It might involve running the cables through the middle of the pallet to some sort of track system or incorporating a spring-loaded arrangement that hangs from the upper sheet metal in a machine and allows cables to extend and retract.

Most end users are quite opposed to having to repeatedly plug in and unplug a rotary table, he said. As a result, the role of a cable management system, which machine tool builders and third-party installation companies provide, is critical.

Koma’s Arnestad added that a cable management system ensures a rotary table is always connected to the machine without operator intervention, which extends connector life. “If you don’t have good cable management, the connections can fail due to abrasion or having the cables flex too much,” he said. “How many times can you plug and unplug a multiple-pin connection before somebody gets a chip underneath the unit, tries to force it on and it leaks and you have problems?”

Going cheap across the board with rotary tables pays initial dividends, but part manufacturers that skimp on quality may miss enhancing the capabilities of their machine tools—even entry-level ones. “If you put the right options on your rotary table,” Frick said, “you can make an inexpensive machine perform as well as a midrange machine.” CTE

Because they don’t have gears and gear-related issues such as backlash, direct-drive rotary tables were expected to eventually replace worm gear-driven ones. For example, CTE’s April 2004 cover story stated, “Whatever the use, more direct-drive NC rotary tables will be purchased in the future, supplanting gear-driven units. These types of tables don’t have a gearbox, thereby eliminating the need to replace worm gears and belts, and are directly driven by the motor.”

That expectation didn’t quite materialize. Although they are quite accurate and rotate considerably faster than gear-driven rotary tables, reaching 250 rpm and higher compared to less than 50 rpm for a standard conventional table, direct-drive rotary tables lack the torque required for machining heavy parts and difficult-to-cut workpiece materials.

Therefore, the primary applications for direct-drive tables are high-volume ones that involve small, lightweight parts and light machining loads, according to Lee Flick at HPI-Pioneer, which offers direct-drive tables. In addition, the motor is essentially the brake. “To get the rpms, you give up torque and braking pressure,” Flick said.

HPI-Pioneer’s Nobu Kiriyama added that rotary table manufacturers have access to the same motors from motor manufacturers, which provide similar motor configurations and specifications. “Then, the various rotary table manufacturers are mostly assembling components and it’s harder to distinguish themselves,” he said. “Direct-drive technology is still evolving.”

Damaged direct-drive tables are also more costly to repair than gear-driven ones, because the components are more expensive than ones for standard servomotors, which can be rewound, said John Arnestad of Koma Precision Inc. “And if you get contamination inside a direct-drive rotary table, the motor is shot and the rotary table needs to be replaced.” Koma offers 5"- to 25"-dia. direct-drive tables.

Ganro also offers a direct-drive table, noted Jamie Schwarz of CNC Indexing & Feeding Technologies, but end users often view them as cost-prohibitive because direct-drive motors are expensive. “We quote it and then the customer says, ‘For that additional cost I think I can live with the standard table I have.’ ”

However, not all suppliers have a less-than-stellar outlook on direct-drive technology. ITI Tooling Co. Inc.’s Mike Bickham emphasized that for L.C.M.’s high-speed, torque-motor-driven tables, the company designs and manufactures many of the direct-drive motors it uses. He added that special direct-drive tables can be ordered that provide enhanced torque and, if needed, a wider range of speed. “There’s tremendous holding power for heavy-duty machining because the motor can be used as the brake,” Bickman said.
