Gas Safety ValvesThese valves automatically control main gas flow. Our automatic pilot valves shut off both the main and pilot gases. Pilot gas is tapped from the main line within the control. Gas will flow only to the pilot burner when the reset button is depressed. The manual pilot valve stop can be adjusted for maximum pilot flow.

When you’re working with gas, safety should be the name of the game. It’s extremely easy to cause a lot of damage, both to yourself and your establishment, when you’re not showing that invisible little devil the respect it deserves. Fortunately, modern-day gas safety valves have been tested and outfitted around the world, and these bad boys are essential pieces to any efficiently-working system. That said, when your gas safety valves are a little worse for wear, making a repair or finding a replacement is a no-brainer. That’s why keeping an extra in your repair kit or tool closet is a smart move, and we’ve got the gas safety valves you need!

Flame safety is a critical aspect of any gas-fired system, but it can present puzzling choices. What equipment do you need? Which parts can be substituted? At Charles A. Hones, Inc. we use Johnson Control’ line of Baso™ safety valves and other components to tailor flame safety on Buzzer gas burners and furnaces to the user’s needs. This brief guide can help you select the right equipment for your job.

The H15 series Baso valve will provide 100% shut down of gas flow in the event of pilot failure. The H15 series valve is recommended for low pressure gas only (1/2 PSI or 14”w/c). We supply this valve in four types of sets, as follows.

This set can be used on larger pipe burners and burners such as FR-14 and multiple pipe burners that include cross flame pilots. 1” Baso set can be used on larger ring burner and discport burners (606, 606A, 312 and 313), larger 2020 Fire-Box oven furnaces and larger melters (#2700, 171A and 172). List $250.

Note: Many Buzzer furnaces already include a #50 cast iron pilot (including the 171A, #250, #2700, ACR 60, and 185 salt bath furnace). Many Buzzer furnaces also come equipped with a redundant pilot system in which the smaller J99 style pilot ignites off the larger #50 cast iron pilot. Please call the factory if you have any questions. Additionally, parts can be substituted. For example, for an IH300 straight style complete with solenoid valves, gas cocks, and pressure gauges, you will need to replace the 60” thermocouple with a 72” thermocouple. This would add $16.00 to the cost. Please refer to the parts price list or call the Hones factory to assist in such modifications.

The H15 Series pilot valves provide safe lighting and complete shutoff of pilot and main burner gas in the event that the flame heating the thermocouple is extinguished. They are designed for standing pilot applications and can be used with natural gas and Liquefied Petroleum (LP) gas, at pressures up to 0.5 psi. Typical applications include commercial cooking equipment, heaters, kilns, dishwashing equipment, industrial ovens, and similar applications.

Baso Gas Safety Valve Nat/Lp 3/8" Fpt In/Out Pilot Plugged Vulcan Griddle 924A 936A 948A 960A 972A New Style Has Thermocouple Inlet 90 Degrees To Gas In/Out. Product Change: Baso Has Changed This Valve. They Turned The Thermocouple Hole 90 Deg. It...

3/8"npt Auto Vent Limiter 2-5PSI Automatic Vent Limiting Device. Gas Escape Rate 2.0 CFH @ 5 PSI. Includes Check Valve That Limits Gas Escape Rate To Safe Levels If Diaphragm Ruptures.

Motorized Gas Valve Actuator. 120V. 13 Sec. Timing. W/Damper Shaft. Use WithV5055C Valve Bodies. Incl. Proof Of Closure And Valve Seal Over travel Interlock Switches.

Two Stage Gas Valve 24V DSI / HSI 3/4" x 3/4" w/ 1/2 inch reducer bushings. 1/4" male spade quick connect. 36H54 36H64 36H54-470 Possibly Replaces: R42360 36H54-401

1/8 Auto Vent Limiter 2-5PSI * Automatic Vent Limiting Device. 1/8 NPT escape Rate 1.0 CFH Nat. Gas @ 2 PSI. Includes Check Valve That Limits Gas Escape Rate To Safe Levels If Diaphragm Ruptures.

Dual Valve Combo Gas Control * Combination Dual Seated Gas Valve. Pilot safety And Pressure Regulator. 24V Coil.5 Amp. 1/2 X 1/2 Or 1/2 X 3/4 NPT Using Adaptor. 130000 BTU. 0F Minimum Includes 1/2 X 3/8 Bushing.
