evt safety valve testing factory

The Electronic Valve Tester, (EVT), is a digital computerized, hydraulic assisted device, designed to test and set safety/relief valves while in service. The EVT is portable and can be used under normal operating conditions without over pressuring the system.

Our Factory and National Board certified technicians, provide total safety/relief valve evaluation utilizing EVT technologies... at your convenience. The Electronic Valve Tester has been approved by the ASME for set point evaluation and or adjustment.

EVT service eliminates the need to overpressure the system for testing. Under normal operating conditions, we save test medium and unnecessary stress on the overall system.

Control Valve Testing is the best way to make sure your current system is performing to an optimal standard. If you’re curious about where your valves are falling short or how you can improve their performance, Pioneer has the solution to get your safety relief valves where they need to be. At Pioneer, we provide specialized equipment to help your pressure relief valves adhere to required standards and certifications. The EVT-Pro from GE offers cutting-edge testing, diagnostics, and reporting for your valves for comprehensive evaluation. The EVT-Pro works for all brands of pressure relief valves.

EVT PRO’s true in-place valve testing enables you to meet local safety requirements for periodic testing and documentation without shutting down processes or dismantling or removing valves from service. EVT PRO has state-of-the-art electronics and proprietary software, including an interface to ValvKeep* valve maintenance and management software.

The Electronic Valve Tester, (EVT), is a digital computerized, hydraulic assisted device, designed to test and set safety/relief valves while in service. The EVT is portable and can be used under normal operating conditions without over pressuring the system.

Our Factory and National Board certified technicians, provide total safety/relief valve evaluation utilizing EVT technologies... at your convenience. The Electronic Valve Tester has been approved by the ASME for set point evaluation and or adjustment.

EVT service eliminates the need to overpressure the system for testing. Under normal operating conditions, we save test medium and unnecessary stress on the overall system.

At each of our 12 convenient locations, the Chalmers & Kubeck Valve and Actuation Technicians are factory trained and certified. Each expert Technician is required to meet stringent factory standards prior certification so you can be confident that we will provide the expert, efficient, and comprehensive service that you expect.

Our services include field trouble shooting, actuator refurbishment, control enhancement, electronic valve testing, torque verification, turnkey overhauls / repairs, retrofits, and valve testing / certification. We offer complete reconditioning of ball valves, butterfly valves, check valves, control valves, gate valves, globe valves, parallel slide valves, pilot operated valves, plug valves, pressure relief valves, pressure safety valves, vacuum break valves, and other specialty valves.

Baker Hughes manufactures the premier boiler safety valves and pressure relief valves in the industry, Consolidated®, and authorizes a very select group of companies to be their exclusive factory authorized repair and service centers, known as Green Tag Centers® (GTC). Ten of the 12 C&K Service Locations are GTCs, which means that you will receive best-in-class aftermarket product support. With our OEM trained and certified valve technicians, you know that your relief valves will be rebuilt correctly to exacting standards. Prior to certification, each of our valve technicians must go through Baker Hughes classroom training that includes applicable codes and standards, proprietary repair procedures, and practical hands-on instruction. The technician must prove their proficiency during both written and practical examinations covering relief valve repair, assembly, and testing. With our certified Green Tag Technicians, you can rest assured that your valves will be serviced in compliance with ASME and NBBI (National Board of Boiler and Pressure Vessel Inspectors) standards so they perform their critical safety function as intended.

Each of our GTC service locations has compete machining capabilities, calibrated measuring and testing equipment, specialized electronic valve testing equipment, and ValvKeep, a proprietary electronic data management system, so you can track and trend the repair history of your valves. We also carry significant inventory of Consolidated pressure relief valves and OEM certified replacement parts ensuring rapid response to your urgent repair needs. If for some reason we don’t have a part in stock locally, we have access to all parts stocked by GTCs throughout the entire United States and can have them overnight shipped to one of our service centers. We are your trusted local pressure relief valve service center whether your valves are Consolidated or another manufacturer’s brand.

Since the first installation of its Limitorque Machine (limit & torque capable) in 1929, Limitorque has been manufacturing some of the most innovative and dependable motor-operated valve actuators for demanding industrial applications.  Flowserve, the parent company of Limitorque, authorizes a select group of companies to be their “Limitorque Blue Ribbon” service and repair centers.  Chalmers & Kubeck is proud to be the largest Limitorque Distributor east of the Mississippi River and that all twelve (12) of our locations are Limitorque Blue Ribbon Service Centers.  With over 20 years  providing outstanding Blue Ribbon Service, C&K is your go-to solution for actuator sizing, selection, adaptation, installation / certification, maintenance, repair, and field service.

This team of valve and instrument specialists works closely together to provide customer assistance in technical sales, quotations and delivery. Chalmers & Kubeck maintains around-the -clock service, which includes the assembly and test of new CONSOLIDATED® pressure relief valves, plus full machining and repair operations for industrial valves of many types and manufacturers. Additionally, C&K provides comprehensive design and manufacturing services to adapt your existing manual valve or a new manual valve to a motor operated actuator for enhanced process control and operator safety.

Precision of proud to be recognized as your local authorized Green Tag Center (GTC) for GE Consolidated® safety and safety relief valve products. The GTC authorization gives you the best-in-class benefits of GTC exclusive programs such as factory trained GTC repair technicians, EVTPRO® auxiliary PRV in line testing, SRVSpeQ® valve sizing program,

ValvKeep® IIis a state-of-the-art, fully customizable valve management database system designed to assist our customers with the storage, management and maintenance of their safety, safety relief, control and block/line valve historical information. With a variety of reporting methods, this program can greatly assist our customers in maintaining their equipment with day-to-day and outage maintenance needs required to comply with OSHA regulations.

Pressure safety valves are designed to protect process piping and equipment in case of an overpressure event. TEAM Valve Solutions inspects, tests, repairs and re-certifies safety valves at 17 service centers across three continents, and in our fleet of mobile facilities, all of which are audited under the jurisdiction of relevant governing bodies.

Our solutions cover all major safety valve brands and support our customers through an inventory of spare parts and loose-assembled valves. In addition, our facilities are audited and governed by the National Board of Boiler and Pressure Vessel Inspectors. Testing, repair, and assembly are performed under license and guidelines of NBIC, and ASME Section I and VIII.

To ensure accurate in-line setpoint verification, TEAM Valve Solutions utilizes Trevitest, the pioneering system for validating safety valve performance in Conventional and Nuclear Power plants, as well as in other industrial process facilities.

vpl has put you on the right track. The Trevitest Device is one brand of Lift Assist Device (others include KISS, EVT, PVT AVK, Hydroset, SPIVOT). SOme are manufactured by Pressure Relief Valve Companies, others by Valve Repair Shops and some are third party vendors with PRV background. A Pressure Relief Valve typically uses a spring (Force S) to hold a movable sealing member (disc) closed on a fixed sealing member (nozzle) until the system pressure (Force P) overcomes the Spring and opens the PRV to relieve an overpressure situation. The PRV works on the simple principle that IF Force S > Force P THEN the PRV remains closed (Static Force Balance Principle). However, IF Force P > Force S THEN the PRV is Open.

The problem is that most Steam Power Generating Stations, whether Fossil or Nuclear, are such high pressure and under so much demand for electricity that they do want to take the time or liability to overpressure their boilers to test Safety Valve Set Pressure. Use of the Lift Assist Device is permitted by ASME Code (both Sec. I, Power Boilers, & Sec. VIII, Pressure Vessels) to determine the Set Pressure of a PRV (Safety, Safety-Relief or Relief Valve).

The Equipment Required is a Calibrated System Pressure Gauge, a Lift Assist Device with an adapter to connect to the PRV Stem, a Calibrated Load Cell to measure the Force Applied to the PRV Stem, a calculator or PC with a program to determine the Set Pressure from the input data and most importantly, a Valve Technician who knows PRV Terminology, and is familiar with the Test Equipment.

Dynamic Engineering Design prepared a maintenance schedule for over 200 relief valves in accordance with the National Board recommendations and based on the service conditions of each valve. Services included compressed air, water, oil, nitrogen, argon, carbon dioxide, and steam.

Dynamic Engineering Design coordinated required outages and scheduled the maintenance actions which include replacing valves, in service testing of valves (EVT – electronic valve testing), and on-site bench testing by a certified valve repair (VR) corporation.

1 GE Oil & GasConsolidated* Pressure Relief ValvesEVT*-Pro Electronic Valve Tester In-Place Testing: No Problem Manages Global Safety Standards Tests All Manufacturers Pressure Relief Valves Helps to Improve Plant Uptime and Increases RevenueConsolidated Valves - EVT*-Pro Valve Testing Device | 32 | GE EnergyHelping You Comply With Global Safety StandardsProtection from Harmful Chemical ReleasesGlobal Safety Standards like OSHA s process Safety Management (PSM) standard was published to help minimize the consequences associated from a catastrophic release of toxic, reactive, flammable, or highly explosive hazardous chemicals. This standard covers several areas, specifically Relief and vent systems and devices. It requires that written procedures, inspection and testing, [and] appropriate job skills be deployed, [and that] records and management of change be in place.

2 Failure to do these things may result in severe to comply with OSHA 29 CFR process Safety Management requirements is one of the most frequent infractions. There are several reasons for this: deficient Pressure Relief devices, inadequate documentation, and lack of Pressure Relief information, procedures, or training and associated Compliance SolutionBy integrating with ValvKeep, EVT-Pro lets you effectively manage the OSHA requirements. Since you can use the device to test any brand of Pressure Relief device, you don t need to manage multiple test suppliers. EVT-Pro and ValvKeep put all your documents in order, so test reports, procedures and other related documents are always available to meet compliance requirements. You are better prepared for audits and lessen the odds of receiving citations and penalties.

3 And EVT-Pro s in-place functionality lets you keep plant operations going while it tests your Set Pressure MeasurementEVT-Pro s true in-place valve testing enables you to meet local safety requirements for periodic testing and documentation without shutting down processes or dismantling or removing Valves from service. You get the true hot set Pressure of the valve, since it is tested under actual operating EVT-Pro device simultaneously examines two critical variables of the Relief device the upward force applied to the spindle and the actual system Pressure . Using sophisticated sensors, including an acoustic device, EVT-Pro testing accu-rately determines the Pressure Relief valve s set Pressure . It can also immediately sense and automatically close a Relief device should it remain open during a test a unique safety feature built into the software and with its rugged yet lightweight test fixture, EVT-Pro has state-of-the-art electronics and proprietary software, including an interface to ValvKeep* valve maintenance and manage-ment software.

4 You can view test results in both tabular form and colorful graphs that depict the exact set Pressure , and historical data and tests are readily available 24/7 with ValvKeep software s database Advanced TestingSee Exact Set Pressures Colorful and clear graphics assist the end user in seeing exact set pressures for the valve in test. Unique acoustic sensor feature provides confirmation of set Pressure on force curves delivering confidence in each TestingHelps to Maximize Plant UptimePre-Planning OutagesID Problem Valves for Rapid TurnaroundsPortable and LightweightCan be Placed in Virtually Any Location in Any Plant Quickly and EasilyUser Defined Report AbilityGet the Report You NeedIndustrial ComputerCan be Taken Just About Anywhere in the Plant No Matter the ConditionsBench Tes tingShop Testing for New and Repaired ValvesAuto Shutdown Safety FeatureSuperb Safety Feature Allows for Closure of Valve Under Full-Lift CircumstancesInterface to ValvKeep SoftwareComprehensive Asset Management Tool Exclusive to GE s GTC sAcoustic Indicator DeviceSensor Takes Guess Work out of Determining Set

5 PressureATEX/UL CertifiedIntrinsic Safety Certified; Available on Certain ModelsTest Gas, Liquid and SteamCapable of Testing all MediaNBBI Accepted (Part 3, para )National Board ComplianceASME-QualifiedMeets ASME Code RequirementsEnd-User Feedback In the past I had to know where my test records were located to demonstrate compliance to our local inspector; this is very important for the OSHA process Safety Management require-ment. With ValvKeep and EVT-Pro, my files are linked and updated so I have quick access to them. Several months ago an inspector was at my plant, standing next to me, asking for the paperwork on the safety Relief Valves . Using ValvKeep I was able to get the reports, show the inspector that the Valves were all certified and had been serviced within the service guidelines.

6 consolidated Valves - EVT*-Pro Valve Testing Device | 54 | GE EnergyHow EVT-Pro WorksNormally, with the Pressure Relief valve online, the much stron-ger force of its spring -- F1 -- is all that is required to prevent system inlet Pressure -- F2 -- from forcing the valve open. However, should F2 increase beyond the operational limit of the system, the valve will first simmer and then prevent the valve from discharging during the EVT-Pro test, the GE-trained service technician introduces just enough pull on the spindle F3 -- to balance the force of the spring. This causes the disc to only crack open or this point the GTC Technician can read the set Pressure from the graphic display of the EVT-Pro and determine if it is set Balance Analysis: F3 + F2 = F1F3 = Artificial pull on the spindle supplied by the hydraulic pumpF1 = Spring force pressing down on the discF2 = Inlet Pressure pushing upward against the discExclusively Available Through Your Local GTC*GE s GTC Network Consists of More Than 80 Facilities Located in More Than 30 Countries WorldwideGreen Tag Center NetworkMore than 125 Years of ExpertiseConsolidated Pressure and safety Relief Valves from GE Oil & Gas have been available for more than 125 years.

7 The EVT-Pro diagnostic tool is the most technologically advanced consolidated field test device ever. EVT-Pro testing meets high standards for quality and accuracy. The GE Green Tag Center (GTC) network is the only place you can access GE s advanced technology, which tests any brand or type of Pressure or safety Relief valve you have. Your local GTC has the EVT-Pro Electronic diagnostics, ValvKeep valve management software and factory-trained and certified technicians to meet your testing and compliance and ValvKeepWide Scope of DocumentationRecord keeping is important to providing proof of your efforts to comply with Global Safety Standards, OSHA included. The scope of documentation is wide, and the more accurately records are maintained, the better it is for audits. Using EVT-Pro Electronic diagnostics and ValvKeep software will lessen the stress of a Safety Inspection inspection and reduce the odds of receiving citations and penalties.

8 As one well known safety organization, OSHA states, OSHA s primary goal is correcting hazards and maintaining compliance, rather than issuing citations or collecting penalties. consolidated Valves - EVT*-Pro Valve Testing Device | 76 | GE EnergyEVT-ProElectronic Valve Test DeviceValvKeepValve Management and Maintenance Software Asset ManagementCompliance TestingGTCG reen Tag CenterValve RepairIntegrated Performance SolutionPressure Relief ValvesCoal-Fired Power PlantGreen TagCenterGEA19101 08/2012* consolidated , EVT, Green Tag Center, and ValvKeep are trademarks of the General Electric company names and product names used in this document are the registered trademarks or trademarks of their respective owners. 2012 General Electric Company. All rights reserved.
