kunkle safety valve model 6252 quotation

Kunkle 6252 Seriesis constructed of heavy duty cast iron with stainless steel semi-nozzle trim and disc. Bolted bonnet design insures easy maintenance. Pressure Limit - 250 psig - 406°F. Available in various inlet sizes - 1-1/2" to 6".

Cast iron ASME section I steam and section VIII, air, steam and gas ‘UV’ National Board certified safety valves including model 6254 to ASME section IV ‘HV’, PED certified for non-hazardous gas.

One of our most popular valves, Kunkle valve 6252 is steam, air and gas certified. Made of cast iron and stainless steel trim, this heavy duty valve is used on steam boilers, steam generators, and pressure reducing steam vessels such as tanks, receivers and oil/gas separators.

ASME Section I Steam and ASME Section VIII, Air, Steam and Gas “UV” National Board Certified. Model 6254 ASME Section IV “HV,” National Board Certified. PED Certified for Non-Hazardous Gas.

Model 6254: Same as Model 6252 except certified for ASME Code Section IV, Low-pressure Steam Heating Boilers. Set 15 PSIG [1.0 barg] only. J through P orifice only.

ASME Section I Steam and ASME Section VIII, Air, Steam and Gas “UV” National Board Certified. Model 6254 ASME Section IV “HV,” National Board Certified. PED Certified for Non-Hazardous Gas.

Model 6254: Same as model 6252 except certified for ASME Code Section IV – Low pressure steam heating boilers. Set 15 psig [1.0 barg] only. J through P orifice only.

Kunkle steam relief valve with a 6" 250 psi flanged inlet x 8" 125 psi flanged side outlet. This valve can be set from 10 to 250 psi pressure with a 25,203 to 216,412 psi per hour capacity. Please state operating pressure when ordering. Kunkle 6252 series steam relief valves are used on steam boilers. These cast iron body with brass trim valves offer side outlet and semi-nozzle trim with steam pressures from 10 to 250 psi and 250°F.

Safety valve for over pressure protection of steam boilers operating up to 250 psi. It is rated up to 250 psi and 406�F saturated steam. 6252 Safety valves meet ASME code, Section I.

Safety relief valve for steam service on unfired pressure vessels. It is also used on accumulators, cleaners, and distillers. Safety relief valves are rated up to 250 psi and 406�F of saturated steam and meet ASME code, Section VIII.

Safety relief valve for air, gas and vapors. It is used on compressors, receivers, burners, dryers and other piping systems. Figure 6252 safety relief valves are rated up to 250 psi and 406�F and meet ASME code, Section VIII.

ASME Code Type--select--Section I; 6252KNM01-AS Steam Boiler Service, V stampSection VIII; 6252KNM01-LS Unfired Pressure Vessel Steam Service, UV stampSection VIII; 6252KNM01-KS Air Service, UV stamp

Kunkle steam relief valve with a 2" NPT female inlet x 3" NPT female side outlet. This valve can be set from 10 to 250 psi pressure with a 2,895 to 24,863 psi per hour capacity. Please state operating pressure when ordering. Kunkle 6252 series steam relief valves are used on steam boilers. These cast iron body with brass trim valves offer side outlet and semi-nozzle trim with steam pressures from 10 to 250 psi and 250°F.

Kunkle Valves offer a wide range of safety and relief valve products for industrial and commercial applications, providing lower cost of operation while exceeding quality and cost expectations. Kunkle Valve provides product from cryogenic through high temperature and vacuum through high pressure Steam, Air, Gas, and Liquid applications. Kunkle Valve provides code certifications that meet various global standards such as ASME, PED, CRN, TU and Chinese as well as non-code requirements.

Cici Boiler Rooms is your one-stop-shop for safety valves! We stock a large inventory of common valves from Kunkle, Watts, and Conbraco. However, we can order any valve that you need.
