non rotating wire rope specifications supplier

Rope Services Direct supplies a variety of anti-spin non rotating wire rope (also called rotation resistant wire-rope). All standard rope wirehas a tendency to develop torque and therefore prone to rotation, whereas non-rotating wire ropes are designed so that the wire-rope outer rotational force naturally counteracts the inner strands rotational force. This is in the event that a rope is subjected to a load.

Rope elongation and rotation occurs on standard ropes when loaded, which can therefore spin the load, quite possibly out of control, which can be dangerous. When the rope rotates in this way the strands will begin to unravel. This causes the rope to lose strength and will undoubtedly fail, which could be catastrophic. It is for these reasons that non rotating wire rope is commonly used for many types of lifting applications including main hoist rope, whip rope,crane rope, off-shore and deck rope and more.

Non rotating wire rope or rotation resistant wire rope has a different construction to standard. as wires and strands are not laid in the same direction like they would be on standard rope. Inner and outer strands of wires are laid in opposite directions. For example the inner may be constructed in left hand lay whilst the outer layer is in right hand lay. The nature of this construction means that torsional forces on the inner and outer wires/strands will counteract each other and therefore minimising the risk of unraveling.

It is worth noting that the number of strand layers will have an effect of the resistance of rotation. A 2 layer rope has less resistance than a 3 layer rope. Therefore the more layers the rope has the greater rotation resistance it will have.

These types of ropes can be classified as spin resistant, rotation resistant or non rotation resistant. Classed on the basis of the number of rotations a certain length of rope does when a force of 20% of the MBF is applied; with 1 turn or less the rope will be classified as non rotating; with rotations between 1 & 4 the rope is classed as low rotation and for rotations between 4 & 10 the rope will be classified as spin resistant, any higher and the rope is NOT rotation resistant at all.

Correct usage and care with handling will prolong the working life. This is due to the friction on the inner wires caused by the strand crossover’s which will eventually cause the inner wires to break up. This is more apparent on non rotating wire rope with two layers. Ropes with 3 or more strand layers will distribute the radial pressures more evenly. Which will reduce friction and stress on the inner wires.

Regular,thorough inspectionsof non rotating rope are essential due to the fact that it is the inner strands that often break first and broken internal wires often go unnoticed as they are difficult to see.Rope Services Direct offer inspectionson all rope with certification issued on completion.

Holding both ends of the rope will prevent unraveling. Correctly fitted terminations will help to prevent damage. Kinking and unraveling may occur and they can also have an effect on the rotational balance if not fitted correctly.

This wire rope construction is available in both galvanised and ungalvanised finish with either ordinary or langs lay. The construction family includes 17X7, 18X7 and 19X7. For further flexibility and other performance characteristics we also supply 32X7, 35X7 and 37X7.

Depending upon your requirement for higher breaking load or better wear characteristics, these wire ropes are available in different finishes and lubrications as well as being available with plastic impregnated.

Depending upon your requirement for higher breaking load or better wear characteristics, these wire ropes are available in different finishes and lubrications as well as being available with plastic impregnated or in compacted constructions.

Manufacturer of standard and custom wire ropes made from phosphorous bronze, Monel®, Inconel® and stainless steel materials. Available in various cable dia. with color and coating options. Features include bright wire, galvanized, rotation and corrosion resistance. Suitable for straight line, medical devices, winches, exercise equipment, aircraft control, rigging and railing applications. Secondary services such as design, CNC machining, electric cutting, extrusion, hydroforming, swaging, coating, tensile testing and zinc die casting are also provided. Serves the aircraft, agricultural, automotive, construction, entertainment, lighting, marine, material handling, medical, military and security industries. Most items available in stock.

SSTE offers  high quality wire ropes for a wide range of applications. The company effectively combines variety of experience and tradition with an up to the minute range of products, and a customer service package ideal for the modern market place.

19X7 is a non-flexible wire rope. It is used for a wide range of applications, example of applications for non-rotating wire ropes include the following

De Ruiter Staalkabel has over 50 years of experience in the field of wire rope and hoisting applications. During this time, we have grown into a globally oriented and turn-key supplier for the offshore, maritime, construction and

verope® merges customer demands for top quality and competitive pricing in production, sales, distribution and services of special wire ropes with a true global reach.

Specialises in:Anchors, Chains & Fenders, Corrosion Control Anodes, Mooring, Ropes, Wires & Cables, Paint & Protective Coatings and Synthetic Fiber Ropes

We offer a solution with DEFIANCE Wire Rope, Fiber Ropes and Hardware, A.L. Don ladders...quality-consistent products that meet or exceed current specifications including but not limited to RRW-410-G, API-9A. Cordage Institute S

Whether you are looking for waterproof salon capes, salon chemical capes, ordinary hair cutting capes, or even special salon gowns such as customised barber capes, you can likely find them on Alibaba.com! Look out for amazing deals for these haircut hair catches and barber gowns and sell them to the many salons in the market! The beauty industry is constantly growing, and even in the worst of economic times, simple beauty tools, cosmetics, and treatments have continued to retain their market size and even growth. The lucrative market draws many barber and hairdresser salons to open at any one time, and you can in turn cater to this market with wholesale equipment and simple wares such as non rotating wire rope!

If you want to gain a competitive edge, you can even sell cute salon capes or cool barber capes with different colours or logo and design customisations. Some wholesalers that are also OEM manufacturers will allow you to do simple printing and customisations. This is especially if you order in large bulk quantities. You can also cater to the upmarket salons with high end salon capes that may be more sleek, made of more durable or slightly better materials. Look out for these non rotating wire rope wholesale or discuss with suppliers when making your purchases to check!

Main and auxiliary hoist line for mobile and for all types of construction tower cranes which require a high strength rotation resistant rope construction.

The large number of outer strands distribute the pressures introduced by sheaves and drum more evenly onto the core minimizing the danger of unexpected rope failures because of undetected core deterioration.

Aside from this safety issue PYTHON® COMPAC 35 satisfies the high-strength requirements of late model tower and mobile cranes which can NOT be met with neither 19 x 7 nor 19 x 19 style ropes.

Some sizes of Python® Compac 35 are available in right AND left hand lay to comply with OEM specifications (LinkBelt, Grove, Favelle Favco, Terex, Krupp, Demag, Liebherr, etc.).

19x7 Rotation- Resistant Wire Rope is a special class of wire rope designed to resist the tendency to spin or rotate under load. This is achieved by laying 6 strands around the core in one direction, then laying 12 strands around the first in another direction. It is often used for hoisting unguided loads with a single part rope. Commonly used as a crane wire rope and hoist cable.

Frequent and regular inspection for broken wires is critical when using this rope. Due to its design, the 19 x 7 construction has relatively low reserve strength and this can result in short service life.

Inspect regularly for visible damage, distortion, elongation, corrosion, cracks, nicks or abrasion, which may cause failure or reduce the strength of the Wire Rope.

We provide Best of Best quality Wire rope as per customer requirement and price wise starting with USHA MARTIN, BWR,BEDMUTHA,OREINT,VIKRANT,NAVIN as per client requirement all with Test certificate

This drawn galvanized wire rope is designed for superior strength and corrosion resistance. Most galvanized wire is first drawn as a bright wire to a predetermined shape and then coated, which slightly increases the diameter while slightly decreasing its strength. The zinc coating helps to protect the wire from weathering and wear, extending the longevity of the rope.

The rope is then compacted to flatten the surface area and increase contact between strands, which helps to decrease friction that can wear down the wire strands and internal core.

Wanting to buy compacted galvanized wire rope? Send Elite Sales a message to learn more about different types of wire rope and purchase the exact type, diameter, and length that you need for any type of application.

The characteristic of these wire ropes are that the outer layer is twisted in the opposite direction of their inner layers. The sometimes confusing issue is that many 8-, 9- and 10 strand constructions are 2-layer types but their inner strands are NOT twisted in the opposite direction and therefore these rope are NOT spin-resistant; plus, for the untrained eye these ropes look very much alike their spin-resistant variants. These and regular 6-strand ropes will spin violently and unlay themselves when loaded when one rope end is allowed to spin freely. They may also develop a significant drop in breaking strength and an even larger drop in their fatigue life characteristic (Torsion Fatigue).

To achieve any degree of resisting the tendency of a rope to spin and unlay under load all such rope types (other than 4-strand ones) are constructed with 2 or more layers of opposite twisted strands (see picture on right).

2-layer ropes (MULTI, COMPAC 18) have a larger tendency to rotate than 3-layer ones (e.g. Class 34 x 7, COMPAC® 35). Furthermore, 2-layer spin-resistant and rotation resistant ropes will develop only about 55% to 75% of their breaking strength when one end is allowed to rotate freely. This number increases to between 95% to 100% for 3-layer (e.g. COMPAC® 35) non-rotating ropes.

Another important issue is that 2-layer rotation resistant and 2-layer spin-resistant rope types have shown to break up from the inside. The 8 (e.g. 8×25 spin-resistant) or 12 outer strands (19×7, 19×19, COMPAC®18) are not able to evenly distribute the radial forces and because of the inherent internal strand cross overs (which make the rope spin- or rotation resistant) the resultant severe notching stresses cause the rope core to break up premature (unless the core is plastic coated, e.g. Python® Multi). Unexpected and sudden rope failures may be the result. Moreover, 2-layer spin-resistant or rotation resistant ropes satisfy only low to moderate rotational resistance demands.

3-layer rope constructions (e.g. COMPAC® 35) have many more outer strands which can much better distribute the radial pressures onto the reverse lay inner strands. These ropes should be selected for larger mobile- and ALL tower cranes.

AFGHANISTANAland IslandsALBANIAALGERIAAMERICAN SAMOAANDORRAANGOLAANGUILLAANTARCTICAANTIGUA AND BARBUDAARGENTINAARMENIAARUBAAUSTRALIAAUSTRIAAZERBAIJANBAHAMASBAHRAINBANGLADESHBARBADOSBELARUSBELGIUMBELIZEBENINBERMUDABHUTANBOLIVIABOSNIA AND HERZEGOWINABOTSWANABOUVET ISLANDBRAZILBRITISH INDIAN OCEAN TER.BRUNEI DARUSSALAMBULGARIABURKINA FASOBURUNDICAMBODIACAMEROONCANADACAPE VERDECAYMAN ISLANDSCENTRAL AFRICAN REPUBLICCHADCHILECHINACHRISTMAS ISLANDCOCOS (KEELING) ISLANDSCOLOMBIACOMOROSCONGOCOOK ISLANDSCOSTA RICACOTE D"IVOIRECROATIACUBACYPRUSCZECH REPUBLICDEMO. PEOPLE"S REP. KOREADemocratic Republic of CongoDENMARKDJIBOUTIDOMINICADOMINICAN REPUBLICECUADOREGYPTEL SALVADOREQUATORIAL GUINEAERITREAESTONIAETHIOPIAFAEROE ISLANDSFALKLAND ISLANDSFED. STATES MICRONESIAFIJIFINLANDFRANCEFRENCH GUIANAFRENCH POLYNESIAFRENCH SOUTHERN TER.GABONGAMBIAGEORGIAGERMANYGHANAGIBRALTARGREECEGREENLANDGRENADAGUADELOUPEGUAMGUATEMALAGuernseyGUINEAGUINEA-BISSAUGUYANAHAITIHEARD AND MC DONALD ISL.HONDURASHONG KONGHUNGARYICELANDINDIAINDONESIAIRANIRAQIRELANDIsle of ManISRAELITALYJAMAICAJAPANJerseyJORDANKAZAKHSTANKENYAKIRIBATIKUWAITKYRGYZSTANLAOSLATVIALEBANONLESOTHOLIBERIALIBYAN ARAB JAMAHIRIYALIECHTENSTEINLITHUANIALUXEMBOURGMACAOMACEDONIAMADAGASCARMALAWIMALAYSIAMALDIVESMALIMALTAMARSHALL ISLANDSMARTINIQUEMAURITANIAMAURITIUSMAYOTTEMEXICOMONACOMONGOLIAMontenegroMONTSERRATMOROCCOMOZAMBIQUEMYANMARNAMIBIANAURUNEPALNETHERLANDSNETHERLANDS ANTILLESNEW CALEDONIANEW ZEALANDNICARAGUANIGERNIGERIANIUENORFOLK ISLANDNORTHERN MARIANA ISL.NORWAYNOT ON THE LISTOMANPAKISTANPALAUPalestinian TerritoryPANAMAPAPUA NEW GUINEAPARAGUAYPERUPHILIPPINESPITCAIRNPOLANDPORTUGALPUERTO RICOQATARREPUBLIC OF KOREAREPUBLIC OF MOLDOVAREUNIONROMANIARUSSIAN FEDERATIONRWANDASaint BarthelemySAINT KITTS AND NEVISSAINT LUCIASaint MartinSAINT VINCENT & GRNDNSSAMOASAN MARINOSAO TOME AND PRINCIPESAUDI ARABIASENEGALSerbiaSEYCHELLESSIERRA LEONESINGAPORESLOVAKIASLOVENIASO. GA & SO. SNDWCH ISL.SOLOMON ISLANDSSOMALIASOUTH AFRICASPAINSRI LANKAST. HELENAST. PIERRE AND MIQUELONSUDANSURINAMESVALBARD & JAN MAYEN ISL.SWAZILANDSWEDENSWITZERLANDSYRIAN ARAB REPUBLICTAIWANTAJIKISTANTHAILANDTimor-LesteTOGOTOKELAUTONGATRINIDAD AND TOBAGOTUNISIATURKEYTURKMENISTANTURKS & CAICOS ISLANDSTUVALUUGANDAUKRAINEUNITED ARAB EMIRATESUNITED KINGDOMUNITED REP. OF TANZANIAUnited States Minor Outlying IslandsUNITED STATES OF AMERICAURUGUAYUZBEKISTANVANUATUVATICAN CITYVENEZUELAVIETNAMVIRGIN ISLANDS (BRITISH)VIRGIN ISLANDS (U.S.A.)WALLIS & FUTUNA ISLANDSWESTERN SOMOAYEMENZAMBIAZIMBABWE

Widely used for hoisting unguided loads with a single part of rope. Typical applications are hoisting ropes on Derricks, boom cranes, shaft sinking hoists and freely suspended mine hoists. Both 19 X 7 and 8 X 19 are bright, right regular lay wire ropes.
