We offer inspections and mobile proof test services for product verification, break testing, and load testing to ensure compliance for all wire rope slings we sell and repair. Our mobile proof test services are available throughout the United States. In addition to our mobile load testing services we have stationary test beds to service Oklahoma, Texas, Kansas, Wyoming, North Dakota, New Mexico and all surrounding areas.

Single Leg Wire Rope Slings otherwise known as eye/eye or Eye & Eye slings are manufactured from high-quality wire rope that has been engineered and mechanically spliced to form the non-reinforced soft eyes found at each end.

Available online with diameters up to 1inch and capacities up to 9.8Tons and lengths of 20ft as well as larger sizes offline. Single body wire rope slings are also offered with various different end terminations like thimble eyes and hooks to suit a variety of industries such as offshore, engineering, automotive, recycling, oil & gas and many others.

Proudly assembled in the USA, our slings are fitted with a robust identification tag displaying the unique serial number and Working Load Limit. Made from an Independent Wire Rope Core (IWRC), our wire slings offer resistance to crushing and less stretch whilst still manageable and flexible. Manufactured from Extra Improved Plow Steel (EIPS).

For further information, advice and quotations on multi-leg or larger sizes of Single Leg Eye & Eye Wire Rope Slings please contact a member of our sales team who will be happy to help.

IMPORTANT: All of our Wire Rope Slings & Chokers are manufactured on demand (extremely quickly) to your exect order, right here in Houston, TX. The date of manufacture is also stamped on each sling tag, for these reasons all sling sales are final and cannot be returned or exchanged once ordered.

Single leg wire rope slings are just as they sound- they are comprised of a single length of wire rope. Also sometimes known as one leg wire rope slings or single leg cable slings, these heavy duty lifting slings offer some versatility as they can be manufactured with a variety of end configurations.

An eye loop is formed using a flemish eye splice, in which the rope is separated into two parts. One part contains three strands and the other three strands plus the core. These two rope parts are then re-laid back into the opposite direction, forming an eye. The entire area is then secured by a metal pressed sleeve.

Sliding Choker Wire Sling:Sliding choker wire rope slings are made of 6 x 19 EIPS wire rope and have a sliding choker hook between the two eyes that slides from one end to the other for easy hook-up. Sliding wire choker slings feature a regular eye for the top portion of the lifting sling and a thimbled eye for the portion of the sling that loops back to attach to the sliding hook. This helps prevent wear and tear on the sling eye by protecting the steel cable rope from rubbing on the hook. Our sliding wire rope choker slings are also available with a latched choker hook by special order.

Ultra Flexible Cable Laid Sling: Cable laid wire rope slings are manufactured using an ultra-flexible 7 x 7 x 7 galvanized aircraft cable to offer more flexibility than a standard steel wire cable sling. Though the cable laid sling is weaker in strength than the standard wire rope, it offers excellent corrosion resistance. Our standard cable laid metal slings have eyes on both ends but other fittings are also available, including thimbles, hooks, crescent thimbles, and slip-thru thimbles to create the custom steel strand lift sling you need.

As with all lifting slings, the rated capacities of single leg wire slings will vary based on the type of wire rope, as well as the direction and angle of the pull.

Single leg design can be used in a range of hitches and angles. Manufactured with mechanical Flemish eye splicing for excellent efficiency and strength.

Single leg design can be used in a range of hitches and angles. Manufactured with mechanical Flemish eye splicing for excellent efficiency and strengt...

Single leg design can be used in a range of hitches and angles. Manufactured with mechanical Flemish eye splicing for excellent efficiency and strength.

Looking for wholesale single leg wire rope sling to sell at your online store? Look no further than Alibaba.com for a rich catalogue of options and features. You can find your ideal drip brewer.

single leg wire rope sling have become the ubiquitous choice for anyone wanting to try a better flavor of coffee. This is owing to their ease of use and maintenance. single leg wire rope sling and the electric filter coffee machine are easy to clean. Just put soapy water on the metal filter and rinse. Same procedure applies for the kettle that is usually made of glass for a sleek and classy look. A myriad of options abound for automatic drip coffee makers. Opt to spend more and you will be introduced to popular drip coffee makers like the spinn coffee maker, cafeteira automatica and programmable coffee maker, with features like programmable brew settings, automatic timers so that you wake up to the pleasant smell of coffee in the morning, a “keep warm” setting that maintains the perfect temperature for the coffee without overcooking it, among other features.

You don"t even need electricity to make coffee with single leg wire rope sling. Compared with drip coffee pot non electric, you can even enjoy the slow, satisfying process in your own home with electric coffeemakers.Just boil water over a camping stove, put a coffee filter over your drip coffee maker, add coffee, and then brew to your heart"s content.

Wire rope lifting slings, bridles and assemblies provide great durability and high tensile strength for lifting heavy loads. In addition, wire rope lifting slings are lighter in weight and more cost efficient than chain slings. Wire rope slings, sometimes referred to as wire slings, or cable lifting slings, are constructed using a variety of different styles and sizes of steel wire rope. Every style and size of wire rope offers different properties and benefits such as:

Each type of wire rope has benefits and drawbacks. What all wire ropes have in common however, is that they are made up of steel wires which form individual stands. These strands are laid in a helical pattern around a fiber or steel IWRC (independent wire rope core) core.

Wire rope lifting slings, bridles and assemblies are highly customizable, so if you are unable to find what you are looking for, or if you don’t know exactly what you need, call or email our sales team to speak with a rigging product specialist.

The durability of steel cable lifting slings is also put to the test in the harsh environments seen in steel mills and forging facilities. Every steel wire rope configuration will offer different properties and will be better equipped to handle certain applications. Generally, a smaller number of large outer wires will provide more wear, corrosion and abrasion resistance. Conversely, a larger number of smaller outer wires will provide better flexibility and fatigue resistance.

After you decide what construction and size of wire rope fits your application, you must configure the entire sling. Wire rope bridles and assemblies are available in single-leg, double-leg, triple-leg, and quadruple-leg configurations. They most commonly have 2 eyes and are constructed using a mechanical flemish splice. Wire rope lifting slings can be used in vertical, choker and basket hitches. They can also be equipped with a variety of attachments and fittings to accommodate almost any overhead lifting application.

Although wire rope sling fittings and attachment can be reused, the wire rope itself is not repairable. If a wire rope sling fails an inspection, it is to be properly destroyed and disposed of

It is important to inspect wire rope slings regularly and to keep a record of all sling inspections. At Tri-State Rigging Equipment we offer a full range of rigging inspection and repair services. The standards that govern wire rope sling inspection are OSHA 1910.184 and ASME B30.9. It is recommended that wire rope rigging slings first undergo an initial inspection when you receive the lifting sling from the manufacturer. The purpose of this initial inspection is to:

Wire rope slings, bridles and assemblies should also be inspected by a designated and qualified individual every day before use to make sure that the sling is in working condition and will lift its rated capacity. The person performing the inspection should examine all the wire rope, fastenings and attachments on the wire rope sling. The inspector is looking for visual indications of any defects, deformities and general damage that might affect the integrity of the sling.

Depending on your application, it may be recommended that you perform these visual inspections more than once a day. If the wire rope sling is used many times throughout the day, by multiple individuals, across multiple shifts, it is imperative that the sling be inspected before every shift change and before any change in lifting application.

ASME standards further require a thorough periodic inspection to be performed at least once a year by either a professional service provider, or by a Qualified Person. In addition, written records must be kept until the next periodic inspection. The rejection criteria for periodic wire rope sling inspections are as follows:

10 or more randomly distributed broken wires in one rope lay, or 5 or more broken wires in one strand in one rope lay, for strand-laid grommets and single part slings.

If your wire rope sling shows any of the rejection criteria above, you must remove the sling from service, and it must be destroyed. Properly destroying rigging equipment is imperative because you can be held accountable for damage done by people who find and use your discarded slings. Therefore, lifting slings deemed not suitable for service must be destroyed beyond use and beyond repair. The process for destroying a wire rope sling is as follows:

The purpose of daily and periodic wire rope sling inspections is not to get anyone in trouble but rather to gain knowledge of the frequency of use, severity of conditions, and nature of lifts, and consider how all these factors affect your wire rope sling. The most important reason to perform daily and periodic wire rope sling inspections, however, is to keep you and your coworkers safe.

Tri-State Rigging Equipment is a custom manufacturer, service provider and distributor for all wire rope lifting slings serving clients from coast to coast, Canada, Mexico and especially focused in the states of Missouri, Illinois, Indiana, Iowa, Kansas, Nebraska, Arkansas, Mississippi, Tennessee, Kentucky, South Carolina, Florida, and Oklahoma.

We are a full service rigging supply company located in Ridgway, Pennsylvania. Our location is fully equipped to handle your wire rope fabricating, chain and synthetic sling and hardware needs.

Wire Rope Material: The lifting slings are made from independent wire rope core (IWRC) offering less stretch and resistance to crushing while maintaining sling flexibility. Wire rope slings are fabricated from extra improved plow steel (EIPS).

A low quality wire rope sling can cause injury and damage. A look-alike wire rope sling often found at lower prices is also often advertised to conform to the same safety standards (if at all). Be aware that it may refer to safety ratings in effect decades ago. So for example under the same safety standard a decade ago, a wire rope sling may be rated to 100% without proof load testing while today it may be 300% with proof load testing. Be assured that we only sell the highest quality wire rope slings and our advertised safety standards conform to the current ASME standards.

Working load limits (capacity) of the wire rope lifting slingsvary depending on the angle of use. The capacity is reduced as the angle of use declines. See drawing below how a 1,000 lbs sling capacity is reduced as the angle of use declines. The capacity of the sling is always highest at a 90 degree angle of use and smallest at an angle of 30 degrees (or less).

The wire rope sling is not quite as durable. The wire rope sling is not as flexible as chain but its greater stiffness can be an advantage if it has to be inserted through a small opening or beneath a load. However, when wrapped around a load, the wire rope sling often tends to deform permanently to the shape of the load. Wire rope suitable for slings comes in a variety of grades and constructions. In most cases looping back and securing the loop with a metal sleeve terminates the rope. This forms a loop or soft eye, the simplest form of sling end. Thimbles are used to support and protect the eye from abrasion. Wire rope is generally cheaper and lighter than chain which can be a plus, particularly for applications that require long sling lengths.

The nylon and polyester slings have the advantage of being lightweight in comparison to chain and wire rope slings. They are very flexible and relatively soft; therefore, they are suitable in applications were minimal damage to the load"s surface finish is important. The rope is made endless or terminated with an eye by means of a handmade splice. Similar to a wire rope sling, various terminal fittings are available. Without adequate protection, nylon and poly slings are susceptible to being severed when impinging on even a relatively moderate sharp edge.

Wire rope is often commonly referred to as cable; they are one in the same. Wire rope is composed of wires, strands, and a core. The basic unit is the wire, which is formed into strands. The strands are wound around the core. Various types of wire rope exist to meet a range of uses and operating conditions. These types are designated by the number of strands; the number, sizes and arrangement of the wires in each strand; and the way in which the wires and strands are wound, or laid, about each other.

Important characteristics of wire rope relate to the number and size of the outer wires. A small number of large outer wires result in better resistance to wear and corrosion. A large number of small wires result in better flexibility and resistance to fatigue.

The core acts as the axial member about which the strands are laid. Wire rope cores are made in two different forms. The one used most extensively is a wire rope of suitable size to serve as a core. It is called as independent wire rope core (IWRC). IWRC has increased tensile strength, offers less stretch, and is resistant to crushing; however, is less flexible. The other type is a wire strand core (WSC). This consists of a multiple-wire strand, and may be the same construction as the main rope strands.

Two grades of carbon steel wire are offered. The bulk of commercial wire rope lifting sling is made from improved plow steel (IPS) or extra improved plow steel (EIPS) which has a higher tensile strength.

Hand Splicing: Because no metal sleeve is required to secure the eye in the hand spliced sling, it exhibits more flexibility than mechanically splice slings of equal diameter. They have a more narrow profile and therefore can fit through tight spaces. Without benefit of a metal sleeve, lifts must be limited to applications where the wire rope sling is restrained from rotation and possible unlaying of the sling body.

Mechanical Splicing:Mechanically spliced eyes do not suffer the limitations of hand splicing, are economical, and offer the highest rated capacity of any spliced wire rope sling. This wire rope sling is fabricated by unlaying the rope body into two parts, one containing half the number of strands, the other having the remaining strands and core. The rope is unlayed far enough back to allow the eye to be formed by looping one part in one direction and the other part in the opposite direction and laying the rope back together. The strands are rolled back around the rope body and a metal sleeve is slipped over the ends and pressed (or swaged) to secure the ends to the body of the wire rope sling.

Wire rope sling assemblies are the most common and rugged slings used today that can be made in single, double, triple and quadruple leg configurations. In addition to meeting the demanding environments as a standard sling, wire rope sling assemblies can also be braided into multiple parts making them more flexible and able to handle higher capacity by increasing the diameter of the sling. Together, all Bishop Lifting Products riggers are trained to fabricated wire rope slings with a flemished eye, not a Texas tuck or turn back eye splice.

Assembled per order and made with 6x25 class wire rope. These superior lifting slings can be used in choker, basket, or vertical hitches. Custom sizes and other wire rope classes are also available per request.
