spacemaster sx wire rope hoist pricelist

We are committed to helping you rise above the challenges of your everyday business. The safety, reliability and reduced maintenance of the Spacemaster® SX wire rope hoist allows you to get the most out of your equipment. As a standard feature, this hoist includes hoist monitoring to provide real-time data about hoist operation.

Designed to maximize dimensional envelope and operational efficiency, the wide capacity range of this hoist is ideal for applications across industries. The Spacemaster SX wire rope hoist can be configured to your precise facility needs, from building headroom and workflow needs to environmental considerations.

Our innovative hoist design provides the best headroom in the industry while minimizing hook drift and maximizing end approaches. This means you get more floor coverage and easier operation of the equipment. Standard inverter controls on the trolley reduce load swing and minimize brake wear.

R&M offers load monitoring systems as standard with every wire rope hoist. The HoistMonitor and HoistWatch systems give you real information about your equipment use and service needs while preventing overloads to the crane. In addition, our regenerative braking system can ensure safe operation for your crane operators.

At R&M, all our equipment is designed in-house, specifically for lifting applications. The innovative gear case design reduces stress on drum bearings, lowering the need for maintenance and extending the life of the equipment. Our unique rope drum design, with 40:1 drum to rope diameter and motor inside the drum, provides the least hook drift in the industry while improving motor cooling efficiency.

Our RX Program has a selection of wire rope hoists ranging from 1 to 40 tons, available in 2-5 business days! Ask a R&M Distributor for more information on this program.

Have an upcoming project? Use our Crane Designer for an instant recommendation of crane and hoist components that will help you rise above your competition.

The Spacemaster® SX Electric Wire Rope Hoists from R&M Materials Handling represents a revolutionary new generation of exceptionally reliable electric wire rope hoists, featuring advanced technology and cutting-edge performance.

An innovative design that includes a large drum diameter gives Spacemaster® SX hoists the lowest headrooms and best wheel loads in the industry while providing near true vertical lift with single reeved hoists, and both exceptional hook approaches and heights of lift.

Standard electric wire rope hoist configurations include normal headroom, low headroom and double girder trolley designs. Hoists in short ton ratings (ASME) or metric ratings (FEM) meet a wide variety of application requirements:

The Spacemaster® SXs’ unique hoist features include new low maintenance, sealed brakes, a two-speed hoist motor, and trolley inverter control. The standard hoist nameplate will carry a CSA c/us rating as well as a NEMA 3R rating for electrical enclosures. Two-component epoxy paint is standard. Spacemaster® SX hoists are designed to meet and exceed either …

The Spacemaster® EX electric wire rope hoist is the hazardous location version of the industry leading Spacemaster® SX hoist. An innovative design that includes a large drum diameter gives the Spacemaster® EX hoists the lowest headrooms and best wheel loads in the industry, while providing near true vertical lift with single reeving, as well as exceptional hook approaches …

The CM Series 653 Lever Operated Hoist features a short handle and minimal lever pull effort combined with high quality, rugged steel for close quarter pulling, stretching, and hoisting applications. This lever hoist is ideal for a wide array of applications in construction, industrial and plant operations.

JET® S90 Series hand chain hoists were designed with reliability and durability to perform in light-duty industrial applications. Easily maintained and serviced, the JET® S90 is available in capacities from ½ ton to 10 ton and standard lifts of 10, 15, 20, and 30 feet (custom lifts available). The JET® S90 is the ideal contractor …

JET is committed to delivering the simplest and most efficient safety solutions. The JLP-A series lever hoists are designed to create a safer work environment. The JLP-A comes standard with the new brake wear indicator. This technology adds additional safety to the job by providing a visual indication when the brake discs need replacing. JLP-A …

Harrington’s Harringtons TCS CHEETAH air chain hoist is available in 1/4, 1/2 and 1 Ton capacities with either pendant or cord control. This hoist has extremely fast and uniquely adjustable lifting and lowering speeds. The TCS is lightweight, compact and has outstanding feathering ability making it a perfect fit for fast-paced assembly line and workstation …

Harrington’s TCR large capacity air chain hoists are market tested and proven to be durable and easily repairable. These high-performance hoists have all of the power required for lifting very heavy material and are the ideal choice for extreme applications including in mines, shipyards, heavy construction, rigging situations and the petrochemical industry.

Harrington’s TCR air chain hoists are designed with a heavy-duty standard body and are able to lift heavy loads in the most demanding or harsh environments. Available in cord control which allows operator to remain within reach of the load and pendant control that provides easier inching or feathering and permits operation from a remote …

Harrington’s SNER electric chain hoists are built for extreme duty applications that require single phase power. A hoist with a 60 minute, H4 duty rated motor is revolutionary and unmatched in a single phase offering. Maintenance friendly features include a unique chain guide, hinged control panel, sealed housing and durable load sheave. For beam travel …

Harrington’s unique SEQ model hoist is a DUAL SPEED VFD, 1-PHASE electric chain hoist with re-connectable 115/230V power. This hoist also includes a no-load high speed function that automatically increases hoist speed up to 130 percent when the load is less than 30 percent of working load limit. Mount the SEQ hoist to our PT …

Harrington’s LB lever hoists combine easy operation with a compact, low headroom design that easily handles real-world demands. Rated the number 1 selling lever hoist in the U.S., these hoists can be used horizontally, vertically, inverted or at any other load angle and have the strength to get the job done.

Harrington’s EQ dual speed VFD 3-phase electric chain hoists are designed for medium to heavy-duty industrial and workstation applications. These hoists include a unique no-load high speed function that automatically increase hoist speed up to 130% when the load is less than 30% of working load limit. Add our MRQ motorized, PT push and GT …

Harrington’s AH Mini Cat air chain hoists offer an extremely lightweight, small body design suitable for on-site jobs, workstations and assembly line applications. Available in pendant, cord and manipulator control and all models can easily lug mount to our ET mini trolley for added mobility. This hoist weighs only 12 lbs. with 10 foot of …

Harrington’s MR three-phase motorized, PT manual push and GT manual geared trolleys easily couple with our (N)ER enhanced features electric chain hoists and provide excellent traversing motion and control. MR electric trolleys are built for the most demanding applications while our PT and GT manual trolleys are used for traversing a load when electric power …

Harrington’s (N)ER enhanced features three phase electric chain hoists are equipped with the latest technology in the market today. All models include a low headroom, lightweight body with a fan-cooled motor, standard thermal motor protection and a count hour meter for preventive maintenance. A secondary mechanical load brake is an additional features on ER models …

JET L-100 Series hand chain hoist integrates safety, durability and innovation enabling it to operate in the most demanding industrial environments. The patented fused brake system reduces maintenance costs and limits downtime. The JET® L-100 is available in ¼ ton to 20 ton capacities and standard lifts of 10, 15, 20, and 30 feet (custom …

Harrington’s SHB trolley hoists combine our industrial grade CB hand chain hoist less slip clutch with a unique permanently attached hand geared trolley. This low profile configuration is ideal for use in limited space applications.

Harrington’s CB and CF hand chain hoists can easily be coupled with our PT push trolleys and our GT geared trolleys for added mobility. These trolley/hoist combinations offer all of the top quality features and benefits of the individual hoist and trolley.

Harrington’s CF hand chain hoists were designed for portability and durability. These hoists are the economical and practical choice for efficient, trouble-free service. The CF model is a long-lasting construction grade hoist that offers the best value in a hand chain hoist.

The CM Cyclone Hand Chain Hoist features superior engineering, efficiency, and durability and is considered one of the most popular hand chain hoists ever designed. It is available in a variety of capabilities from ¼ ton to 10 tons.

The CM Valustar Electric Chain Hoist features a compact, lightweight design built specifically for general commercial applications. Valustar is an economical choice for your material handling needs.

The CM ShopAir Chain Hoist features superior lifting speeds, rugged design, and precise load spotting in a portable air chain hoist. It is ideal for a workstation hoist or a production line hoist due to its compact design and very light weight.

The R&M Spacemaster® SX hoist is a reliable electric wire rope hoists with an innovative design. It has a large drum diameter, giving this R&M hoist the lowest headroom and best wheel loads in the industry while providing near true vertical lift for a single reeved hoist.

What does a larger hoist drum do for you? A drum/rope diameter ratio of approximately 40:1 minimizes rope flex, reducing wear and extending rope life. The Spacemaster® hoist drum"s large diameter contributes to a reduction in frame size and weight. Also, the placement of the electric rope hoist motor inside the drum allows airflow through the drum for optimal motor cooling.

The larger drum diameter provides near true vertical lift with only 1/8 inch drift per foot of lift. The Spacemaster® hoist"s larger drum provides consistent smooth movement and better vertical positioning. This R&M hoist design also means a shorter frame length, allowing closer end approaches.

4-position hoist limit switch includes an innovative phase mismatch protection circuit that prevents the block from running up and damaging the R&M hoist in the event of phase reversal.

Hardened ground gears, thermal motor protection, exceptional rope life and ergonomic hook block design with sturdy safety latch contribute to the hoist"s safe operation and increased reliability.

The R&M Spacemaster® SX design utilizes a large drum diameter ensure the lowest headrooms and best wheel loads in the industry. The single reeved hoist provides near true vertical lift with only 1/8" of drift per foot of lift making load positioning accurate and easy. The reduce trolley frame allows exceptional hook approaches. The SX features low maintenance, sealed brakes, a two-speed hoist motor, and trolley inverter control.

Hoist and trolley motors: The standard hoist is two-speed with a 6:1 ratio. The motors are designed specifically for hoisting applications, offers high starting torque and ensures precise and reliable load handling. This motor is class F insulated. It is rated for use 30 minute out of an hour giving it a 60% effective duty. The trolley motor"s standard VFD control offers two-step or infinitely variable control for smooth acceleration and deceleration, minimal load swing; fast, and precise load placement.

We pursue excellence and meet the real and potential needs of our customers with high quality Warehouse Jib Crane, electric hoist for pickup truck bed, electric hoist 5 ton 220v.In the future, we will develop innovative, practical, cost-saving solutions and technology applications as well as high-quality electric wire rope hoist 2 ton in relevant industries. Our employees always adhere to the concept of "morality and courtesy", pay close attention to the current situation of the industry, constantly research and innovation, and strive to become the backbone of the industry. Our staff have scientific thinking and skills, they have the sense and ability of innovation. We have all-day online customer service, provide good pre-sales and after-sales services, and communicate with customers in time to solve customer needs. We firmly believe that only with innovation can there be prospects and only with credibility can there be a market. As a social organism, an enterprise must not only be a money making machine, but also have its own value pursuit. High quality products and services and a high number of product marketing make our enterprise to achieve one after another business objectives and to achieve our enterprise"s ideal. We have accumulated a wealth of experience and lessons learned, and developed a unique technical capability.

Product: Electric Wire Rope Hoist Model Number: C1W02D025-15M2D1 Capacity: 2 Ton (4,000 lbs) Lift: 25 Feet Hoist Speed: 15 FPM Voltage: 230/460-3-60 Suspension: Motorized Trolley Trolley Speed: 50 FPM Flange Range: 4 1/4” - 10 ...

2 Ton Rope Hoist Pulley Wheel Block and Tackle, 4000LB 65 Feet Poly Rope Hoist Pulley Block 7:1 Ratio Lifting Power . Brand: J&R Quality Tools. ... 110V Electric Hoist Zinc-Plated Steel Wire Overhead Crane Garage Ceiling Pulley Winch w/Straps (w/Emergency Stop Switch) #1 Best Seller ....

R&M"s Spacemaster SX wire rope hoist features a large drum diameter that creates near true vertical lift, and its frame design allows closer end approaches than other hoists on the market. Standard electric wire rope hoist configurations include normal headroom, low headroom and double girder designs. Contact Us. 800-955-9967; Distributor Login ......

2 Ton Electric Wire Rope Hoist Price List $700 - $1,100. 2 Ton Electric Wire Rope Hoist Price List only includes the Electric Hoist price. Please also provide the Electric Wire Rope Hoistlifting height, and fill in below. 2 Ton Electric Wir +86 15836006986. sales@ygcrane.com. Home About Us. Company Introduction; Crane Certificates; Plant View;...

Jul 29, 2019 · Electric wire rope hoists 2 ton The electric wrie rope hoists has 0.8m/m, 8m/m two speed options which coordinate with each other to realize the efficient material handling work with precision. MD hoist for sale....

ACCO 2-Ton Wire Rope Hoist with Motorized Trolley. Product: Electric Wire Rope Hoist Model Number: C1W02D025-15M2D1 Capacity: 2 Ton (4,000 lbs) Lift: 25 Feet Hoist Speed: 15 FPM Voltage: 230/460-3-60 Suspension: Motorized Trolley Trolley Speed: 50 FPM Flange Range: 4 1/4” – 10 1/2” Reeving: 2 Part Manufacturer: ACCO Wright Speedway Hoist ......

Our company has a strong customer base, a high-quality professional team, and a complete sales network to provide high-quality products and perfect services for various mini electric wire rope hoist 1050w pa-500, 4 point electric hoist. We"re well-known as one of the leading electric wire rope hoist 2 ton manufacturers and suppliers in China, specialized in providing the best customer design service. We warmly welcome you to buy high quality electric wire rope hoist 2 ton for sale here from our factory. For price consultation, contact us.

2 Table of Contents 1 PERFORMANCE General HOIST DUTY SERVICE CLASSIFICATION FEM Hoist Duty Service Classification ASME Hoist Duty Service Classification Comparison of Hoist Duty Service Classifications HOIST FEATURES Standard Features HOIST CHARACTERISTICS Height of Lift and Drum Code Hoist Speeds Suspension Type Code Reeving Code Rope Type Code Hoist Duty Rating Hoist Characteristics Table MAIN COMPONENTS - HOIST HOIST MOTOR Hoist Motor Features Optional Hoist Motor Features Ambient Conditions P-Motors T-Motors Motor Temperature Protection Motor Cooling Hoist Motor Brake Hertz Hoist Motor Data Two-speed Hertz Hoist Motor Currents Two-speed Hertz Hoist Motor Data Two-speed Hertz Hoist Motor Currents Two-speed Hertz Hoist Motor Data Inverter Motors Hertz Hoist Motor Data-Inverter Motor Hoist Motor Currents Inverter Motor (100 & 120 Hertz) HOIST GEARBOX Hoist Gear Reducer Hoist Gear Lubricant ROPE DRUM Drum Data Drum Length Code Rope Clamps Rope Guide REEVING ILLUSTRATION Single Reeved Double Reeved Rope Anchor WIRE ROPE Wire Rope Technical Data Heavy Duty Wire Rope RR BOTTOM BLOCK Bottom Block Dimensions Block Construction RSN and HBC Hook Dimensions RM-SX-TG-SPEC ENG.doc

3 11.4 DIN Hooks HOK Other Hooks HOK Ramshorn (twin-points) Hooks HOK Sheaves HOIST LIMIT SWITCH - STANDARD SETTING SX1 Hoist SX2-SX7 Hoists OVERLOAD DEVICE, MECHANICAL (MEC) TROLLEY Special Low Headroom Hoist Low Headroom Hoist Normal Headroom Hoist Patented Track Wheel Option TR Swivel Trolley for Curved Track Double Girder Trolley Trolley Gauge Cross Mounting Double Girder Hoist INVERTER CONTROL Infinitely Variable (EP) Speed Control Multi-step (MS) Speed Control Dynamic Braking Factory settings of Inverters VARIABLE FREQUENCY DRIVE TYPES CMXC AFD ControlMaster Select VFD ControlMaster Plus VFD ControlMaster Elite VFD INVERTER TROLLEY SPEEDS Low Headroom - Inverter Trolley Normal Headroom Inverter Trolley Double Girder - Inverter Trolley TWO-SPEED TROLLEY SPEEDS Low Headroom Two-speed Trolley Normal Headroom Two-speed Trolley Double Girder Two-speed Trolley GEK DRIVE MF06 Inverter-duty Motor Compact Brake MF06 Two-speed Motor D.C. Brake GEK GEAR LUBRICANTS BRIDGE AND TROLLEY MOTOR DATA Inverter Duty Motor Data MF Inverter Duty Motor Data MF Two-speed Motor Data MF Two-speed Motor Data MF Two-speed Motor Data MF HOIST CONTROLS Monorail Package Hoist (Solo Hoist) Crane Package Hoist Power Supply and Control Voltage HOIST PROTECTION RATING PENDANT RM-SX-TG-SPEC ENG.doc

4 24.1 Technical Data Direction Symbols or Labels HOIST MONITOR Hoist Monitor HS Optional Features Hoist Monitor Select HS HoistMonitor Elite HS HoistMonitor Plus PE OUTDOOR SERVICE PROTECTION SURFACE TREATMENT Hoist & Trolley Color End Truck Color Standard Painting Method MATERIALS HOIST OPTIONS Second Hoist Brake BRA Bumper Extensions between Trolleys DES Contactor Control, Trolley Two-speed Control Transformer & Mainline Contactor DES Hoist Motor, IP66 Protection HM Crank Shaft for Hoist Motor HM Derailment Catches for Double Girder Trolleys OTH Hoist Drum Brake HS Hoist Motor External Fan MOT Hoist without Electrical Controls ELE Limit Switch, Hoist Operating with Bypass LIM Limit Switch, Extra - Level Setting LIM Limit Switch, Hook Operated HS Limit Switch, Trolley Traveling One-step (Slowdown) LIM Limit Switch, Trolley Traveling One-step (Stop) LIM Limit Switch, Trolley Traveling Two-step (Slowdown + Stop) - LIM Lockable Hook in Bottom Block HOK Lug Mount Suspension Manual Brake Release for Hoist Motor BRA Manual Brake Release for Trolley Motor BRA Nonstandard Voltage/frequency for Hoist Rain Cover for Hoist Motor HS Rain Cover for Trolley Motor MOT Special Paint Thickness PAI Stainless Steel Hoist Enclosure, IP66 PAN Stainless Steel Hoist Enclosure, IP55 PAN Stainless Wire Rope RR Standby Heater for Hoist Control Panel PAN Standby Heater for Motors MOT03 (hoist) MOT04 (trolley) MOT16 (bridge) Transformer for Trolley Control ELE Trolley Motor, IP66 Protection TM Trolley Motor, Thermal Protection TM Trolley Rail Gauge, One Step Smaller from Standard PRI Trolley Rail Gauge, One Step Larger from Standard PRI Trolley Speed, Faster than Standard SPD Trolley Speed, Slower than Standard SPD Trolley, Double Girder High Connection DES Trolley, Double Girder Low Connection DES Trolley, Special Flange Width for Low Headroom DIM Trolley, Special Flange Width for Normal Headroom DIM Multi-hook Leveling HS RM-SX-TG-SPEC ENG.doc

5 30 HOIST SPEEDS QX CRANE PACKAGE BRIDGE PANEL CRANE ELECTRIFICATION PACKAGE BRIDGE PANEL DIMENSIONS LIMIT SWITCH, BRIDGE TRAVEL ONE-STEP (SLOWDOWN) LIM PLUG CONNECTORS Control Plugs Power Plugs Plug Kits and Stainless Steel Enclosures BRIDGE GIRDER TANDEM HOISTS CRANE OPTIONS Anti-collision Device for Crane OTH Anti-collision Device for Second Crane BT Bumper Extensions between End Trucks DES Contactor Control, Bridge Two-speed Flashing Light for Bridge Traveling ELE Horn ELE Limit Switch, Bridge Traveling One-step (Stop) LIM Limit Switch, Bridge Traveling Two-step (Slowdown + Stop) LIM Limit Switch, Hook Operated, Trips Mainline Contactor ELE Limit Switch, Trolley Travel, Trips all Trolleys on Bridge ELE Load Display HS Load Display for Two Hoists on Crane HS Longer Chain for Trolley Tow Arm & Festoon Manual Brake Release for Bridge Motor BRA Nonstandard Voltage/frequency for Crane Pliotex Type Wire Marking ELE Provision for Crane Lights (115v, max. 3x400W) ELE Provision for Lights on Bridge (as main voltage) ELE Rain Cover for Bridge Motor MOT Stainless Steel Bridge Control Enclosure, IP66 PAN Standby Heater for Bridge Control Panel PAN Standby Heater for Pendant Enclosure PEN Standby Heater for Bridge Motor MOT Thermal Protection for Bridge Motor MOT Transformer for Entire Crane ELE Transformer for Bridge Control ELE Bridge Motor, IP66 Protection BM CONVERSIONS RM-SX-TG-SPEC ENG.doc

6 1 Performance 1.1 General Hoists are designed for lifting and transporting of materials only. Under no conditions or circumstances are hoists to be used for lifting or transporting of personnel. Spacemaster SX wire rope hoists are designed for indoor use where the ambient temperature between 14 F and 104 F (-10 C and 40 C), and the elevation is less than 3300 ft [1000m], and the relative humidity is less than 90%. When specially equipped, the hoists may be used for outdoor use or in more extreme ambient temperature conditions -4 F to 122 F (-20 C and 50 C) or a higher elevation. The sound intensity level of the hoist in the assumed operating location does not exceed 70dB. 2 Hoist Duty Service Classification 2.1 FEM Hoist Duty Service Classification Service conditions have important influence on the performance of wearing parts of a hoist such as gears, bearings, rope, sheaves, electrical equipment, brake linings, load and lift limit devices, wheels, etc. Careful consideration of the hoist-duty service classifications will enable the user to evaluate the application, and to obtain a hoist designed for optimum performance and minimum maintenance. According to FEM9.511 standard, the hoist-duty service classification can be determined from its 1) load spectrum 2) average daily operating time FEM Load Spectrum The load spectrum can be determined from the table below. LIGHT Occasional full loads. Usually light load. Small fixed load. MEDIUM Occasional full loads. Usually light load. Average fixed load. Load % Load % Operating time % Operating time % HEAVY Repetitive full loads. Usually average load. Heavy fixed load. VERY HEAVY Usually almost full loads. Very heavy fixed load. Load % Operating time % Load % Operating time % 6 RM-SX-TG-SPEC ENG.doc

7 2.1.2 FEM Average Daily Operating Time The average daily operating time of the hoist can be calculated from the running time of the hoisting machinery [hours/day]. 2 H N T t = V 60 H = average hoisting height [m] N = number of work cycles per hour [cycles/h] T = daily working time [h] V = hoisting speed [m/min] Determining the FEM hoist duty service classification When the load spectrum and the average daily operating time of the hoist are identified, the duty service classification of the hoist is obtained from the table below. Load spectrum LIGHT MEDIUM HEAVY VERY HEAVY Average daily operating time ISO/FEM (hours per day) M3 1Bm M4 1Am M3 1Bm M4 1Am M5 2m M3 1Bm M4 1Am M5 2m M6 3m M4 1Am M5 2m M6 3m M7 4m M5 2m M6 3m M7 4m M6 3m M7 4m 2.2 ASME Hoist Duty Service Classification For information about ASME Hoist Duty Service Classification, reference ASME publication catalog ASME HST-4 (latest edition) for electric wire rope hoists. 2.3 Comparison of Hoist Duty Service Classifications Code ISO M3 M4 M5 M6 FEM 1Bm 1Am 2m 3m ASME HST-4M H2 H3 H4 H4* Starts per Hour FEM ASME HST-4M FEM Intermittent Duty-ANSI/ASME Uniformly Distributed Work Periods (min/hr) FEM ASME HST-4M *None of the Spacemaster SX hoists is or can be rated higher than ASME H4 duty service classification. 7 RM-SX-TG-SPEC ENG.doc

8 3 Hoist Features 3.1 Standard Features Two-speed hoist motor (6:1 ratio) with thermal protection, class F insulation D.C. disc hoist brake Compact hoist gear box Overload limit device Over-travel protection Rope guide **Hoist and trolley controls Inverter trolley control (except SX1 hoist; contactor control) 65 fpm [20 m/min] trolley speed (except SX1 hoist; 80/20 fpm [25/6.3 m/min]) Trolley drive with inverter-duty motor with brake (except SX1; two-speed motor) Crown tread wheels on under-hung trolley suitable for flat or tapered flange Flat tread wheels on double girder trolley Trolley bumper and safety drop lug HBC or RSN style hook with spring-return safety latch IP55 protection for motor Standard hoist nameplate carries a CSA c/us rating and a NEMA 3R rating for electrical enclosures Plugs for power (some exceptions) and controller cables (except SX1 hoist; hardwired) Wiring Diagram Hoist Owner s manual - Paper + CD (1 set) Includes: Hoist (load) test certificate Hook certificate for RSN or HBC hook Wire rope certificate ** For monorail applications, the mainline contactor, control transformer and the pushbutton pendant are available as equipment adders except these items are standard equipment on the SX1 hoist. ** For crane applications, the mainline contactor and control transformer are supplied as standard in the bridge panel. The pushbutton pendant is selected as part of the crane components. 8 RM-SX-TG-SPEC ENG.doc

9 4 Hoist Characteristics The hoist characteristics table is a summary of the hoist characteristics, which include: Height of lift and corresponding drum (length) code Hoist speeds including alternate speeds for both two-speed and inverter controls Availability of standard suspension types for each model Reeving Code Rope type code for each model Hoist duty rating 4.1 Height of Lift and Drum Code The height of lift along with the corresponding drum length code is listed for each basic model. In this table, height of lift is specified in meters. To convert meters to feet, multiply by The drum code is included in the hoist model code. 4.2 Hoist Speeds The published hoist speeds are nominal. The actual hoist speed could vary ±15% when comparing hoists with the same nominal speed but with different reeving, different gearing and/or different motor type. Always use VFD hoisting controls when better speed accuracy is needed on hoists operating together. 4.3 Suspension Type Code Suspension types that are available for the hoist model are marked with a code. Special suspensions are not included here. Suspension Code in table Description J Special low headroom hoist L Low headroom hoist DH Double girder trolley high: Height above the rail is higher than the standard trolley - to get better headroom below the rail. D0 Double girder trolley standard DW Double girder trolley low: Height above the rail is lower than the standard trolley to get better overhead clearance but it increases headroom. N Normal headroom hoist F Foot mount 4.4 Reeving Code Reeving code Description Reeving code Description part single part double part single part double part single part double part single part double A2 2 part single Smaller rope diameter; reduced capacity; longer lift; SX4 low headroom hoists only A4 4 part single Smaller rope diameter; reduced capacity; longer lift; SX4 low headroom hoists only 4.5 Rope Type Code The rope type code is listed for each height of lift. The characteristics of the wire rope can be found in the Wire Rope section. The double-reeved hoists use two separate ropes a right-hand lay and a left-hand lay. See Wire Rope section for definition of Rope Type code. 4.6 Hoist Duty Rating ASME hoist duty ratings (H3, H4, etc.) apply to hoists marked with typical U.S. capacities (for example, 1 ton = 2000 lbs = 907 kg) and do not apply to hoists marked with typical metric capacities (for example, 1 metric ton = 1,000 kg = 2,200 lbs). FEM/ISO ratings apply to hoists with typical metric capacities. 9 RM-SX-TG-SPEC ENG.doc

10 4.7 Hoist Characteristics Table Load Contactor Inverter Suspension Drum Rope Duty Rating Control Control Ton Kg L D D D N F J HOL Gear Motor Speed Motor Speed ASME FEM/ISO Hoist Reeving H 0 W Code ft m Code Type Ratio code fpm m/min code fpm m/min SX1 021 J A 19"-8" 6 A E PX 32/ /1.5 H4 2m/M5 B SX1 041 J B 19"-8" 6 A E PX 16/ /0.7 H4 2m/M5 C /4 800 SX2 021 L H 0 N F A A F P1 40/6.6 12/2 T H4+ 3m/M6 C SX2 021 L H 0 N F A A F P1 40/6.6 12/2 T H4 2m/M5 C ½ 1600 SX2 041 L H 0 N F A 19"-8" 6 A F P1 20/3.1 6/1 T H4+ 3m/M6 C SX2 041 L H 0 N F A 19"-8" 6 A F P1 20/3.1 6/1 T H4 2m/M5 C SX3 021 L H 0 N F A A F P2 40/6.6 12/2 T H4+ 3m/M6 C G 106 P2 50/7.8 15/2.5 T H 87.7 P3 60/9.8 19/3.3 T ¼ 1250 SX3 021 L H 0 N F A A F P2 40/6.6 12/2 T H4+ 3m/M6 C G 106 P2 50/7.8 15/2.5 T H 87.7 P3 60/9.8 19/3.3 T ½ 1600 SX3 021 L H 0 N F A A F P2 40/6.6 12/2 T H4 2m/M5 C G 106 P2 50/7.8 15/2.5 T H 87.7 P3 60/9.8 19/3.3 T SX3 041 L H 0 N F A 19"-8" 6 A F P2 20/3.1 6/1 T H4+ 3m/M6 C G 106 P2 25/ /1.3 T H 87.7 P3 30/ /1.6 T ½ 2500 SX3 041 L H 0 N F A 19"-8" 6 A F P2 20/3.1 6/1 T H4+ 3m/M6 C G 106 P2 25/ /1.3 T H 87.7 P3 30/ /1.6 T SX3 041 L H 0 N F A 19"-8" 6 A F P2 20/3.1 6/1 T H4 2m/M5 C G 106 P2 25/ /1.3 T H 87.7 P3 30/ /1.6 T SX4 A2 L C B F P2 40/6.6 12/2 T H4+ 3m/M6 D H P4 60/9.8 19/3.3 T ¼ 1250 SX4 A2 L C B F P2 40/6.6 12/2 T H4+ 3m/M6 D H P4 60/9.8 19/3.3 T ½ 1600 SX4 A2 L C B F P2 40/6.6 12/2 T H4 2m/M5 D H P4 60/9.8 19/3.3 T SX4 A4 L C A F P2 20/3.1 6/1 T H4+ 3m/M6 D H P4 30/ /1.4 T ½ 2500 SX4 A4 L C A F P2 20/3.1 6/1 T H4+ 3m/M6 D H P4 30/ /1.4 T SX4 A4 L C A F P2 20/3.1 6/1 T H4 2m/M5 D H P4 30/ /1.4 T RM-SX-TG-SPEC ENG.doc

11 Load Contactor Inverter Suspension Drum Rope Duty Rating Control Control Ton Kg L D D D N F J HOL Gear Motor Speed Motor Speed ASME FEM/ISO Hoist Reeving H 0 W Code ft m Code Type Ratio code fpm m/min code fpm m/min 1 ½ 1600 SX4 021 L H 0 N F B D E P3 30/ /1.6 T H4+ 3m/M6 C F P2 40/6.6 12/2 T H 0 N F E D F H P4 60/9.8 19/3.2 T SX4 021 L H 0 N F B 39-4 " 12 D E P3 30/ /1.6 T H4+ 3m/M6 C F P3 40/6.6 12/2 T D F H P4 60/9.8 19/3.2 T H 0 N F E / SX4 021 L H 0 N F B 39-4 " 12 D E P3 30/ /1.6 T H4 2m/M5 C F P3 40/6.6 12/2 T H 0 N F E D F H P4 60/9.8 19/3.2 T SX4 041 L H 0 N F B D E P2 16/ /0.8 T H4+ 3m/M6 C F P2 20/3.1 6/1 T H 0 N F E D H P4 30/ /1.6 T SX4 041 L H 0 N F B D E P3 16/ /0.8 T H4+ 3m/M6 C F P3 20/3.1 6/1 T H 0 N F E D H P4 30/ /1.6 T SX4 041 L H 0 N F B D E P3 16/ /0.8 T H4 2m/M5 C F P3 20/3.1 6/1 T H 0 N F E D H P4 30/ /1.6 T SX4 061 H 0 N F C E F P3 13/2 4/0.6 T H4+ 3m/M6 D H P4 20/3.1 6/1 T E ½ 7500 SX4 061 H 0 N F C E F P3 13/2 4/0.6 T H4 2m/M5 D H P4 20/3.1 6/1 T E ½ 8000 SX4 081 H 0 N F C E F P3 10/1.5 3/0.5 T H4 2m/M5 D H P4 16/ /0.8 T E SX4 081 H 0 N F C E F P3 10/1.5 3/0.5 T H3 1Am/M4 D H P4 16/ /0.8 T E RM-SX-TG-SPEC ENG.doc

12 Load Contactor Inverter Suspension Drum Rope Duty Rating Control Control Ton Kg L D D D N F J HOL Gear Motor Speed Motor Speed ASME FEM/ISO Hoist Reeving H 0 W Code ft m Code Type Ratio code fpm m/min code fpm m/min SX5 021 L H 0 W N F D G E P5 30/ /1.6 T H4+ 3m/M6 E F P5 40/6.6 12/2 T F J H P6 60/9.8 19/3.2 T H 0 W N F G J 94.3 P7 80/13 24/4 T SX5 021 L H 0 N F D G E P5 30/ /1.6 T H4 2m/M5 E F P5 40/6.6 12/2 T F J H P6 60/9.8 19/3.2 T H 0 W N F G J 94.3 P7 80/13 24/4 T SX5 041 L H 0 N F D 29"-6" 9 G E P5 16/ /0.8 T H4+ 3m/M6 E F P5 20/3.1 6/1 T F H P6 30/ /1.6 T H 0 W N F G J 94.3 P7 40/6.6 12/2 T ½ 8000 SX5 041 L H 0 N F D 29"-6" 9 G E P5 16/ /0.8 T H4+ 3m/M6 E F P5 20/3.1 6/1 T F H P6 30/ /1.6 T H 0 W N F G J 94.3 P7 40/6.6 12/2 T SX5 041 L H 0 W N F D 29"-6" 9 G E P5 16/ /0.8 T H4 2m/M5 E F P5 20/3.1 6/1 T F H P6 30/ /1.6 T H 0 W N F G J 94.3 P7 40/6.6 12/2 T SX5 061 H 0 W N F D H F P5 13/2 4/0.6 T H4 2m/M5 E H P6 20/3.1 6/1 T F J 94.3 P7 25/ /1.3 T G SX5 061 H 0 W N F D H F P5 13/2 4/0.6 T H3 1Am/M4 E H P6 20/3.1 6/1 T F J 94.3 P7 25/ /1.3 T G SX5 081 H 0 W N F D H F P5 10/1.5 3/0.5 T H4 2m/M5 E H P6 16/ /0.8 T F J 94.3 P7 20/3.1 6/1 T G SX5 081 H 0 W N F D H F P5 10/1.5 3/0.5 T H3 1Am/M4 E H P6 16/ /0.8 T F J 94.3 P7 20/3.1 6/1 T G SX5 022 H 0 W F D D F P5 40/6.6 12/2 T H4+ 3m/M6 E H P6 60/9.8 19/3.2 T F Dr J 94.3 P7 80/13 24/4 T G H J SX5 022 H 0 W F D D F P5 40/6.6 12/2 T H4 2m/M5 E H P6 60/9.8 19/3.2 T F Dr J 94.3 P7 80/13 24/4 T G H J RM-SX-TG-SPEC ENG.doc

13 Load Contactor Inverter Suspension Drum Rope Duty Rating Control Control Ton Kg L D D D N F J HOL Gear Motor Speed Motor Speed ASME FEM/ISO Hoist Reeving H 0 W Code ft m Code Type Ratio code fpm m/min code fpm m/min SX5 042 H 0 W F D D F P5 20/3.1 6/1 T H4+ 3m/M6 E H P6 30/ /1.6 T F Dr J 94.3 P7 40/6.6 12/2 T G H J ½ 8000 SX5 042 H 0 W F D D F P5 20/3.1 6/1 T H4+ 3m/M6 E H P6 30/ /1.6 T F Dr J 94.3 P7 40/6.6 12/2 T G H J SX5 042 H 0 W F D D F P5 20/3.1 6/1 T H4 2m/M5 E H P6 30/ /1.6 T F Dr J 94.3 P7 40/6.6 12/2 T G H J SX5 062 H 0 W F E E F P5 13/2 4/0.6 T H4+ 3m/M6 F H P6 20/3.1 6/1 T G Er J 94.3 P7 25/ /1.3 T H J SX5 062 H 0 W F E E F P5 13/2 4/0.6 T H4 2m/M5 F H P6 20/3.1 6/1 T G Er J 94.3 P7 25/ /1.3 T H J SX5 082 H 0 W F F E F P5 10/1.6 3/0.5 T H4 2m/M5 G H P6 16/ /0.8 T H Er J 94.3 P7 20/3.1 6/1 T J SX5 082 H 0 W F F E F P5 10/1.6 3/0.5 T H3 1Am/M4 G H P6 16/ /0.8 T H Er J 94.3 P7 20/3.1 6/1 T J RM-SX-TG-SPEC ENG.doc

14 Load Contactor Inverter Suspension Drum Rope Duty Rating Control Control Ton Kg L D D D N F J HOL Gear Motor Speed Motor Speed ASME FEM/ISO Hoist Reeving H 0 W Code ft m Code Type Ratio code fpm m/min code fpm m/min SX N F C K E P6 30/ /1.6 T H4+ 3m/M6 D F P6 40/6.6 12/2 T E M G P7 50/7.8 15/2.5 T F H T G J T H J K ½ 8000 SX N F C K E P6 30/ /1.6 T H4 2m/M5 D F P6 40/6.6 12/2 T E M G P7 50/7.8 15/2.5 T F H T G J T H J K SX N F C K E P6 30/ /1.6 T H3 1Am/M4 D F P7 40/6.6 12/2 T E M G P8 50/7.8 15/2.5 T F H T G J TA H J K ½ SX N F C 24"-6" 7.5 K E P6 16/ /0.8 T H4+ 3m/M6 D F P6 20/3.1 6/1 T E G P7 25/ /1.3 T F H T G J T H J K SX N F C 24"-6" 7.5 K E P6 16/ /0.8 T H4 2m/M5 D F P6 20/3.1 6/1 T E G P7 25/ /1.3 T F H T G J T H J K SX N F C 24"-6" 7.5 K E P6 16/ /0.8 T H3 1Am/M4 D F P7 20/3.1 6/1 T E G P8 25/ /1.3 T F H T G J TA H J K RM-SX-TG-SPEC ENG.doc

15 Load Contactor Inverter Suspension Drum Rope Duty Rating Control Control Ton Kg L D D D N F J HOL Gear Motor Speed Motor Speed ASME FEM/ISO Hoist Reeving H 0 W Code ft m Code Type Ratio code fpm m/min code fpm m/min SX N F C L E P6 10/1.5 3/0.5 T H4+ 3m/M6 D F P6 13/2 4/0.6 T E G P7 16/ /0.8 T F H T G J T H J K SX N F C L E P6 10/1.5 3/0.5 T H4 2m/M5 D F P6 13/2 4/0.6 T E G P7 16/ /0.8 T F H T G J T H J K SX N F C L E P6 10/1.5 3/0.5 T H3 1Am/M4 D F P7 13/2 4/0.6 T E G P8 16/ /0.8 T F H T G J TA H J K SX N F E L E P6 8/ /0.4 T H4 2m/M5 F F P7 10/1.5 3/0.5 T G G T H H T J J TA 20 6 K SX N F E L E P6 8/ /0.4 T H3 1Am/M4 F F P7 10/1.5 3/0.5 T G G P8 13/2 4/0.6 T H H T J J TA 20 6 K SX N F E G E P6 30/ /1.6 T H4+ 3m/M6 F F P6 40/6.6 12/2 T G Gr G P7 50/7.8 15/2.5 T H H T J J T K L M N RM-SX-TG-SPEC ENG.doc

16 Load Contactor Inverter Suspension Drum Rope Duty Rating Control Control Ton Kg L D D D N F J HOL Gear Motor Speed Motor Speed ASME FEM/ISO Hoist Reeving H 0 W Code ft m Code Type Ratio code fpm m/min code fpm m/min 7 ½ 8000 SX N F E G E P6 30/ /1.6 T H4 2m/M5 F F P6 40/6.6 12/2 T G Gr G P7 50/7.8 15/2.5 T H H T J J T K L M N SX N F E G E P6 30/ /1.6 T H3 1Am/M4 F F P7 40/6.6 12/2 T G Gr G P8 50/7.8 15/2.5 T H H T J J TA K L M N ½ SX N F E 26"-3" 8 G E P6 16/ /0.8 T H4+ 3m/M6 F F P6 20/3.1 6/1 T G Gr G P7 25/ /1.3 T H H T J J T K L M N SX N F E 26"-3" 8 G E P6 16/ /0.8 T H4 2m/M5 F F P6 20/3.1 6/1 T G Gr G P7 25/ /1.3 T H H T J J T K L M N SX N F E 26"-3" 8 G E P6 16/ /0.8 T H3 1Am/M4 F F P7 20/3.1 6/1 T G Gr G P8 25/ /1.3 T H H T J J TA K L M N RM-SX-TG-SPEC ENG.doc

17 Load Contactor Inverter Suspension Drum Rope Duty Rating Control Control Ton Kg L D D D N F J HOL Gear Motor Speed Motor Speed ASME FEM/ISO Hoist Reeving H 0 W Code ft m Code Type Ratio code fpm m/min code fpm m/min SX N F E 18"-1" 5.5 H E P6 10/1.5 3/0.5 T H4+ 3m/M6 F F P6 13/2 4/0.6 T G Hr G P7 16/ /0.8 T H H T J J T K L M N SX N F E 18"-1" 5.5 H E P6 10/1.5 3/0.5 T H4 2m/M5 F F P6 13/2 4/0.6 T G Hr G P7 16/ /0.8 T H H T J J T K L M N SX N F E 18"-1" 5.5 H E P6 10/1.5 3/0.5 T H3 1Am/M4 F F P7 13/2 4/0.6 T G Hr G P8 16/ /0.8 T H H T J J TA K L M N SX N F F 18"-1" 5.5 H E P6 8/ /0.4 T H4 2m/M5 G F P7 10/1.5 3/0.5 T H Hr G T J H T K J TA 20 6 L M N SX N F F 18"-1" 5.5 H E P6 8/ /0.4 T H3 1Am/M4 G F P7 10/1.5 3/0.5 T H Hr G P8 13/2 4/0.6 T J H T K J TA 20 6 L M N RM-SX-TG-SPEC ENG.doc

18 Load Contactor Inverter Suspension Drum Rope Duty Rating Control Control Ton Kg L D D D N F J HOL Gear Motor Speed Motor Speed ASME FEM/ISO Hoist Reeving H 0 W Code ft m Code Type Ratio code fpm m/min code fpm m/min 12 ½ SX F F 50"-10" 15.5 K E P6 32/ /1.4 2 T H4+ 3m/M6 G F P6 39/6.2 12/2 2 T H Kr G P7 49/7.2 15/2.5 2 T J H T K J T L M N SX F F 50"-10" 15.5 K E P6 32/ /1.4 2 T H4 2m/M5 G F P6 39/6.2 12/2 2 T H Kr G P7 49/7.2 15/2.5 2 T J H T K J T L M N SX F F 50"-10" 15.5 K E P6 32/ /1.4 2 T H3 1Am/M4 G F P7 39/6.2 12/2 2 T H Kr G T J H T K L M N SX F F K E P6 16/ /0.8 2 T H4+ 3m/M6 G F P6 20/3.1 6/1 2 T H Kr G P7 25/4 7.5/1.3 2 T J H T K J T L M N SX F F K E P6 16/ /0.8 2 T H4 2m/M5 G F P6 20/3.1 6/1 2 T H Kr G P7 25/4 7.5/1.3 2 T J H T K J T L M N SX F F K E P6 16/ /0.8 2 T H3 1Am/M4 G F P7 20/3.1 6/1 2 T H Kr G T J H T K L M N RM-SX-TG-SPEC ENG.doc

19 Load Contactor Inverter Suspension Drum Rope Duty Rating Control Control Ton Kg L D D D N F J HOL Gear Motor Speed Motor Speed ASME FEM/ISO Hoist Reeving H 0 W Code ft m Code Type Ratio code fpm m/min code fpm m/min SX F F L E P6 10/1.6 3/0.5 2 T H4+ 3m/M6 G F P6 13/2 4/0.6 2 T H Lr G P7 16/ /0.8 2 T J H T K J T L M N SX F F L E P6 10/1.6 3/0.5 2 T H4 2m/M5 G F P6 13/2 4/0.6 2 T H Lr G P7 16/ /0.8 2 T J H T K J T L M N SX F F L E P6 10/1.6 3/0.5 2 T H3 1Am/M4 G F P7 13/2 4/0.6 2 T H Lr G T J H T K L M N SX F H L E P6 8/ /0.4 2 T H4 2m/M5 J F P6 10/1.6 3/ T K Lr G P7 13/2 4/0.6 2 T L H T M J T N SX F H L E P6 8/ /0.4 2 T H3 1Am/M4 J F P7 10/1.6 3/ T K Lr G T L H T M N RM-SX-TG-SPEC ENG.doc

20 5 Main Components - Hoist The hoist motor and gearbox, rope drum and the bottom block are the main hoist components. 1. Hoist motor 2. Hoist gearbox 3. Cover 4. Rotary limit switch 5. Gear guard 6. Drum gear 7. End plate A, B, C, D mounting bolts c_r1hm1a 6 Hoist Motor c_homo1a 1. Fan cover 2. Fan 3. Inspection port 4. Brake 5. Brake Disc 6. Mounting bolts 7. Friction plate 6.1 Hoist Motor Features Squirrel cage motor Double windings for two-speed motor, 6:1 speed ratio Synchronous speed See Motor Data IP55 protection Class F insulation Klixon type bimetal switch for thermal protection P1 P8 code designate standard two-speed hoist motors T1 TA code designate standard inverter hoist motors Power ratings See Motor Data 6.2 Optional Hoist Motor Features Standby heater (tropicalized protection is standard) IP66 protection Class H insulation 20 Bulletin: RM-SX-TG-SPEC ENG.doc

21 6.3 Ambient Conditions The standard motor is designed for operation at a minimum ambient temperature 10 C to a maximum ambient temperature 40 C and maximum altitude of 1000 meters (3280 feet). 6.4 P-Motors The alpha character P designates a standard two-speed hoist motor and the numeric character indicates power size. 6.5 T-Motors The alpha character T designates a standard inverter-duty hoist motor and the numeric character that follows indicates power size. The inverter-duty motors are specially designed for use with a variable frequency drive. 6.6 Motor Temperature Protection As standard, P or T type motor is equipped with normally closed, automatic reset thermal protector embedded in the stator winding(s). 6.7 Motor Cooling The hoist motors have ribbed outer frames to maximize convection cooling. The motors are normally equipped with an integral cooling fan that is driven directly by the motor shaft. The shaft driven fan is only effective when the motor is energized. In severe environmental conditions, such as high ambient temperature, a blower fan replaces the shaft driven fan to improve the cooling. 6.8 Hoist Motor Brake All hoist models are equipped with a disc brake to bring the load to a smooth and quick stop and to hold the load when the motor is not energized. The disc brake is integrated into the design of the motor and located between the motor end bell and the cooling fan. (On double reeved SX5 hoist models for drum lengths H and J, the disc brake is mounted to the gear case cover inline with the motor instead of mounted directly to the hoist motor.) A single disc with friction linings on both sides is used. The hub of the disc is engaged on the splined motor shaft. The disc can also move axially along the shaft to accommodate any friction lining wear. The brake is engaged by a number of springs that force a stationary pressure plate against the friction disc. An energized coil releases the brake. Since the brake is always engaged when the brake coil is not energized, the brake is a fail-safe system. 21 RM-SX-TG-SPEC ENG.doc

22 Hertz Hoist Motor Data Two-speed Duty Group Fem/ISO motor data PX P1 P2 P3 MF09ZA106 MF10M-106 MF10Z-106 MF10X-106 Synchronous speed RPM Brake torque Nm Max el. Brake torque Nm El. Brake torque Nm Power fact. Start Starting torque Nm Weight kg Brake inertia kgm Inertia w/o brake kgm m/M5 Load tm/min Nominal power kw Starts/h starts/h Nominal torque Nm % ED 60 % ED Nominal speed RPM /3.5 min Short time duty min Power factor Efficiency m/M6 Load tm/min Nominal power kw Starts/h starts/h Nominal torque Nm % ED 60 % ED Nominal speed RPM /4 min Short time duty min Power factor Efficiency Duty Group Fem/ISO motor data P4 P5 P6 P7 MF11XA106 MF11X-106 MF13Z-106 MF13X-106 Synchronous speed RPM Brake torque Nm Max el. Br. Torque Nm El. Br. Torque Nm Power fact. Start Starting torque Nm Weight kg Brake inertia kgm Inertia w/o brake kgm m/M5 Load tm/min Nominal power kw starts/h starts/h Nominal torque Nm % ED 60 % ED Nominal speed RPM /3.5 min Short time duty min Power factor Efficiency m/M6 Load tm/min Nominal power kw starts/h starts/h Nominal torque Nm % ED 60 % ED Nominal speed RPM /4 min Short time duty min Power factor Efficiency RM-SX-TG-SPEC ENG.doc

23 Duty Group Fem/ISO motor data P8 * MF13XA106 Synchronous speed RPM Brake torque Nm 200 Max el. Br. Torque Nm 290 El. Br. Torque Nm 150 Power fact. Start Starting torque Nm Weight kg 99 Brake inertia kgm Inertia w/o brake kgm m/M5 Load tm/min Nominal power kw starts/h starts/h Nominal torque Nm % ED 60 % ED Nominal speed RPM /3.5 min Short time duty min Power factor Efficiency m/M6 Load tm/min Nominal power kw 18 3 starts/h starts/h Nominal torque Nm % ED 60 % ED Nominal speed RPM /4 min Short time duty min Power factor Efficiency *The P8-motor can only be used on hoists with a FEM 1Am or ASME H3 duty rating. External fan on the P8 motor is standard. 23 RM-SX-TG-SPEC ENG.doc

24 Hertz Hoist Motor Currents Two-speed Currents Nominal voltage 230 V 400 V 500 V 660 V Used in voltage range V V V V ton m/min fast slow fast slow fast slow fast slow PX Starting current (A) MF09ZA106 Nominal current (A) No-load current (A) P1 Starting current (A) MF10M-106 Nominal current (A) No-load current (A) P2 Starting current (A) MF10Z-106 Nominal current (A) No-load current (A) P3 Starting current (A) MF10X-106 Nominal current (A) No-load current (A) P4 Starting current (A) MF11XA106 Nominal current (A) No-load current (A) P5 Starting current (A) MF11X-106 Nominal current No-load current (A) P6 Starting current (A) MF13Z-106 Nominal current (A) No-load current (A) P7 Starting current (A) MF13X-106 Nominal current (A) No-load current (A) RM-SX-TG-SPEC ENG.doc

25 Currents Nominal voltage 230 V 400 V 500 V 660 V Used in voltage range V V V V ton m/min fast slow fast slow fast slow fast slow P8 Starting current (A) MF13XA106 Nominal current (A) No-load current (A) RM-SX-TG-SPEC ENG.doc

26 Hertz Hoist Motor Data Two-speed Duty Group Fem/ISO motor data PX P1 P2 P3 MF09ZA106 MF10M-106 MF10Z-106 MF10X-106 Synchronous speed RPM Brake torque Nm Max el. Brake torque Nm El. Brake torque Nm Power fact. Start Starting torque Nm Weight kg Brake inertia kgm Inertia w/o brake kgm m/M5 Load tm/min Nominal power kw starts/h starts/h Nominal power hp % ED 60 % ED Nominal torque Nm /3.5 min Nominal speed RPM Short time duty min Power factor Efficiency m/M6 Load tm/min Nominal power kw starts/h starts/h Nominal power hp % ED 60 % ED Nominal torque Nm /4 min Nominal speed RPM Short time duty min Power factor Efficiency Duty Group Fem/ISO motor data P4 P5 P6 P7 MF11XA106 MF11X-106 MF13Z-106 MF13X-106 Synchronous speed RPM Brake torque Nm Max el. Brake torque Nm El. Brake torque Nm Power fact. Start Starting torque Nm Weight kg Brake inertia kgm Inertia w/o brake kgm m/M5 Load tm/min Nominal power kw [hp] 9 [12] 1.4 [1.9] 11 [14.8] 1.6 [2.1] 18 [24.1] 3 [4] 21[28.2] 3.5 [4.7] starts/h starts/h Nominal torque Nm % ED 60 % ED Nominal speed RPM /3.5 min Short time duty min Power factor Efficiency m/M6 Load tm/min Nominal power kw [hp] 7.2 [9.6] 1.2 [1.6] 9 [12] 1.4 [1.9] 14 [19] 2.3 [3] 18 [24.1] 3 [4] starts/h starts/h Nominal torque Nm % ED 60 % ED Nominal speed RPM /4 min Short time duty min Power factor Efficiency RM-SX-TG-SPEC ENG.doc

27 Duty Group Fem/ISO motor data *P8 MF13XA106 Synchronous speed RPM Brake torque Nm 200 Max el. Brake torque Nm 290 El. Brake torque Nm 150 Power fact. Start Starting torque Nm Weight kg 99 Brake inertia kgm Inertia w/o brake kgm m/M5 Load tm/min Nominal power kw starts/h starts/h Nominal power hp % ED 60 % ED Nominal torque Nm /3.5 min Nominal speed RPM Short time duty min Power factor Efficiency m/M6 Load tm/min Nominal power kw Nominal power hp starts/h starts/h Nominal torque Nm % ED 60 % ED Nominal speed RPM /4 min Short time duty min Power factor Efficiency *The P8-motor can only be used on hoists with a FEM 1Am or ASME H3 duty rating. External fan on the P8 motor is standard. 27 RM-SX-TG-SPEC ENG.doc

28 Hertz Hoist Motor Currents Two-speed Currents Nominal voltage 220 V 380 V 460 V 575 V Used in voltage range V V V V ton m/min fast slow fast slow fast slow fast slow PX Starting current (A) MF09ZA106 Nominal current (A) No-load current (A) P1 Starting current (A) MF10M-106 Nominal current (A) No-load current (A) P2 Starting current (A) MF10Z-106 Nominal current (A) No-load current (A) P3 Starting current (A) MF10X-106 Nominal current (A) No-load current (A) P4 Starting current (A) MF11XA106 Nominal current (A) No-load current (A) P5 Starting current (A) MF11X-106 Nominal current (A) No-load current (A) P6 Starting current (A) MF13Z-106 Nominal current (A) No-load current (A) P7 Starting current (A) MF13X-106 Nominal current (A) No-load current (A) RM-SX-TG-SPEC ENG.doc

29 Currents Nominal voltage 220 V 380 V 460 V 575 V Used in voltage range V V V V ton m/min fast slow fast slow fast slow fast slow P8 Starting current (A) MF13XA106 Nominal current (A) No-load current (A) RM-SX-TG-SPEC ENG.doc

30 Hertz Hoist Motor Data Inverter Motors Duty Group Fem/ISO motor data T1 T2 T3 T4 T5 T6 MF10MA200 MF10MB200 MF10MC200 MF11MA200 MF11MB200 MF13Z-200 Rated power kw Synchronous speed RPM Brake torque Nm Pull-out torque Nm Speed at 80% of rpm pull-out torque Weight kg Brake inertia kgm Inertia w/o brake kgm m/M5 Load tm/min Nominal power kw starts/h starts/h Nominal torque Nm % ED 60 % ED Nominal speed RPM /3.5 min Short time duty min Power factor Efficiency m/M6 Load tm/min Nominal power kw starts/h starts/h Nominal torque Nm % ED 60 % ED Nominal speed RPM /4 min Short time duty min Power factor Efficiency Duty Group Fem/ISO motor data T7 T8 T9 TA MF13ZA200 MF13ZB200 MF13ZC200 MF13X-200 Rated power kw Synchronous speed RPM Brake torque Nm Pull-out torque Nm Speed at 80% of pullout rpm torque Weight kg Brake inertia kgm Inertia w/o brake kgm m/M5 Load tm/min Nominal power kw starts/h starts/h Nominal torque Nm % ED 60 % ED Nominal speed RPM /3.5 min Short time duty min Power factor Efficiency m/M6 Load tm/min Nominal power kw starts/h starts/h Nominal torque Nm % ED 60 % ED Nominal speed RPM /4 min Short time duty min Power factor Efficiency RM-SX-TG-SPEC ENG.doc

Who We Are? Founded in 1988, WEIHUA is a world-leading material handling solutions supplier. In 2022, WEIHUA total production facilities area reaches 3,420,000 m2. What We do? At Weihua, we pursue technology-driven development and enhance our products and systems to the next level of automation by applications of artificial intelligence and IoT technology. We provide customers with bridge cranes, gantry cranes, electric hoists, intelligent multifunctional cranes, Automated Guided Vehicles (AGVs), bulk material handling equipment, port equipment & comprehensive solutions, and the solutions for turn-key material hoisting and handling engineering. Customers We serve? Our customers are...

Heavy-duty lifting requires heavy-duty solutions. When you need a rugged hoist with high capacities and long lifts, the SXL open winch wire rope hoist is there to meet the most rigorous lifting demands.

The SXL open winch hoist is tailored to meet your specific requirements. The modular design of the hoists and trolleys allow a wide variety of application-specific designs, with all the functionality of a custom built-up hoist. Choose from an abundance of special features, such as outdoor protection and special temperature ranges, specialty hooks and provisions for below the hook devices, precision load and sway controls, maintenance platforms, extra long lifts, and extra durable hardened hoist drum and sheaves.

The SXL open winch wire rope hoist is designed for strength and reliability, and engineered in-house specifically for heavy lifting applications. With operations this critical, nothing is more important than safety, reliability, and precision.

All SXL open winch wire rope hoists come equipped with the HoistMonitor® load monitoring system to control overloads and provide vital safety and performance data about the equipment. SXL hoists also include key safety features such as rope overwrap protection as standard. Additional features such as micro speeds and inching give the operator precise control of the load and increasing safety.

The SXL’s rugged design starts at its core. All SXL winches are equipped with D.C. disk brakes for all motions, Class H insulation on the motors, and three-step helical gearing. This machinery is designed specifically for hoisting operations, meaning you are getting the most out of your equipment. The SXL open winch hoist’s unique rope drum design features a flexible two-stage geared coupling for dynamic bending and movement of the drum, reducing fatigue on the coupling.

SXL open winch hoists come standard with closed-loop vector controls, providing the most precise lifting experience available. Specialty controls also maximize the effectiveness of the equipment in your operations. Some of these features are load floating, anti-sway controls, hoisting synchronization, and extended speed ranges. Our controls packages are customizable to suit a wide variety of special applications.
