ss wire rope clamps made in china

Wire rope clips are widely used for making end terminations. Clips are available in two basic designs; the U-Bolt and fist grip. The efficiency of both types is the same.

When using U-Bolt clips, extreme care must be exercised to make certain that they are attached correctly; Incorrect installation can reduce the working load limit by 40%. Below are general guidelines for installing wire rope clips.

The saddle shall be placed on the live end of the wire rope, with the U-bolt on the dead-end side—Remember the well-known saying: “Never saddle a dead horse.” Use at least two or three wire rope clips to secure the ends properly to the length of the rope, and tighten nuts evenly one by one until reaching the recommended torque.

Step 1. Turn back a specified amount of rope from the thimble or loop. The first clip must be placed one bridge width from the turned back rope tailor dead end of the rope, Apply U-Bolt over dead end of wire rope – live end rests in the saddle (Never saddle a dead horse!) Tighten nuts evenly, alternate from one nut to the other until reaching the recommended torque.

Step 2. When more than two clips are required, apply the second clip as near the loop or thimble as possible, tighten the nuts firmly but not yet to the specified torque.

Step 3. When three or more clips are required, space additional clips equally between the first two – take up rope slack – tighten nuts on each U-Bolt evenly, alternating from one nut to the other until reaching recommended torque.

Step 4. Apply the first load to test the assembly. This load should be of equal or greater – weight than loads expected in use. Next, check and retighten nuts to recommended torque.

In accordance with good rigging and maintenance practices, the wire rope end termination should be inspected periodically for wear, abuse, and general adequacy. Periodically re-tightening of the nuts must be done at 10.000 cycles (heavy usage), 20.000 e.g. every 3 months, 6 months, annually.

Malleable clips are to be used for making eye termination assemblies only with the right regular lay wire rope and only for light-duty uses with small applied loads, such as handrails, fencing, guard rails, etc.

If you have any wire rope clips questions, you can contact us by email at info@hilifting.com. We will be glad to share with you more useful information.

Duplex stainless wire rope clips easily create an eye or loop, for the use of the so-called card-snap method, we also have Simplex Stainless Steel Wire Rope Clips for your option.

Hilifting is the leading duplex AISI 316 and 304 wire rope grips manufacturer in China, our stainless steel cable clamps can provide amazing corrosion protection from salt water and harsh weather conditions.

We are based in Guangdong, China, start from 2011,sell to Domestic Market(7.00%),South Asia(7.00%),Southern Europe(7.00%),Northern Europe(7.00%),Central America(7.00%),Western Europe(7.00%),Eastern Asia(7.00%),Mid East(7.00%),Oceania(7.00%),Africa(7.00%),Southeast Asia(7.00%),Eastern Europe(7.00%),South America(7.00%),North America(7.00%). There are total about 5-10 people in our office.

We"ve been specialized in the field for 12 years(Wire rope/rigging hardware)Different surface:Staiinless steel/Polish/Galvanized!!!.Good quality and favorable price.If you are small order,we also can send to your appointed forwarder agent!

Foshan Nanhai Taiguanglong Stainless Steel Co., Ltd. is a perfect example of the fusion between the mature experience of our workforce and innovative technologies concerning machinery involved in the production process of Stainless Steel Wire Rope Clamp. Our prolonged experience in serving a diverse clientele made us able to adapt constant technical change and improvement, leading to Australia,Canada,Germany,Israel,United Kingdom,United States market share. The unmatched technical expertise in combination with a desire to be the best in the industry has pushed us ahead in line and we achieved US$1 Million - US$2.5 Million.We intruded the market back in 2001 as Manufacturer and Retailer of Stainless Steel Wire Rope Clamp with initial business capital estimating around US$50 Million - US$100 Million. Since inception, Foshan Nanhai Taiguanglong Stainless Steel Co., Ltd. is operating as a Private Limited company in Foshan, , China holding Own Lisence.To ensure a finished product line we have gathered a force of professional grade technicians and innovative standard of processes. This is to mark perfection in all segments of business, from dealing with Stainless Steel Wire Rope Clamp to stainless steel wire rope,link chain,shackle,turnbuckle,eye nut & eye bolt.

Italian stainless steel wire rope clips are widely use in marine equipment. Our company can offer you all sizes of this product. Please feel free to get in touch with us.

It is mainly used for fixing or connecting the rope ends of the medium round strand steel wire ropes used in heavy industries such as cranes, mine transportation, ships and construction industry.

By setting up quality control points and inspecting at each production process with strict standards, the defective products will be eliminated before packaging and delivery. For partner factories, we use a comprehensive system of quality standards to evaluate the

Stainless Steel Wire Rope Clips is also called wire rope bayonet. The Stainless Steel Wire Rope Clips is mainly used for temporary connection of steel wire rope, fixation of the back hand rope when the steel wire rope passes through the pulley group, and fixation of the cable wind rope head on the derrick mast, including phosphatized coated steel wire rope, galvanized steel wire rope, stainless steel wire rope and smooth steel wire rope. It is a widely used wire rope clamp in hoisting operation.

Wire rope chuck is also called wire rope bayonet. The Stainless Steel Wire Rope Clips is mainly used for temporary connection of steel wire rope, fixation of the back hand rope when the steel wire rope passes through the pulley block, and fixation of the cable wind rope head on the derrick mast, including phosphatized coated steel wire rope, galvanized steel wire rope, stainless steel wire rope and smooth steel wire rope. It is a widely used wire rope clamp in hoisting operation.

Generally, the clamp connection method of wire rope is commonly used to fix the clamp head. Generally, there are three types of steel wire rope chucks: horse riding type, pressing plate type and fist grip type, among which horse riding type has strong connection force; it is widely used, pressing plate type is the second, fist grip type is easy to damage the steel wire rope because there is no base, and the connection force is poor, so it is only used in secondary places.

a) When selecting the Stainless Steel Wire Rope Clips, the clear distance between the inner side of the U-ring should be 1-3mm larger than the diameter of the steel wire rope, which is too large for the connection of the buckle to be tight and prone to accidents.

b) When installing the Stainless Steel Wire Rope Clips, the bolt must be tightened until the rope is flattened by 1 / 3-1 / 4 of the diameter. After the rope is stressed, the collet bolt shall be tightened once again to ensure the joint is firm and reliable

c) The Stainless Steel Wire Rope Clips shall be arranged in a straight line, and the U-shaped part shall be in contact with the rope head and shall not be in contact with the main rope. If the U-shaped part is in contact with the main rope, the main rope is flattened and the wire is easy to break when it is stressed.

d) In order to check whether the joint is reliable and whether the steel wire rope is sliding, another chuck can be installed about 500mm behind the * rear chuck, and a "safety bend" can be set out for the rope head. In this way, when the steel wire rope of the joint slips, the "safety bend" is straightened first, and then measures should be taken immediately.

The rated load must be strictly observed. Excessive frequent use and overload use are not allowed. Product advantages: stable quality, complete specifications, sufficient goods, low price, convenient delivery, features: smooth appearance, no cracks and defects, durable anti-corrosion rust, strong resistance

Hot Tags: stainless steel wire rope clips, China, manufacturers, suppliers, high quality, factory, crane, customized, coated, strong, low price, plastic coated, High Tensile Stainless Steel Wire Rope, Stainless Steel Wire Rope, Stainless Steel Cable, Others, Sling Stainless Steel Cable, Chain

Welcome to buy the newest and competitive price DAWSON Stainless Steel Wire Rope Clip JIS Type from our factory. We"re one of the leading China manufacturers and suppliers, offering you the wholesale service and the OEM service at a discount. With CE certification, our products made in China in stock are high in quality and low in price. Please be free to get the free sample from us.

APO/FPO, Afghanistan, Africa, Albania, American Samoa, Andorra, Armenia, Azerbaijan Republic, Bahrain, Bangladesh, Belarus, Bermuda, Bhutan, Bosnia and Herzegovina, Central America and Caribbean, China, Cook Islands, Fiji, French Polynesia, Georgia, Gibraltar, Greenland, Guam, Guernsey, Iceland, India, Iraq, Israel, Japan, Jersey, Jordan, Kazakhstan, Kiribati, Korea, South, Kuwait, Kyrgyzstan, Lebanon, Liechtenstein, Macedonia, Maldives, Marshall Islands, Mexico, Micronesia, Moldova, Monaco, Mongolia, Montenegro, Nauru, Nepal, New Caledonia, New Zealand, Niue, Norway, Oman, Pakistan, Palau, Papua New Guinea, Qatar, Russian Federation, Saint Pierre and Miquelon, San Marino, Saudi Arabia, Serbia, Solomon Islands, South America, Southeast Asia, Sri Lanka, Svalbard and Jan Mayen, Switzerland, Tajikistan, Tonga, Turkmenistan, Tuvalu, Ukraine, United Arab Emirates, United Kingdom, Uzbekistan, Vanuatu, Vatican City State, Wallis and Futuna, Western Samoa, Yemen

2 – Attach the first clip so the U-Bolt is one clip base width from the dead end of the wire rope. The live end of the rope seats in the saddle (clip base). Remember: Live End Saddle, Dead End U-Bolt.

If some other object is used for rope turn back, at least one additional Wire Rope Clip should be used. The number of clips specified in the chart is based on the use of the following types of new wire rope: “Right Regular” or “Lang Lay” wire rope 6 x 19 class or 6 x 37 class, Fibre Core (FC) or Steel Core (WSC or IWRC)

US type wire rope clips is drop forged clips for critical heavy duty applications such as guy wires or support lines. Constructed with a u-bolt, a saddle and two nuts, this heavy duty clips was designed with two grooves inside the saddle which can well hold the wire ropes.

DIN1142 wire rope clips is made by malleable steel. Constructed with double saddle, u bolt and two nuts, it is a good choice whenever you want to make a wire rope loop end. Two or more wire clips are recommended to make the loop. Galvanized surface offers a very good corrosion resistant.

We"re well-known as one of the leading wire rope clips manufacturers and suppliers in China. Welcome to buy high quality wire rope clips at competitive price from our factory. Also, free sample is available for quality checking. Korean type turnbuckles, infra ray light curtain for passenger elevator, Grade 8 chain shortenting hooks

Regarding the stainless steel wire rope, the material is AISI304, AISI316, AISI316L etc, and the standard is DIN, BS and EN etc. For the construction:We can produce 1*7 & 1*19, which mainly be used in chemical, engineering, aviation, machine, instrument.

For extreme environments exposed to moisture, salt water or corrosive or corrosive chemicals, non-magnectic stainless steel wire ropes are preferred. For mosr applications, galvanized coatings will provide some form of corrosion resistance and still provide the strength and flexibility characteristics desired by the end user.

It is the most cost effective solution. For construction sites, this stainless steel wire rope can be used as a perimeter cable or as a barrier or lashing cable for high-altitude employees. For applicationthat may be used in the field for weeks or months, they can be safely disposed of after the project is completed.

You may know that due to the environmental protection, our Chinese government has ordered the closure of many steel wire rope factory, becauce those factories are without land owership, building ownership and pollution control license. Fortunately, our company has our own factory, the land and buildings are all belong to ourselves, so our factory will not been closed. And in the meanwhile, we have built a new drawing factory in early of this year, so our factory is running normal. so please don"t worry about the delivery time.
