stainless steel wire rope handrail factory

All Cable and Fittings are Manufactured from Marine Grade 316 Stainless Steel. Stainless Steel Cables provide corrosion resistance, durability and strength, as well as beauty, year after year.

Stainless cable is cut to length per your measurements or may be ordered uncut in bulk.Two different construction types are available to complete your wire rope cable assembly.

1x19 STAINLESS CABLE is used for straight cable runs and cable runs with slight bends. 19 individual wires are twisted to form the wire strand. Actual Breaking Load: 3/16"4719 lbs/ 1/8"1890 lbs

7x7 STAINLESS CABLE is more flexible than 1x19. 7 individual wires form a bundle and 7 bundles are twisted into the wire rope. Actual Breaking Load: 3303 lbs

STAINLESS CABLE & RAILING Professional Swaging Service or Hand Swage using our Recommended Tools. Using the wrong swage die can result in cable pull out.

Rainier cable railing is part of the AGS Stainless Clearview® line of stainless steel railing systems which are well-revered throughout the industry, and can be accompanied with wide array of top rail options for a fully-customized look. AGS will create CAD drawings specifically for your custom railing system.

Atlantis Rail Systems offers a complete line of stainless steel cable railing systems. This innovative collection of low maintenance railings offers unobstructed views capable of fitting any indoor or outdoor, commercial or residential design. Cable hardware can be surface mounted using a turnbuckle style compression fitting or through-posted using hand swage fittings.

is a manufacture of glass railing systems, including welded or non-welded components. Standard railings are designed for tempered glass and can include a combination of stainless steel, aluminum, brass or wood components including caps and sub-rails. Commercial, industrial or residential, complex or simple.

Excell aluminum railings are an engineered railing system that meets IBC International Building Code requirements for spacing and loading. Our durable cable railing systems are constructed of powder-coated aluminum stainless steel fasteners cleverly hidden within the posts, with cables available in 3 sizes. Ideal for interior or exterior applications and residential or commercial projects.

Fortress® is at the front line of railing design with our vertical and horizontal steel cable railing systems. Virtually maintenance-free and easy to install with pre-assembled railing panels, choosing Fortress means unobstructed views with less hassle or up-keep. Backed by a 15-year warranty.

is the worldwide leader in manufacturing custom-made AISI 316 stainless steel wire rope, nets, rods, fasteners and fittings. We strive to combine the aesthetic sense of the architect with the structural requests of the contractor and engineer, which allows us to offer an incredibly broad product range.

Customer service is our most important product. Morse Architectural manufactures a vast selection of railing systems, including glass rail and glazed, steel cable, and stainless steel rod. Engineered from the highest quality stainless steel materials, Morse"s cable railing systems and components are the easiest to use and most cost effective in the industry.

Rainier cable railing is part of the AGS Stainless Clearview® line of stainless steel railing systems which are well-revered throughout the industry, and can be accompanied with wide array of top rail options for a fully-customized look. AGS will create CAD drawings specifically for your custom railing system.

Atlantis Rail Systems offers a complete line of stainless steel cable railing systems. This innovative collection of low maintenance railings offers unobstructed views capable of fitting any indoor or outdoor, commercial or residential design. Cable hardware can be surface mounted using a turnbuckle style compression fitting or through-posted using hand swage fittings.

is a manufacture of glass railing systems, including welded or non-welded components. Standard railings are designed for tempered glass and can include a combination of stainless steel, aluminum, brass or wood components including caps and sub-rails. Commercial, industrial or residential, complex or simple.

Excell aluminum railings are an engineered railing system that meets IBC International Building Code requirements for spacing and loading. Our durable cable railing systems are constructed of powder-coated aluminum stainless steel fasteners cleverly hidden within the posts, with cables available in 3 sizes. Ideal for interior or exterior applications and residential or commercial projects.

Fortress® is at the front line of railing design with our vertical and horizontal steel cable railing systems. Virtually maintenance-free and easy to install with pre-assembled railing panels, choosing Fortress means unobstructed views with less hassle or up-keep. Backed by a 15-year warranty.

is the worldwide leader in manufacturing custom-made AISI 316 stainless steel wire rope, nets, rods, fasteners and fittings. We strive to combine the aesthetic sense of the architect with the structural requests of the contractor and engineer, which allows us to offer an incredibly broad product range.

Customer service is our most important product. Morse Architectural manufactures a vast selection of railing systems, including glass rail and glazed, steel cable, and stainless steel rod. Engineered from the highest quality stainless steel materials, Morse"s cable railing systems and components are the easiest to use and most cost effective in the industry.

Seco South is the leader in stainless steel cable systems for balustrade infill. Now we provide complete cable railing systems in stainless steel, carbon steel or aluminum for any residential or commercial building project. Our systems are completely mechanical and require no welding. We provide design assistance, engineering, CAD details, approval drawings and installation nationwide.

Alibaba.com brings to you a comprehensive selection of durable and decorative wire rope handrail for all types of decorative and functional purposes. These sturdy, trendy and beautiful wire rope handrail are used for all types of interiors as well as in outdoor locations such as gardens. Trusted suppliers and wholesalers offer these fantastic wire rope handrail at the most cost-effective prices and attractive deals.

Modern wire rope handrail are offered on the site, in several distinct designs. wire rope handrail are made from quality materials that guarantee long durability and performance over time. Materials used include pure aluminum, stainless steel, PVC and rigid glass. They are easy to maintain and not prone to damage. These wire rope handrail are designed to be easy to install. These products are equipped with good tensile compression and impact resistance qualities that make them a great fit for guardrails and fencing requirements.

Alibaba.com offers different varieties of wire rope handrail that are available in multifarious designs, colors, sizes and thicknesses. This ensures that there is something perfect for every requirement on the site. These wire rope handrail are equipped with many brilliant features such as anti-collision and additional LED lights. Some of the varieties available on the site include stair railings, porch railings and deck railings. These may be mounted to the floor or wall. wire rope handrail from the site are sure to elevate the style of the space in which they are used.

Alibaba.com offers marvelous wire rope handrail that meet your needs and budget. wire rope handrail suppliers and manufacturers are sure to want to purchase these for their future needs. Place bulk orders and spruce up the architecture of your space today.

Jakob products are manufactured in Switzerland using only high-quality AISI 316. Whether your project needs stainless steel fittings, stainless steel fasteners or any stainless steel hardware, you won"t find a better product anywhere in the world.

This section includes stainless steel railing balustrades and guardrail created with our wire rope wire mesh netting, rods, fittings, and other INOX Line components manufactured by Jakob, Inc.. Components provided by Jakob, Inc. are fabricated from chromium-nickel austenitic stainless steel with low carbon content and containing molybdenum for greater corrosion resistance. These stainless steel, corrosion resistant, low maintenance, high tensile strength products provide design flexibility, durability, high strength to weight ratio, functionality, and impressive aesthetics.

** NOTE TO SPECIFIER ** It is the Architect"s responsibility to design the stainless steel wire rope railings including supporting posts, frames, and anchorage method to comply with applicable codes and regulations. Consult load tables contained in the manufacturers product data for required data. The following paragraphs identify typical code conditions, edit as required to suit actual requirements. Delete if data is indicated on the Drawings.

A.Structural Requirements: Provide wire rope railings systems capable of withstanding the effects of gravity loads and the following loads and stresses within limits and under conditions indicated on the Drawings:

** NOTE TO SPECIFIER ** It is the Architect"s responsibility to design the stainless steel wire rope railings including the height of railings, size and clearance of handrails, size of openings in guardrails, and other attributes to comply with applicable codes and regulations. The following paragraphs identify typical code conditions, edit as required to suit actual requirements. Delete if data is indicated on the Drawings.

C.Wire rope railing systems shall be designed, fabricated, and installed to accommodate expansion and contraction of metal components without causing undue stress, buckling, opening of joints, and distortion.

4.Where materials or fabrications are indicated to comply with design loadings, include material and safety factor properties, and other information needed for structural analysis.

A.Manufacturer Qualifications: Company specializing in manufacturer of stainless steel wire rope, fittings, and other stainless steel components with 10 years minimum successful experience.

A.Acceptable Manufacturer: Jakob Rope Systems, which is located at: 2665 N.W. 1st Ave.; Boca Raton, FL 33431; Toll Free Tel: 866-215-1421; Tel: 561-330-6502; Fax: 561-330-6508; Email: request info; Web: https://www.jakob-usa.com

** NOTE TO SPECIFIER ** Select wire rope paragraph(s) required and delete those not required. 6x7 wire rope is used for most railing applications due to ease of use and flexibility to accommodate stairs and curves. 1x19 has higher tensile capacity and is more resistant to bending and deformation under load. Typically 3 mm (1/8 inch) to 6 mm (1/4 inch) is used for cable infill. The type and size of wire rope to be used can be selected by Architect from Jakob product literature and load tables. Contact Jakob for assistance in determining the correct cable size and end fittings for your application.

A.Material: ASTM A 492 and ASTM A 555, Type 316 stainless steel. Fabricate wire rope with integral colored filament designating specific manufacturer.

** NOTE TO SPECIFIER ** Wire netting is a flexible, extendable, stainless steel wire mesh that when stretched between perimeter supports accommodates stretch and tension forces in three dimensions. Use the following paragraphs if Webnet is to be used as infill for guardrails. Delete if not required.

A.Material: Webnet as manufactured by Jakob, Inc. Parallel stainless steel wire ropes connected by reciprocally curved offset sleeves or clamps such that ropes are neither knotted nor crossed. Wire rope shall be fabricated from cold-drawn, AISI Type 316 stainless steel wire complying with ASTM A 492 and ASTM A 555.

** NOTE TO SPECIFIER ** The type and size of wire netting to be used can be selected by Architect from Jakob product literature and load tables. Contact Jakob for assistance in determining the correct cable size and end fittings for your application.

** NOTE TO SPECIFIER ** Guardrails can be infilled with vertical solid stainless steel rod spindles. Edit and include this article if rod spindles required. Contact Jakob for assistance in determining the correct rod size and end fittings for your application. Delete if not required.

** NOTE TO SPECIFIER ** Stainless steel rods are available in eight standard diameter sizes as listed in the following paragraph. Select the diameter required and delete those not required.

** NOTE TO SPECIFIER ** Stainless steel rods can be shop swaged with end connectors or rolled with external threaded connectors for on-site attachment. Select the rod termination required and delete those not required.

** NOTE TO SPECIFIER ** Guardrails and infill require fittings for attachment and connection of stainless steel wire rope wire netting and metal rods to support framework and substrates. Edit the following paragraphs as required. Contact Jakob for assistance in determining the correct end fittings for your application.

** NOTE TO SPECIFIER ** Fitting strength is typically a percentage of the wire minimum breaking strength. Depending on type of fitting, breaking strength can vary from 40 to 120 percent of wire rope minimum breaking strength.

C.Types: Fabricate from AISI Type 316 and 316L stainless steel complying with ASTM F 1145; INOX Line Fittings as manufactured by Jakob, Inc. Provide sizes and types as required to meet project design conditions specified and indicated on Drawings and reviewed shop drawings including:

** NOTE TO SPECIFIER ** Jakob, 1nc. manufactures numerous stainless steel fittings for wire rope ends, for attachment to different substrates, and for connecting wire rope segments. To ensure structural compatibility it is important the Jakob wire rope only be used with Jakob fittings. Typically required fittings will be determined by manufacturer to accommodate Project conditions and loadings. Edit the following to indicate basic type of fittings required for specific project. Delete the fitting type paragraphs not required.

1.Shop applied swaged rope ends: Threaded external and internal swivel ends, turnbuckles, tensioning screws, end stops, clevis ends, eye ends, loop ends, and end cones.

2.Screwed rope ends for on-site assembly: Threaded external and internal swivel ends, turnbuckles, tensioning screws, end stops, clevis ends, eye ends, loop ends, and end cones.

5.Anchoring systems: Studs, clevis, eye end, eye bolt, slotted, spacer baskets, radial clevis holder, cross clamp with support disk, slotted rope deflector, ball cage.

D.Accessories: Provide threaded couplings, tensioning screws, cover disks, eye bolts, eye nuts, carabiners, shackles, clips, welded rings, screws, washers, lock nuts, hexagonal nuts, dome nuts, wall anchors, screws, and wire endcaps as required to complete the installation.

E.Coordinate requirements, dimensions and spacings of wire rope railing system to ensure required factory drilled holes in supporting framework are correctly located.

C.Verify supporting posts and framework for stainless steel wire rope railings are prepared for attachment of anchors, fittings, wire rope, and wire netting and transfer of calculated loads.

For over a decade Seco South has been the leader in stainless steel cable handrail industry. These unique systems offer the designer a whole new approach to interior and exterior railing design capabilities. Our cable railing systems are used on commercial and residential projects all over the world. The incredible transparency as well as the extremely low maintenance is what set these systems apart from other obtrusive and high maintenance railing systems.

Seco South offers a variety of different cable systems to choose from. Our stainless steel cable infill systems for railings utilize 1/8", 3/16" or 1/4" cable diameters. Larger sizes are available if desired. The type of cable we use is either a 1×19 or 7×7 construction.

The railing framework, which supports the cable systems, is available in a few different pre-engineered designs. Typically, there are all stainless steel but other types of materials and finishes are also available.

FB1-2000 welded railing frame system: This is a welded railing frame system that is designed for bolt in or core drilled applications. The vertical balusters are made of 1/2" × 1 1/2" stainless steel flat bars and bridged together with sections of stainless tubing which enclose the cable fittings. Te handrail is made from 1 1/2" diameter stainless steel. A #320 non-directional satin finish is standard but other finishes as well as powder coating are also available.

SP1-2000 component railing system: This system is designed for easy installation on the job site. All the components are shipped separately and can be easily assembled on site. The components consist of 1 1/2" square vertical balusters designed for bolt in or core drilled applications. The posts are pre-drilled for the cable system. The unique design of the post cap assembly allows it to be installed in minutes. The saddle for the handrail is suitable for wood or metal. The standard finish for the vertical balusters is a #320 non-directional satin finish. Other finishes are available including powder coating as well.

FB2-2000 welded railing frame system: This is a welded railing frame system designed for both bolt in or core drilled applications. The vertical balusters are made of 3/8" × 1 1/2" stainless steel flat bars. The handrail is a 1 1/2" diameter stainless steel. A #320 non-directional satin finish is standard but other finishes as well as powder coating are also available.

RP1-2000 welded railing system: This is a welded railing frame system designed for both bolt in or core drilled applications. The vertical balusters and handrail are made of a 1.9" diameter stainless steel tube. A #320 non-directional satin finish is standard but other finishes as well as powder coating are also available.

FB3-2000 welded railing frame system: This is a welded railing frame system that is similar to our FB1-2000 system except the vertical balusters are bridged by small gusset plates instead of tubing. The vertical balusters are made from the same 1/2" × 1 1/2" stainless steel flat bars and the handrail is a 1 1/2" diameter stainless steel. A #320 non-directional satin finish is standard but other finishes as well as powder coating are also available.

UC1-2000 welded railing frame system: This is a welded railing frame system designed for bolt in or core drilled applications. The vertical balusters are made of 3/8" × 1 1/2" stainless steel flat bar and the horizontal component of the system is a 1 1/2" u-channel. The handrail is a 1 1/2" diameter stainless steel. A #320 non-directional satin finish is standard but other finishes as well as powder coating are also available.

For over a decade Seco South has been the worldwide leader in cable handrail and guardrail systems. Our unique horizontal stainless steel cable infill systems offer the designer a unique and innovative approach when it comes to interior and exterior handrail

transparency coupled with extremely low maintenance, blended into a beautiful streamlined design are only some of the features which sets our unique handrail and guardrail cable systems apart from our competitor’s typically obtrusive, unattractive, high maintenance counterparts.

We have manufacturing facilities in both the United States and the United Kingdom that incorporate the latest advances in CNC machining and manufacturing technology. Our stainless steel cable handrail and guardrail systems comply with all existing code

To make it easy for you to select, specify, and order your railing we have divided our cable assemblies into a simple part-number-system. The following stainless steel cable assemblies are currently available:

they are of an all-stainless-steel (type 316 stainless) construction. This advanced alloy provides superior corrosion resistance while maintaining a beautiful luster and appearance over extended periods of time. Other types of materials and specialized

Seco South designs, manufactures and distributes the widest range of stainless steel cable and strand assemblies and hardware nationwide. Our manufacturing capabilities range from cable assemblies as small as 1/8" diameter and as large as 1-1/4" diameter. Some of our applications include the following:

Modern architecture requires that material be high strength, corrosion resistant and as maintenance free as possible. High tensile stainless steel wire used in our assemblies is manufactured from type 316S31 to achieve maximum corrosion resistance. Furthermore, a balanced design with king wires providing support for the outer wires and lay length are arranged to give maximum strength with minimum stretch. Unlike other types of cable, our stainless steel cable is dry and free of lubricants, which will provide the best finish available and will remain maintenance-free for many years. All of our stainless steel cables and fittings are manufactured from the highest quality marine grade type 316 stainless steel, which eliminates the need for expensive paint systems and reduces maintenance cost as well.

Maximum corrosion resistance is achieved by manufacturing assemblies from Type 316S31 high tensile stainless steel wire. Strength is increased and stretching is minimized through a specialized design allowing outer wires to be supported by king wires. The cables are free of lubricants to allow for years of maintenance free utilization. Superior quality marine grade Type 316 stainless steel is utilized to manufacture all our stainless steel cables and fittings. Besides reducing maintenance costs, this product eradicates the need for costly paint equipment.

Strand is a group of wires wound concentrically in a helix. Normally, they are wound around a center wire known as the king wire. Strand is referred to as I by the total numbers of wires in the stand.

Constructional Stretch – occurs when a cable is put under load and the outer wires of a strand compress around its core causing the cable to extend. This permanent extension will vary depending on the load applied and the number of cycles of applications. The permanent extension can be as much as 0.1% for a conventional 1×19 strand.

The low constructional stretch properties of our stainless steel Compact Strand make it the most suitable for structural applications. The unique manufacturing process that compacts the strands, not only increases the metallic area of the strand but also has the effect of removing the conditions within the strand that give rise to constructional stretch. Constructional stretch is as low as 0.01% and is achieved virtually on the initial loading thus eliminating any need for pre-stressing or subsequent retensioning of assemblies. In addition, the strength is increased by approximately 30% and the modulus is increased by a similar amount.

Swage – To swage a fitting on the end of a cable means to press the fitting onto the end. There are several different methods used to swage fittings onto cables. All types of machines can produce a swage as strong as the wire (except hand crimp swaging) when adjusted and used correctly. All of our swage terminal dimensions comply with the US military standard that has been used exclusively for many years in the USA, UK and Australia. You can find our full range of swage fittings here.

Swageless – The Norseman swageless system is an extremely effective way to attach fittings to a cable without the use of any specialized equipment. These fittings can be installed on a cable with nothing more than a simple adjustable or open end wrench. This allows you to install the fittings at the job site yourself and manufacture a cable assembly to length without having any predetermined dimensions. The Norseman swageless system will exceed the break strength of a cable when installed properly. You can find our full range of swageless fittings here.

Seco South uses only the highest quality of Type 316L stainless steel bar stock to manufacture our tie bar assemblies. Bar stock is manufactured in lengths ranging from 10 – 12 ft depending on the diameter required. For tie bar assemblies that require longer lengths, a tie bar connector is used to join multiple sections together. The completed assembly is available in a polished or satin finish.

The tie bar tension barrels are used as an in-line tensioning device. We offer both closed and open body style barrels. Our #535 body is solid stainless steel. Our #651 body is solid stainless steel with unique aluminum-bronze threaded inserts to help prevent the galling of threads under load. Our #671 body is chrome plated aluminum-bronze that has an open body to view the threads.

Jakob Rope SystemsJakob Rope Systems is one of the market leaders in the manufacture and supply of top-end, design-forward solutions to industrial and construction-related rope and cable applications in which elegance, simplicity and superlative quality are required.

Now, for more than a century and in over 55 countries, Jakob offers a range of steel rope products to our clients who return time and again seeking a reliable maker and provider of stainless steel wire ropes, rod fasteners, nets and unique fittings, all custom-designed and produced to fit exact specifications. At Jakob, we understand it’s the little details that make the big differences.

Every piece of finished goods leaving our warehouses is put through a stringent testing process to ensure compliance with AISI 316, ISO and DIN standards. Our cable railing, wire mesh, wire ropes, and rods can be used in multiple applications, both indoor and outdoor and at various scales, such as sign stanchions, shelving, as trellises on green walls, safety netting, and even in zoo enclosures.

Jakob and our USA -based team can provide cables and wire netting solutions for any commercial and business application. We take pride in offering custom-made designs to fit our clients’ needs.

Used as both interior and exterior barriers and fall protection systems, cable railings are commonly made of durable and weather resistant materials such as stainless steel. This results in low maintenance railing with a sleek and elegant look.

There are several basic components applied in the design of a cable railing system. The cable itself has three main elements known as filaments, strands, and cores. Filaments are cold drawn rods of metal materials of varying diameters. These wires are then twisted or braided together to form what are known as strands. Each strand may contain as few as two strands or several dozen. Variable numbers of these strands are then wrapped around the third and final component, the core. Cores can be fibrous or made of wire as well, depending upon the application.

The framework used with stranded wire railing must be very rigid due to the force applied by tensioning the cable. The cable tension prevents deflection and can yield great amounts of stress which are placed on the posts. Intermediate posts are placed at varying intervals throughout the railing system to relieve some of the burden from the end posts.

Ready Stainless Steel Bollards for Shipping to UAE Diameter 114mm round stainless steel bollards with 3.4mm thickness Please contact us for more infor...

Check out the our latest house glass railing project for Canada . Round stainless steel glass railing post with 12mm thick clear tempered glass , top ...

We have recently finished production of 1000 sets of steel guarails / handrails of different deisgns /dimensions for outdoor use . These guardrail/han...

Loading container for square stainless steel wall mounted handrails Brushed stainless steel durable finish for&ensp...

Cable railing systems are typically more expensive than traditional all-wood railing systems. The added value compensates for the initial cost to your property.

The presence of cables is what distinguishes cable guardrail systems. The posts must be strong enough to withstand the pulling force of the steel cables. Furthermore, top rails are frequently subjected to light impacts and pressure from objects or people leaning against the structure.

Most state residential codes require railings to be at least 36″ tall. California is an exception to this rule, requiring at least 42″ railing for all residential railing installations. The 42″ railing height requirement applies to commercial building codes as well. The height of the post is measured from the ground to the top of the handrail.

All railing installations must adhere to all applicable standards for post height and cable spacing. You should consider the handrail, the type of location, as well as local, city, and international building codes when determining the height of the railing posts.

If a person stands on the cable (point load), the cable will by definition start to sag. A tensile force is created in the cable, which is transferred to the end posts. The magnitude of that force can be as much as ten times the weight of the person. It is therefore important to ensure the end posts have the correct rigidity. Adding a handrail to the top is usually sufficient.
