Based on the catalog breaking strength of wire rope, Crosby® wire rope clips have an efficiency rating of 80% for 1/8 - 7/8 in sizes and 90% for sizes 1 in through 3-1/2 in

Wire rope clips, sometimes referred to as u bolt clamps, u bolt clips, u clips, u clamps or cable clamps, are used to secure the loose end of a wire rope when forming an eye. Wire rope u clips have a u-bolt that is secured into a saddle by two nuts. Wire rope assemblies almost always require two, or more wire rope clamps to secure the wire rope properly. When using wire rope cable clamps to form an eye in a wire rope, the working load limit of the wire rope is reduced by about 20%.

Here at Tri-State Rigging Equipment we pride ourselves on providing only the highest quality wire rope clamps from only the most reputable manufacturers. We can provide you with any wire rope clip on the market so, if you are unable to find what you are looking for, or if you don’t know exactly what you need, call or email our sales team to speak with a rigging product specialist.

Wire rope cable clamps come in a variety of materials ranging from galvanized and zinc plated steel, to stainless steel. The two most important different types, however, are drop forged and malleable wire rope u bolt clips.

Drop forged wire rope clips are more heavy duty than malleable rope clips and can therefore be used for more heavy-duty rigging applications. In addition, they are galvanized with a heavy coating of zinc that resists the corrosion and abuse found in rugged work environments. Wire rope cable clamps of every type are not designed to be used in an overhead lift but drop forged wire rope u bolt clamps can be used to suspend an overhead load. This makes wire rope cable clamps ideal for use with:

Regarding the first question, if the load is being moved, wire rope clips are not to be used. If the load is being held in place, heavy-duty drop forged wire rope clips can be used. For the second question, if the load is near the ground, malleable wire rope clips may be used, as their lighter duty design is more than enough for the job. On the other hand, if the load is being suspended above the ground, heavier duty drop forged wire rope clamps must be used.

In the rigging and lifting industry there is a common saying that is used to remember the correct way to use wire rope u clips: “Never saddle a dead horse.” This means that the saddle of the u clamp should always be in contact with the live side of the wire rope rather than the dead side. The dead side of the wire rope is the side of the eye that has the cut end. The dead end is attached to the live end of the wire rope to form an eye and it is imperative that the saddle be on the live side of the wire rope.

Tri-State Rigging Equipment is a service provider and distributor for all wire rope cable clamps, and u bolt clips for rigging serving clients from coast to coast, Canada, Mexico and especially focused in the states of Missouri, Illinois, Indiana, Iowa, Kansas, Nebraska, Arkansas, Mississippi, Tennessee, Kentucky, South Carolina, Florida, and Oklahoma.

Fs-supplies makes every effort to provide full and accurate information on its websites of all goods offered for sale. The information is the same as that given in the manufacturer’s brochure. We do not send out brochures, but if you require further advice, please email your query to our customer service team. info@fs-supplies.co.uk

On receipt of payment, Fs-supplies will automatically send you an invoice by e-mail or if requested by post to the address you provide (Postage Charges Applies). Whether or not you receive the e-mail, this invoice confirms our acceptance of your order and constitutes a binding contract.

We offer goods for sale through eBay. Prices are subject to change and Fs-supplies updates its prices on a daily basis, however we cannot accept orders based on earlier pricing that may have been cached on the web. In the event that a supplier fails to inform us of a price rise, we may need to pass this increase on to you, but will not accept your order unless you are aware of the price increase and are willing to pay it.

Our prices vary from time to time and printed material such as catalogues or advertisements will always show our best prices at the time of printing. During the valid period of a catalogue we may offer things at a lower price. This could be a special offer or just an everyday price cut. Our website will always show one price, the lowest price we have, and if you order from a catalogue which quotes a higher price we undertake to process your order at the lower price. We will always use the lowest price we are quoting at the time that your order is processed and this will never exceed the valid prices published in our catalogue.

All of our goods are offered to you on an immediate payment basis. Your payment is due to us before we dispatch your goods and we accept PayPal / most credit and debit cards.

We will normally dispatch your goods on the same working day, provided that your order is received by 12pm. The goods becomes your property as soon as they are dispatched to you. Please note in busy period we might not be able to dispatch the item same day.

We will deliver your order to any UK address. The prices mentioned are for some parts of UK Mainland only, remote areas will incur extra postage charges. International Items over 2 Kg will incur extra charge and Remote area of Spain will incur extra charges too. Our standard delivery is handled by national carrier and in most cases you will receive your goods within 2-5 working day unless you have paid for express delivery. If you live in a remote area or the carrier finds your address more difficult to find, your delivery may take a little longer. Carriers plan their activities at the last moment in order to achieve the quickest turn-around for the greatest number of items. It is therefore not possible to book a delivery time, although Fs-supplies will make every effort to arrange a date convenient for you.

We aim to keep sufficient stocks levels on hand. However, in times of unexpectedly high demand we may unfortunately run out. If this happens we may delay dispatch of your order for a day or two while new stock is delivered. If you have opted for a premium delivery option, or we are expecting a longer delay we will use the information you have provided with your order to keep you informed. You may contact us at any time to check on the progress of your order.

You have the unconditional right under Distance Selling Regulations to cancel an order within 30 days, starting from the day after the goods are delivered.

If you wish to cancel the order you should do so by emailing the following cancellation form to info@fs-supplies.co.uk and we will process it accordingly

You are responsible for the care of the goods whilst in your possession and returning them in good condition in the original packaging including all documents and manuals.

Fs-supplies will reimburse you in full for the goods if they are returned as new. If the goods are found to be used, misused or damaged on return, we reserve the right to issue you partial refund for it.

Once your order has been dispatched you may return the goods at your expense for a full refund, without giving a reason, provided the goods are not used and are in their original packaging and you do so within 30 days of purchase.

If any of the goods we supply fails to perform satisfactorily due to faulty materials or workmanship you may return them to us for a refund at any time in the first 12 months. All we ask is that you provide an explanation of the problem and details of the purchase. Some of the goods we sell carry longer manufacturer"s warranties, our guarantee is intended to give you additional piece of mind and not as a substitute for the manufacturer’s warranty. Furthermore for some manufacture warranty to apply you do need to register your item on their website.

We are constantly updating our products prices and offers. We are confident of our technology and staff but acknowledge that human error is always possible. If goods are offered for sale incorrectly we will always try to honour our offer. There may be rare circumstances where it is not possible for us to do so. In such cases we will contact you and explain the situation, if we are unable to resolve the matter fairly with you we reserve the right to refuse your order and refund any payment you may have made.

If performance of any of our obligations to you is prevented, frustrated or impeded by reason of acts of God, war and other hostilities, civil commotion, acts of terrorism, accident, strikes, lock outs, trade disputes, acts or restraints of Government, imposition or restrictions of imports or exports or any other cause not within our reasonable control, we will do our best to maintain our deliveries. However, we shall have no liability to you for any failure which is due to such unforeseen circumstances or any other situation outside our control.

Age restrictions apply to the supply of some goods. By ordering these goods you confirm that you are over 18 and that the person receiving the delivery is also over 18.

The terms and conditions of business are not intended to affect your statutory rights or to limit our liability for death, personal injury or fraudulent misrepresentation resulting from our negligence. If there is a problem you may receive a refund or replacement under the terms of our guarantee. Our liability to you will always be limited to a full refund of the goods purchased. We will not compensate for delivery delays or failures unless you have requested a premium delivery option. In these circumstances our liability to you will be limited to a refund of the delivery charges you have paid. Our liability to you specifically excludes compensation for indirect or consequential loss or damage however it arises and except as described above will always be limited to a refund of your payment.

Byculla, Mumbai No. 2/14, Pais Street, Byculla West, Opposite Kinjal Towers Near Veena Killedar Industrial Estate, Byculla, Mumbai - 400011, Dist. Mumbai, Maharashtra

West Mambalam, Chennai New No. 21, Old No. 9, First Floor, Rajagopalan Street (Off Jubilee Road) West Mambalam, West Mambalam, Chennai - 600033, Dist. Chennai, Tamil Nadu

We deals in Forged Pipe Fittings, Butt Weld Fittings, Dairy Fittings, Flanges, Fasteners, Refractory Anchors, Plates, Sheets & Coils, Pipes & Tubes, Bars and Olets. In addition, we also offer Angle & Channel, Titanium Products, Inconel, Monel and hastelloy Products and Duplex & Super Duplex Products.

JALALPURA, Nagpur Shri Gokulesh Bhavan, Near Rapid Transport Co., Behind Prateesh Sales Near Madhur Courier, Opposite Shankar Mandir, Gandhi Bagh,, JALALPURA, Nagpur - 440002, Dist. Nagpur, Maharashtra

We supply a quality range of U Clamps that is used to fix the loose end of the loop back to the wire rope. It consists of a u-shaped bolt, a forged saddle and tworead more...

We have invested millions of dollars in our own test labs and factories, so our tools will go toe-to-toe with the top professional brands. And we can sell them for a fraction of the price because we cut out the middleman and pass the savings on to you. It"s just that simple!

Wire rope clips are widely used for making end terminations. Clips are available in two basic designs; the U-Bolt and fist grip. The efficiency of both types is the same.

When using U-Bolt clips, extreme care must be exercised to make certain that they are attached correctly; Incorrect installation can reduce the working load limit by 40%. Below are general guidelines for installing wire rope clips.

The saddle shall be placed on the live end of the wire rope, with the U-bolt on the dead-end side—Remember the well-known saying: “Never saddle a dead horse.” Use at least two or three wire rope clips to secure the ends properly to the length of the rope, and tighten nuts evenly one by one until reaching the recommended torque.

Step 1. Turn back a specified amount of rope from the thimble or loop. The first clip must be placed one bridge width from the turned back rope tailor dead end of the rope, Apply U-Bolt over dead end of wire rope – live end rests in the saddle (Never saddle a dead horse!) Tighten nuts evenly, alternate from one nut to the other until reaching the recommended torque.

Step 2. When more than two clips are required, apply the second clip as near the loop or thimble as possible, tighten the nuts firmly but not yet to the specified torque.

Step 3. When three or more clips are required, space additional clips equally between the first two – take up rope slack – tighten nuts on each U-Bolt evenly, alternating from one nut to the other until reaching recommended torque.

Step 4. Apply the first load to test the assembly. This load should be of equal or greater – weight than loads expected in use. Next, check and retighten nuts to recommended torque.

In accordance with good rigging and maintenance practices, the wire rope end termination should be inspected periodically for wear, abuse, and general adequacy. Periodically re-tightening of the nuts must be done at 10.000 cycles (heavy usage), 20.000 e.g. every 3 months, 6 months, annually.

Malleable clips are to be used for making eye termination assemblies only with the right regular lay wire rope and only for light-duty uses with small applied loads, such as handrails, fencing, guard rails, etc.

If you have any wire rope clips questions, you can contact us by email at info@hilifting.com. We will be glad to share with you more useful information.

WIRE ROPE END FITTINGS Forged Wire Rope Clip • Each base has a Product Identification Code (PIC) for material traceabilit, the name CROSBY or CG, and a size forged into it. • Based on the catalog breaking strength of wire rope, Crosby wire rope clips have an efficiency rating of 80% for 1/8” through 7/8” sizes, and 90% for sizes 1” through 3-1/2”. • Entire Clip is Galvanized to resist corrosive and rusting action. • Sizes 1/8” through 2-1/2” and 3” have forged bases. • All Clips are individually bagged or tagged with proper application instructions and warning information. • Clip sizes up through 1-1/2” have rolled threads. • Meets or exceeds all requirements of ASME B30.26 including identification, ductilit, design factor, proof load and temperature requirements. Importantly, these wire rope clips meet other critical performance requirements including fatigue life, impact properties and material traceability, not addressed by ASME B30.26. • Look for the Red-U-Bolt®, your assurance of Genuine Crosby Clips. Page 56 Para Espanol: www.thecrosbygroup.com Rope Size * Electro-plated U-Bolt and Nuts. ** 2-3/4” and 3-1/2” base is made of cast steel. Copyright © 2019 The Crosby Group LLC All Rig
