wire rope cable thimbles factory

US based company with manufacturing in US and China. ISO 9001:9002, ISO 9001:2000 & ISO/TS 16949 certified manufacturer & distributor of rigging hardware including load binders, anchor & chain shackles, and wire rope thimbles. Products are available in different sizes. Capabilities include aluminum die casting, investment casting, iron sand casting, steel forging, sheet metal stamping and forming, plastic injection molding and aluminum extrusion. Services include CAD model development, stress analysis, mechanical & chemical lab tests & prototyping service. Local US customer service handles project from beginning to end.

Thimbles are designed to extend the longevity of wire rope loops by preventing fraying that can occur due to friction at the bearing point. Thimbles must be used in conjunction with either sleeves or wire rope clips in several specifications.

The purpose of thimbles are to underline and support the eyes made by looping the exteriors of wire ropes together. As alternatives to wire clips and swage sleeves thimbles create a durable wear surface & aid in supporting the wire rope eye by preventing pinching and fraying of the wire rope. Thimbles can be used with swage sleeves or wire rope clips.

Available in standard duty, heavy duty, zinc plated, galvanized, stainless steel material. US Rigging offers a wide variety of metals and sizes to best suit your needs, Including AN100 type and Federal Spec FF-T-276 B type. gusseted. tube and nylon thimbles.

Wire rope thimbles also known as cable thimbles, are used for making reinforce loop(eyelet) with grips, clips or clamps by preventing fraying caused by friction at the bearing anchor point to protect and extend the service life of the wire rope or sling. They are just one of the many types of wire rope fittings (ferrules, wire rope clips, terminals, etc.).

Wire rope thimbles are available in a variety of strengths and materials(carbon steel and stainless steel, see our post on Surface Finish: 4 Common Types You Should Know) but mainly they come in two different duty grades.

If you use it in high moisture or corrosive environments, recommend our stainless steel wire rope thimbles which can offer resistance to corrosion on the surface, particularly in marine applications.

Simply wrap the end of the wire rope around the outer groove of the thimble, lace the dead end of the wire rope past the U-bolt of the wire rope grips or a wire rope ferrule crimp to hold onto the bearing anchor point at the end of the thimble to prevent fraying caused by friction.

Once in place, put another wire rope clip as near the loop you just wrapped over the thimble. Turn nuts firmly but do not yet tighten to the proper torque, we recommend using a crimping/swaging tool to compress the ferrule firmly onto the rope to hold your thimble loop securely.

Alternatively, you can use a wire rope ferrule crimp to secure your thimble in place. this method is quick and easy to install. For further information on installation using a wire rope ferrule please – click here

Wire rope thimbles are used in conjunction with cable and rope to protect the eyes and will allow for smooth rope guiding around natural curves. So that the most important thing is to make sure the thimble eye securely fastened. Here are some tips for correctly using wire rope thimble:

Make sure that the cable thimbles size properly and securely fastened in the eye of the loop, not too loose or too tighten, so they can create an extra layer of support to connect with other properly sized rigging fittings.

While you are using a vinyl coated cable, you should multiply the actual size of the cable, usually use a larger size thimble than normal, for the actual diameter is the thickness of the vinyl coating plus the inside wire rope diameter. For example, if you are using a 5/16″ vinyl coated cable that is coated to 3/8″ diameter, you’d want to use a 3/8″ wire rope thimble.

Hilifting is the leading wire rope thimbles supplier in China. We supply many types of wire rope thimbles, including BS464 wire rope thimbles, galvanized DIN6899 wire rope thimbles, tube wire rope thimble, and heavy duty and light duty thimbles, which meet the standards of the US, EN, DIN, and JIS.

SAS’s Cable thimbles are required for wire rope terminations on the CRA HLL systems. These thimbles come in galvanized steel or Stainless Steel. Offered specifically for 3/8” diameter wire rope, thimbles reduce both wear and stress on the cable. Designed specifically for use with SAS commercial anchors, these components can be used with other mfg. equipment when engineered by a qualified person.

Rigging Kits: our standard turnbuckle/clamps/thimbles/sliders/energy absorber for lifeline lengths up to 120’. They include everything you need for a complete installation except for the cable. Available in galvanized or stainless-steel finishes. See part numbers 1050-G and 1051-S.

Turnbuckles: used in the horizontal lifeline system to adjust wire rope length and tension. Available in galvanized or stainless-steel finishes. Use 1 turnbuckle in systems up to 60’ and 2 turnbuckles in systems 60’ – 120’.

Cable: galvanized 3/8” cable rated for 14,000 pounds. Stainless Steel rated for 12’000 pounds. Use in runs up to 120’ and in conjunction with the rigging kits.

Cable Thimble: used to terminate the end of our cable systems and are required on both ends of the HLL. Available in galvanized or stainless-steel finishes.

G411 is a standard duty wire rope thimble with electric galvanized surface treatment. This thimble provides a hard eye in a wire rope lifting sling. The galvanized surface increases the corrosion resistance. It is recommended for light duty applications.

G414 wire rope thimble is a heavy-duty wire thimble that provide a hard eye in a wire rope sling, it made according to federal specification FF-T-276b. It is the most selling wire rope thimble for heavy duty service.

We"re well-known as one of the leading wire rope thimbles manufacturers and suppliers in China. Welcome to buy high quality wire rope thimbles at competitive price from our factory. Also, free sample is available for quality checking. Galvanized fishing wire ropes, European ordinary wire rope thimble, Stainless steel snap hooks
