Wire rope clips are widely used for making end terminations. Clips are available in two basic designs; the U-Bolt and fist grip. The efficiency of both types is the same.

When using U-Bolt clips, extreme care must be exercised to make certain that they are attached correctly; Incorrect installation can reduce the working load limit by 40%. Below are general guidelines for installing wire rope clips.

The saddle shall be placed on the live end of the wire rope, with the U-bolt on the dead-end side—Remember the well-known saying: “Never saddle a dead horse.” Use at least two or three wire rope clips to secure the ends properly to the length of the rope, and tighten nuts evenly one by one until reaching the recommended torque.

Step 1. Turn back a specified amount of rope from the thimble or loop. The first clip must be placed one bridge width from the turned back rope tailor dead end of the rope, Apply U-Bolt over dead end of wire rope – live end rests in the saddle (Never saddle a dead horse!) Tighten nuts evenly, alternate from one nut to the other until reaching the recommended torque.

Step 3. When three or more clips are required, space additional clips equally between the first two – take up rope slack – tighten nuts on each U-Bolt evenly, alternating from one nut to the other until reaching recommended torque.

In accordance with good rigging and maintenance practices, the wire rope end termination should be inspected periodically for wear, abuse, and general adequacy. Periodically re-tightening of the nuts must be done at 10.000 cycles (heavy usage), 20.000 e.g. every 3 months, 6 months, annually.

Malleable clips are to be used for making eye termination assemblies only with the right regular lay wire rope and only for light-duty uses with small applied loads, such as handrails, fencing, guard rails, etc.

If you have any wire rope clips questions, you can contact us by email at info@hilifting.com. We will be glad to share with you more useful information.

Matching up with the never ending demands of customers our company offers high quality range of Handled Rope Clamp. This Handled Rope Clamp is highly appreciated amongst customers for its corrosion resistant nature and superior finish. Our product range is available in different specifications as per the client’sread more...

The Sabre C40-056-003 5/16 in wire rope clip meets Federal Specifications FF-C-450, Type 1, Class 1. Wire rope clips are used with guy strand or wire rope. The Sabre wire rope clips are forged and galvanized in accordance with ASTM A153. Designed to be used with 5/16 in EHS guy wire.

Galvanized steel ropes in 11 different thicknesses: 1mm, 1.5mm, 2mm, 3mm, 4mm, 6mm, 8mm, 10mm, 12mm, 14mm and 16mm.Equipped with eyelets, hims, as winches, or forestry rope and set for tensioning.The steel ropes are processed in Germany after the DIN-European standard 13414.

Wire rope meter in 11 different thicknesses: 1mm, 1.5mm, 2mm, 3mm, 4mm, 6mm, 8mm, 10mm, 12mm, 14mm and 16mm.Smoothed in five different constructions: 7x7, 6x19, 7x19, 6x37 and 18x7 Available as a rotary wire rope.All offered wire ropes correspond to the DIN EN 13414-1.

galvanized wire ropes with eyelets in the strengths of 1mm to 16mm according to the specifications of the DIN-European standard 13414-2 made in Germany and optimally suitable for many applications.

Our steel cables with box galvanized steel, high quality and strict DIN specifications pressed in 2mm - 16mm strength.The cheese according to DIN6899 protects the wire rope from the inside to the load absorption point.

galvanized steel ropes tension with the help of firmly connected steel cable clamps or in set with clamps, tensionersand sleep.You will receive the sets both with smoothly cut steel rope as well as with a one-sided shew of the compression.

wire rope with hook in different versions: for light suspensions with snap hooks, as choker rope with high-strength sliding hookFor forstarts, steel cable with hooks and eyelets or as a wire rope for winches.The steel ropes are processed in Germany after the DIN-European standard 13414 and are pressed with carabiner hooks, load hooks or eyelethook of Grade 8.

Our steel cables with rope stopper " are compressed from galvanized steel in 1.5mm - 12mm strength and can be opened with an open end,to be ordered a loop or kausche.The one-sided pressed round clamp according to DIN 13411-3 fulfills the purpose of a stop terminal.

forestry ropes in seven different strengths of 5mm - 16mm.Available as choker rope with high-strength sliding hook, stop rope with hook & loop, as well as with grade 8 Load hook.The steel cables are processed in Germany after the DIN-European standard 13414 and are not highly damaged.

wire ropes for winches in eight different strengths: 4mm, 5mm, 6mm, 8mm, 10mm, 12mm, 14mm and 16mm.The wire ropes are made up to a thickness of 8mm annealed, so that fixing in the wind is very easy and easy to use.

Our Rotary wire ropes Get with the construction 18x7 in 5 different strengths. Through the,In opposite directed, strand layers, the wire ropes exert a low torque to an isolated load.The wire rope optimally serves as Hub - or Kranil to lift and depend on appropriate loads.

Labels With a compressed cheese according to DIN 6899 and a glow-separated end in 13 different lengths of 0.5m - 20m, optionally equipped with a wire cable holder and in the strengths of1.5mm - 8mm permanent & fast available.

Wire ropes for garage doors With a compressed cheese to DIN 6899 and a glow-separated end in individual length, optionally pressed with a M10x100 eye screw and in the strengths of 2mm- 5mm permanent & fast available.

Our steel rope sets are equipped with a steel cable and matching clamps, himming and wire ropes.You can choose from both different lengths, different strengths, as well as different equipment.

Our Fuse ropes for the event technique correspond to the BGV-C1 guidelines (security for events and production loads over persons) and can be optimal forLoads of 2kg - 100kg be used.

Our horizontal Rope locking system " SAVEKINGLINE?® corresponds to the DIN EN 795 type C? and serves as fall protection of personsFor the use on high-volume workplaces.The cable locking system is available in variable or defined length.

wire rope for a shoot for three different web lengths: 25m, 50m and 100m.The tension rope is one-sided melted and pressed on one side with a cheaper and equipped with a emergency element.

For various rope diameters, Fassadengrün has corresponding cross clamps, such as: SK 01515 (1.5-2 mm), SK 03012 (3 mm, available in AISI 304 and AISI 316), and SK 04015 (3-4 mm). They all have a graceful build but provide sufficiently strong holding strengths/clamping forces for your plant climbing systems. SK 03420 is suitable for security-relevant applications; due to the M10 thread, even stronger holding strengths are possible. There are SK 03099 and SK 03006 as more economical options; here, the crosses are not screwed but pressed with pliers... later corrections are then rarely possible at the cross point. The connector SK 34515 is particularly suitable for combinations of cable and rods because, with two separate grub screws, strong holding strengths are made possible. Most cable cross clamps are made of stainless steel A2; only SK 03444, SK 04444, SK 03420 and SK 03006 are made of A4.

FassadenGrün cross clamps have a greater holding strength compared with similar products imported from Asia, primarily due to the shallow depth of our threaded holes, which are flush with the deeper cross grooves (see photo), creating no significant height offset. Nevertheless, the work to form the internal thread deeply enough makes it more difficult and expensive to manufacture. Then, because no concave pressure for the ropes arises, they do not undergo any deformation and are held firmly by the cable clamps. however, because they are clamped on an anvil without being concave.

With large distances from intersection to intersection, i.e. large "meshes" of more than about 1 square meter, use a (wall-connected) cross mount instead of a floating cable clamp: See cable system

For mesh sizes well under 1 square meter, all points on the outer contours of the system are fitted with (wall connected) cross mounts; but inside the field, use floating cross clamps at cable intersections. See cable system

With mesh sizes of 30 x 30 cm and smaller, cross mounts on the edge of the field can also be exchanged for free-floating cross clamps. See this under cable system 5050.

Floating cross clamps can also facilitate the mounting of certain cable systems by serving as a temporary support, where the mounting starts with the outer frame (for example with 4020 and 7040). Instead of the two recommended vices,only one is then needed, and the other can be replaced by a floating cross clamp. If the respective kit does not already contain one or more cross clamps, a matching one can be ordered.
