wire rope clamp strength pricelist

Wire rope clips are widely used for making end terminations. Clips are available in two basic designs; the U-Bolt and fist grip. The efficiency of both types is the same.

When using U-Bolt clips, extreme care must be exercised to make certain that they are attached correctly; Incorrect installation can reduce the working load limit by 40%. Below are general guidelines for installing wire rope clips.

The saddle shall be placed on the live end of the wire rope, with the U-bolt on the dead-end side—Remember the well-known saying: “Never saddle a dead horse.” Use at least two or three wire rope clips to secure the ends properly to the length of the rope, and tighten nuts evenly one by one until reaching the recommended torque.

Step 1. Turn back a specified amount of rope from the thimble or loop. The first clip must be placed one bridge width from the turned back rope tailor dead end of the rope, Apply U-Bolt over dead end of wire rope – live end rests in the saddle (Never saddle a dead horse!) Tighten nuts evenly, alternate from one nut to the other until reaching the recommended torque.

Step 3. When three or more clips are required, space additional clips equally between the first two – take up rope slack – tighten nuts on each U-Bolt evenly, alternating from one nut to the other until reaching recommended torque.

In accordance with good rigging and maintenance practices, the wire rope end termination should be inspected periodically for wear, abuse, and general adequacy. Periodically re-tightening of the nuts must be done at 10.000 cycles (heavy usage), 20.000 e.g. every 3 months, 6 months, annually.

Malleable clips are to be used for making eye termination assemblies only with the right regular lay wire rope and only for light-duty uses with small applied loads, such as handrails, fencing, guard rails, etc.

If you have any wire rope clips questions, you can contact us by email at info@hilifting.com. We will be glad to share with you more useful information.

Galvanized steel ropes in 11 different thicknesses: 1mm, 1.5mm, 2mm, 3mm, 4mm, 6mm, 8mm, 10mm, 12mm, 14mm and 16mm.Equipped with eyelets, hims, as winches, or forestry rope and set for tensioning.The steel ropes are processed in Germany after the DIN-European standard 13414.

Wire rope meter in 11 different thicknesses: 1mm, 1.5mm, 2mm, 3mm, 4mm, 6mm, 8mm, 10mm, 12mm, 14mm and 16mm.Smoothed in five different constructions: 7x7, 6x19, 7x19, 6x37 and 18x7 Available as a rotary wire rope.All offered wire ropes correspond to the DIN EN 13414-1.

galvanized wire ropes with eyelets in the strengths of 1mm to 16mm according to the specifications of the DIN-European standard 13414-2 made in Germany and optimally suitable for many applications.

Our steel cables with box galvanized steel, high quality and strict DIN specifications pressed in 2mm - 16mm strength.The cheese according to DIN6899 protects the wire rope from the inside to the load absorption point.

galvanized steel ropes tension with the help of firmly connected steel cable clamps or in set with clamps, tensionersand sleep.You will receive the sets both with smoothly cut steel rope as well as with a one-sided shew of the compression.

wire rope with hook in different versions: for light suspensions with snap hooks, as choker rope with high-strength sliding hookFor forstarts, steel cable with hooks and eyelets or as a wire rope for winches.The steel ropes are processed in Germany after the DIN-European standard 13414 and are pressed with carabiner hooks, load hooks or eyelethook of Grade 8.

Our steel cables with rope stopper " are compressed from galvanized steel in 1.5mm - 12mm strength and can be opened with an open end,to be ordered a loop or kausche.The one-sided pressed round clamp according to DIN 13411-3 fulfills the purpose of a stop terminal.

forestry ropes in seven different strengths of 5mm - 16mm.Available as choker rope with high-strength sliding hook, stop rope with hook & loop, as well as with grade 8 Load hook.The steel cables are processed in Germany after the DIN-European standard 13414 and are not highly damaged.

wire ropes for winches in eight different strengths: 4mm, 5mm, 6mm, 8mm, 10mm, 12mm, 14mm and 16mm.The wire ropes are made up to a thickness of 8mm annealed, so that fixing in the wind is very easy and easy to use.

Our Rotary wire ropes Get with the construction 18x7 in 5 different strengths. Through the,In opposite directed, strand layers, the wire ropes exert a low torque to an isolated load.The wire rope optimally serves as Hub - or Kranil to lift and depend on appropriate loads.

Labels With a compressed cheese according to DIN 6899 and a glow-separated end in 13 different lengths of 0.5m - 20m, optionally equipped with a wire cable holder and in the strengths of1.5mm - 8mm permanent & fast available.

Wire ropes for garage doors With a compressed cheese to DIN 6899 and a glow-separated end in individual length, optionally pressed with a M10x100 eye screw and in the strengths of 2mm- 5mm permanent & fast available.

Our steel rope sets are equipped with a steel cable and matching clamps, himming and wire ropes.You can choose from both different lengths, different strengths, as well as different equipment.

Our Fuse ropes for the event technique correspond to the BGV-C1 guidelines (security for events and production loads over persons) and can be optimal forLoads of 2kg - 100kg be used.

Our horizontal Rope locking system " SAVEKINGLINE?® corresponds to the DIN EN 795 type C? and serves as fall protection of personsFor the use on high-volume workplaces.The cable locking system is available in variable or defined length.

wire rope for a shoot for three different web lengths: 25m, 50m and 100m.The tension rope is one-sided melted and pressed on one side with a cheaper and equipped with a emergency element.

We have ½" Galvanized Super Swaged Cable. For a smoother, quieter and faster zip line ride. This 6X26 Cable boast a 35,210 pound tensile strength. It is made by swaging 9/16" Wire Rope down to

A must when connecting cable to nut eye bolts or ovaleye bolts. Keeps the cable from flattening around the eye causing the cable to weaken. Also used in eyespliced ropes. *When using a guy thimble

Usually only used on cable or wire rope. Match the thimble size to your cable diameter. We offer an open pattern of the 3/8" which is gapped to fit onto our nut eye bolts and ovaleye bolts.

Wire Rope Clips are used to secure the end of wire rope when forming a loop; i.e., for wire rope turn-back. Clips are available in two configurations: mid-grip (double saddle) and single

Based on the catalog breaking strength of wire rope, Crosby wire rope clips have an efficiency rating of 80% for 1/8"-7/8" sizes, and 90% for sizes 1" through 3-1/2".

Meets or exceeds all requirements of ASME B30.26 including identification, ductility, design factor, proof load and temperature requirements. Importantly, these wire rope clips meet other

Based on the catalog breaking strength of wire rope, Crosby wire rope clips have an efficiency rating of 80% for 3/16"-7/8", and 90% for sizes 1" through 1-1/2".

Meets or exceeds all requirements of ASME B30.26 including identification, ductility, design factor, proof load and temperature requirements. Importantly, these wire rope clips meet other

Fist Grip wire rope clips meet or exceed the performance requirements of Federal Specification FF-C-450 Type III, Class 1, except for those provisions required of the contractor. For additional

Apply the first clip one base width from the dead end of the wire rope. The base or saddle should bear on the line end of the rope - U-bolt on the short end. Tighten nuts firmly.

We supply a quality range of U Clamps that is used to fix the loose end of the loop back to the wire rope. It consists of a u-shaped bolt, a forged saddle and tworead more...

With sincerity and hard work of our professionals, we have carved a niche for ourselves in this domain by manufacturing highly durable gamut of Wire Rope Clamp.

Wire Ropes Slings and AccessoriesOffering you a complete choice of products which include wire rope clamp, wire rope sling, wire rope, life line ropes, construction frame work tie rod and galvanised threaded rod.

We supply a quality range ofWire Rope Clamp that is used to fix the loose end of the loop back to the wire rope. These products consist of a u-shaped bolt, a forged saddle and two nuts. Three or more clamps are usually used to terminate a wire rope. Available in standard specification, these can also be customized as per the requirements of our clients. Our offered products offer various applications in industries such as cement plant, chemical industry and oil industries.

We bring forth to our customers, a premium quality range ofWire Rope Sling. These rope slings are manufactured using quality assured raw material employing latest tools and techniques. Our offered product is highly appreciated by our customers due to high efficiency and sturdy construction. All our products are thoroughly tested using variable well defined parameters to ensure the quality of products. customers can avail it economical prices

With the help of our skilled professionals, we are successfully engaged in offering qualitative range of Wire Rope Sling that is extensively demanded for electrical applications. The wire rope provided by us is designed and manufactured in complete compliance with quality standards using superior quality raw materials with the help of state-of-the-art technology. Additionally, we offer this wire rope in various dimensions as per the exact requirements of our precious clients.

Owing to our expertise in this domain, we are engrossed in providing a comprehensive spectrum of Wire Rope that is made available in various dimensions and specifications to accomplish diverse requirements of our prestigious clients. The wire rope provided by us is designed and manufactured using the best quality raw materials and pioneering machine in compliance with set industry standards. Additionally, this wire rope is vigorously verified diverse quality parameters to ensure its defect-free delivery at the clients’ end.

As a well-known entity in this domain, we are engaged in offering an exquisite range ofLife Line Ropes. These line ropes are precisely manufactured in complete compliance with market quality standards using the best quality raw material with the help of sophisticated technology at the vendors’ end. Furthermore, the line ropes provided by us are widely appreciated in the market for their salient attributes which includes easy installation and high strength.

Backed by the years of experience and expertise, we are engaged in offering a wide range of PVC Coated Wire Rope to meet the demands of our clients. These ropes are finely coated that makes them high durable and reliable in nature. All these ropes are highly efficient and ensure long lasting service life. Furthermore, we are offering these products at reasonable rates.

We are enlisted amongst the leading names in the industry, offering a comprehensive range of Automatic Come Along Clamp. They have exceptional finishing and are durable in nature. Automatic Come Along Clamp is performance based and is used in different industrial and commercial sectors. Furthermore, we offer them in well-defined time.

We provide a comprehensive array ofLifting Thimble that are widely demanded in the industries like construction, automobiles and shipping. The offered Thimbles are the devices that are installed in the wire loops, to prevent its shape and provide ease in loading in heavy lifting operations. These Thimbles prevent the wire looping that is in direct contact with the material to be lifted. In addition to this, our quality controllers conduct a series of tests on various parameters to ensure their flawlessness.

We are engaged in trading, wholesaling, retailing and supplying of Wire Rope in various sizes, quantities and specifications as per the Customers requirements. Our offered ropes are used in general and heavy engineering industries. These ropes are stringently tested for quality before being supplied to our esteemed customers. We also offer Steel wire ropes and Stainless steel wire ropes at affordable prices.

The Safe-Line Wire Rope Clamps are ideal for field installations that require quick, easily thimbled rope terminations, with the reliability that wire rope clips cannot provide. Designed only for 6 x 19 IWRC or 7 x 19 right regular-lay wire rope sizes 1/8″ thru 3/4″, the cadmium plated Safe-Line Clamp assembly includes a two-piece plug and cold-finish bar-steel socket.

The finished assembly provides a neat, clean profile (similar to a swage fitting) with no sharp edges or loose ends to snag. And they hold! The Safe-Line Clamp is rated with an efficiency of over 90% of rated wire rope strength. The clamp meets or exceeds all requirements for Military Standard MS-16843 and conforms to Federal Spec. FFC-450. They are warranted for one year.

This listing is about Galvanized Steel Wire Rope. A high-quality product with 7x7 construction features a steel structure and 1760 lbs bearing capacity. It is an excellent assistant in your daily life, such as clothesline, stair cable railing, garden fence, shipbuilding, etc.
