wire rope flemish eye manufacturer

I&I Sling wire rope slings are mechanically spliced. Compared to loop back or turn back slings, mechanically spliced slings are considered to be the safer option due to the backup redundancy of the splice in the eye. This splice can keep the sling eye together in a situation where the pressed sleeve fails. Flemish Eye slings are fabricated at your local I&I Sling branch location with domestically sourced wire rope.  Tight length tolerances are available, wire rope slings can be constructed with +/- the diameter of the rope or in matching sets.  Flemish eye slings are compliant with ASME B30.9 and can be proof tested to twice the working load limit.

Slings are made using flemish splice technique to form the eyes. Unlike the simple return loop method that places 100% of its strength on the swagad sleeve, slings have reserve strength should the sleeve become damaged in use.

It is an eye termination where the rope end is split in two parts of three and four strands each, which are laid back together again in the opposite direction, to form a soft eye, which can be provided on demand with various types of thimbles.

Swaging the Flemish Eye with its heavy conical steel ferrule offers the best solution against abrasion and distortion of the termination. Combined with its steel core rope construction and steel termination, Flemish Eye manufactured slings and steel wire ropes can be set into service in a potential highly temperatured environment.

Hilifting is the best flemish eye steel swage ferrule manufacturers in China, we supply many different types of wire rope ferrules and swage sleeve which suit a variety of rope and applications.

When looking for strength and durability on that next big rigging job, look no further than our array of HSI Wire Rope Slings. A wide-variety of sizes are available whether working on a small-load lift or preparing to maneuver a massively heavy element. Our slings are there to solve your hoisting, lifting and towing problems.

The wide offering of Single Leg Wire Rope Slings will surely meet your rigging needs on the jobsite. Each eye on these slings is formed using the mechanical Flemish Eye Splice. This process allows for the most efficient use of the rope capacity with top-quality steel as the pull is directly along the centerline of the rope and eye.

The Flemish eye without the sleeves has already an efficiency of 75% of the breaking load of the rope; with the sleeve this termination has the same breaking load as the rope, for thick ropes down to 90% of the rope’s breaking load. Superloop with Flemish eye can be used on ropes up to 114 mm in diameter. At our workshop we can make Superloop with a diameter up to 68 mm.

There are at least six prominent varieties of lifting slings that are presently widely used across many sectors, including single-use one-way slings, wire rope slings, round slings, fiber rope slings, chain slings, and web slings, sometimes also known as webbing slings. Check out the wholesale flemish eye wire rope sling options on Alibaba.com; you should be able to find the bulk of them at a great wholesale price here!

Before you search for a flemish eye wire rope sling below, let"s go over some of the crucial aspects to consider when choosing lifting slings. First and foremost, you must evaluate the overall weight of your load in relation to the load limit of the sling type you have decided on. Secondly, consider how frequently you will need to lift the load. In order to achieve correct load balance, you must also consider optimal sling configuration while picking the appropriate sling for your load. Another essential element to consider is the environment in which your loads are stored or lifted. Humidity, temperature, and the presence of corrosive substances may greatly affect the durability and quality of your chosen slings too.

The eye or loop end preparation is formed using the Flemish Eye Splice. This splice is then secured by swaging a metal sleeve over the strang ends, at the junction of the splice. There are no exposed wires and serving is not required.

The swage metal sleeve flows around the wires and prevents the strands from unlaying. Depending on the application, the sleeve can be steel, aluminum, or stainless steel.

The Flemish Eye is spliced by unlaying one half of the strands from the other half at the core. The two halves are joined at the bearing point of the eye and laid back in the opposite direction. The final step is to secure the strands with a metal sleeve.

1. Vertical- The Vertical, or straight, attachment is simply using a sling to connect a lifting hook or other device to a load. Full rated load of the sling may be used, but never exceeded. A tagline should be used on such a lift to prevent rotation, which can damage the sling. A wire rope sling with a hand-tucked splice can unlay and fail if the sling is allowed to rotate.

Triple leg slings have 50% more capacity than double leg only if the center of gravity is in center of connection points and the legs are adjusted properly(equal share of the load)

When lifting vertically, the load will be shared equally if the center of gravity is spaced equally between the pick points, as in the first illustration at right. If the weight of the load is 10,000 lbs., then each sling will have a load of 5,000 lbs. and each shackle and eyebolt will also have a load of 5,000 lbs.

“Tough-Lock™” and “Cable-Flex™” slings are uniquely constructed unlike various return wire loop types. Note that our five step manufacturing process, commonly

referred to as a “Flemish” splice, results in 100% breaking strength promoting additional safety. Further testing proved increased efficiency and greater work load limits.

All “Tough-Lock™” slings adhere and comply with current specifications of OSHA, ASME B30.9c-2000 Wire Rope Technical, and Associated Wire Rope Fabricators.

EYE AND THIMBLE - A protective thimble is present to attach the bottom end of the sling to a separate lifting element while the Flemish loop is located atop to allow a choker hitch.

FLEMISH EYE SPLICED SWAGING - The ends of the sling are mechanically formed allowing for larger load capacities than hand-laid wire rope. Loops are secured with a forged metal sleeve and go over the spliced area.

GREATER WEAR RESISTANCE - A 6 x 25 IWRC (Independent Wire Rope Core) classification for wire rope slings offer large outer wires that provide a balance between fatigue and wear resistance.

When looking for strength and durability on that next big rigging job, look no further than our array of LKS Wire Rope Slings. A wide-variety of sizes are available whether working on a small-load lift or preparing to maneuver a massively heavy element. Our slings are there to solve your hoisting, lifting and towing problems.

The wide offering of Single Leg Wire Rope Slings will surely meet your rigging needs on the jobsite. Each eye on these slings is formed using the mechanical Flemish Eye Splice. This process allows for the most efficient use of the rope capacity with top-quality steel as the pull is directly along the centerline of the rope and eye.

or wire rope slings, you may opt for thimble eye (where a thimble if fixed inside the loop to preserve the natural loop shape and prevent direct contact that will damage the cable) or soft eye. Besides, rope ends with machine swaged with ferrules or sockets is a better option than hand spliced slings as it offers more protection.

Do you experience a short lifespan for your steel wire ropes? Deal with a supplier who is slow in responding & customer service? Or did you pay high prices for average quality products that fails you all the time? 83%of our clients claim that these made them search for a better option and subsequently worked with us since.

Wire rope slings are strong, efficient, and reliable accessories in the material handling industry. Wire rope functions as a excellent sling material in applications where a combination of strength and abrasion are necessary. Wire rope slings are available in an array of configurations to fit almost any application. Wire rope is composed of wires, strands and a core. The basic unit of wire rope is wire, which is carefully processed and drawn from selected grades of steel to predetermined physical properties and sizes. A predetermined number of finished wires is then helically laid together in a uniform geometric pattern to form a strand. This process must be performed with precision and exactness to form a strand of correct size and characteristics.

The required number of suitably fabricated strands are laid symmetrically with a definite length of lay around a core, forming the finished wire rope. Wire rope is identified by its construction, or the number of strands per rope, and number of wires in each strand. For example, the construction 6×25 denotes a 6-strand rope, with each strand having 25 wires. Constructions having similar weights and breaking strengths are grouped into wire rope classifications, such as the 6×19 and 6×37 Classes. Consult our technical resources for additional information.
