sae hydraulic pump mount dimensions in stock

HYDRAULIC PUMP, GEAR PUMP 2.0IN3 DISPLACEMENT, MOUNT IS SAE B 2/4 BOLT FLANGE, 7/8"-13 SPLINED SHAFT, 1.62 SHAFT LENGTH, PILOT IS 4", 3000 MAX PSI, BIROTATIONAL (CW OR CCW), DUAL PORTED (SIDE PORTS ARE 1" NPT, REAR PORTS ARE 1" NPT).

These are high-quality hydraulic gear pumps. Hydraulic demands extremely fine tolerances & quality materials. GRH has been producing hydraulic items for 20 years. We offer a 12-month warranty. These are interchangeable with much more expensive pumps such as Casapa. These come with Clockwise rotation as standard, but we can supply counterclockwise. Please contact us for this option. These come with UNO threaded ports, either a 7/8" keyed shaft, a 7/8" 13 Tooth splined shaft, & 2 bolt SAE B mount. If you are unsure about identifying your pump, please clean & send a photo of numbers & letters stamped in the body of all pumps. We will try to interpret this for you.

The Hydraulic Troubleshooting App is a nifty tool to keep on your phone or tablet, so you can refer to it when needed. And you will need it at some point, that"s for sure.

High pressure hydraulic gear pump. Constructed of an aluminum center section and cast iron end plates. Mounting flange is a 2 bolt AA. Ports are SAE 8 inlet and SAE 6 outlet and the drive Shaft is a 1/2” Dia.meter x .75 long straight keyed Shaft with 1/8” keyway. Shaft is determined when the Shaft is facing you.

The pump mounting plates are designed to mount SAE and metric pumps, but they can also be customized to fit a variety of other mounting requirements. All pump mounting plates come standard with a rust protective coating and are available in a variety of thicknesses.

The pump mounting flanges are made of steel and cast iron for hydraulic pumps with flange connections according to SAE-A, -B, -C, -D and-E in a design with 2 holes and 4 holes.

Pump connection housings made of cast iron of our portfolio are suitable for direct mounting to the back plate of the engine. Our pump mounting flanges are also availabe with surface coating as well as special flange dimensions on request.
