We provide expert Mechanical Seal Repair of all major brands, including John Crane®, Flowserve®, Burgmann®, and more. With locations in Gonzales, LA, and Williston, VT, we are the reliable, convenient single source repair for all styles of mechanical seals.

Our comprehensive library of manufactured design solutions addresses applications in the field and pump-specific challenges providing upgrades and replacement seals manufactured to perform better and last longer.

Flexaseal’s experienced maintenance and repair technicians have worked with mechanical seals from the world"s largest pump and seal manufacturers, including John Crane® and Flowserve®. Below is just a sampling of the many manufacturers and styles that we have repaired. If your seal isn’t listed, just click “Request A Quote” to send us a message.

Each repair that comes to our repair departments in Louisiana or Vermont - whether it is a third-party design or a Flexaseal model - goes through a detailed, 5-step process to ensure customer satisfaction.

Flexaseal offers repair kits for on-site seal repair. These kits are specific to your Flexaseal cartridge and are a great way to have parts on hand for an emergency situation. All items in the kit are packaged and labeled to ensure efficient change-out.

Every mixer, agitator, and reactor model is distinctive and engineered for specific applications. When repairing a mixer seal, Flexaseal evaluates the conditions in which the seal operates. This evaluation ensures we are repairing your seal to your parameters.

Sometimes a failed seal is no longer a candidate for repair. Flexaseal provides straightforward solutions from our comprehensive seal lines or upgraded options designed for your unique operating environment.

The Flexaseal Gulf South location is a fully functional, self-sufficient mechanical seal repair and service facility for  mechanical seals. Our Southern U.S. shop - located between Baton Rouge and New Orleans in Gonzales, LA - is  a  brand new 5,000 square foot, state-of-the-art facility ready for your mechanical seal repair and service needs.

Machining Capabilities – Our Gulf Coast technicians have extensive knowledge and machining experience. These skills enable the team to quickly and efficiently process seal repairs, getting your equipment back into operation with minimal interruption.

Stocking Location – The Gonzales store front has a range of Flexaseal sealing products for immediate off-the-shelf delivery. We are also an assembly and stocking location forseal support systems including barrier fluid reservoirs.

The scope of our mechanical seal product range far exceeds any other seal manufacturer. From small elastomer bellows seals used in millions of domestic water pumps to double mechanical seals that ensure maximum sealing safety and large, highly customized dry-running gas seals for mission critical high speed turbo compressors, John Crane has the right product for any application.

Our world-class rotating equipment technologies, paired with an unmatched breadth of applied engineering expertise, meet virtually all international standards including API 682 and help plants reduce maintenance costs, slash down time and improve reliability. When it comes to keeping your rotational equipment running 24/7, John Crane’s comprehensive range of mechanical seals and systems has you covered.

A range of seals for mission-critical applications, designed to solve the application-specific challenges of each industry. From API 682 compliance for the oil and gas industries, using gas seal technology on our innovative pump gas seals to eliminate fugitive emissions, dealing with slurry in the mining and minerals processing industries, to the difficulties associated with maintenance on large pumps and rotating equipment — we have a solution.

Dry-running, non-contacting gas seals have been the industry standard since the early 1980s for turbomachinery. John Crane gas seals, separation seals and support, monitoring, control and conditioning systems — the heart of any reliable sealing solution — are constantly evolving to meet the needs of customers. The product portfolio is supported by unrivaled global service capability providing repair, retrofit, gas seal storage and reliability expertise, delivering total solutions throughout the product lifecycle.

In industries like chemical, pharmaceutical, pulp and paper, and food and beverage, safeguarding and compliance with industry standards, avoiding contamination and efficiency are always top priorities. Our range of vessel and agitator seals optimize equipment performance, maintain product purity and conform to industry regulations, no matter where you are.

Our range of mechanical seals, packing and bearing isolators combines advanced, thoroughly proven technologies with extensive industry expertise to create a range of products characterized by innovative design concepts and outstanding manufacturing quality. Tried, tested and effective solutions for virtually any application that deliver robust performance, reduced installation times and lower maintenance costs.

Create the optimum operating environment that will ensure outstanding seal performance and reliability. Our comprehensive range of engineered pressure reservoirs, gas seal control panels, heat exchangers and abrasive separators can be combined to produce the perfect seal support system for any application.

Designed to overcome rigorous challenges, our comprehensive suite of seal face technologies combat limited seal face lubrication that adversely affects reliability, cost and durability. Our engineers designed these face treatments to extend rotating equipment life through advanced micro machined patterns and features improving seal face lubrication that optimizes equipment performance. We deliver the right face technology for the right application.

We specialize in hard-to-find seals and demanding applications. Our extensive network of resources enables us to locate the right manufacturer and part, every time.

At All Seals we know down time is not an option. We specialize in hard-to-find seals and demanding applications. With over 40 years of experience in supplying quality replacement mechanical seals, we can help you identify the seal you need and solve your sealing problem. Our technical staff is available to help you – just give us a call. Our comprehensive stock of components ensures that we can build almost any seal combination for same day shipment. Whether you need a new seal or you have a seal to be repaired, we welcome the opportunity to help you with your rotary sealing needs.

We carry a comprehensive inventory of mechanical seal components, which allows us to build the right seal for your application. We’ll even design custom seals for one-of-a-kind applications.

Need hard faces or specialty elastomers? Give us a call. We can quickly build a repair kit to withstand any medium being pumped. You’ll find All Seals’ pump repair kits an invaluable part of your operation.

repair kits keep your Scot Pump in prime condition. Choose a replacement seal or contact us for help finding the right part for your pump. Our Scot Pump product specialists will help you get the right seal at the right price.

We stock mechanical seals and seal kits for all scot pump models. If you need help identifying the seal you need just get in touch and we’re happy to assist.

Mechanical seals are made using both flexible and rigid elements. The combination of materials maintains contact to create a seal at their interface, while allowing the rotating shaft to pass through. A spring or other device is both hydraulically and mechanically loaded to maintain the seal.

1400 series are glass filled PTFE piston seals with a rubber energizer. Designed for low friction and high strength in a double-acting seal. It can withstand a temperature range of -40 to +220 F, a presure range of 0 to 5,000 psi, with a speed of 12 ft/second.

Magnetic seals are used when axial space is limited to <.500" and operating conditions and customer requirements are beyond elastomeric or polymer seal capabilities. Our magnetic seals have two components: the seal head assembly and the magnetic mating ring. These two components create a magnetic attraction, which eliminates the need for a spring and other items needed in face seal designs. This allows for our seals to be used in a variety of applications that have limited space requirements.

For rotating shaft equipment and machinery that include large pumps, seal maintenance can be a time-consuming and expensive proposition. That was the case at one Midwestern power plant, where installing and maintaining the cartridge seals on its six large, recirculating service pumps were a regular ordeal.

Repairing or replacing one of its cartridge seals was a process that involved disassembling the pump, removing and replacing the seal and rebuilding the pump—which required 240 man-hours throughout multiple days. The plant usually performed seal maintenance at least once per year on these large pumps, so the labor hours and costs added up quickly.

Each time the plant performed its cartridge seal maintenance, it relied on a backup pump while the regular pump and its associated system were down. The plant provides essential electricity to the surrounding area, including fire stations, hospitals, retirement communities and the general economy as a whole. If the backup pump experienced any problems, the results could be catastrophic.

The power plant’s seal maintenance issues are familiar to maintenance personnel and operators in many other process industries. Long periods of downtime for maintenance can eat into production time and profits.

According to U.S. Department of Labor statistics from December 2011, the utility industry pays $57 per hour on average to its workers, including wages and benefits. Based on that figure, the power plant spent more than $13,000 in labor costs alone to maintain one seal. That figure also does not take into account the cost of the new seal and any related pump parts or materials that were needed.

While some industries shut down production to replace a seal on a pump, shutting down is not an option for power plants or other essential service providers. These providers often rely on backup equipment during maintenance, making quick up-time for their regular equipment particularly critical. A problem with a backup pump can result in the loss of key services, fines from governmental agencies and millions in lost revenue.

Anxious to reduce its maintenance time and costs, the power plant operators decided to replace the cartridge seal on one of its large pumps with a fully-split mechanical seal. Unlike conventional non-split, cartridge seals, split seals can be installed without dismantling the equipment that they are sealing. This makes them a good choice for hard-to-disassemble equipment, time-sensitive services or critical systems.

When selecting a split design seal, operators must follow the same selection criteria as for a non-split design, paying close attention to all operating conditions. As with non-split mechanical seals, a variety of designs are available to meet the needs of a number of particular applications. In this particular situation, the plant chose a split seal that was designed specifically for heavy-duty horizontal or vertical rotating shaft equipment and pumps that are challenging to maintain.

The seal could handle large shaft deflections, high vibration levels and even major misalignment. The selected design also featured a minimal number of components and no springs or O-rings, which streamlined the installation process further and helped prevent installation errors.

The plant’s maintenance personnel spent between eight and 10 man-hours on the initial installation of the split seal on the 10-foot-high pump, which was nearly 25 times fewer man-hours than the previous cartridge seal’s maintenance turnaround. The split seal installation involved the one-time removal of the original, non-split cartridge seal; installing a special hardware adapter to which the split seal mounts; and mounting the seal outside the pump’s sealing chamber. This installation location allowed for the easy access and visibility of all the split seal parts. Upon completion, any future seal maintenance required just one to two man-hours each time to inspect or replace any necessary components.

While split seals require less installation and maintenance time than non-split cartridge seals, the two types are virtually identical in performance. Split seals can withstand similar pressures, temperatures and shaft speeds as non-split seals and operate just as well.

The power plant installed its split seal on a pump recirculating limestone slurry, but split seals also perform well in other challenging sealing services. Based on their needs, operators in a wide variety of process industries can choose from split seals designed to handle wet-running services, such as:

After a few weeks of problem-free operation, the power plant was sold on the split seal’s performance. The plant is now researching the conversion to cartridge seals on its other pumps to split seals.

In many cases, Cartridge Seals may contain the exact same major items that are sold separately as Component Seals. These pieces include the Rotary Seal and Stationary Face as well as other minor parts like O-rings or Gaskets all required at assembly. The advantage of using a Cartridge Seal is that the time required for installation, and even more importantly, the possibility of error during installation is dramatically reduced. When installing a Cartridge Seal, the necessity of having to measure internal components positioning on the shaft to achieve proper face loading is eliminated. Cartridge Seals come pre-assembled from the factory with all internal components assembled with proper face loading and all pieces in place, exactly where they should be. Cartridge Seals eliminate the need to handle delicate, polished parts such as Seal Faces that can be compromised by the presence of dirt, smudges and oils that can result from handling during assembly. So, for the easiest and most reliable Seal installation, Cartridge Seals go a long way towards helping you achieve trouble free startup and extended service life from your equipment.

Structural Features: single end, unbalanced, dependent direction of rotation, rubber bellow, bellow transmission. This component has a compact structure with good compatibility and easy installation. The bellow can provide support against the pressure to eliminate indentation and corrugation. The bellow and the spring provide pressure compensation to the seal faces. The rubber bellow design prevents possible radial run-out so that the floatability of the rotary ring is increased.

This mechanical seal is also known as KSB Part No. 433 mechanical seal. Many other pump manufacturers such as WILO are also using the same type of mechanical seal as their standard sealing solutions.

Our company excels in offering Mechanical Pump Seals to the clients. These products are widely admired by clients for excellent finishing, resistance to corrosion,read more...
