DESCRIPTIONPOWER END COMPLETE, Less Intermediate Rodscomposed of:WIPER, Intermediate Rod (JM-16203-H)FITITNG, Alemite 1/8 No. 1610-BRETAINER, Intermediate Rod WiperGASKET, Intermediate Rod Wiper RetainerPLATE, Crosshead Oil Reservoir CoverSCREW, 1/2" x 1 Hex Head Cap:For Crosshead Oil Reservoir Cover PlateFor Power End Top CoverFor Power End Rear CoverGasket, for Crosshead Oil Reservoir CoverGasket, for Power End Top CoverGasket, for Power End Rear CoverCAP, Breather Donaldson No. S-183ROD, Complete Connecting, LESS Crank End BushingComposed of:ROD, Only, Includes:BUSHING, Bronze Crosshead End (Service)BOLT, Drilled Head Connecting RodPIN, 3/8 x 1/2" Dowel (For Crank End Bushing)BUSHING, Aluminum Crank End Connecting RodTROUGH, OilSCREW, 1/2" x 1 Hex Head Cap Oil TroughWASHER, 1/2" Regular Spring Oil TroughPLATE, Power End Top CoverFRAME ONLYPLATE, Power End Rear Cover (JWS)GAUGE, Dipstick OilPLUG, 1 Std. PipePIN, 1/8 x 1 Spring Roll (Snap Rings)PIN, Crosshead Includes:SCREW, 1/4" x 1/2" Socket Head Cone Pt. SetCROSSHEADPIN, Spring SlotBOLT, Intermediate Rod Hook Includes:NUT, 1/2" ESNAWASHER, 1/2" Stat-O-SealCRANKSHAFT ONLYEXCLUDER, DirtRETAINER, Crankshaft Bearing (Cage Side) Belt or Direct DriveRETAINER, Crankshaft Bearing (Cage Side) Gear Reducer DriveSCREW, 5/8: x 1 Drilled Head Cap:For Main Bearing CageFor Crankshaft Bearing RetainersGASKET, Crankshaft Bearing Retainer (Cage Side)CAGE, Main BearingGASKET, Main Bearing CageBEARING, Crankshaft Main RollerRING, Center Bearing Crankshaft SnapRING, Center Bearing Frame SnapBEARING, Crankshaft Center RollerPIN, 3/16 x 1/2" Spring RollSPROCKET, 60T 1/2" Pitch SingleGASKET, Crankshaft Brg. Retainer (Opp. Cage Side)RETAINER, Crankshaft Brg. (Opp. Cage Side)WASHER, Timken No. TW-126 LockNUT, Timken No. Tan-26 LockPIPING, Low Speed Lubrication (See Page 4)PLUG, 1 Std. Pipe

DESCRIPTIONPIPING, LOW SPEED LUBRICATION, Composed of:PUMP, #1S-B&S #713-10-2WASHER, 3/8 Spring LockPIPE, Power End LubricationPIN, 1/4" x 1 CotterWASHER, 3/8 W Type A-1.000 O.D.SPRING, Ball ValveRETAINER, SpringBALL, ValveCONNECTOR, #68 x 3 (1/8 Pipe x 3/16 Tube)TUBING, 3/16 Copper (6-0)CLAMP, 1 Std. PipeSCREW, 1/4" x 1/2" Hex Head CapELBOW, #1469 x 8K (3/8 Pipe x 1/2" Tube)BUSHING, 1/2" x 3/8 Std. PipeTUBING, 1/2" Synflex (4-0)CONNECTOR, #1468 x 8K (3/8 Pipe x 1/2" Tube)ADAPTER, Gauge ConnectionPLUG, 3/8 Sq. Hd. Solid PipeCHAIN, 1/2 Single 76 Pitches RC-40LINK, Connecting 1/2 Single RC-40SUPPORT, Pump MountingSCREW, 1/2" x 1 Hex Hd. CapWASHER, 1/2" Spring LockWASHER, 1/2 W Type A-1.375 O.D.SPROCKET, 13T Pitch SingleSCREW, #10-24 x 3/8 Cup Point SetKEY, 1/8 x 1/8 x 5/8 Rd. One EndSCREW, 3/8 x 1 Hex Hd. Cap

DESCRIPTIONRod, Clamp Type IntermediateRod, Threaded IntermediateClamp Cpt., - Plunger Intermediate Rod (340-019),Composed of:Clamp, Plunger Bolt HalfClamp, Plunger Threaded HalfScrew, 1/2" x 3 CapWasher, Spring Lock Type 304 S.S.Plate, Rubber Baffle (Intermediate Rod)Nut, 1-3/8 Heavy Hex-Fluid Cylinder to FrameNut, 1-3/8 Special Aluminum Bronze Acorn (Opt.)Cylinder Only, Fluid Forged Steel, Composed of:Stud, 1-3/8 x 7 Fluid Cyl. to FrameCover, Threaded Top and FrontPlate, Top and Front CoverSeal, Top and Front Cover PlateRetainer, Discharge SpringScrew, 1/2" x 1 CapWasher, 1/2" Reg. Spring LockSeat Only, Discharge Includes:O-Ring, Discharge SeatValve Complete, Suction & Discharge Includes:Body, ValveDisc, Valve PolyurethaneDisc, Valve Hycar (Optional)Retainer, Valve DiscScrew, 3/4" x 1 CapWasher, 3/4" Heavy External ToothSpring, Suction and Discharge ValveBracket, Suction Valve SpringScrew, 1/2" x 1 CapWasher, 1/2" Reg. Spring LockSeat Only, Suction Valve Includes:O-Ring, Suction SeatManifold, SuctionGasket, Suction ManifoldScrew, 3/4" x 2 CapWasher, 3/4"Reg. Spring LockRing, BX-152 Type S-304Screw, 3/4" x 3 Cap Grade 5 Discharge FlangeWrench, Valve Cover, OPTIONAL FLANGE:Flange, 2-1/16 API-10,000# Ring Joint Discharge

WELL SERVICE PUMPJWS-340 PARTS LISTPART NO.179004564661271680008368000621717344240404824040197811071781107217101251713021702720817131111713112G-171761547125307200020740042078040801717498

National Oilwell Varco is a leadingmanufacturer of reciprocating plungerpumps, Mission Fluid King centrifugalpumps, and fluid end replacement parts.We also offer a complete set of solutions toyour fluid transfer challenges. For moreInformation, contact National Oilwell Varcodirectly at the Headquarters in Houston,Texas. All National Oilwell Varco productsare available throughout the U.S. andaround the world from service centers,authorized distributors, andrepresentatives.

Used National JWS-340 triplex well service mud pump, 4" metal plungers x 5" stroke, steel fluid end, chain case, Plunger lubricator, Rated maximum input 340 HP at 450 RPM, Fluid end pressure tested to 15,000 PSI

Rig pump output, normally in volume per stroke, of mud pumps on the rig is  one of important figures that we really need to know because we will use pump out put figures to calculate many parameters such as bottom up strokes,  wash out depth, tracking drilling fluid, etc. In this post, you will learn how to calculate pump out put for triplex pump and duplex pump in bothOilfield and Metric Unit.

2 MISSION Products Mission Products offers a comprehensive range of pumping systems, fluid end expendables, pressure control systems, flowline equipment, and wellheads with worldwide support and service. Mission combines these products into drilling and well service solutions backed by decades of experience in the oil and gas industry.

3 TABLE OF CONTENTS Drilling and Well Service Solutions ii-01 Centrifugal Pumps 02 Fluid End Expendables and Fluid End Modules BLAK-JAK Equipment 05 Reset Relief Valves 06 Gate Valves 07 Manifolds 08 ANSON Flowline Equipment ANSON Flowheads 13 Pressure Gauges and Float Valves 14 Custom Dies and Inserts 15 Well Service Pumps 16 Well Service Pump Expendables 17 Frac Manifold Trailer 18 SAFE Container and Trailer 19

4 MISSION PRODUCTS Drilling Solutions Centrifugal Pumps 1-1/8 Type S (1x1-1/2 to 3x4) 1-7/8 Type W (2x3 to 6x8) 2-1/ SUPREME (3x2 to 10x8) 2-1/2 MAGNUM (3x2 to 10x8) Horizontal Close Coupled MAGNUM (4x3-10x8) MAGNUM XP (8x6x18, 12x10x23, 14x12x22) SPACESAVER Close Coupled (1x1-1/2 to 3x4) SUPREME SHEAR Solids Shear Pump TURBOSHEAR Polymer/Clay Shear Pump (6x5, 8x6) Vertical Close Coupled MAGNUM (4x3 to 10x8) Vortex Pumps (3x3, 4x4, 6x6) Fluid End Expendables Crosshead Extension Rods (Pony Rods) Gland Bushings and Junk Rings Piston Rod Clamps Seats Springs Valve Inserts Gaskets Liners Ceramic Liner Chrome Iron Sleeved Hardened Steel Packing Pistons BLUE LIGHTNING FLEXLIP GREEN DUO SUPREME Slip Seal BULLITT WHITE LIGHTNING Bonded Piston Rods BLAK-JAK HYDRA-LIGN Rod System OEM Pullers/Tools Valves Bonded Crossarm Style Full Open ROUGHNECK and ROUGHNECK HP SERVICE MASTER II Fluid End Modules and Accessories Discharge Manifolds Liner Retention Systems BLAK-JAK TORQUE PRO Hammerless, Quick Change Valve Cover Retention Systems Modules MISSION L Style Module - 5,000 and 7,500 PSI MONOBLOCK OEM Style Jewelry Conversion Kits Cylinder Head Caps/Plugs/Rings/Locks Valve Covers/Caps/Rings Wear Plates BLAK-JAK TORQUE PRO LITE Valve Cover Retention System BLAK-JAK TORQUE PRO LITE Strainer Cover Pipe Handling Equipment Accessories OEM for BJ VARCO NOI WOOLLEY M & W Brand Tools Custom Manufactured Dies and Inserts Elevator Balancing Straps Hydraulic Power Units Hydraulic Tongs Slip Inserts - All Makes, Manual and Automatic Tong Dies - All Makes, Manual and Automatic Tong Pullback Straps Complementary Products Air Seal Unions and Tubes Expansion Joints High Pressure Test Units Hoselifters Portable Hydrostatic Test Units ii Ring Joint Gaskets String Swivels Turnback and Wireline Rollers Custom Design and Unitization GPM Centrifugal Pumps Belt Driven Pump Packages Brake/Winch Cooling Systems Brine Filtration Systems Diesel Driven Pump Packages Diesel Fuel Filtration Systems Electric Driven Pump Packages High Pressure Washdown Systems Liner Wash Pumps Oil Filtration Systems Portable/Sanitary Water Pressure Sets Trailer Mounted Packages Electric Motor Options Close Coupled Motor Controls NEMA and IEC Large inventory of Siemens Explosion-Proof Motors Starters Reduced Voltage Explosion Proof Non-Explosion Proof Large inventory of *Sprecher+Schuh Across-the-Line Starters Washpipe and Packing BLAK-JAK Washpipe Cartridge System Solids Control Equipment Mud Guns Mud Hoppers - 4, 6 Dust Collecting Hopper Specialty Custom Investment Castings Thread Compounds API Modified Compounds Drill Collar Compounds Tool Joint Compounds Valves Custom Designs Float Valves Frac Valves Chokes Automatic and Manual Electric Drilling Choke Hydraulic Drilling Choke Pressure Gauges Gate Valves ANSON E-TYPE - API 6A Dual Block Gate Valves - API 6A Mud Gate Valves - 5,000 PSI and 7,000 PSI SHAFFER Types B, HB, DB - API 6A Manifolds Cement Choke and Kill Discharge Diverter Squeeze Standpipe Test Relief Valves ANSON High Pressure Relief Valves Shear Relief Valves TITAN BX Automatic Reset Relief Valve TITAN Type B, C, and RX Reset Relief Valves * SPRECHER+SCHUH is a trademark of Sprecher+Schuh.

5 Well Service Solutions Centrifugal Pumps 1/ SUPREME (3x2x13 to 10x8x14) 2-1/2 MAGNUM (3x2 to 10x8) Horizontal Close Coupled MAGNUM (4x3 to 10x8) MAGNUM XP (8x6x18, 12x10x23, 14x12x22) SANDMASTER (3x2x13 to 10x8x4) Vertical Close Coupled MAGNUM (4x3 to 10x8) High Pressure Test Units Flowline Equipment Cementing and Circulating Hoses Quarter - Turn Valves (see Plug Valves) Relief Valves Swivel Joints Check Valves - API 6A In-line Dart Top Entry Crossovers Flanged Hammer Union Hub Threaded Elbows Forged Hammer Union Manifold Welded Fittings Block Flanged Hammer Union Manifold - forged and cast, up to 10,000 PSI Studded - API 6A Threaded Hammer Lug Unions Butt Weld - up to 20,000 PSI CWP Sour Gas - up to 15,000 PSI CWP Threaded - up to 15,000 PSI CWP Custom Design Plug Valves - up to 15,000 PSI and Sour Gas Compact DB Premier Pup Joints Forged - up to 20,000 PSI NPST - up to 15,000 PSI Threaded - up to 15,000 PSI Welded - up to 15,000 PSI Reciprocating Pumps and Expendables D-750L JWS-185 JWS-340 JWS-400 WS-600 WS-600-SA WS-2250 WS-2400 WS-2500 Fluid End WS-2600 SERVICE MASTER II Well Servicing Valves ROUGHNECK Well Servicing Valves Valves Cage Chokes - High Pressure Frac Valves Pressure Gauges Quarter - Turn Valves (see Plug Valves) Check Valves - API 6A In-line Dart Top Entry Gate Valves ANSON E-TYPE - API 6A Dual Block Gate Valves - API 6A Mud Gate Valves - up to 7,500 PSI SHAFFER Types B, HB, DB - API 6A Plug Valves - up to 15,000 PSI and Sour Gas Compact DB Premier Surface Test Trees up to 15,000 PSI Solid Block Configuration Module Block Configuration Inverted WYE Configuration 01 mission@nov.com

6 MISSION PRODUCTS Centrifugal Pumps The MISSION centrifugal pump line has proven to be the best centrifugal design for handling abrasive mud. This pump line offers a broad selection of innovative features for a variety of routine, demanding, abrasive and corrosive applications. These pumps are designed for a wide range of flow rates, from a few gallons per minute to thousands of gallons per minute. MISSION Centrifugal Pump Offerings MAGNUM 2500 SUPREME SANDMASTER MAGNUM XP MAGNUM VORTEX Shear pumps Close coupled centrifugal pumps 1180 Type S 1780 Type W Vertical Close Coupled MAGNUM (4x3 to 10x8) Versatile drive and mounting options Unitization services and options compliment the centrifugal pump line. MISSION centrifugal pumps are available as horizontal electric, vertical electric, close coupled electric, horizontal diesel, overhead belt, side belt and hydraulic driven pumping units. MAGNUM Direct Connect 2500 SUPREME MAGNUM Belt-Driven MAGNUM 02

7 Fluid End Expendables and Fluid End Modules Mission manufactures fluid end expendables for all pump manufactures. All fluid end expendables are manufactured from high quality materials to provide extended run times and longer service life. Piston Rods Clamp Assembly Bushing X-TRACTOR Self Aligning Rod With Dual Cooling Tubes BLUE LIGHTNING Piston ROUGHNECK Family Short Stem SUPREME Liner Pistons BLUE LIGHTNING FLEXLIP GREEN DUO SUPREME Slip Seal BULLITT WHITE LIGHTNING Crosshead Extension Rods (Pony Rods) Gland Bushings and Junk Rings Piston Rod Clamps Seats Springs Valve Inserts Piston Rods BLAK-JAK HYDRA-LIGN Rod System Self-Aligning OEM Gaskets Cylinder Head High Temperature Polyurethane Liner OEM Polyurethane Valve Cover Wear Plate Pullers/Tools Bushing X-TRACTOR Liner Bushing Puller (P Series Pumps) Liner Pullers Piston Rod Nut Wrenches Seat Pullers Liners Ceramic Liner Chrome Iron Sleeved Hardened Steel Valves Bonded Crossarm Style Full Open ROUGHNECK and ROUGHNECK HP Well Service - SERVICE MASTER II Packing Rod (Duplex) Pony Rod Well Service Plungers Modules MISSION L Style Module - 5,000 and 7,500 PSI MONOBLOCK OEM Style Well Service Packing 03 m i s s i o n o v. c o m

8 MISSION PRODUCTS Fluid End Expendables and Fluid End Modules Ceramic Liner MISSION ceramic liners offer longer run times, lower operating costs and reduced risk exposure when compared to operating with chrome iron liners. The ceramic sleeve material is manufactured from alumina oxide, known for its wear resistance, and has proven run times in all types of operating conditions. The outer hull material for large bore liners is manufactured from alloy steel to increase yield strength and aid in fatigue resistance. MISSION ceramic liners are corrosion resistant and have a smoother surface finish for reduced friction and heat. Combining these features, the extensive history of NOV in ceramics, and proprietary pump technology, results in a liner unmatched by any other in the industry. MISSION ceramic liners are field proven as the longest running liner ever manufactured. MISSION L 7500 Module The MISSION L 7500 modules are designed as an upgrade solution for existing mud pumps equipped with 5000 psi fluid ends. They can also be specified as original equipment for certain new NOV mud pumps and as original equipment on new pumps from other manufacturers. These modules create added value by increasing the operating range of existing mud pumps and by reducing maintenance and pump down time. Added features can include the BLAK-JAK liner retention system, MISSION ceramic liners, and ROUGHNECK valves and seats. The MISSION L 7500 modules are available for specific NATIONAL, OILWELL, CONTINENTAL EMSCO and IDECO brand pumps. WHITE LIGHTNING Bonded Piston The MISSION WHITE LIGHTNING bonded piston is manufactured from a highly engineered elastomeric compound that provides high resistance to water, oil and synthetic based drilling fluids. The compound provides superior resistance to tear, abrasion and extrusion and is capable of operating in fluid temperatures up to 230 F (110 C). BLUE LIGHTNING Piston The MISSION BLUE LIGHTNING piston is a super premium bonded polyurethane piston designed for operating in all drilling environments. It is manufactured for an engineered elastomeric compound that delivers excellent resistance to tear, abrasion and extrusion while maintaining high mechanical properties. The BLUE LIGHTNING piston is capable of operating in fluid temperatures up to 220 F ( C) 04

9 BLAK-JAK Equipment BLAK-JAK HYDRA-LIGN Rod System The MISSION BLAK-JAK HYDRA-LIGN rod assembly is designed to reduce operational risk exposure and improve risk environments during change-outs of high use fluid expendable parts. Additional value to operators and contractors is realized through design features that allow self-aligning capabilities between the pump liner and piston. Run times of expendables will be positively affected and pump down time reduced. BLAK-JAK Liner Retention System mounted in a pump Only 1 person required for liner change-out 33% lighter than OEM BLAK-JAK Liner Retention System The MISSION BLAK-JAK liner retention system provides a simple, compact design with easy installation and reduced weight for easier operation. There is only one HYDRA-CEL (hydraulic, tension device) to maintain rather than individual hydraulic assemblies. The redesigned LOK-CEL (tensioned, mechanical device) body and locking nut assemblies are designed in conjunction with National Oilwell Varco liner and fluid end technology. These mechanical designs are simple, rugged, and effective. The BLAK-JAK is available for specific NATIONAL, OILWELL, CONTINENTAL EMSCO, and *Gardner Denver pumps. LOK-CEL mechanically retains the liner while the pump is in operation. HYDRA-CEL places the LOK-CEL in tension while simultaneously placing the liner in compression. Hammerless Valve Cover Retention System Installed 1. Valve Cap Lug Adapter 2. Stop Locator BLAK-JAK Washpipe Cartridge System Designed for speed and efficiency, the MISSION BLAK-JAK washpipe cartridge system is a self contained unit designed to be repacked on the rig floor, not at the swivel. Once the assembly has been repacked, the single cartridge can be installed quickly in the swivel just by tightening the nuts to the gooseneck. A spanner bar is utilized to tighten the nuts, eliminating the use of hammers. Quick change cartridge system 25% lighter than competing designs for ease of maneuverability Cartridge assembly and disassembly is simple and quick Utilizes standard packing and washpipe, with optional high temperature resistant packing available BLAK-JAK Washpipe Cartridge System BLAK-JAK TORQUE PRO Wrench BLAK-JAK TORQUE PRO Hammerless Valve Cover Retention System The MISSION BLAK-JAK TORQUE PRO valve cover retention system utilizes a hydraulic wrench to tighten and loosen the valve cap retainer and then requires only a quarter turn to remove the retainer. This quick and easy valve access allows for faster change-outs and improved safety by eliminating the need for hammers. This system works with OEM valve covers as well as MISSION L style plugs. No modification to the fluid end is required. * GARDNER DENVER is a trademark of Gardner Denver, Inc mission@nov.com

10 MISSION PRODUCTS Reset Relief Valves MISSION TITAN Class reset relief valves encompass the best standalone, mechanically operated reset relief valves on the market today. The TITAN Class includes: TITAN Class 3-inch B TITAN Class C and CH TITAN RX TITAN BX TITAN BX Automatic Reset Relief Valve The MISSION TITAN BX reset relief valve is the only air-operated, fully automatic reset relief valve on the market that fails open. When pump pressure exceeds set pressure, the MISSION TITAN BX reset relief valve automatically opens through an electronic system. After a time delay pre-selected by the operator, the valve will automatically close using instrument air pressure, eliminating the need for manual reset. In the event that the rig loses power, air, or mud pressure, the valve will automatically open. The unit is ISO 9001:2000 and ABS type approved. TITAN BX Automatic Reset Relief Valve The MISSION TITAN BX automatic reset relief valve system consists of 1-6 valves, one pilot valve box per valve, one mud cup transducer per valve, and one control panel for the entire system. Mud Cup Transducer Control Panel TITAN RX The TITAN RX reset relief valve automatically snaps to a full open position when the set pressure is reached. In addition, this relief valve comes equipped with a position release button that indicates, at a glance, whether the value is open or closed. Titan RX Reset Relief Valve 06

11 Gate Valves ANSON E-TYPE Gate Valves ANSON E-TYPE through conduit gate valves have been developed to satisfy the need for a high quality, high specification valve which is reliable and reasonably priced. The E-TYPE gate valve makes full use of modern materials and manufacturing techniques. The valve is robust, easy to maintain, and conforms to international design requirements and quality assurance programs. The E-TYPE gate valve is a monogrammable API 6A valve. ANSON Actuated Gate Valves The ANSON E-TYPE gate valve is available with hydraulic actuation. Valves can be supplied with spring return fail-safe, open return failsafe, open (FSO) or closed (FSC), or double acting cylinders (DA). Both types offer a compact design, are fully weather sealed and available with extras such as position indicators, hydraulic power packs and control systems. FS Actuated E-TYPE Gate Valve ANSON Mud Gate Valves ANSON mud valves are solid gate, rising stem, gate valves with resilient seals. They are purpose-made for mud, cement, fracturing and water service. They are easy to operate and simple to maintain. Two ranges are available: MV50 The unit is suitable for a maximum working pressure of 5000 psi. MV75 The unit is suitable for a maximum working pressure of 7500 psi. SHAFFER Gate Valves Type 2300 Manual and hydraulic operated (double acting type c/w manual override) gate valves SHAFFER Type B Manual operated API 6A gate valves SHAFFER Type DB Hydraulic operated API 6A gate valves (double acting type with or without manual override) Through conduit gate valves. Forged steel body and bonnet. Slab gate, floating seats, downstream sealing, bi-directional. Metal to metal sealing body and seat, seat to gate, and bonnet to body. Non-rising stem with back seat. Shear pin protected internals. API 6A Twentieth Edition Available sizes: 2-1/16, 3-1/8 (5K only), 3-1/16, 4-1/16, and ratings: 5,000 psi (5K), 10,000 psi (10K), 15,000 psi (15K) MV75 Mud Valve SHAFFER Type B 07 mission@nov.com

12 MISSION PRODUCTS Manifolds NOV manifold systems are designed and manufactured to customer specifications using only the highest quality materials and standards. The Mission line of ANSON flowline equipment includes API 6A gate valves, mud valves, check valves, and plug valves. These, coupled with the ANSON manifold fittings, flanges, hubs, hammer unions, API blocks and NOV welding capabilities, allow NOV to control the design, quality and scheduling of the most complex manifold projects. NOV manifolds are designed and supplied fully certified in accordance with the recognized oilfield equipment standards. NOV designs and builds the following types of manifolds: Choke and Kill Manifolds Well Test Manifolds Diverter Manifolds Truck Mounted Manifolds Ground Pipe Manifold Cement Manifolds Standpipe Manifold Containerized Manifolds Standpipe Manifolds Gas Gathering Manifolds Mud Tank Manifolds Underbalanced Drilling Manifolds Choke and Kill Manifold 08

20 MISSION PRODUCTS Well Service Pumps MISSION well service pumps are built for today s rugged pumping applications such as fracturing, acidizing and matrix stimulation. MISSION field-proven and time-tested well service pumps are available in triplex and quintuplex designs. Mission manufactures quality and reliability into every well service pump that comes off the production line. MISSION well service pumps offer: Pump availability Global service and support Engineering support Parts availability Proven performance Cutting edge technology JWS-340 The JWS-340 is a 340 horsepower 5 stroke intermittent duty single acting well service piston/plunger pump. It is equipped with a forged alloy steel mono-block fluid end and rated at pump speeds up to 450 RPM and maximum discharge pressures up to 10,000 psi. It can be equipped with multiple external gear reduction units. JWS-400 The JWS-400 is a 400 horsepower 7 stroke intermittent duty single acting well service piston/plunger pump. It is equipped with a segmented forged alloy steel fluid end and rated at pump speeds up to 286 RPM and maximum discharge pressures up to 10,000 psi. It is equipped with 4.667:1 chain reduction drive. WS-600-SA Triplex Plunger Pump Combining a small footprint, 600-input horsepower, and a total weight of 4600 lbs, the WS-600-SA is suitable to a wide range of applications including water blasting, well acidizing, gravel packing, cementing and coiled tubing units. Featuring a high rod load, and alloy steel continuous welded power frame, the WS-600-SA provides durability unmatched by other pumps possessing the same horsepower and footprint. JWS-340 Triplex Piston/Plunger Pump WS-600-SA Triplex Plunger Pump WS-2400 Triplex Plunger Pump The WS-2400 is a 2400 horsepower 8 stroke intermittent duty single acting well service plunger pump. It is equipped with a forged alloy steel mono-block fluid end and rated at pump speeds up to 330 RPM and maximum discharge pressures up to 20,000* psi. This triplex pump can deliver up to 1227 GPM and it is equipped with 6.35:1 gear reduction drive. WS-2600 Quintuplex Plunger Pump The WS-2600 is a 2600 horsepower 8 stroke intermittent duty single acting well service plunger pump. It is equipped with a forged alloy steel mono-block fluid end and rated at pump speeds up to 330 RPM and maximum discharge pressures up to 18,000* psi. This quintuplex pump can deliver up to 1896 GPM and it is equipped with 6.68:1 gear reduction drive. WS-2400 Triplex Plunger Pump Mission also provides replacement fluid ends for well service pumps from most major manufacturers. Fluid End Features Alloy steel mono-block forging Redesigned suction valve configuration with 1 thicker walls around suction valve pot results in longer fluid end life MISSION SERVICE MASTER II valves and seats Log style or Zoomie suction manifold *These ratings are for intermittent service. Applications at pressures above 15,000 psig must be approved by NOV Engineering Department. WS-2600 Quintuplex Plunger Pump 16

21 Well Service Pump Expendables SERVICE MASTER II Well Service Valves and Seats MISSION SERVICE MASTER II well service valves are the industry standard for pumping well fracturing media such as sand and man-made resin-coated sand proppants. The SERVICE MASTER II valve s engineered toughness and integrity gives unparalleled performance in the most punishing conditions such as pumping highstrength ceramic proppants or sintered bauxite at pressures above 15,000 psi. The SERVICE MASTER II well service valve is a full open valve designed for maximum flow characteristics. The SERVICE MASTER II valve with the standard polyurethane insert has a maximum temperature rating of 180 F (82 C), maximum pressure rating of 20,000 psi and is designed for a solids content from low to moderate. MISSION ROUGHNECK Well Service Valves and Seats The ROUGHNECK valve and seat line sets industry standards, meeting the demands of today s hostile pressure pumping environments encountered by well service contractors worldwide. The ROUGHNECK valve with the standard polyurethane insert has a maximum temperature rating of 180 F (82 C), maximum pressure rating of 7,500 psi and is designed for a solids content from low to high. ROUGHNECK valves and seats have an extreme pressure well service valve design, one-piece cast uni-body construction valve body allowing greater flow area, reduced abrasion, and reduced fluid velocity. The one-piece valve body for superior strength results in fewer replacements, longer run times, and reduced cost per pumping hour. SERVICE MASTER II Valves and Seats ROUGHNECK Well Service Valves and Seats MISSION brand service pump expendables are compatible with many popular drilling and well service pump brands including but not limited to: American Block* BJ Hughes (Byron Jackson)* Bomco* Cameron* Chapparell* CONTINENTAL EMSCO Demay(Axon)* Dowell* Drillmec* Dragon* Ellis Williams* Eweco* Failing* Fairbanks Morse* FMC* Gardner Denver* GASO Geoquip* Great American* Halliburton* Hong Hua* IDECO K&T* Load Master* Massarenti* Maxus* MSI* Myers Aplex* NATIONAL NATIONAL OILWELL VARCO OFM* OILWELL OMEGA OPI* Premium Frac* Serva* Shale Pumps* SJ Petro* SKYTOP BREWSTER Soilmec* SPM (Weir)* Texas First Industrial* TFI* TSC* TSM* Tulsa Rig Iron* Upetrom* Weatherford* Western* WHEATLEY Wirth* Worthington* 17 * Each of the trademarks and/or trade names referenced above are used solely for the purpose of indicating that National Oilwell Varco provides well service pump expendables that are compatible with pumps produced under each of the trademarks and/or trade names listed. The trademarks and/or trade names listed above are each owned by their respective owners. For those trademarks and/or trade names owned by third parties, National Oilwell Varco, L.P. is not affiliated with those third parties or their affiliates and those third parties do not endorse any of the National Oilwell Varco, L.P. expendables. mission@nov.com

22 MISSION PRODUCTS Frac Manifold Trailer The MISSION frac manifold trailer, 15K psi working pressure, is suitable for operating eight frac pumps (as a standard offering). Its high strength trailer and fifth wheel connect provide for mobility and frac site accessibility. The MISSION frac manifold trailer is equipped with certified ANSON equipment and is designed for today s extreme well servicing environment. With ease of customization, an option of six to twelve trucks operating and trailer sizes available in 36 ft or 45 ft (as a standard offering), the MISSION frac trailer is built to meet customer fracturing and well servicing requirements. Features and Benefits Easily customizable High quality parts with certification Ease of accessibility No extra equipment needed Market leading delivery times Double axle available Battery for powering the hydraulic lift without the assistance of a semi-truck (self-contained unit, no extra power supplies needed) LED tail lights standard Incandescent lights available upon request 8 frac pumps as a standard offering, 10 and 12 place options available Trailer sizes 36 and 45, other sizes on request Photo courtesy of ProPetro 18
