Centerline Manufacturing is committed to the highest level of customer service quality.  Every Centerline pump is comprehensively and repeatedly tested at diverse pressure levels to assure that it goes to our customer in perfect operational order. Centerline technicians work to ensure that our customers fully understand the operation of the model being delivered.  If a customer"s pump is down, we understand the importance of timely response and parts availability.  Centerline technicians will assess the problem and make repairs to bring the pump back into new specification. The Centerline mud pump technicians are well versed and qualified to operate and repair any product that is provided to the customer.

W-440/446 Pump can be widely used in all kinds of works in the oil field. When the cylinder liner specification is 6""-3 1/2"", piston structure is recommended and it is suitable for Oil-Well Repair and shallow-well drilling, etc. When the cylinder liner specification is 3 1/4""-2"", axial piston structure is recommended and it is suitable for high-pressure work.

Rated input power 328KW (440HP) Rated Stroke 320 Stroke/Minute(320SPM) Stroke 152.4mm (6"") Gear Ratio 4.578: 1 Max. operation pressure 35Mpa Valve chamber Valve-Over API 4# Max. liner dia. 6"" Max. liner mud pressure(160 stroke/minute)16.9Mpa Dia. of suction manifold, 6""(150#) Flange Dia. of discharge manifold 3""(900#) Flange Dia. pinion shaft 95.25 mm(3.75"") Key 22.174x15.9mm Dimension:(No included base), 2479X1219X1103 mm

ISO 9002 certified distributor of a wide range of pumps & related process equipment including: diaphragm, progressive cavity, Leakproof canned motor centrifugal, Hastelloy C process centrifugal, corrosion resistant gear, epoxy, internal gear, Hydra-cell high pressure diaphragm, centrifugal, Iwaki centrifugal, modular drum and container, centrifugal, side channel & vertical inline, centrifugal & multi-stage centrifugal. Custom manufacturer of fiberglass sump & spill-stop pumps. Services include pump repair, re-building industrial mechanical equipment to factory standards & dynamic balancing. UL certified for rebuilding Class I, Group C & D, Division I, XP equipment. Factory authorized service for most products.
