NOV 12-P-160 Mud Pump is rated at 1600 input horsepower (1193 kw) at 120 strokes per minute, with a 12-inch (304.8 mm) stroke. Multiple liner sizes allow pressures and volumes to handle circulation requirements in deep drilling applications.

Flexibility: Compact engineering provides higher efficiency in less space. The NOV 12-P-160 Triplex Mud Pump light weight and flexible design make it easily adaptable to a variety of rig configurations. This provides flexibility as drilling requirements and conditions change.

Fluid End Modules: NOV offers a choice of fluid end modules and valve covers for every P Series pump model to select the fluid end module that exactly matches drilling requirements. All pump models can be equipped with either the standard or premium forged, two-piece interchangeable fluid modules

Lake Petro provides high quality Mud Pump Parts including Mud Pump Liners, Mud Pump Fluid End Module, piston, Valve and Seat etc. With more than 10 years of experience in the oil and gas industry, we are dedicated to help and support our loyal clients with the most cost-effective and quality Liners and Pistons. We also provide mud pump price and mud pump for sale.

We offer Liners with Ceramic (Zirconia and Aluminium oxide) and Steel (Metal and Bi-metal) materials for all common brands of the mud pump and triplex mud pump.

Bi-metal liners (double metal liners) are made of forged steel shell and wear-resistant sleeve of high chromium iron. In the production process, the size accuracy should be strictly controlled, which can ensure that they can be easily and stably installed. The inner sleeve with high finish and hardness is wear-resistant, corrosion-resistant and has a long service life. The bi-metal liners are suitable for a lot of bad working conditions. Its service life is more than 800 hours.

Ceramic Liners are made of a ceramic inner sleeve and a forged steel outer shell. The service life of ceramic liners is about 4000 to 10000 hours, the minimum time is at least 2000 hours, which is a lot more than bi-metal liners. Because of the phase transformation toughen technology, the ceramic liners have the features of wear-resistance, erosion-resistance, high-pressure-resistance, high hardness and strength. Zirconia type and Alumina type are common type of ceramic sleeve. Compared with Alumina type, Zirconia type liners have better toughness properties and a much longer service life. Piston wear and water consumption for lubrication can be reduced as well.

Seal Rings for Liner packing are also important. Liner Seal Rings is designed and made with hard corner which is an integral part of seal rings and soft nitrile element rubber center. We could provide reliable liner Seal Rings for our customers could order them at the same time.

All Lake Petro liner products are interchangeable with O.E.M. products. Meanwhile, we provide customized Liners according to drawings. Our liners, also with our other mud pump spares, are supplied for use in Honghua, F-Series, Bomco, Emsco and National lines of triplex drilling pumps. Let Lake Petro be your one-stop shop for your whole fleet of pumps. Please refer to “Suitable Pump Models” Lable for more details.

14-P-220 Triplex Mud Pump Specifications LINER SIZE (INCHES) 9 8 7½ 7 6½ 6 5½ 5 MAX DISCH. PRESSURE, PSI OF 14-P-220 WITH HIGH PRESSURE FLUID END 2795 3535 4025 4615 5360 6285 7475 7500 SPEED (SPM) INPUT (HP) **HYD (HP) GALLONS PER MINUTE *105 *2200 1980 1215 960 843 735 633 540 454 375 80 1676 1509 925 731 643 560 483 411 346 286 60 1257 1131 694 548 482 420 362 308 259 214 40 838 754 462 366 321 280 241 206 173 143 VOLUME/STROKE (GALLONS) 11.57 9.14 8.03 7 6.03 5.14 4.32 3.57

TECHNICAL SPECIFICATIONS:Rated input at 105 SPM ..........................2200 HPSingle acting Triplex, rated ......................105 SPMStroke .............................................................14"Gear ratio ....................................................3.969Pinion speed ..........................................417 RPMHydro. Test Pressure14-P-220 ............................................10,000 PSI14-P-220 withHigh Pressure Fluid End .......................11,250 PSI

10000 Richmond AvenueHouston, Texas 77042 NATIONAL OILWELL VARCOUnited StatesPhone: 713 346 7500Fax: 713 435 219514-P-220 Triplex Mud Pump

10000 Richmond AvenueHouston, Texas 77042 NATIONAL OILWELL VARCOUnited States © 2006 National Oilwell VarcoPhone: 713 346 7500 PP010000734 Rev. 02

? Its compact structure, lighter weight, and small size with high efficiency can be matched with kinds of pump devices according to drilling rig’s requirement and different conditions.

? Its durable fluid end has greatly improved triplex pump’s function and capacity, what’s more, its independent design is easy to inspect and convenient to maintenances.

W-440 Well Service Pump is a continuous duty 6" stroke high performance triplex. This pump is an Ellis Williams Style (EWS) design. The W-440HP is rated to 5,000 PSI, with 3-1/2" Piston/Liners, with a maximum output of 5.3 BPM. Our W-446 is a 3K pump and can accommodate from 3" liners/pistons to 6" liners/pistons. W-446 can turn out 15 BPM with 6" liners at 1027PSI.

Our 500 horsepower TT-660 pump package offers up to 720 GPM normal pumping volumes. This is one of our best selling pumps for HDD applications, because it offers high volumes at relatively low pressures. It can produce pressures required to run a mud motor and the volume to clean the hole, while running the largest of hole openers. It features a smaller footprint and lighter weight than competing models, making it completely legal load size and weight in most instances. The standard TT-660 skidded package weighs in at a mere 26,000 lbs. Available as a bare pump, with chain box, or a complete skidded package.
