Here are pictures of the two (2) Mud Pump Gauges 1 – 1,000 PSI NDS Drilling Supply, Inc. stocks.  The Gauge on the left is full-faced with a diameter of 6 inches.  The Gauge on the right is a parking meter style with a face diameter of 3.5 inches for placement close to the back of the rig.

RIGCHINA Stand Pipe Gauges provide a quick, accurate display of pump pressure. Main applications are for standpipes and to be mounted on mud pumps. This style of gauge has been in service for many years and has proven to be a tough, dependable and reliable way to monitor pump pressure.

RIGCHINA Stand Pipe Gauges provide a quick, accurate display of pump pressure. Main applications are for standpipes and to be mounted on mud pumps. This style of gauge has been in service for many years and has proven to be a tough, dependable and reliable way to monitor pump pressure.

Crown Oilfield Instrumentation’s mud pressure gauges are extremely accurate and widely used in the harshest drilling environments. Each of our mud pressure systems are designed to meet or exceed API specifications, and you can count on a Crown mud pump pressure gauges to stand up to whatever the oil and gas industry can throw at them.  Our mud pressure systems monitor the pump pressure for a variety of pumps and applications to ensure that you are getting the most out of your drilling fluids. Our single pointer systems use a 6" aluminum cast gauge to detect the slightest pressure changes and come with three different sensors: diaphragm gauge protector, 1:1 piston separator and 4:1 debooster gauge protector. The  Crown compound pointer system uses  unique pointer design that affords the reader to see the smallest pressure changes at a glance. Crown"s unitized pressure gauges are gauge and protector in one and can be mounted on a standpipe and seen up to 60 ft. away. Crown’s pressure gauges are designed, developed and tested to be durable, reliable and dependable, and all systems can stand up to the rigors of the oilfield. Manufactured in the US, you can depend on our pressure gauge systems to provide years of service.

The mud pump pressure gauge is a specialized gauge for mud pumps. It is mainly used for the petroleum, coal, chemical industry, drilling industries. This new model is used in measuring pressure of high viscosity and easy crystal medium. The gauge is also used for measurement of stationary pressure. We provide a full range of gauges. Whether you are looking for it, we can accommodate your needs for land or offshore drilling rigs.

Mud Pump Pressure is extremely important to the drilling process. The Mud Pump Pressure Gauge enables the driller to monitor the pressure while drilling. Any unusual change in pressure will alert the driller of down hole problems. Pressure too low could indicate washed out pipe orbit nozzle, loose joint or broken drill string, worn pump packing or liners, or lost returns due to formation breakdown. Pressure too high could indicate a plugged drill bit or an increase in mud density or viscosity. Reliable indication of mud pump pressure provides an early warning of circulation problems, enabling the driller to make corrections avoiding major problems.

Mud pump, refers to the drilling process to the drilling mud or water and other washing liquid machinery. The main components are volute, impeller, pump seat, pump case, support cylinder, motor seat, motor and other components. Impeller nut is cast iron, so corrosion resistance is good, and convenient processing technology. Pump seat is equipped with four skeleton oil seal and shaft sleeve, prevent shaft wear, prolong the service life of the shaft.

ATO offers high quality vertical mud pumps with thick, solid shaft and copper motor. Various models are available, such as 2 inch mud pump, 3 inch mud pump, 4 inch mud pump and 6 inch mud pump.

Vertical mud pump is used as suction and pouring of river mud, suitable for oil refining, construction, printing and dyeing, chemical industry and other industries.

The unit consists of a small pressure vessel (approximately 3 cc. in volume) in conjunction with a 12" length of small bore (.010" ID) capillary. The pressure enters the small vessel volume and gauge through the capillary and is trapped momentarily thus "smoothing" out the pressure pulse. A stainless steel filter (20 micron) is included at the entrance of the capillary to prevent dirt or foreign objects from clogging the small bore of the capillary.

The gauge snubber concept has proven to be superior to using a valve having an extremely small orifice, or a close fitting pin in a cylinder, due to clogging or instability. While the bore of .010" ID may appear be quite small, it is actually very large when compared to the orifices required for "snubbing" using other means.
