self running mud pump quotation

Mud Pumps come in both electric and gas / diesel engine drive along with air motors. Most of these pumps for mud, trash and sludge or other high solids content liquid dewatering, honey wagon and pumper trucks. Slurry and mud pumps are often diaphragm type pumps but also include centrifugal trash and submersible non-clog styles.

WARNING: Do not use in explosive atmosphere or for pumping volatile flammable liquids. Do not throttle or restrict the discharge. Recommend short lengths of discharge hose since a diaphragm mud pump is a positive displacement type and they are not built with relief valves.

15 Models below. Made in USA. Gas, Diesel or Electric diaphragm pump, or mud / sludge pump. Easily maneuverable, the gas diaphragm pump is built for performance; Ideal for seepage dewatering, high suction lift, cleaning septic tanks, pumping industrial waste and marine tanks, small wellpoint systems and dewatering in sandy, muddy waters. Honda or Briggs gasoline engine or Electric diaphragm pump with motor.

Durable design with enclosed gears in oil bath, self cleaning flow path, dry run without damage, auto priming. Built in polyurethane flapper / check valve assures self-priming to 20 feet. This unit has steel suction strainer, two NPT hex nipples and wheel kit with 10" semi-pneumatic transport wheels for portability.

Diaphragm Mud pump Suction & discharge port size cannot be reduced. Cast aluminum construction with thermoplastic rubber diaphragm. Also called a mudhog. 90 degree rotatable base on all models to fit through narrow gates. As a alternate in a centrifugal pump dredge pump design see 316F-95 2" mud pumps. Trash pumps, centrifugal Dredge Pump. Hoses and accessories.

A mud pump is a reciprocating piston/plunger pump designed to circulate drilling fluid under high pressure (up to 7,500 psi (52,000 kPa)) down the drill string and back up the annulus. A duplex mud pump is an important part of the equipment used for oil well drilling.

Duplex mud pumps (two piston/plungers) have generally been replaced by the triplex pump, but are still common in developing countries. Two later developments are the hex pump with six vertical pistons/plungers, and various quintuplex’s with five horizontal piston/plungers. The advantages that Duplex mud pumps have over convention triplex pumps is a lower mud noise which assists with better Measurement while drilling and Logging while drilling decoding.

Use duplex mud pumps to make sure that the circulation of the mud being drilled or the supply of liquid reaches the bottom of the well from the mud cleaning system. Despite being older technology than the triplex mud pump, the duplex mud pumps can use either electricity or diesel, and maintenance is easy due to their binocular floating seals and safety valves.

A mud pump is composed of many parts including mud pump liner, mud pump piston, modules, hydraulic seat pullers, and other parts. Parts of a mud pump:housing itself

Duplex pumps are used to provide a secondary means of fuel transfer in the event of a failure of the primary pump. Each pump in a duplex set is sized to meet the full flow requirements of the system. Pump controllers can be set for any of the following common operating modes:Lead / Lag (Primary / Secondary): The lead (primary) pump is selected by the user and the lag (secondary pump operates when a failure of the primary pump is detected.

Alternating: Operates per Lead / Lag (Primary / Secondary) except that the operating pump and lead / lag status alternate on consecutive starts. A variation is to alternate the pumps based on the operating time (hour meter) of the lead pump.

Manufactured to withstand the toughest drilling and environmental conditions, our K-Series triplex mud pumps are ideal for all drilling applications. This legacy product features a balanced forged-steel crankshaft and Southwest Oilfield Products ‘L” Shaped modules which is essential to minimize wear, noise, and operating vibrations. These attributes are essential when drilling deeper high pressure formations, long laterals and when handling corrosive or abrasive fluids and slurries.

Every American Block triplex mud pump is manufactured and fully load tested before leaving our manufacturing campus, and is available in sizes ranging from 800 HP to 2200 HP. The American Block K1600 HP Mud Pump is also available in a 2000 HP up-grade version, when more HP is needed in the same 1600 HP footprint.

This website is using a security service to protect itself from online attacks. The action you just performed triggered the security solution. There are several actions that could trigger this block including submitting a certain word or phrase, a SQL command or malformed data.

We have attained huge reputation as prominent manufacturer and supplier of Portable Dewatering Submersible Pumps. These pumps are well accepted in the market for their light weight, robust construction and excellent functional accuracy. We design these pumps by utilizing latest tools and techniques as per latest industrial norms with quality tested raw materials. We supply these machines in wide specifications at affordable price range to our customers.

• Portable submersible pumps are one of its kinds. We have a wide range of selection within the same Horse Power rating for these pumps. Our construction is robust compared to other make pumps and has proved its self in the market with its trouble free Operation

• Motor – submersible pumps are available in Single phase and three-phase squirrel cage induction dry motor with ‘F" class insulation and IP 68 protection

• We provide pumps with Aluminum MOC, which will make the pump very light and will be extremely handy for the operator. Trolley mounted construction is also an available option

We are a three-decade-old company that manufactures and supplies high quality pumps, for a range of industrial sectors and purposes. Our products are revered for their finesse and integrity which has been honed by our expert engineers. Moreover, as we understand the diverse needs of the dynamic industries we cater to, our products are highly customizable.

This website is using a security service to protect itself from online attacks. The action you just performed triggered the security solution. There are several actions that could trigger this block including submitting a certain word or phrase, a SQL command or malformed data.

The Varisco J6 series of centrifugal self priming pump is capable of transferring fluids that are clean, dirty or contain solids in suspension up to 76mm. The largest model in the J6 series can produce flow rates up to 380m³/hr and heads up to 55m.

The pump is installed in a dry area above the fluid, only the suction pipe needs to be immersed in the fluid. This makes maintenance incredibly simple compared to submersible pumps.

All the wearing parts are easily replaceable, once replaced the pump is back to its original performance. This vastly increases the life span of the pump.

This centrifugal self priming pump is available in various materials including ductile iron, aluminium bronze and stainless steel. This makes it excellent at handling a wide range of fluids including but not limited to; water, sea water, muddy water, low viscosity fuels, solvents (clean or dirty), milk of lime, caustic soda, hot or corrosive waste water, bilge water, acids and alkaline.

Common application for this centrifugal self priming pump include; fire fighting, grey water transfer, black water transfer, marine general service, aquaculture, ballast water transfer, bilge water transfer, marine deck wash, fuel loading and unloading, diesel transfer, stripping, liquid manure transfer and spraying, sea water cooling, water cooling, sump emptying, dewatering and many more.

The SNT-SP is the self-priming version of the SNT long coupled end suction centrifugal pump. Either an electric or air vacuum priming pump is fitted to the body to enable full self-priming capability. This variation has the full ability of the standard version; however, it can only be used for clean liquids such as sea water and fresh water containing no solid particles.

The SNT-SP long coupled, end suction, single stage horizontal centrifugal pump is standardised to EN 733/DIN 24255 and can be used for a vast range of applications in the industrial and marine markets. Common applications include energy plants, mining, firefighting, irrigation, water supply, water treatment, pressurisation, grey water, dewatering, building systems, ballast transfer, sea water general service, scrubber systems, marine and cooling/heating conditioning (HVAC).

This self-priming centrifugal pump is required when it is not possible to supply the inlet with fluid via gravity. This range is ideal for installations where the pump sits above the supply tank requiring a suction lift or where the inlet conditions are difficult such as long pipe runs. Priming is achieved by the main pump and the priming system working in tandem. They operate simultaneously, the priming device works by removing all the air from the inlet pipework, this draws the fluid into the body of the main pump, thus priming. A pressure switch then shuts down the priming device once the adequate pressure is achieved to enable to main pump to operate independently.

The long-coupled design is very easy to maintain as it is possible to access the pump head without removing the motor. This centrifugal pump is also more robust and designed for continuous use as additional bearings are installed in the pump head, these take a large deal of strain away from the motor during operation.

The back pull-out design allows the motor to be removed while the pump is still connected to the pipework, this in turn allows time saving while the pump is serviced/maintained.

The centrifugal pump and motor have independent shafts, this means that only the pump shaft will need to be replaced in the event of it breaking. Other less robust horizontal centrifugal pumps on the market only use the motor shaft, this means that if the shaft breaks, the entire motor needs to be replaced.

The long-coupled design means that there is a large space between the pump and motor, this in turn protects the motor from fluid ingress in the case of a seal failure.

Wear rings can be installed in the pump head, this is a sacrificial part that wears first protecting the impeller and casing from wear and prolonging the life of these parts and therefore the pump.

The long coupled horizontal centrifugal pump complies with DIN 24255 and EN733, this means that the pump is dimensionally the same as many other pumps on the market, this enables the replacement of most horizontal centrifugal pumps that are already installed.

This website is using a security service to protect itself from online attacks. The action you just performed triggered the security solution. There are several actions that could trigger this block including submitting a certain word or phrase, a SQL command or malformed data.

The drilling industry has roots dating back to the Han Dynasty in China. Improvements in rig power and equipment design have allowed for many advances in the way crude oil and natural gas are extracted from the ground. Diesel/electric oil drilling rigs can now drill wells more than 4 miles in depth. Drilling fluid, also called drilling mud, is used to help transfer the dirt or drill cuttings from the action of the drilling bit back to the surface for disposal. Drill cuttings can vary in shape and size depending on the formation or design of the drill bit used in the process.

Watch the video below to see how the EDDY Pump outperforms traditional pumps when it comes to high solids and high viscosity materials commonly found on oil rigs.

The fluid is charged into high-pressure mud pumps which pump the drilling mud down the drill string and out through the bit nozzles cleaning the hole and lubricating the drill bit so the bit can cut efficiently through the formation. The bit is cooled by the fluid and moves up the space between the pipe and the hole which is called the annulus. The fluid imparts a thin, tough layer on the inside of the hole to protect against fluid loss which can cause differential sticking.

The fluid rises through the blowout preventers and down the flowline to the shale shakers. Shale shakers are equipped with fine screens that separate drill cutting particles as fine as 50-74 microns. Table salt is around 100 microns, so these are fine cuttings that are deposited into the half-round or cuttings catch tank. The drilling fluid is further cleaned with the hydro-cyclones and centrifuges and is pumped back to the mixing area of the mud tanks where the process repeats.

The drill cuttings contain a layer of drilling fluid on the surface of the cuttings. As the size of the drill cuttings gets smaller the surface area expands exponentially which can cause rheological property problems with the fluid. The fluid will dehydrate and may become too thick or viscous to pump so solids control and dilution are important to the entire drilling process.

One of the most expensive and troubling issues with drilling operations is the handling, processing, and circulation of drilling mud along with disposing of the unwanted drill cuttings. The drilling cuttings deposited in the half round tank and are typically removed with an excavator that must move the contents of the waste bin or roll-off box. The excavators are usually rented for this duty and the equipment charges can range from $200-300/day. Add in the cost for the day and night manpower and the real cost for a single excavator can be as much as $1800/day.

Offshore drilling rigs follow a similar process in which the mud is loaded into empty drums and held on the oil platform. When a certain number of filled drums is met, the drums are then loaded onto barges or vessels which take the drilling mud to the shore to unload and dispose of.

Oil field drilling operations produce a tremendous volume of drill cuttings that need both removal and management. In most cases, the site managers also need to separate the cuttings from the drilling fluids so they can reuse the fluids. Storing the cuttings provides a free source of stable fill material for finished wells, while other companies choose to send them off to specialty landfills. Regardless of the final destination or use for the cuttings, drilling and dredging operations must have the right high solids slurry pumps to move them for transport, storage, or on-site processing. Exploring the differences in the various drilling fluids, cutting complications, and processing options will reveal why the EDDY Pump is the best fit for the job.

The Eddy Pump is designed to move slurry with solid content as high as 70-80 % depending on the material. This is an ideal application for pumping drill cuttings. Drill cuttings from the primary shakers are typically 50% solids and 50% liquids. The Eddy Pump moves these fluids efficiently and because of the large volute chamber and the design of the geometric rotor, there is very little wear on the pump, ensuring long life and greatly reduced maintenance cost for the lifetime of the pump.

plumbed to sweep the bottom of the collection tank and the pump is recessed into a sump allowing for a relatively clean tank when the solids are removed. The Eddy Pump is sized to load a roll-off box in 10-12 minutes. The benefit is cuttings handling is quicker, easier, safer, and allows for pre-planning loading where the labor of the solids control technician is not monopolized by loading cuttings. Here, in the below image, we’re loading 4 waste roll-off bins which will allow the safe removal of cuttings without fear of the half-round catch tank running over.

Mud cleaning systems such as mud shaker pumps and bentonite slurry pumps move the material over screens and through dryers and centrifuges to retrieve even the finest bits of stone and silt. However, the pump operators must still get the raw slurry to the drill cuttings treatment area with a power main pump. Slurry pumps designed around the power of an Eddy current offer the best performance for transferring cuttings throughout a treatment system.

Options vary depending on whether the company plans to handle drill cuttings treatment on-site or transport the materials to a remote landfill or processing facility. If the plan is to deposit the cuttings in a landfill or a long-term storage container, it’s best to invest in a pump capable of depositing the material directly into transport vehicles. Most dredging operations rely on multiple expensive vacuum trucks, secondary pumps, and extra pieces of equipment.

Using an EDDY Pump will allow a project to eliminate the need for excavators/operators to load drill cuttings, substantially lowering both labor and heavy equipment costs. The EDDY Pump also allows a company to eliminate vacuum trucks once used for cleaning the mud system for displacing fluids. Since the pump transfers muds of all types at constant pressure and velocity throughout a system of practically any size, there’s little need for extra equipment for manual transfer or clean up on the dredge site.

The EDDY Pump can fill up a truck in only 10 minutes (compared to an hour) by using a mechanical means such as an excavator. For this reason, most companies can afford one piece of equipment that can replace half a dozen other units.

This application for the Eddy Pump has the potential to revolutionize the drilling industry. Moving the excavator out of the “back yard” (the area behind the rig from the living quarters) will make cuttings handling a breeze. Trucking can be easier scheduled during daylight hours saving on overtime and incidences of fatigued driving. Rig-site forklifts can move the roll-off boxes out of the staging area and into the pump loading area. The operator can save money on excavators rental, damages, and keep the technician operating the solids control equipment.

The EDDY Pump is ideal for drilling mud pump applications and can be connected directly onto the drilling rigs to pump the drilling mud at distances over a mile for disposal. This eliminates the need for costly vacuum trucks and also the manpower needed to mechanically move the drilling mud. The reasons why the EDDY Pump is capable of moving the drilling mud is due to the hydrodynamic principle that the pump creates, which is similar to the EDDY current of a tornado. This tornado motion allows for the higher viscosity and specific gravity pumping ability. This along with the large tolerance between the volute and the rotor allows for large objects like rock cuttings to pass through the pump without obstruction. The large tolerance of the EDDY Pump also enables the pump to last many times longer than centrifugal pumps without the need for extended downtime or replacement parts. The EDDY Pump is the lowest total life cycle pump on the market.

We are able to provide you with stable flow, self-priming ability, smooth running mud pump, we have been working on oil equipment for many years, we have overseas markets, such as the United States, Canada, Russia and so on. If you see our website and information, and interested in our products, please contact us, we will be honored very much!

We are a Chinese manufacturer of oil equipment, our mud pump noise is small, smooth operation, vibration is relatively small. Our mud pumps deliver stable flow and low flow rates while maintaining high rejection pressures. Self-priming ability, easy disassembly and maintenance.

Mud pump before starting, please check the inlet pipe, outlet pipe is blocked, before and after the bearing whether to add butter, check the packing is full. Mud pump work should be equipped with high pressure water pump, will be greater than the pressure of the mud pump water leakage leak-proof filler, the filler protection, mud pump work must not turn off the washing pump, otherwise, will make the seal part of the rapid wear and tear. Whether the gap between the impeller and the guard plate is reasonable, a great impact on the life of the mud pump. The gap is unreasonable, the pump running vibration and noise, over flow parts quickly damaged, so the replacement of the impeller, should pay attention to the gap to meet the requirements of the drawings, clearance adjustment, through the rear bearing body to adjust the screw to carry out. The allowable suction of the mud pump is measured when the water is delivered, and the effect of the mud on the suction capacity should be taken into account when sucking the slurry.

Mud PumpProviding you the best range of self priming mud pump, chemical process pump, sewage monoblock pumps, centrifugal self priming pump, mud pumps and mud pump with effective & timely delivery.

The chemical process pump "GCP" is widely used for chemical, petrochemical industries, media which can be easily pumped are acids, caustic, ammonia, phosphate, dyes, oils, solvents, alcohol, aromatics etc. Also suitable for textile, food, paper & pulp, pharmaceuticals etc.

Dewatering, Mud, Marine, effluent, hotel, loading & transfer of oils, spirits, swimming pools, gas oils, engine cooling. Vessels, industrial-pumping petroleum products, chemical Civil Construction-dewatering foundation, trenches and pits. Filter Press Feeding, ETP, STP water for marine engines and shovels. Technical Data Capacity : up to 75 m3/hr

The chemical process pump "GCP" is widely used for chemical, Petrochemical industries. Media which can be easily pumped are Acids, Caustic, Ammonia, Phosphate, Dyes, Oils, Solvents, Alcohol, Aromatics etc. Also suitable for Textile, Food, Paper & Pulp. Pharmaceuticals etc.

Any application where priming is to be avoided,Industry : Transfer of clean 01 dirty neutral, acid or alkali liquids containing sand, mud or solids in suspension; clean or dirty low viscosity petroleum products or solvents; milk of lime, caustic soda; washing, cooling, circulation; smoke scrubbing; emergency duty.

Waste treatment: Pumping polluted, hot or corrosive waste water containing sand, mud or solids in suspension; dosing neutralising liquids; pumping out settled sludge.

Whether onshore or offshore, well drilling sites rely on a multitude of systems to successfully perform the drilling operation. The mud pump is a key component tasked with circulating drilling fluid under high pressure downhole. The mud pump can be divided into two key sections: the power end or crosshead and the fluid end. Proper alignment of the pump’s crosshead to the fluid end liner is necessary to maximizing piston and liner life. Misalignment contributes to

accelerated wear on both the piston and the liner, and replacing these components requires downtime of the pump. Traditional methods of inspecting alignment range from using uncalibrated wooden rods, Faro Arms and micrometers to check the vertical and horizontal alignment of the piston rod OD to the piston liner ID. These are time consuming and cumbersome techniques that are ultimately not well suited to troubleshoot and solve alignment issues.

A “Mud Pump Laser Alignment Kit” enables you to measure where the piston will run through the liner at various positions along the pump’s stroke. It will also project a laser centerline from the fluid end back towards the rear power end of the pump that can be used to determine how much shimming is required to correct any alignment issues. The kit can include either a 2-Axis receiver or a 4-Axis which accepts the laser beam and documents where it falls on the active surface of the receiver. The 4-Axis receiver can decrease alignment time by as much as 50% as it will measure angularity as well as X and Y while the 2-Axis does not and will need multiple measurement locations to get the same information. In addition, the alignment system is a non-intrusive service requiring the removal of only the piston rod which allows for much quicker service and less down time on the pump. As the mud pumps in question are located globally both on and offshore, having a small, portable system is another great advantage. Our recommendation would be Pinpoint laser System’s “Mud Pump Alignment Kit”. They are being used by many of the leading repair service companies and have been their main alignment tool for over 15 years. Manufacturers are also utilizing these for new pump set-up.

The company is well known in the market for the manufacture and the supply of an excellent range of pumps which are inclusive of the Self Priming Mud Mono Pumpset which offer a high performance to the customers and they have been made using the best technology available in the market. These products are non-corrosive and theyread more...
