Today, Patterson’s vertical turbine technology is the product of years of vertical pump experience. The result is a refined design that produces exceptional

hydraulic performance, with low vibration and noise levels. And pumping sections can be staged as necessary to meet desired pressure requirements. Vertical

turbine units require only minimal floor space and operate in low NPSHA applications. The above-grade discharge, motor and controller allow easy, safe maintenance.

Specifically designed to handle stringy solids, H2O Works™ Multi-Purpose Vertical Turbine® pumps are widely used in municipal/industrial solids handling, water

Patterson technology helps transform even wastewater into a valuable resource. Designed to move sewage, sludge and dirty water, these pumps do not clog and serve

Air Diaphragm Pumps by All-Flo for water, chemicals, thick viscous liquids, soaps, lubricants, oils and fluids with trash / debris. Non-metallic and Metal pneumatic diaphragm pump models from 1/4" to 3" size. Lube Free, Non-Stalling air v...

ASP manufactures all 304SS Stainless Steel centrifugal pumps for the commercial / OEM chemical and water pump marketplace. Used in commercial flatware and chiller equipment. Hazardous location or Explosion Proof pumps available. St...

The AMT Pumps product line consists of a wide range of electric / engine driven pumps in Cast Iron (CI), Bronze, Stainless Steel (SS) and Aluminum (AL). American Machine and Tool Company (A M T) is one of the largest manufactu...

AquatecWater pumps, was established as the premier manufacturer of electric Diaphragm demand pumps for the Point-of-Use Water Purification Industry. Today Aquatec"s advanced technology serves RO, RV, Marine, Water, 12v, solar, including ele...

Barnes submersible pumps: electric, sump, effluent, sewage, trash, pond fountain water pumps provide versatility, high performance and unequaled value. For more than a century, design and specifying engineers, plumbing contractors and end-...

Berkeley centrifugal water pumps are designed for irrigation pumping, waterfalls, well pumps, water truck pumps, fire, and other water pumping needs. Berkeley pumps are powered by electric motors or gas driven engines...

Briggs and Stratton Gas Engine generators and water pumps. High performance Pump engines for construction, fire fighting, irrigation, industrial, commercial, golf & sports, farm & ranch, and rental industries. Briggs & Str...

W.S. Darley & Co. Champion Fire Pumps combines solid engineering with the latest technology to provide you with the highest quality fire pump for the job. The Darley and Davey Fire pumps have a long reputation in the fire pump service mark...

EBARA pumps - Stainless Steel pumps CI pumps - End Suction, Self-priming, multi-stage - Vertical, Sump, Effluent, Sewage, fountain submersibles. Pumps for water and chemicals. Ebara, not Ebera pumps are found world wide. For Ebara parts to th...

In a fine example of "Yankee Ingenuity", Jacob Edson invented the diaphragm pump, and in 1859 established The Edson Corporation in Boston, Massachusetts to manufacture and sell his pump. He continued to invent a wide range of marine p...

Finish Thompson Inc. FTI industrial Chemical pumps enjoy a reputation for state-of-the-art pump engineering, quality, delivery, as a diversified manufacturer of industrial chemical solvent acid pumps. FTI Pump Product line r...

FLOJET Corporation is a leading global manufacturer of small Utility RV Spray pumps, motors and dispensing pumps for a variety of Industries including General Industrial Equipment, Agricultural Lawn & Garden, Recreational Vehicle, Mar...

Flotec Pump. Flotec Water pumps provide a complete range of pumps to service the home sump, waste water, utility, sewage, and effluent pump needs. Sprinkler, fire and battery backup pumps also. Flotec pumps are a consumer grade pump.

General Pump is the world leader in plunger pump products for high pressure cleaning, pressure washers, car wash, reverse osmosis/desalination, and industrial process applications. They offer one of the widest ranges. General is a divisi...

Goat Throat is a revolutionary new barrel pump that costs far less than competitive products, and quickly pays for itself by preventing potentially hazardous spills and assuring precise, measurable pump flow control. Unlike costly electri...

Gorman Rupp Pump manufactures of all types of trash pumps, submersible pumps, portable pumps, high-pressure fire pumps, and self-priming pumps. Centrifugal and diaphragm pumps. Electric Gas Diesel powered. Mansfield, OH. OTS Off-The-Shelf...

Graco pump line of pumps for oil & fuel transfer. Oil pumps in 115v or 12v DC. Diesel fuel pumps in 115v or 12v DC. Graco oil pump and fuel transfer pump are made in USA.

Graymills coolant pump and parts washer manufacturer. Whether it is a vertical pump for circulating machine tool coolants, cleaning in production, maintenance and service industries. Founded in 1939 as a coolant pump manufacturer for machin...

Offering a wide range of pumps for industrial / chemical fluid transfer applications. You can select from the following product lines: SHURflo ® centrifugal pumps and SherTech positive displacement,...

Manufactures pumps for industrial / marine / utility applications including for diesel / fuel oil. Pumps available in 12vdc, 115 or 230vac, PEO and pedestal mounted. Boat bilge pumps, water pumps. Run dry pumps. California

Koshin pumps are the standard and known world wide in the contractor, rental, and portable pump markets as the brand to use. Most portable water pumps by Koshin feature Honda gas engines. Need replacement Parts or repair kits for your Koshin p...

Water Pumps, Lancaster Pump, has manufactured a complete line of electric well and water pumps for residential, commercial, and industrial use. Water pump for well, sump, sprinkler irrigation. Jet and submersible water well Pumps are made in cast iron, brass, bronze and SS. Pennsylvania.

Little Giant Pump Company"s origins date back to 1941, when an idea by a plumber named Doc Wolfe became the world"s first submersible electric motor-driven pump. Little Giant Pump comprehensive line now includes waste water pumps, sump, ...

March Pumps for Chemicals / water IN STOCK. These pumps made in the suburbs of Chicago are a magnetically coupled pump or magnet drive sealless pump, leak proof, no seals - no seal problems. Magnetic couplings create magdrive pump. Used i...

Monarch pumps, Centrifugal pumps are built on the strength of cast iron. Monarch manufactured high efficiency pumps of all types. Water pumps, submersible, effluent, sewage pumps, trash, utility, fire, Ag, irrigation, industrial pumps. Monarc...

Available close or long coupled in cast iron, bronze and SS. MTH pump offers turbine pumps in mechanical sealed and sealless canned motor. Flows to 150 gpm and p...

F.E. Myers Pumps - Pentair. They now make waste water and industrial pumps of all types. They are a div. of Pentair. Myers is located in Ashland Ohio with over 410,000 Sq.Ft. of mfrg. Pumps include: centrifugal, jet, submersible, well, utility,...

Oberdorfer Pumps has been manufacturing high-quality, dependable\npumps for over 100 years. We manufacture gear pumps, centrifugal\npumps, rubber impeller pumps, progressive cavity pumps, and roller\npumps. Positive displacement ...

Pacer Pumps are manufacturer of high performance centrifugal pumps. Pacer pumps for dewatering, agriculture, aquaculture, fire, industrial chemicals, wastewater and water, construction and marine usage has resulted in worldwide market acceptanc...

Pearl Calpeda water pumps, high quality electric well pump (Jet, Submersible), Constant pressure boost, turbine and end suction centrifugals in Cast Iron, Stainless Steel.

Sta-Rite pumps is an industry leader in water transfer, sprinkler, irrigation, AG and much more. Electric pumps by Sta-Rite, like water booster pumps are made with motors in both single and three phase...

Stanley detwatering pumps, the pure power of hydraulic tools is also exemplified in our trash pumps. Our TP03 pump discharges an impressive 450 gallons per minute (1688 lpm) and can handle up to 3 inch (76 ...

G.H. Stenner Company, Inc. began manufacturing chemical metering pumps in 1957. Proprietary peristaltic design, Capable of outputs ranging up to 170 GPD/514 LPD and pressure capabilities to 100 PSI/7 Bar. Available in 4 different voltages and...

PTO driven dewatering pumps. Trunk Pumps also come in trash (high flow) and pressure tractor PTO pump models. Use your existing tractor, skid steer PTO 3-point hitch or hydraulics to operate these 2...

Wayne Pump Water Systems, over 70 years of unwavering devotion to our customers, Wayne Pump has become the leader in the water pump industry. Wayne Water Systems is a manufacturer of sprinkler, sump and utility water pumps in Ohio. Wayne also o...

Torontech is a leading North American based international manufacturer and supplier of pumps, pipes, valves & actuators. The Torontech ™ group has established an extensive network in the USA as well as international markets and remains to be a preferred vendor of choice supplying quality pumps for today’s leading corporations.

The Torontech ™ group offers a complete range of quality pumps that are, ANSI to ISO approved and engineered to last, ensuring your company continuous production without interruptions.

Since the beginning, we have succeeded in only offering quality manufactured pumps that are currently being used worldwide. We offer the best value for your investment and provide world-class support.

Due to the demand for our quality pumps, Torontech has experienced explosive growth primarily in the oil & gas, water filtration and chemical refinery industries.

We offer an extensive range of solutions and products for oil & gas projects, refineries, petrochemical plants, and marine applications. Our main class of pumps includes API (American Petroleum Institute) Standard, Mining, Water & Sewage and Firefighting applications.

American-Marsh Pumps Series 340, 10x10-10 HD horizontal split case pumps feature a 250 psi case working pressure. Thru-Bore line bore design allows removal and replacement of the packing housing or seal chamber, extending casing assembly life. The pumps have an internal Plan 1 flush for packing or seal lubrication without external flush lines. The pumps are designed with bolt-on bearing housings that allow the bearing to be removed from the shaft without removing the casing top or removing the rotor assembly from the casing. 901/860-2300; www.american-marsh.com.

Cornell Pump"s cutter pump is designed to address fouled impellers. The cutter design uses a stationary and rotating element to reduce masses of solids to a size that will pass through. Cutter rings can be added to existing installations. 503/653-0330; www.cornellpump.com.

The Proseries-M M-2 peristaltic metering pump from Blue-White Industries provides pumping action at near continuous output even at low feed rates. The self-priming valveless design will not vapor lock. The pump has advanced serial and Ethernet communications and feed rates range up to 14 gph with pressure ratings of 125 psi. A Tube Failure Detection system shuts the pump off if a chemical is detected in the pump head and sends an alarm. A safety switch stops the pump when the front cover is removed, and the pump will only operate in maintenance mode (a set RPM) while the front cover remains off. 714/893-8529; www.proseries-m.com.

The L-Frame progressing cavity pump from Moyno can handle clean, thin, shear-sensitive products, as well as viscous, corrosive, abrasive slurries and sludges in water, wastewater and mining applications. Features include non-pulsating metered flow, long life, vibration-free operation, viscosities over 1 million cps, capacities to 450 gpm and pressure to 2,100 psi. 877/486-6966; www.moyno.com.

The APP 800 automated water transport controller from Flygt – a Xylem Brand, is modular and scalable, allowing quick and easy expansion. With an embedded Web server, operators can check pump status from any location to monitor, troubleshoot, identify trends, handle alarms, and diagnose and resolve faults. The system gives operators access to data from anywhere. 704/409-9700; www.flygtus.com.

The Danfoss MBS1900 pressure transmitter monitors the water pressure in variable-speed booster pumps and relays the information to a programmable logic controller (PLC). If there is little or no water flow, the PLC will slow or put the motor on standby. The PCB design and shielded cable minimize RF conducted noise and maintain a stable output signal. The device uses advanced piezoresistive silicon sensor technology, providing overload pressure up to three times the working pressure. 410/931-8250; www.danfoss.us/ia.

The Channel MonsterXD sewage grinder from JWC Environmental comes in sizes including the XD 3.0, 13 feet tall and producing 7 tons of cutting force at peak loads. The unit combines rotating screening drums and a Muffin Monster grinder to shred solids, rags, plastics and wood while processing up to 59 mgd. It has a 15 hp grinder motor and 1 hp motor for the drums. 800/331-2277; www.jwce.com.

The Valveless Piston Metering Pump from Fluid Metering provides fluid control for environmental monitoring, sampling and treatment. The CeramPump design uses a rotating and reciprocating ceramic piston to accomplish pumping and valving functions without valves. The piston and mated liner are made of dimensionally stable, sapphire-hard ceramics for long-term, drift-free accuracy of 1 percent or better. The inert fluid path of ceramic and fluorocarbon is suited for injection of concentrated tracer dyes and water treatment chemicals. 800/223-3388; www.fmipump.com.

The natural-gas-fueled ReliaPrime emergency bypass station from Gorman-Rupp Co. includes a 6-inch Super T Series pump that passes 3-inch spherical solids. A soundproof lightweight aluminum enclosure has lockable door panels and can be removed for maintenance of the pump or engine. The unit comes complete and ready for hookup. 419/755-1011; www.GRpumps.com.

The ES400 helical screw pump from Elastec/American Marine is an economical, high-capacity pump for transferring liquids, oils and solids up to 1.5 inches while maintaining high head pressure. The pump handles flows up to 520 gpm with a maximum discharge pressure of 81 psi. It is fully submersible and has an enhanced chromium carbide-coated impeller and volute to generate high discharge pressure. 618/382-2525; www.elastec.com/pumps.

The MultiSmart pump station manager from Multitrode is designed for fast and easy deployment. It uses pre-programmed logic to reduce operating costs and prevent failures, blockages and spills. It provides preventive versus reactive control, calculates pump efficiency, and decreases pump station electrical consumption by leveraging the most efficient pump. Remote control programming reduces maintenance and troubleshooting costs and site visits. It includes PID controls for booster pumps and built-in local SCADA without HMI hardware and software. 561/994-8090; www.multitrode.com.

Komline-Sanderson plunger pumps are self-priming, handle sludge with entrained gases, and have high volumetric and hydraulic efficiencies. Flow rates are not dependent on sludge concentration. The units are easy to clean and have large internal clearances. They have replaceable connecting rod liners and a packing arrangement that reduces leakage. 800/225-5457; www.komline.com.

The Vertical Turbine Pump from Ruhrpumpen has multi-stage capability, enabling high discharge heads. Because the suction is in the fluid being pumped, no efficiency is lost on the suction side of the pump. Site suction head can be increased by lowering the pump in the fluid being pumped. Systems can be designed to pump fluids from deep levels. The pumps can be installed in areas where space is a problem and can be fitted with submersible motors to minimize noise. 918/627-8400; www.ruhrpumpen.com.

The TORNADO T2 rotary lobe pump from NETZSCH Pumps uses lobes running inside a metal housing with a replaceable elastomer liner. The design requires no O-rings or gaskets, yet has robust construction and is simple to maintain. A single, synchronous-toothed timing belt replaces a gearbox. A pulsation-reduction system of channels molded into the rubber walls of the pumping element releases lobe energy and dampens pulsation. The housing design permits full flange-to-flange access when servicing the pump and provides space to access pump internals without disassembling piping. 610/363-8010; www.netzschusa.com.

The Flowserve MPT self-priming solids-handling pump passes solids up to 3 inches and handles dirty, gritty water as well as free-flowing slurries, sewage, sludges and many trade effluents. It includes a back pull-out design, belt drive protection, quick-disconnect clean-out and external impeller adjustment, an abrasion-resistant mechanical seal, dual sight glasses, high-temperature capability, portability, oversized shaft and bearings, a solid one-piece flap valve, run-dry capability, oil-lubricated double mechanical seal, and externally adjustable clearances without shims. 800/728-7867; www.flowserve.com.

The IQ Series rotary lobe pump from Vogelsang reduces operating and maintenance costs by eliminating 50 percent of traditional wet-end wear parts. Simply remove the front cover to service the entire wet-end in minutes, without disturbing any connected piping. The ultra-compact design uses integrated flanges that can be oriented in a variety of ways to fit almost anywhere. It features an advanced flow-path for effective suction-lift and pulsation-free flow, and can handle highly viscous sludge containing

The StationComm automated alarm system from Smith & Loveless provides wireless pump station monitoring and control with a cellular-based automated alarm texting system that provides two-way communication between user and pump station. Users can text pump stations to remotely operate and maintain the control panel. Supervisors receive simultaneous messages while the system wirelessly sends sequential service messages to up to 10 operators with alarm messages. Various status checks include wet well level, pump run time, station temperature, flow rate and motor amperage. 800/898-9122; www.smithandloveless.com.

TITAN II 5812 and 5813 frame vertical motors from Nidec Motor Corp. have a cast iron frame and insulated bearings with shaft grounding provisions. Bearing and winding temperature detectors are available. Both frame sizes are custom-built. The 5813 includes WPI and WPII (weather-protected) enclosures ranging from 250 hp to 1,750 hp. The motor is available as hollow or solid shaft in both low and medium voltages. The 5812 has a fan-cooled enclosure for applications in severe-duty industries. Speeds range from 400 to 1,800 rpm and power ranges from 200 to 1,250 hp. 888/637-7333; www.usmotors.com.

The Vacuum-Assisted Trash Pump from Thompson Pump provides flows up to 11,000 gpm, heads up to 340 feet, and solids handling up to 4 inches. It provides fast dry-priming and automatic re-priming with high-pressure capability. The vacuum priming system operates with no oil lubrication, low maintenance and high air handling for faster priming. The unit includes an end-suction centrifugal pump end with a heavy-duty cast iron casing and brackets, stainless steel shaft sleeves, cast iron impeller and wear rings, and an abrasion-resistant tungsten carbide mechanical seal. 800/767-7310; www.thompsonpump.com.

The Eco Smart Station AB Control System from SJE-Rhombus provides a safe, simple, energy-efficient solution for optimum pump control in municipal lift stations. The 700-color display helps users monitor and configure the pump station. The controller provides energy-efficient level control, automatic pump alternation, flow monitoring, data logging, alarm logging and historical trending. It comes with an SD memory card for data storage and download. The control and power circuitry are isolated in separate compartments, protecting operators from high-energy circuits and arc flash. 888/342-5753; www.EcoSmartPanel.com.

SCADAPack E Smart RTU pump station controllers from Schneider Electric suit many water and wastewater applications. When used with ClearSCADA critical infrastructure remote management software, centralized SCADAPack E configuration and security management integration saves on total cost of ownership for geographically distributed water and wastewater assets. Encryption protects DNP3 data transmission using unique security keys, ensuring data confidentiality and integrity for revenue metering data and critical operations. 888/778-2733; www.schneider-electric.us.

The OLS Series control panel from Orenco Controls contains integrated variable-frequency drives that optimize system operation, reduce energy usage, and prolong pump and system life by reducing hard starts and water hammer. Multiple drives can be configured through one simple human-machine interface. Engineers can pre-program user interfaces to site-specific needs. The outdoor-rated control panel, housed in a weatherproof enclosure, has circuit protection, heat dissipation systems, phase and voltage protection, and level controls. 877/257-8712; www.orencocontrols.com.

Sludge pumps from Schwing Bioset can pump dewatered biosolids from belt presses, centrifuges, plate and frame presses and screw presses. The pumps have a volumetric capacity exceeding 300 gpm and operating pressures up to 1,885 psi. Along with non-flowable materials, they pump scum and grease. The pumps operate with a single-circuit, open-loop hydraulic system. A hydraulically actuated poppet valve works with the pump to prevent material backflow and ensure proper sequencing of operations. 715/247-3433; www.schwingbioset.com.

The Flow Pulse pipe flow monitor from Pulsar Process Measurement monitors flow rates for pump efficiency in sewage pumping stations. Ultrasound is fired through the pipe wall and reflected back from bubbles, particles and vortices in all directions. A digital signal processing system analyzes and integrates received signals over a wide frequency range, then slices them for real-time analysis and flow rate calculation. It operates in a flow range from 1 to 13 feet per second. The system provides repeatability and accuracy of ±5 percent. 850/279-4882; www.pulsar-pm.com.

The piping-contained Cake Pump System from seepex replaces the open-air cake transfer method using conveyors. The pitch, diameter and speed of the auger can be adjusted to match the application, while load cells automate the process. The hopper is fitted with sensors that detect the increase in weight and adjust pump speed accordingly, saving energy. The system includes a pressure sensor, a dry-running protection sensor, a boundary layer injection system, and an engineered control panel. 937/864-7150; www.seepex.net.

The Triton screw centrifugal pump from Vaughan Company has an open-channel impeller that handles thick sludges, large or stringy solids, and delicate or highly abrasive materials. 888/249-2467; www.chopperpumps.com.

The PHP-800 diaphragm metering pump from Omega Engineering has PVDF double ball valves, pumps up to 42 gph and handles output pressures up to 175 psi. The pump has a digital touchpad and backlit LCD display that shows the output percentage and diaphragm failure alarm status. A diaphragm failure detection system shuts off the pump head if a chemical leak occurs. 800/826-6342; www.omega.com.

The KRT series of submersible pumps from KSB includes a closed-loop cooling jacket that does not use the pumped media for cooling the motor. This cooling system provides optimal heat dissipation even if the submersible motors are exposed to the air, allowing the pumps to work continuously at low water levels. They are offered with several impeller types, and include mechanical seals and hard metal wear rings and sensors to monitor the motor windings, bearings, and mechanical seals. The pumps also feature epoxy-sealed cable glands along with additional material variants. 804/222-1818; www.ksbusa.com.

The 100 FLOW AC drive from Vacon is optimized for pump and fan applications and designed for water and wastewater applications. Features include Multimater and Multifollower for simultaneously controlling multiple pumps, multilingual graphical display, configuration wizards for easy setup, and intuitive built-in block programming function for special needs, including retrofits. The drive has a power range of 0.75 to 250 hp and voltage range of 230 to 500. 717/261-5000; www.vacon.com.

S4SHR and S4SHR-LP 4-inch hydraulic submersible shredder pumps from Hydra-Tech continuously rip and shear solids with a 360-degree shredding action. A carbide-tipped impeller and hardened macerator suction plate produce a violent shredding action that keeps the discharge open. The pump"s 21.5-inch diameter allows it to fit through most manholes. 570/645-3779; www.hydra-tech.com.

MRoy Series metering pumps from Milton Roy offer application flexibility for efficient performance at capacities from 0.46 to 170 gph. The pumps have a design life of 30 years for the drive and 96,000 hours for the pure PTF0E diaphragm. Turndown flexibility and the ability to accept process signals enable technicians to tune the pump to the application. 215/ 441-0800; www.miltonroy.com.

Explore a wide variety of long shaft pump on Alibaba.com and enjoy exquisite deals. The machines help maintain drilling mud circulation throughout the project. There are many models and brands available, each with outstanding value. These long shaft pump are efficient, durable, and completely waterproof. They are designed to lift water and mud with efficiency without using much energy or taking a lot of space.

The primary advantage of these long shaft pump is that they can raise water from greater depths. With the fast-changing technology, purchase machines that come with the best technology for optimum results. They should be well adapted to the overall configuration of the installation to perform various operations. Hence, quality products are needed for more efficiency and enjoyment of the machines" full life expectancy.

Alibaba.com offers a wide selection of products with innovative features. The products are designed for a wide range of flow rates that differ by brand. They provide cost-effective options catering to different consumer needs. When choosing the right long shaft pump for the drilling project, consider factors such as size, shape, and machine cost. More powerful tools are needed when dealing with large projects such as agriculture or irrigation.

Alibaba.com provides a wide range of long shaft pump to suit different tastes and budgets. The site has a large assortment of products from major suppliers on the market. The products are made of durable materials to avoid corrosion and premature wear during operations. The range of products and brands on the site assures quality and good value for money.

Vertical immersion pumps (also known as vertical column and shaft pumps) are a design whereby the motor is separated from the fluid being pumped. Typically used in tanks or pits in place of pumps which require flooded suction or priming.

A cantilever pump has an extended motor shaft meaning the maximum length of the vertical column is limited to just under 2M. An immersion pump has a separate shaft driving working parts enabling it to be manufactured to longer lengths up to 100M.

Their design is similar to an end suction centrifugal pump connected at the end of a column. An impeller is housed in the submerged casing, driven by the shaft within the column. A motor is connected at the top outside of the fluid which can be on a base plate sized to cover the pit. Discharge connections can be at a 90° angle to the suction port at the bottom of the column, or alternatively be mounted on the mounting plate for ease of connection during installation. High pressure pump designs utilise a multistage pump design, which contains several impellers enabling clean fluids to be transferred at low to medium flows.

As the pumps are immersed in the liquid, with the absence of seals which are often most vulnerable to high temperature degradation. This enables liquids of several hundred degrees to be transferred where self-priming pumps or submersible pumps can not be utilised.

Vertical centrifugal immersion pumps are the ideal solution where there is a cavitation risk. When high temperature liquids close to their boiling point are being transferred, there is often a very narrow margin of NPSH Available.

This can often mean a self-priming pump is not suitable particularly when which during its lifespan in the application the pump will experience a loss of efficiency potentially leading to cavitation. A pumps NPSH required can increase by 50% due to a doubling of wear ring clearances. This means the only viable option is a sump pump.

Submersible pumps are no longer advised as being suitable for the transfer of fuels or other flammable liquids. Immersed pumps mean the liquid is kept separate from the motor.

If submersible pumps are used and seals on the motor wear or degrade it poses a risk of explosion. Manufacturers of oils and fuels often change fuel blends through the addition of additives, which can cause previously thought sound seals to degrade.

Submersible pumps require periodic checks for signs of wear, should be monitored and typically operate in duty/standby mode in critical applications. Often the first sign of a submersible pump requiring maintenance is its failure in duty as it is located out of sight and out of mind. As motors of immersion pumps are outside the fluid, they are more durable, and less susceptible to seal failure.

Immersed pumps can have individual components specified for applications, and longevity rather than acceptance of a standard manufacturers materials as is common with submersible pumps. Parts can be specified for chemicals in materials such as polypropylene, or PVDF to Stainless Steels, hastelloys or duplex Stainless steel not possible with submersible pumps. In high purity applications pumps can be manufactured in a single material eliminating the possibility of cross contamination with metals for example in plating applications and with plastics with purified water.

Vertical sump pumps do not require entrance to a pit for maintenance and are usually removed from service for maintenance via a crane or hoist. Submersible pumps require entry into confined spaces for installation and at times for maintenance thereby increasing the risk and associated cost of maintenance.

These types of equipment are used in place of Self Priming pumps which may not be practical for selection due to large suction depths, viscous fluids, volatile fluids and high temperatures.

Separate Shaft to motor shaft meaning motor shaft, and bearings do not bear the full load of pump. Also means components can be replaced individually rather than complete unitNo bearing support in pump means reliance is on motor bearings. The pump components including column and impeller are solely supported by the motor.

This limits the pumps overall length to around 1.5M making the units only suited for shallow sumps as beyond this length the radial forces become excessive for the pumpShafts are given extra support through utilisation of additional bearings however care must be taken to ensure pure and solid laden liquids do not cause damage to the pump bearings

Enables various pump designs to be utilised from single stage impellers to multistage designs for higher pressuresDue to the absence of components in the liquid this design is used in high purity applications such as pharmaceutical and plating as only a single type of metal is in contact with the liquid.

Tank emptying – as the pump is immersed in the tank the pump can be used to empty tanks, with models selected to completely empty tanks, or be positioned slightly above the bottom of the tank meaning sludge and debris are not introduced into pumping processes.

High temperature fluid transfer – As mentioned above, sump pumps are able to handle fluids of several hundred degrees, and also cope with low NPSH requirements.

Long suction lines – if large amounts of air require evacuating from long suction lines, the change to an immersed pumps can mean reduced priming times.

Impeller types range from standard closed impeller for high efficiency of clean fluids, to open impellers for solid handling with up to 85% efficiency or non clog for the handling of sludges, sewage or abrasive matter in suspension of the liquid.

It is possible to have dry run designs of sump pump which include a lubricated shaft either by oil, or glycols. This keeps the shaft and seal cool enabling the pump to operate without fluid. However the fluid must be monitored to ensure it remains at specified levels.
