wear plate mud pump price

A wide variety of mud pump wear plate options are available to you, such as 1 year, not available.You can also choose from new, mud pump wear plate,As well as from energy & mining, construction works , and machinery repair shops. and whether mud pump wear plate is 1.5 years, 6 months, or unavailable.

A wide variety of wear plate for mud pump options are available to you, such as 1 year, not available.You can also choose from new, wear plate for mud pump,As well as from energy & mining, construction works , and machinery repair shops. and whether wear plate for mud pump is 1.5 years, 6 months, or unavailable.

Wear plate is the main component of hydraulic power end in drilling mud pump. It is forged of 35CrMo alloy steel.The wear-resistant disc produced by our company has high hardness and nickel plating, which has good wear resistance and corrosion resistance.

The wear plate for mud pump has high hardness and nickel plating on the surface, which has good wear resistance and corrosion resistance. The wear plate is used on the F1300/1600 mud pump and is installed on the inner side of the liquid cylinder to function as a cylinder liner.

The blank of the mud pump wear plate is made of 35CrMo forging, and the quenching and tempering treatment is 241-285HB. The metric system of the wear plate differs in that the screw holes are different, and the remaining dimensions are identical.

For maximum performance and durability, our modules are made from individually forged, heat-treated alloy steel and feature an API 7 valve assembly for improved flow. Our L-shaped design features bore-seal technology for improved seal performance in higher pressures and is compatible with numerous “F-Series” drilling pumps including Honghua®, Bomco® Rongsheng®, Workforce® and other similar designs.

The 2,200-hp mud pump for offshore applications is a single-acting reciprocating triplex mud pump designed for high fluid flow rates, even at low operating speeds, and with a long stroke design. These features reduce the number of load reversals in critical components and increase the life of fluid end parts.

The pump’s critical components are strategically placed to make maintenance and inspection far easier and safer. The two-piece, quick-release piston rod lets you remove the piston without disturbing the liner, minimizing downtime when you’re replacing fluid parts.

A mud pump (sometimes referred to as a mud drilling pump or drilling mud pump), is a reciprocating piston/plunger pump designed to circulate drilling fluid under high pressure (up to 7,500 psi or 52,000 kPa) down the drill string and back up the annulus. A mud pump is an important part of the equipment used for oil well drilling and manufactured according to API specification 7K.

The advantages of the drilling mud pump include the ability to move high-solids-content fluids laden with abrasives, the ability to pump large particles, ease of operation and maintenance, reliability, and the ability to operate over a wide range of pressures and flow rates by changing the diameter of pump liners and pistons.

As an important equipment for oilfield drilling operation, a drilling mud pump delivers circulating high-pressure drilling fluid or drilling mud to the bottom of the oil well, flushes the bottom of the well, breaks the rock, cools, lubricates and clean the drill bit, and carries the cuttings back to the ground.

The drilling mud is also used to suspend and carry out drill cuttings from the drill bits as it is brought in and out of the hole. This ensures that the drill bit does not clog and overheat, and makes the entire drilling operation smooth and safe.

Rotational power is supplied to the mud pump through an external power source like a diesel engine or electric motor. The power end of the mud pump converts the rotational energy through a crankshaft to a reciprocating motion of pistons.

The pistons move back and forth in mud pump liners, exerting a force on the cylinder chamber. During the retraction of the piston, valves open to allow the fluid to be drawn into the cylinder. Once the piston has fully retracted, it is pushed back into the cylinder.

For Fluid End: piston rod clamp, piston rod, piston assembly, cylinder cover, liner, liner flange, wear plate, cylinder, valve assembly, valve cover, valve guide, flashboard assy., cylinder cover flange, cylinder head, gaskets, studs, nuts, seal rings, pulsation dampener, bladder, discharge manifold, suction manifold, etc.
