slickline overshot for sale

The Hunting Releasable Overshot is designed to engage tools that have damaged or have no fish necks. The Overshot is designed to withstand high impacts associated with fishing operations.

Hunting Releasable Overshots are available in all common industry toolstring sizes and are manufactured with either sucker rod or integral quick connections as per customer requirements

The overshot is “planted” onto the fish to provide a new fish neck profile. This is then engaged with a standard releasable pulling tool or a Peak HD FRC pulling tool for heavy jarring applications.

The GG Overshot is generally used when there is a need to latch a fishneck that has been damaged due to corrosion, intense jarring, or deformation of the fishneck. The BT GG utilizes a collet to achieve a uniform grip on a damaged fishneck rather than just in a localized spots as conventional pulling tools do.

Incrementally sized grapples can be selected to suit the outside diameter of the fish whilst the adjustable core feature of the Overshot can be altered to suit the reach required to engage the fish. Due to the interchangeable nature between the LiMAR® Releasable and Non-Releasable Overshot versions, the top sub can also be removed and fitted with a releasable type top sub for both running and retrieval.

The Wireline Releasable Overshot is a slip type overshot used to retrieve a fish lost in the well bore that does not have a conventional fishing neck.

Once latched onto a fish the overshot can be released by jarring downwards provided the overshot has a solid footing upon which the core can be driven against.

The Wireline Releasable Overshot is composed of the top sub, cylinder, nut, main spring, mandrel, auxiliary spring, adapter sleeve, slips etc., simple structure,easy to use.

The Exwell Overshot is used to well-bore during wireline fishing operation. Overshots consist of hardened steel slips with sharpened upward teeth. They are used to bring a sub-surface tool or part of wireline tools that are lost in well- bore due to wear or mechanical damage to the fishing neck . The tools available with various sizes with complete range of hardened slips.

PARVEEN Wireline Overshots are used retrieve a fish lost in the well that does not have a conventional fishing neck or a damaged fishing neck on it. The tool is operated by applying the weight of the tool string on to the fish. This will allow the slips to expand around the fish when the tool string is picked up, the slip will engage the fish. These are non releasable type overshots.

The Coil Solutions Overshots are used to engage and pull a fish from the well bore. It uses a grapple to bite into the outside of the fish and releases by following through a predetermined rate to disengage the grapple. The tool comes with a range of grapples to accommodate various fish sizes.
