The series of hydraulic power tongs adopt inner cam rolling-up clamping mechanism, with a hydraulic backup tong. It is an ideal tool for makeup or breakout of various of tubings, and small sizes of casings and drill pipes in workover operation. The tong with extra long rod is available for backup tong to grip tubing body. The power tong also can be equipped with automatic torque control system.

MOT"s Hydraulic Power Tongs are used for running or pulling tubular strings during well repair, workover, snubbing, drilling and casing operations to extract oil and gas from wells. MOT’s

Our TEDA Style power tongs apply correct, uniform torque, reducing costly rod and tubing failures, delivering ample power to make up and break out rods and tubulars from 5/8” rod to 5-1/2” casing. Our series of XQ power tongs come with Bi-Directional jaw systems that save time and enhance safety, and go from make to break with the flip of a knob.

Tongs offer a variety of upgrades from our standard XQ series of TEDA Style models featuring Eaton hydraulic motors for extra torque and reliability, two or three spool directional control valves for more efficient hydraulic operations, and modified structures for higher strength, durability and adaptability to specific job requirements.

Are available from 5-1/2” to 20” pipe and are able to handle both API Standard and PREMIUM (Proprietary Steel Grade) casing connections which require higher torque. Available in a variety of models with hydraulic back-up tongs optional: “KMA", “KHT”, “TQ", “KJD”, “KD” and SE 16-25 with torques ranging from 15,000 ft-lbs up to 55,000 ft-lbs.

Are designed for quick and safe making up and breaking out of drill pipe and drill collars. Our “ZQ” series of hydraulic power drill pipe tongs are widely used in oil and gas drilling, in land and offshore operations around the world. The integrated torque tong and bucking tong eliminate the need for manual tongs and spinning chains, able to handle pipe from2-3/8” up to 8” drill collars, providing torques of up to 92,000 Lbs-Ft.

Lake Petro TQ series of casing tongs are widely used for making-up or breaking-out of casings or pipes. The casing tong features high-efficiency, safety, reliability, labor-saving, and can ensure connection quality. Tong head is designed as open and is fitted with two jaws which can ensure reliable gripping. Air tyre clutch is utilized as gearshifting mechanism, so it is possible to change gear under running. The series of casing tongs can be configured with torque device to perform computer monitoring and managing on pressure, torque and rounds. The casing tong has been granted with National Invention Patent. The casing tongs are designed and manufactured according to SY/T5074 and API Spec 7K “Specification for Drilling Equipment”

ZQ drill pipe power tong is an ideal well head tool for oil drilling, widely applied for making-up and breaking-out in offshore and onshore drilling operations and workover operations. Open-throat design of the ZQ series allows the tongs to escape from drilling pipe freely with high mobility. The tong is a combination of spinning tong and torque tong. It substitutes cathead, manual tong and rotary rope in making-up and breaking-out. The tongs are designed and manufactured according to API Spec 7K “Specification for Drilling Equipment”

XYQ series power tong is used for quick make-up /break-out in well service operations .The tong is equipped with hydraulic bacdup tong and use inner curved cam to clamp..

Manual Tong Dies and Slip Inserts are made of high-quality alloy steel and are chemically heat-treated for surface hardness. They feature wear-resisting, corrosion-resisting and have a long service life. We can also design and manufacture special inserts according to customer"s requirements.

Hydraulic Casing Power Tongs TQ series of casing tongs are widely used for making-up or breaking-out of casings or pipes. The casing tong features high-efficiency, safety, reliability, labor-saving, and can ensure connection quality. Tong head is designed as open and is fitted with two jaws which can ensure reliable...

Hydraulic Tubing Power Tong API 7K Hydraulic Tubing Power Tong with closed head and open head is used for make up and break out quickly in well service operation. The hydraulic tubing power tong is equipped with hydraulic backup tong and use inner curved cam to clamp. It is as per API 7K specification with oil pipe...

Hydraulic Drill Pipe Tong ZQ drill pipe power tong is ideal tool for oil & gas drilling, widely applied for makeup and breakout in offshore and onshore drilling operations and workover operations. Open head design of the ZQ series allows the tongs to disengage from drill string with high mobility. The tong is a...

Hydraulic Drill Pipe Power Tong After a quench and temper heat treat, the tool joints are cut into box (female) and pin (male) threads. Tool joints are commonly 120 ksi SMYS, rather than the 135 ksi of the tube. They generally are stiffer than the tube, increasing the likelihood of fatigue failure at the junction. The...

Hydraulic Casing Power Tongs TQ series of casing tongs are widely used for making-up or breaking-out of casings or pipes. The casing tong features high-efficiency, safety, reliability, labor-saving, and can ensure connection quality. Tong head is designed as open and is fitted with two jaws which can ensure reliable...

CD Type Elevator Model CD side door elevators with square shoulder are suitable for handling tubings, casings, drill pipes and drill collars in oil drilling , natural gas drilling and well construction, The products shall be designed and manufactured according to API Spec 8A/8C Specification for drilling and...

Manual Tong Manual tong is an essential tool in oil drilling operation to fasten or remove the screws of drill pipe and casing joint or coupling. The handling size of manual tong I can be adjusted by changing latch lug jaws and latch steps. Details • Manual tong is as per API7K standard • Manual tong is an essential...

We usually keep on with the principle "Quality To start with, Prestige Supreme". We"ve been fully committed to offering our purchasers with competitively priced excellent solutions, prompt delivery and skilled support for Power Tong , Tubing Power Tong , Oil Pipe Power Tongs , persistent management idea.

"Well-run gear, qualified revenue workforce, and superior after-sales companies; We"ve been also a unified huge loved ones, anyone persist with the organization benefit ""unification, determination, tolerance"" for Power Tong , Tubing Power Tong , Oil Pipe Power Tongs , contact us at any time. We look forward to establishing good and long-term business relationships with you.

Hydraulic Tubing Power Tong API 7K Hydraulic Tubing Power Tong with closed head and open head is used for make up and break out quickly in well service operation. The hydraulic tubing power tong is equipped with hydraulic backup tong and use inner curved cam to clamp. It is as per API 7K specification with oil pipe...

Hydraulic Casing Power Tongs TQ series of casing tongs are widely used for making-up or breaking-out of casings or pipes. The casing tong features high-efficiency, safety, reliability, labor-saving, and can ensure connection quality. Tong head is designed as open and is fitted with two jaws which can ensure reliable...

Manual Tong Manual tong is an essential tool in oil drilling operation to fasten or remove the screws of drill pipe and casing joint or coupling. The handling size of manual tong I can be adjusted by changing latch lug jaws and latch steps. Details • Manual tong is as per API7K standard • Manual tong is an essential...

Hydraulic Casing Power Tongs TQ series of casing tongs are widely used for making-up or breaking-out of casings or pipes. The casing tong features high-efficiency, safety, reliability, labor-saving, and can ensure connection quality. Tong head is designed as open and is fitted with two jaws which can ensure reliable...

Hydraulic Drill Pipe Power Tong After a quench and temper heat treat, the tool joints are cut into box (female) and pin (male) threads. Tool joints are commonly 120 ksi SMYS, rather than the 135 ksi of the tube. They generally are stiffer than the tube, increasing the likelihood of fatigue failure at the junction. The...

Hydraulic Drill Pipe Tong ZQ drill pipe power tong is ideal tool for oil & gas drilling, widely applied for makeup and breakout in offshore and onshore drilling operations and workover operations. Open head design of the ZQ series allows the tongs to disengage from drill string with high mobility. The tong is a...

Our solutions are greatly recognized and reliable by customers and will fulfill continuously altering financial and social requirements for Tubing Power Tong , Casing Power Tong , Hydraulic Tubing Power Tongs , please contact us at any time!

"We emphasize progress and introduce new solutions into the market each individual year for Tubing Power Tong , Casing Power Tong , Hydraulic Tubing Power Tongs , Based on experienced engineers all orders for drawing-based or sample-based processing are welcomed. We have won a good reputation for outstanding customer service among our overseas customers. We will continue to try the best to offer you good quality products and the best service. We are looking forward to serving you.

2018 marks the 60th anniversary for Eckel. We are the oldest continuous leading manufacturer of world-class hydraulic power tongs and trusted for reliability, safety and high performance.

The Eckel Model 25 Hydra-Shift® HS-85 features a two-speed motor with two-speed gear train, producing 60,000, 80,000 and 125,000 ft-lb of torque respectively in low-low, at 2,500 psi. This tong easily handles ultra-heavy casing strings from 9 5/8 inches to 25 inches.

The Eckel Model 25 Hydra-Shift® HT-200 Tri-Grip®introduced features a two-speed motor with two-speed gear train, producing 200,000 ft-lb of torque respectively in low-low, at 2,500 psi. This tong easily handles ultra-heavy casing strings from 9 5/8 inches to 25 inches - featuring a three head Tri-Grip®biting system design which like the Tri-Grip®New Revised Version Backup encompasses the tubular to apply an evenly distributed gripping force. The additional head in the tong reduces the risk of radial deformation, die penetration, marking, and wear of the tubular by 1/3 at extreme torques...

The new 7.25 HS HT-80 for Drill Pipe and High Torque Casing Tong takes on the toughest job with make-up and break-out of drill pipe, drill collars and high torque casing with a maximum torque of 80,000 ft-lbs. The 7.25 HS HT-80 is available with a two-speed Hydra-Shift® motor coupled with a two-speed gear train providing (4) torque levels and (4) RPM speeds. The variable speeds can slowly or quickly spin tubulars 2-3/8 through 7 1/4 inch as necessary. Having exceptional gripping capabilities with rig dies for drill pipe or wrap-around dies that securely encompass the tubular limit potential for damage. The 7.25 HS HT-80 is also available with either Eckel Pyramid Fine Tooth dies or True-Grit dies. The 7.25 HS HT-80 is another of our tongs models that exceeds the competition in its class.

Extremely popular among the most successful of pipe handlers, the Model 5 1/2 UHT combines high torque (up to 25,000 ft-lbs) with a wide capacity range. Ideal for handling tubing, casing and small drill pipe. Options include manual backup or Tri-Grip®backups.

The WD Tri-Grip®Backup is a high performance no compromise backup that is suitable for make-up and break-out of the most resilient connections. The WD Tri-Grip®Backup features a three head design that encompasses the tubular that applies an evenly distributed gripping force. A constant radial load is applied when a single wedge drive to actuate the front two pivot heads with a third stationary head providing a reactionary force to provide a superior gripping performance. Wedge Drive Tri-Grip®Backup has exceptional gripping capabilities with Rig Dies when running drill pipe or optional Eckel Wrap-Around True-Grit dies or Pyramid Fine Tooth dies for making up other types of tubulars.

The 4 1/2 Hydra-Shift® is packed with all the features you"ve come to expect from Eckel: patented cam biting system, quick-change sliding heads, self-aligning open throat. Options include both torque gauge and manual backup or cam-type hydraulic backup. The unit is also available with front or side controls, standard chain bridle suspension, or with its own built-in suspension arm.

The Eckel Model 14 Hydra-Shift® handles pipe from 4 inches to 14 inches and incoporates the Hydra-Shift® technology which provides smoother operating environment and a wider selection of torque/RPM"s that are available to the operator. The 14 Hydra-Shift® is capable of delivering 35,000 ft-lb of torque in low-speed, low-gear. Also available with hydraulic Tri-Grip®backup.

The Eckel Model 30 Hydra-Shift® features a two-speed motor with a two-speed gear train, producing 130,000 ft-lb of torque in low-low at 2,500 psi. Weight 9,000 pounds, this tong easily handles ultra heavy casing strings from 14 inches to 30 inches.

The Eckel Model 14 Hydra-Shift® handles pipe from 4 inches to 14 inches and incoporates the Hydra-Shift® technology which provides smoother operating environment and a wider selection of torque/RPM"s that are available to the operator. The 14 Hydra-Shift® is capable of delivering 35,000 ft-lb of torque in low-speed, low-gear. Also available with hydraulic Tri-Grip®backup.

Except for added torque (up to 24,000 ft-lb) and expanded pipe capacity (from 4 to 13 3/8 inches), the 13 3/8 Standard tong offers the same basic engineering and design as the smaller, lighter Model 10 3/4. Highly recommended where applications demand the ultimate in size range and torque output.

For casing up to 22 inches, here"s a tong that has strong torqueing ability and will handle pipe sizes down to 7 inch. The tong utilizes a two-speed motor and a two-speed gear train, allowing the operator to correctly adjust the tong for the optimum torque and RPM needed for the current application. Maximum torque for the 22 Hydra-Shift® is 80,000 ft-lb.

For casing up to 20 inches, here"s a tong that combines surprising speed with an ability to handle smaller sizes economically (as small as 7 inches). The 20 Standard reaches peak efficiency at just 38 horse power input, thus requiring no "souped-up" power unit. Available torque: 42,000 ft-lb.

An excellent choice where applications demand the combination of size range and high torque output, the Eckel Model 14 UHT handles pipe from 4 inches to 14 inches. Upgraded in design and performance over the Model 14 HS, this tong is capable of delivering 65,000 ft-lb of torque. Also, available with Wedge Drive Tri-Grip®backup which handles pipe from 4 inches to 15.5 inches.

When application demand a wide range of sizes, this tong handles pipe sizes 2 3/8 inches all the way to 7 5/8. Built around the 7 5/8 Standard, the 7 5/8 HS HD provides a thicker rotary gear for more added strength, an additional idler gear, a larger pinion gear, and stronger bearings for load bearing capacity and durability.

When application demand a wide range of sizes, this tong handles pipe sizes 2 3/8 inches all the way to 7 5/8. Built around the 7 5/8 Standard, the 7 5/8 Heavy Duty provides a thicker rotary gear for more added strength, an additional idler gear, a larger pinion gear, and stronger bearings for load bearing capacity and durability.

The Eckel Model 25 Hydra-Shift® features a two-speed motor with two-speed gear train, producing 60,000 ft-lb of torque in low-low, at 2,500 psi. Weighing 6,290 pounds, this tong easily handles ultra-heavy casing strings from 9 5/8 inches to 25 inches.

A maximum torque up to 25,000 ft-lb and a small foot print design this tong meets your application requirements. A two speed mechanical shift transmission in conjunction with the two speed Hydra-Shift® motor provides the operator a flexible choice of torque and rpm"s to work with during make-up or breakout. The 9 5/8 Hydra-Shift® HD is capable of handling a range of pipe from 2 3/8 inches to 9 5/8 inches.

Extremely popular among the most successful of pipe handlers, the Model 5 1/2 UHT combines high torque (up to 25,000 ft-lbs) with a wide capacity range. Ideal for handling tubing, casing and small drill pipe. Options include manual backup or Tri-Grip®backups.

The Eckel 870 DPT combine power tong and Wedg Drive Tri-Grip®Backup, providing a single piece of equipment to replace several...one smooth continuous operation instead of numerous time-wasting steps at each connection...and a quick, safe means of tripping, replacing methods that endanger crew members and pipe string a like. For drill strings up to 8 inch collars, the model 870 offers over 75,000 ft-lb of torque for break-out and make-up operations, plus ample speed for spinning joints.

The Eckel Model 24 UHT features a two-speed motor with single-speed gear train, producing 95,000 ft-lb of torque in low speed, 25,000 ft-lb in high, both at 2,500 psi. Weighing 8,000 pounds, this tong easily handles ultra-heavy casing strings from 13 3/8 inches to 24 inches.

Except for added torque (up to 24,000 ft-lb) and expanded pipe capacity (from 4 to 13 3/8 inches), the 13 3/8 Standard tong offers the same basic engineering and design as the smaller, lighter Model 10 3/4. Highly recommended where applications demand the ultimate in size range and torque output.

An excellent choice where applications demand the combination of size range and high torque output, the Eckel Model 14 UHT handles pipe from 4 inches to 14 inches. Upgraded in design and performance over the Model 14 HS, this tong is capable of delivering 65,000 ft-lb of torque. Also, available with Wedge Drive Tri-Grip®backup which handles pipe from 4 inches to 15.5 inches.

When applications require the combination of size and torque up to 18,000 ft-lbs, the Eckel 9 5/8 Hydra-Shift® (Narrow Body) meets these requirements. The narrow body design allows this tong to easily operate on smaller rig configurations. A two speed mechanical shift transmission in conjunction with the two speed Hydra-Shift® motor provides the operator a flexible choice of torque and RPM"s to work with during make-up or breakout. The 9 5/8 Hydra-Shift® is capable of handling a range of pipe from 2 3/8 inches to 9 5/8 inches.

When applications require the combination of size and torque up to 18,000 ft-lbs, the Eckel 9 5/8 Hydra-Shift® (Narrow Body) meets these requirements. The narrow body design allows this tong to easily operate on smaller rig configurations. A two speed mechanical shift transmission in conjunction with the two speed Hydra-Shift® motor provides the operator a flexible choice of torque and RPM"s to work with during make-up or breakout. The 9 5/8 Hydra-Shift® is capable of handling a range of pipe from 2 3/8 inches to 9 5/8 inches.

The 14 HS HT Tri-Grip®Tong is used for making up and break out casing and risers. Capable of handling tubulars from 4 in. to 14 in. (101.6 - 355.6 mm) in diameter with a maximum torque of 135,000 ft-lbs (183035.4) of torque capacity. A two-speed Hydra-Shift® motor coupled with a two-speed gear train provides (4) torque levels and (4) RPM speeds. The tong features a three head - Tri-Grip®biting system design which like the Tri-Grip®Backup encompasses the tubular to apply an evenly distributed gripping force. The additional head in the tong reduces the risk of radial deformation, die penetration, marking, and wear of the tubular by 1/3 at extreme torques. The tong performs exceptional gripping capabilities with either Eckel True-Grit dies or Pyramid Fine Tooth dies.

The Eckel Top Drive Casing Tong is a tool developed for use on hydraulic top drive rigs to provide a high quality connection while reducing tubular damage and providing a safer enviroment for crews. With an operating capacity of 4 1/2 inch through 10 5/8 inch, is connected to the output stem of the power swivel. After installation the tong becomes an integral part of the swivel, raising and lowering as a unit and transfering the power swivel"s RPM and torque to the pipe/connection. A guide attached beneath the top drive tong simplifies alignment of the collar within the tong. Once the collar of the pipe is enclosed within the top drive tong, the tong will grip the collar by operating the power swivel. Torque and rotational speed are controlled through the operation of the power swivel. Reversal of the power swivel will cause the tong jaws to release. Tong jaws are spring loaded to retract away from the collar. Utilizing three gripping jaws and a patented Eckel Cam Biting System to grip the pipe collar. The same type of proven biting system found in the industry leading Eckel Power Tongs. These jaws are spaced evenly about the circumference of the collar to provide even distribution of the gripping forces

The Oil & Gas Industry has needed a specialized power tong with an integral backup. This tong is sized small enough and has the right amount of controlable torque output. It is designed so as to properly grip small tubulars such as small macaroni type strings of tubing.

This tong incorporates Eckel"s Hydra-Shift® technology for smooth tranfers of power and speed directly to the tubular. Special built in torque control valving allows the operator to pre-set the maximum desired torque for the connection. This tong also incorporates our new Radial Lock Door. If you are looking for a tong for this lighter type of word look no further.

Except for added torque (up to 24,000 ft-lb) and expanded pipe capacity (from 4 to 13 3/8 inches), the 13 3/8 Standard tong offers the same basic engineering and design as the smaller, lighter Model 10 3/4. Highly recommended where applications demand the ultimate in size range and torque output.

An excellent choice where applications demand the combination of size range and high torque output, the Eckel Model 14 UHT handles pipe from 4 inches to 14 inches. Upgraded in design and performance over the Model 14 HS, this tong is capable of delivering 65,000 ft-lb of torque. Also, available with Wedge Drive Tri-Grip®backup which handles pipe from 4 inches to 15.5 inches.

When applications require the combination of size and torque up to 18,000 ft-lbs, the Eckel 9 5/8 Hydra-Shift® (Narrow Body) meets these requirements. The narrow body design allows this tong to easily operate on smaller rig configurations. A two speed mechanical shift transmission in conjunction with the two speed Hydra-Shift® motor provides the operator a flexible choice of torque and RPM"s to work with during make-up or breakout. The 9 5/8 Hydra-Shift® is capable of handling a range of pipe from 2 3/8 inches to 9 5/8 inches.

Extremely popular among the most successful of pipe handlers, the Model 5 1/2 UHT combines high torque (up to 25,000 ft-lbs) with a wide capacity range. Ideal for handling tubing, casing and small drill pipe. Options include manual backup or Tri-Grip®backups.

An excellent choice where applications demand the combination of size range and high torque output, the Eckel Model 14 UHT handles pipe from 4 inches to 14 inches. Upgraded in design and performance over the Model 14 HS, this tong is capable of delivering 65,000 ft-lb of torque. Also, available with Wedge Drive Tri-Grip®backup which handles pipe from 4 inches to 15.5 inches.

When application demand a wide range of sizes, this tong handles pipe sizes 2 3/8 inches all the way to 7 5/8. Built around the 7 5/8 Standard, the 7 5/8 Heavy Duty provides a thicker rotary gear for more added strength, an additional idler gear, a larger pinion gear, and stronger bearings for load bearing capacity and durability.

Compact Size...Big Torque...if this is what you are looking for in a power tong, look no further. Our 5-1/2 Hydra-Shift® is sized smaller in width than our 5-1/2 Standard model. Like all of our newly developed tongs, the 5-1/2 incorporates the Hydra-Shift® technology, allowing the operator to shift from high speed to low speed without having to manually shift the tong. You will see many years of trouble free operation, not to mention the smoother hydraulic shifting. With two models to choose from, Eckel has the right 5-1/2 Hydra-Shift® for your needs. The 5-1/2 Hydra-Shift® LS with a two-speed motor and a single-speed gear train is the original 5-1/2 Hydra-Shift® which has gained wide acceptance in the industry. Slide heads with rig dies are available for handling drill pipe tool joints.

Special applications and tough requirements demanded that we respond with a new tong designed and built with today"s pipe handling challenges in mind, the 8 5/8 Hydra-Shift® HT. By utilizing a two speed mechanical shift transmission in conjunction with the two speed Hydra-Shift® motor, the operator has a more flexible choice of torque/RPM"s to work with during make-up or break-out. At the beginning of the job, the operator will choose a tong gear ratio that is most appropriate for the current tubular connection and shift the variable speed motor handle into high or low as required. This tong also offers sliding heads with wrap-around dies which provides an evenly applied pressure to the pipe and a greater pipe gripping coverage which in return reduce tubular damage. This tong not only offers the operator the speed options down to the slow speed parameter now demanded by the pipe manufactures and oil companies, it also has the option of speeds of 100 RPM"s when required. Available torque: 40,000 ft-lb

When application demand a wide range of sizes, this tong handles pipe sizes 2 3/8 inches all the way to 7 5/8. Built around the 7 5/8 Standard, the 7 5/8 Heavy Duty provides a thicker rotary gear for more added strength, an additional idler gear, a larger pinion gear, and stronger bearings for load bearing capacity and durability.

Eckel Tri-Grip®an industry standard for reliable backup in make-up and break-out of tubular connections and optionally supplied with Eckel tongs. Eckel backups utilize hydraulic cylinders and a head arrangement that insures slip-free operation. The hydraulic backup is suspended at an adjustable level below the power tong by means of three hanger legs and allowing the backup to remain stationary while the power tong moves vertically to compensate for thread travel of the connection. The Tri-Grip®uses two pivoting heads and one stationary while the cam backup uses two head to grip tubulars using a head and cam configuration that is similar to the method the tong grips tubulars.

The Eckel Closed Mouth Tongs uses three sliding heads with each head equipped with a wide angle wrap-around die. This provides a maximum gripping area of 342 degrees; on the pipe. The CMT"s utilizes the Hydra-Shift® shifting technology which allows the operator to shift from high to low speed without stopping the tong. Reversing the pipe rotation is effortless and done simply by pulling the tong control in the opposite direction. There is no need to physically take out the jaws and turn them over as there is with other brands of closed head tongs. The CMT"s also come with an optional backup that utilizes the same heads/dies as the tong.

The Model 4 1/2 UHT-13 is rugged, light weight tong capable of providing 8,500 ft-lb of torque at 2,500 PSI. The tong will handle pipe from 1.050 inches to 4 1/2 inches. A notable feature is the Eckel patented quick-change sliding head biting system that compensates for worn or under gauge pipe. Also available with an optional rod package for sizes 5/8 inch through 1-1/8 inches and your choice of manual type or hydraulic type backups.

For casing up to 17 inches, here"s a tong that combines speed and the ability to handle smaller sizes economically. If you are running 17 inch casing, give this tong a try. The 17 Hydra-Shift® features the two-speed motor and the two-speed gear train which allows for multiple selections of torque or RPM, not to mention the smoother operation of the tong.

The Eckel Model 14 Hydra-Shift® handles pipe from 4 inches to 14 inches and incoporates the Hydra-Shift® technology which provides smoother operating environment and a wider selection of torque/RPM"s that are available to the operator. The 14 Hydra-Shift® is capable of delivering 35,000 ft-lb of torque in low-speed, low-gear. Also available with hydraulic Tri-Grip®backup.

The Eckel 3500 Hydra-Shift® DTT (Dual Tubing Tong) provides fast, easy running on dual strings of 3 1/2 inch or smaller tubing. It grabs from the side, or head-on. Go ahead and torque it up; this tong is Eckel tough. And speed shifts are no problem, thanks to a patented Hydra-Shift® concept that eliminates clutching. The Model 3500 DTT Hydra-Shift® is packed with all the features you"ve come to expect from Eckel: quick-change sliding heads, self-aligning open throat.

Except for added torque (up to 24,000 ft-lb) and expanded pipe capacity (from 4 to 13 3/8 inches), the 13 3/8 Standard tong offers the same basic engineering and design as the smaller, lighter Model 10 3/4. Highly recommended where applications demand the ultimate in size range and torque output.

The big, capable Model 36 UHT easily produces 100,000 ft-lb of torque for makeup or break-out operations involving casing in sizes 16 inches through 36 inches. Weighing approximately 13,000 pounds, this casing tong is 81 inches wide and 135 inches in length. A two-speed motor delivers 16 RPM in high, 3 1/2 RPM in low range, both at 70 GPM.

The Eckel 870 DPT combine power tong and Wedg Drive Tri-Grip®Backup, providing a single piece of equipment to replace several...one smooth continuous operation instead of numerous time-wasting steps at each connection...and a quick, safe means of tripping, replacing methods that endanger crew members and pipe string a like. For drill strings up to 8 inch collars, the model 870 offers over 75,000 ft-lb of torque for break-out and make-up operations, plus ample speed for spinning joints.

Eckel has been at the forefront of this developing technology with the development of larger wrap-around type dies for many of its tong models. Wrap-Around Dies are symmetrically spaced from each other at all times insuring an equally distributed load on the tubular.

The 4 1/2 Hydra-Shift® is packed with all the features you"ve come to expect from Eckel: patented cam biting system, quick-change sliding heads, self-aligning open throat. Options include both torque gauge and manual backup or cam-type hydraulic backup. The unit is also available with front or side controls, standard chain bridle suspension, or with its own built-in suspension arm.

An excellent choice where applications demand the combination of size range and high torque output, the Eckel Model 14 UHT handles pipe from 4 inches to 14 inches. Upgraded in design and performance over the Model 14 HS, this tong is capable of delivering 65,000 ft-lb of torque. Also, available with Wedge Drive Tri-Grip®backup which handles pipe from 4 inches to 15.5 inches.

The Model 5 1/2 Standard is the first open-throat design in its size range to generate 12,000 ft-lb of available torque. Versatility is the name of the game here as this tong works well whether powered by a workover rig or a portable casing tong power unit. Options include manual backup or cam-type hydraulic backups.

Extremely popular among the most successful of pipe handlers, the Model 5 1/2 UHT combines high torque (up to 25,000 ft-lbs) with a wide capacity range. Ideal for handling tubing, casing and small drill pipe. Options include manual backup or Tri-Grip®backups.

When applications demand a wide range of sizes, the 7-5/8 Standard tong handles pipe sizes 2-1/16 inches all the way to 7-5/8. Its rugged design is based upon knowledge gained from the 5-1/2 model...combining an extremely compact, high torque concept with added versatility. Options include either manual backup or Tri-Grip®backup. Available torque: 15,000 ft-lb

For casing up to 20 inches, here"s a tong that combines surprising speed with an ability to handle smaller sizes economically (as small as 7 inches). The 20 Standard reaches peak efficiency at just 38 horse power input, thus requiring no "souped-up" power unit. Available torque: 42,000 ft-lb.

The Eckel Model 24 UHT features a two-speed motor with single-speed gear train, producing 95,000 ft-lb of torque in low speed, 25,000 ft-lb in high, both at 2,500 psi. Weighing 8,000 pounds, this tong easily handles ultra-heavy casing strings from 13 3/8 inches to 24 inches.

A two-speed Hydra-Shift® motor coupled with a two-speed gear train provides (4) torque levels and (4) RPM speeds. Easily shift the hydraulic motor in low speed to high speed without stopping the tong or tublar rotation, saving rig time.

A patented door locking system (US Patent 6,279,426) for Eckel tongs that allows for latchless locking of the tong door. The tong door swings easily open and closed and locks when torque

is applied to the tong. When safety is important this locking mechanism combined with our safety door interlock provides unparalleled safety while speeding up the turn around time between connections. The Radial Door Lock is patented protected in the following countries: Canada, Germany, Norway, United Kingdom, and the United States.

The WD Tri-Grip® Backup is a high performance no compromise backup that is suitable for make-up and break-out of the most demanding connections. The WD Tri-Grip®Backup features a three head design that encompasses the tubular that applies an evenly distributed gripping force. The WD Tri-Grip®is a high performance backup with no compromises that is available for specific applications that provdies exceptional gripping capabilities with either Eckel True Grit® dies or Pyramid Fine Tooth dies.

The field proven Tri-Grip® Backup features a three head design that encompasses the tubular that applies an evenly distributed gripping force. The Tri-Grip®Backup provides exceptional gripping capabilities with either Eckel True Grit® dies or Pyramid Fine Tooth dies. The hydraulic backup is suspended at an adjustable level below the power tong by means of three hanger legs and allowing the backup to remain stationary while the power tong moves vertically to compensate for thread travel of the connection.

-nnnnn indicates size being designated by replacing "nnnnn" sequence with size required (in inches) to three decimal places; i.e., 4.500 for 4 1/2" OD casing.

Sucker rod power tong XQ28/1.8Y: Pipe size range of master tong: 5/8""-1 1/8"" sucker rod, 1 7/8""-2 3/8""tubing; Pipe size range of the backup tong:5...

Sucker rod power tong XQ28/2.6Y: Pipe size range of master tong: 5/8""-1 1/8"" suck rod; Pipe size range of the backup tong:5/8""-1 1/8"" suck rod; Hi...

Tubing power tong XQ89/3YC: Pipe size range of master tong: 2 3/8""-3 1/2"" ; Pipe size range of the backup tong:2 3/8""-4 1/2"" ; High gear rated tor...

SDD manual tongs are designed and manufactured in accordance with the API Spec 7K..Which is a useful tool applied to make up and break out drill pipes...

Cooperating with Rapid-Torc in U.S.A and TENTEC Ltd in U.K,HTS can offer all range of Hydraulic Torque Wrench.1.Square drive and hex drive;2.Output ac...

WQ Series Multifunctional pneumatic drill is used to slip in oil or gas drilling card holders drill pipe, drill collars or casing of a power kava, kav...

Tubing power tong XQ114/6YB: Pipe size range of master tong: 2 3/8""-4 1/2"" ; Pipe size range of the backup tong:2 3/8""-5 1/8"" ; High gear rated to...

Tubing power tong XQ140/12YA: Pipe size range of master tong: 2 3/8""-5 1/2"" ; Pipe size range of the backup tong:2 3/8""-6 1/8"" ; High gear rated t...

Drill pipe tong ZQ127/25Y: Pipe size range:2 3/8"-3 1/2" drill pipe, 3 1/2"-4 1/2" tubing and 4 1/2"-5 1/2" casing ; High gear rated torque: 3500N. M ...

Drill pipe tong ZQ203/100: Pipe size range of master tong:3 1/2"-8" drill pipe; High gear rated torque: 9500N. M (7007ft /lbs) ; Low gear rated torque...

Drill pipe tong ZQ203/125: Pipe size range of master tong:3 1/2""-8"" drill pipe; High gear rated torque: 10000N. M (7370ft /lbs) ; Low gear rated tor...

Casing tong TQ245/20Y: Pipe size range: 4 1/2"", 5"", 5 1/2"", 7"", 8 5/8"", 9 5/8""; High gear rated torque: 2600N. M@12Mpa (1924ft /lbs@1740psi) ; L...

Casing tong TQ340/35YA Pipe size range: 5 1/2"", 6 5/8"",7"", 8 5/8"", 9 5/8"",10 3/4"", 13 3/8""; High gear rated torque: 4800N. M@13.8Mpa (3540ft /...

Casing tong TQ508/70Y: Pipe size range: 9 5/8"",10 3/4"", 13 3/8"",16"",18 5/8"",20""; High gear rated torque: 10160N. M@17.3Mpa (7500ft /lbs@2500psi)...

Rated working pressure: 2320 psi (16 MPa); Maximum supply pressure: 2900 psi (20 MPa); Rated flow rate: 135L/min; Hydraulic oil tank volume: 520L; Fu...

ZQ203/100 drill power tong is a new type of mechanize tool on drilling floor. The tong is made of the upper tongs and low tongs. Open head design allo...

The series of power tongs are opening tongs, which are used for quickly make-up?break-out in well service operations. The tong is equipped with hydrau...

XQ series hydraulic power tongs, with advanced steering control structure and tubing clamping technology, and uipped with hydraulic backups, are ideal...

YQ48 Sucker Rod Tong is a new pattern multi-purpose sucker rod hydraulic power tong, using advanced foreign technology, and co-produced with American ...

XQ series of hydraulic power tongs have inner cam rolling-up clamping mechanism, with a hydraulic backup tong. It is an ideal tool for makeup or breakout of various of tubings, and small sizes of casings and drill pipes in workover operation. The tong with extra long rod is avaulable for backup tong to grip tubing body. The power tong also can be equipped with automatic torque control system.
